Database Management System (CS403)

Lecture No. 06

Reading Material

"Database Systems Principles, Design and Implementation"

Section 2.4

written by Catherine Ricardo, Maxwell Macmillan.

Overview of Lecture

o Detailed DFD Diagrams:

o Database Design Phase

o Data Models

o Types of Data Models

o Types of Database Designs

Detailed Data Flow Diagram:

This Type of the Data flow diagrams is used when we have to further explain the

functionality of the processes that we showed briefly in the Level 0 Diagram. It means

that generally detailed DFDS are expressed as the successive details of those processes

for which we do not or could not provide enough details.

The symbols and other rules regarding the detailed DFD are same as are in other types of

DFDs. The special features associated with this diagram are that, one, it is optional, that

is, it is created for only those processes from the level 0 diagram for which we want to

show the details. For a small sized system we may not need to develop even a single

detailed DFD, since the level 0 diagram might be covering it sufficiently. Second specific

characteristic of the detailed DFD is its processes' numbering. Numbering of processes in

the detailed DFD is done on the basis of numbering of the particular process in level 0

diagrams whose sub-processes are being included in the detailed DFD. For example, a

specific process which was numbered in the level 0 diagram as 1.0 or 1 may have a

number of sub-processes since we did not represent the process 1.0 in detail in level 0

diagrams. So in the detailed dataflow diagram we create sub-processes of that process

and then number all the sub processes of that specific process as the sublets of the process.

Database Management System (CS403)

Numbering of such sub processes is done as 1.1, 1.2, and 1.3... for first second and third

sub-processes of the process 1.0 respectively. The phenomenon of creating sub-processes

does not end at creating a few sub-processes for a specific process shown at level 0

diagrams. Rather it may continue deeper if there is requirement for further explanation of

the any process or sub-processes. In such a case when we create sub-process of a sub-

process 1.2 then the numbering is done in further extension of that specific sub processes

number and example of such a numbering process is 1.2.1, 1.2.2, 1.2.3,...

Another point that is worth mentioning here is that we call processes in the detailed

DFDs as sub-processes, but they are sub-processes only in reference to the process whose

details they are explaining otherwise they are just like processes; transforming some input

data into some form of output. The sub-processes may be performing relatively small

amount of operations, still they are processes.

Maximum Number of Process in a DFD should not be very huge. Having a moderate

number for a detailed DFD is also recommended because it adds clarity to our detailed

data flow diagram. For clarity propose it is good to have a maximum of 7 or 9 processes

in one detailed DFD. Moreover all the processes, sub processes, data stores, entities data

flows and all other components of the DFD must be named properly, so that anyone who

is using this DFD should be able to understand the DFD easily.

In all the levels of DFD it must be considered that all the processes have data inputs as

well as data outputs. Data being sent to one process should be processed so that it

changes its form and transforms from one form to another.

When creating a detailed diagram the data inputs and data outputs must be in coincidence,

mean in both the diagrams the data input to a process and data output in the form of data

flows must be same.

Data Dictionary

A database that containing data about all the databases in the database system. Data

dictionaries store all the various schema and file specifications and their locations. They

also contain information about which programs use which data and which users are

interested in which reports.

Types of Data Dictionaries:

o Integrated

There are basically two types of data dictionaries which are available for use by a DBMS,

with respect to their existence.

Database Management System (CS403)

The first type of data dictionary in this context is the integrated data dictionary. Such a

data dictionary is place embedded into the database system, and is created by the DBMS

for its usage under the directions and requirements provided by the DBA

As the DBMS needs to talk with the "three level architecture" of database and mapping

information along with all the database design information lies in the database schema.

The DBMS uses the data dictionary to access the database at each layer or model, for this

purpose the data dictionary of any type can be used but the integrated data dictionary is

far more efficient than any free standing data dictionary because an integrated data

dictionary is created by the DBMS itself and uses the same data accessing techniques etc.

o Free Standing

Second type of data dictionary is free standing data dictionary create by any CASE tool

and then attached to the database management systems. A number of case tools are

available for this purpose and help user designing the database and the database

applications as well in some modern forms of the CASE tools.

Cross Reference Matrix

This is a tool available in the data dictionary and helps us in finding entities of the

database and their associations. CRM is developed at the designing stage of the database;

we can say that at the time of creation of the user views of reports for certain users we

identify the material required by the users. In the cross reference matrix, on the Y axis we

specify the accessible components of the database such as transitions, reports, or database

objects and on the x axis we specify the attributes that will be accessed in the

corresponding accessed object.

Now the matrix gets a shape of two dimensional arrays on which we have accessible

objects of the database and on the other hand we have the elements which are available

for access through those objects. Then whichever data item is accessible through a certain

object we place a tick on the intersection of that row and column and thus we can easily

identify the deferent items accessed in different reports.

Database Management System (CS403)

courseName √

√

cumulativeGPA √

√

date

√

fatherName

√

finalMarks

√

grade

√

grdPoint

√

marks

√

midTerm

programName √

√

semesterGPA √

√

semesterNo

√

semName

√

session

√

sessMarks

√

stName

√

stNames

stRegistration √

√

Table 1: An example cross reference matrix

The cross reference matrix shown in table 1 lists different attributes against different

reports required by different user groups of an exam system. Rows in this matrix contain

different attributes and the columns contain different reports. Now the tick mark in the

cells represents the use or presence of attributes in different reports. This matrix

represents, on one side, the relative importance or use of different attributes. On the other

hand it also helps to identify different entity types and their defining attributes. The

attributes that are represented collectively on one or more reports are candidates of

combining into a single entity type. Although it is necessary that attributes appearing

together should be grouped into same entity type, but still they are candidates for

combining into the one.

Data Dictionary in not very necessary for using such a cross reference matrix, instead for

relatively small systems it can be created manually.

Outcome of the Analysis Phase

Database Management System (CS403)

In the preliminary study phase, database designers collect information about the existing

system from the users of the system. For this purpose they may interview different users

or concerned persons, or they may distribute questionnaires among different users and

ask them to fill them in and later may use these questionnaires in the analysis phase.

Designers represent their understanding of the working of existing system in the form of

DFDs and discuss it with the users to make it sure that they have understood all details of

the existing system and the requirements of different users groups.

The DFDs are input to the analysis phase, where designers analyze the requirements of

the users and establish the procedure to meet those requirements. From the database

perspective, in the analysis phase designers have to identify the facts or data that is

required to be stored in order to fulfill the users' requirements. For this purpose they may

use some CASE tools, like cross reference matrix. Generally, in the analysis phase,

designers prepare a draft or initial database design that they ultimately finalize in the next

phase, that is, the database design phase. So in short we can say, that DFDs are the output

of the preliminary phase and are input to the analysis phase. The initial design or a draft

form of design (generally in entity-relationship data model) is the output of the analysis

phase and input to the design phase. In the design phase, then you finalize the design.

The sequence of the activities mentioned above is not much important, however, the

activities mentioned are important and must be performed in order to have a correct

database or database application design. In the following lectures, we are going to study

different tools that are used in the design phase, that is, the data models. We will be

studying, both, the data models and their implementation in the database design phase.

Database Design Phase

Database design phase follows the analysis phase. Before starting the discussion on the

design activity, it will be wise if we clearly understand some basic concepts that are

frequently used in this phase.

o Database Design /Database Model

These terms can be used interchangeably for the logical structure of the database. The

database design/model stores the structure of the data and the links/relationships between

data that should be stored to meet the users' requirements. Database design is stored in

the database schema, which is in turn stored in the data dictionary.

o Database Modeling

The process of creating the logical structure of the database is called database modeling.

It is a very important process because the designing of the application provides us the

basis for running our database system. If the database is not designed properly the

implementation of the system can not be done properly. Generally the design of the

database is represented graphically because it provides an ease in design and adds

flexibility for the understanding of the system easily.

Database Management System (CS403)

Data Model

Data model is a set or collection of construct used for creating a database and producing

designs for the databases. There are a few components of a data model:

o Structure:

What structures can be used to store the data is identified by the structures provided by

the data model structures.

o Manipulation Language

For using a certain model certain data manipulations are performed using a specific

language. This specific language is called data manipulation language.

o Integrity Constraints

These are the rules which ensure the correctness of data in the database and maintain the

database in usable state so that correct information is portrayed in designing the database.

Generally these components are not explicitly defined in data models, they may be

available in some of the modern DBMSs but in traditional and general model, these may

not be available.

Significance of the Data Model

Data model is very important tool because it is something which is sued for designing the

database for a DBMS and no DBMS can exist independent of any data model, now if we

use a specific DBMS but are not sure about the data model it uses for data abase usage,

we can not create a proper database.

As a specific DBMS is base on the use of a specific data model so when using a DBMS it

is of great use to know that what structures, manipulation languages and integrity

constraints are implemented by a specific DBMS. As it is the only way to know the

facilities and functionalities offered by the DBMS.

This is the reason whenever we get a specific DBMS, it is explicitly mentioned with that

DBMS, that which data model this DBMS uses.

Types of Data Models

o Semantic Data Model

These are the data models which provide us better flexibility in implementing constraints,

better language utilities and better data structure constructs. As a result actions performed

using proper data and structure tools gives us better data designing and manipulation

facilities. A better data model provides better opportunities to express multiple situations

in the database design and as a result get better output from the tool or model in the form

of a better database design.

ER- Data Model

Object oriented data model

Database Management System (CS403)

· Record Based Data Model

This is the second type of data models available to use and has three basic types

Hierarchical Data Model

Network Data model

Relational Data model

These models are records based and are not in similarity with those of semantic data

models. These models handle the data at almost all the three level of the three layers of

the database architecture. Semantic data models are generally used for designing the

logical or conceptual model of the database system, once very common example of the

semantic data model is ER-Data Model and is very much popular for designing databases.

No DBMS is based on ER Data model because it is purely used for designing whereas a

number of DBMS are available based on OO data model, network data model, relational

data model l and hierarchical data model.

Types of Database Design

Conceptual database design

This design is implemented using a semantic data model, for example for creating a

design for an organization database we can use and we do use the ER-Data model.

Logical Database design

This design is performed using a data model for which we have a DBMS available and

we are planning to run our database system that DBMS.

Physical Database Design:

The Logical design created using a specific data model and created after the analysis of

the organization, it needs to be implemented in a physical DBMS software so the

Physical database design is performed and the design created so far in the logical form

are implemented on that very DBMS.

By separating the three design levels we get the benefit of abstraction on one hand

whereas on the other hand we can create our logical and conceptual designs using better

design tools, which would have not been possible if we are using the same design-tool for

al the three levels. Moreover if in future there is a need to make a change in the physical

implementation of the data we will have to make no changes in the logical or conceptual

level of the database design , rather the change can be achieved by only using the existing

conceptual model and implementing it again on Physical model using a separate DBMS.

Table of Contents:
