Introduction to Mass Communication MCM 101

LESSON 32

TELEVISION A NEW DIMENSION IN MASS COMMUNICATION

Television is the process of capturing photographic images, converting them into electrical

impulses, and then transmitting the signal to a decoding receiver. Conventional transmission is by means of

electromagnetic radiation, using the methods of radio.

Among the technical developments that have come to dominate our lives, television is surely one of the top

few. In the developed world, the average household watches television for seven hours per day, which

helps to explain why news, sports, and educational entities, as well as advertisers, value the device for

communication.

The device we call the television is really an image and sound receiver that is the end point of a broadcast

system that starts with a television camera or transmitter and requires a complicated network of transmitters

using ground-based towers, cables, and satellites to deliver the original picture to our living rooms.

TV came like a bang as the time distance between the invention of radio and television is not much. People

across the world were still amazed by the presence of radio in their lives that within years they were having a

device which also showed images with sound a great fun indeed.

How it started?

The electronic way of communication was quite well know by the start of the 20th century but in

almost all cases it was limit to sending or receiving voice messages. Since most researchers and scientists

were focusing on the voice transmission, the radio broadcast resulted almost simultaneously in many parts

of the world with the exception of a difference of few years. The name of Marconi, however, stands

distinguished in the eyes of many as the inventor of radio.

The inventor of television, the device responsible for receiving voice as well as images, is John Logie Baird

of Scotland. But obviously the new invention has been the result of the extensive work done by scores of

other scientists as well. The development of the television occurred over a number of years, in many

countries, and using a wide application of sciences, including electricity, mechanical engineering,

electromagnetism, sound technology, and electrochemistry. No single person invented the television;

instead, it is a compilation of inventions perfected by fierce competition.

Early Discoveries

Chemicals that are conductors of electricity were among the first discoveries leading to the TV.

Baron Ȯns Berzelius of Sweden isolated selenium in 1817, and Louis May of Great Britain discovered, in

1873, that the element is a strong electrical conductor. Sir William Crookes invented the cathode ray tube in

1878, but these discoveries took many years to merge into the common ground of television.

Paul Nipkow of Germany made the first crude television in 1884. His mechanical system used a scanning

disk with small holes to pick up image fragments and imprint them on a light-sensitive selenium tube. A

receiver reassembled the picture. In 1888, W. Hallwachs applied photoelectric cells in cameras; cathode rays

were demonstrated as devices for reassembling the image at the receiver by Boris Rosing of Russia and A.

A. Campbell-Swinton of Great Britain, both working independently in 1907. Countless radio pioneers

including Thomas Edison invented methods of broadcasting television signals.

Although Logie Baird had been developing his own methods of televised images for many years it was in

1924 that he first demonstrated a mechanically scanned television system which transmitted objects in

outline and went on the following year to show the head of a dummy, not just in outline but as a real image.

First Pictures were shown on Sept 7, 1927.

TV changes some basic concepts

TV is largely responsible for bringing about so many social, cultural and economic changes- and

that too with rapid speed, and is considered as one major factor to help globalize human thinking and

understanding on various matters by fully exploiting all the elements possible in visual communication, or

say broadcasting. More on this aspect will be discussed in a coming lecture.

107

Introduction to Mass Communication MCM 101

By 1935, mechanical systems for transmitting black-and-white images were replaced completely by

electronic methods that could generate hundreds of horizontal bands at 30 frames per second. Vladimir K.

Zworykin, a Russian immigrant who first worked for Westinghouse, patented an electronic camera tube

based on the cathode tube. Philo T. Farnsworth and Allen B. Dumont, both Americans, developed a pickup

tube that became the home television receiver by 1939.

From Black and White to color

The Columbia Broadcasting System (CBS) had entered the color TV fray and battled with RCA to

perfect color television, initially with mechanical methods until an all-electronic color system could be

developed. Rival broadcasts appeared throughout the 1940s although progress was slowed by both World

War II and the Korean War. The first CBS color broadcast on June 25, 1951, featured Ed Sullivan and

other stars of the network.

Commercial color television broadcasts were underway in the United States by 1954.

In December of 1954, RCA introduced their 21" color TV. Although the number recorded in history

books is 5,000 units sold, the common belief (amongst collectors) is that the actual number sold to the

public was considerably less.

1950-1959 was an exciting time period for television. In the USA, B&W television exploded onto the scene

at the beginning of the decade, mid-decade saw electronic color television and remote controls launched,

and at the end of the decade the public witnessed some interesting styling changes and the introduction of

transistorized television.

II World War

The sudden outbreak of WW2 halted to some extent progress on TV transmissions and

improvement in technological advancement in making TV a household item for most. The B/W limited

scale TV transmission continued to excite people. The images of war ridden and ravaged sites on mini

screens of old-fashioned TV sets would pull crowd to watch those and get influenced by the devastation of

the mad war. Seeing is believing, worked to make people understand as who was winning the war and who

was controlling the known cities at different stages of the years long fighting. It was a sight not to be

forgotten for those who first witnessed defeat of German armies at different fronts and marching of the

allied forces on the German land towards the last days of the war.

TV Programs

TV program pattern remained like the ones seen on radio broadcast. Classification of its

transmission has been made in the following manner.

News

Music

Films

Comedy shows

Live shows

Sports

There are currently 3 main television transmission standards used throughout the world:

NTSC - National Television Standards Committee. The oldest existing standard, developed in the USA.

First used in 1954. Consists of 525 horizontal lines of display and 60 vertical lines.

SECAM - Système Électronique pour Couleur avec Mémoire. Developed in France. First used in 1967. A

625-line vertical, 50-line horizontal display.

PAL - Phase Alternating Line. Developed by German engineer Walter Bruch who patented his invention

1963 and the first commercial application of the PAL system was in August 1967. Also a 625/50-line

display and alternative of NTSC. Proponents call it "Perfection At Last."

108

Introduction to Mass Communication MCM 101

Broadcast, Cable, and Satellite Television Transmission

Television programs may be transmitted either "live" or from a recording. The principle means

recording television programs for future use is videotape recording. Videotape recording is similar

conventional tape recording .The sound is recorded along with the video signal on the same tape.

When a television program is broadcast, the varying electrical signals are then amplified and used

modulate a carrier wave the modulated carrier is usually fed to an antenna, where it is converted

electromagnetic waves and broadcast over a large region. The waves are sensed by antennas connected

television receivers.

The range of waves suitable for radio and television transmission is divided into channels, which are

assigned to broadcast companies or services.

Most television viewers across the world no longer receive signals by using antennas; instead, they receive

programming via cable television. Cable delivery of television started as a way to improve reception. A

single, well-placed community antenna received the broadcast signals and distributed them over coaxial or

fiber-optic cables to areas that otherwise would not be able to receive them. Today, cable television is

popular because of the wide variety of programming it can deliver. Many systems now provide more than

100 channels of programming. Typically, a cable television company receives signals relayed from a

communications satellite and sends those signals to its subscribers.

The first transatlantic television broadcast was accomplished by such a satellite, called Telstar, on July 10,

1962. Some television viewers use small satellite dishes to receive signals directly from satellites. Most

satellite-delivered signals are scrambled and require a special decoder to receive them clearly.

The Future

The future of television seems bright. More research is going into this process. High Definition

Television (HDTV) was developed by the Japanese Broadcast Corporation and first demonstrated in 1982.

This system produces a movie-quality picture by using a 1,125-line picture on a "letter-box" format screen

with a 16 to nine width to height ratio. High-quality, flat screens suitable for HDTV, are being perfected

using synthetic diamond film to emit electrons in the first application of synthetic diamonds in electronic

components.

Other developments in the receiver include gold-plated jacks, an internal polarity switch on large screens

that compensates for the effect of Earth's magnetic field on image reception, accessories to eliminate ghosts

on the screen. Liquid crystal display (LCD) technology is also advancing rapidly as an alternative to the

cumbersome television screen. Assorted computer chips add functions like channel labeling, time and data

displays, swap and freeze motions, parental channel control, touch screens, and a range of channel-surfing

options.

Digital television of the future will allow the viewer to manipulate the angle of the camera, communicate

with the sports commentator, and merge and edit movies on screen. Two-way TV will also be possible.

Current screens may be used thanks to converter boxes that change the analog signal that presently

energizes the phosphors on the back of your television screen to digital signals that are subject to less

distortion--and are the language of computers. Computer technology will then allow a world of

manipulation of the data as well as broadcast of six times as much data.
