Locking Idea, DeadLock Handling, Deadlock Resolution, Timestamping rules

<< Serial Execution, Serializability, Locking, Inconsistent Analysis

Database Management System (CS403)

Lecture No. 45

Reading Material

"Database Systems Principles, Design and Implementation" written by Catherine Ricardo,

Maxwell Macmillan.

Overview of Lecture:

o Deadlock Handling

o Two Phase Locking

o Levels of Locking

o Timestamping

This is the last lecture of our course; we had started with transaction management. We

were discussing the problems in transaction in which we discussed the locking

mechanism. A transaction may be thought of as an interaction with the system,

resulting in a change to the system state. While the interaction is in the process of

changing system state, any number of events can interrupt the interaction, leaving the

state change incomplete and the system state in an inconsistent, undesirable form.

Any change to system state within a transaction boundary, therefore, has to ensure

that the change leaves the system in a stable and consistent state.

318

Database Management System (CS403)

Locking Idea

Traditionally, transaction isolation levels are achieved by taking locks on the data that

they access until the transaction completes. There are two primary modes for taking

locks: optimistic and pessimistic. These two modes are necessitated by the fact that

when a transaction accesses data, its intention to change (or not change) the data may

not be readily apparent.

Some systems take a pessimistic approach and lock the data so that other transactions

may read but not update the data accessed by the first transaction until the first

transaction completes. Pessimistic locking guarantees that the first transaction can

always apply a change to the data it first accessed.

In an optimistic locking mode, the first transaction accesses data but does not take a

lock on it. A second transaction may change the data while the first transaction is in

progress. If the first transaction later decides to change the data it accessed, it has to

detect the fact that the data is now changed and inform the initiator of the fact. In

optimistic locking, therefore, the fact that a transaction accessed data first does not

guarantee that it can, at a later stage, update it.

At the most fundamental level, locks can be classified into (in increasingly restrictive

order) shared, update, and exclusive locks. A shared lock signifies that another

transaction can take an update or another shared lock on the same piece of data.

Shared locks are used when data is read (usually in pessimistic locking mode).

An update lock ensures that another transaction can take only a shared lock on the

same data. Update locks are held by transactions that intend to change data (not just

read it). If a transaction locks a piece of data with an exclusive lock, no other

transaction may take a lock on the data. For example, a transaction with an isolation

level of read uncommitted does not result in any locks on the data read by the

transaction, and a transaction with repeatable read isolation can take only a share lock

on data it has read.

319

Database Management System (CS403)

DeadLock

A deadlock occurs when the first transaction has locks on the resources that the

second transaction wants to modify, and the second transaction has locks on the

resources that the first transaction intends to modify. So a deadlock is much like an

infinite loop: If you let it go, it will continue until the end of time, until your server

crashes, or until the power goes out (whichever comes first). Deadlock is a situation

when two transactions are waiting for each other to release a lock. The transaction

involved in deadlock keeps on waiting unless deadlock is over.

DeadLock Handling

Following are some of the approaches for the deadlock handling:

Deadlock prevention

Deadlock detection and resolution

Prevention is not always possible

Deadlock is detected by wait-for graph

Wait for Graph:

It is used for the detection of deadlock. It consists of nodes and links. The nodes represent transaction,

whereas arrowhead represents that a transaction has locked a particular data item. We will see it

following example:

Now in this figure transaction A is waiting for transaction B and B is waiting for N.

So it will move inversely for releasing of lock and transaction A will be the last one to

execute. In the second figure there is a cycle, which represents deadlock, this kind of

320

Database Management System (CS403)

cycle can be in between two or more transactions as well. The DBMS keeps on

checking for the cycle.

Two Phase Locking

This approach locks data and assumes that a transaction is divided into a growing

phase, in which locks are only acquired, and a shrinking phase, in which locks are

only released. A transaction that tries to lock data that has been locked is forced to

wait and may deadlock. During the first phase, the transaction only acquires locks;

during the second phase, the transaction only releases locks. More formally, once a

transaction releases a lock, it may not acquire any additional locks. Practically, this

translates into a system in which locks are acquired as they are needed throughout a

transaction and retained until the transaction ends, either by committing or aborting.

For applications, the implications of 2PL are that long-running transactions will hold

locks for a long time. When designing applications, lock contention should be

considered. In order to reduce the probability of deadlock and achieve the best level

of concurrency possible, the following guidelines are helpful.

When accessing multiple databases, design all transactions so that they access

the files in the same order.

If possible, access your most hotly contested resources last (so that their locks

are held for the shortest time possible).

If possible, use nested transactions to protect the parts of your transaction most

likely to deadlock.

321

Database Management System (CS403)

Levels of Locking

Lock can be applied on attribute, record, file, group of files or even entire

database

Granularity of locks.

Finer the granularity more concurrency but more overhead.

Greater lock granularity gives you finer sharing and concurrency but higher overhead;

four separate degrees of consistency which give increasingly greater protection from

inconsistencies are presented, requiring increasingly greater lock granularity.

Databas

Area

Area B

Area C

File

Rec

A11

A12

A13

A111

A112

A113

When a lock at lower level is applied, compatibility is checked upward. It means

intimation would be available in the hierarchy till the database. The granularity of

locks in a database refers to how much of the data is locked at one time. A database

server can lock as much as the entire database or as little as one column of data. Such

extremes affect the concurrency (number of users that can access the data) and

locking overhead (amount of work to process lock requests) in the server. By locking

at higher levels of granularity, the amount of work required to obtain and manage

locks is reduced. If a query needs to read or update many rows in a table:

It can acquire just one table-level lock

It can acquire a lock for each page that contained one of the required rows

It can acquire a lock on each row

322

Database Management System (CS403)

Less overall work is required to use a table-level lock, but large-scale locks can

degrade performance, by making other users wait until locks are released. Decreasing

the lock size makes more of the data accessible to other users. However, finer

granularity locks can also degrade performance, since more work is necessary to

maintain and coordinate the increased number of locks. To achieve optimum

performance, a locking scheme must balance the needs of concurrency and overhead.

Deadlock Resolution

If a set of transactions is considered to be deadlocked:

choose a victim (e.g. the shortest-lived transaction)

Rollback `victim' transaction and restart it.

The rollback terminates the transaction, undoing all its updates and releasing

all of its locks.

A message is passed to the victim and depending on the system the transaction

may or may not be started again automatically.

Timestamping

Two-phase locking is not the only approach to enforcing database consistency.

Another method used in some DMBS is timestamping. With timestamping, there are

no locks to prevent transactions seeing uncommitted changes, and all physical updates

are deferred to commit time.

Locking synchronizes the interleaved execution of a set of transactions in such

a way that it is equivalent to some serial execution of those transactions.

Timestamping synchronizes that interleaved execution in such a way that it is

equivalent to a particular serial order - the order of the timestamps.

Problems of Timestamping

When a transaction wants to read an item that has been updated by a younger

transaction.

A transaction wants to write an item that has been read or written by a younger

transaction.

323

Database Management System (CS403)

Timestamping rules

The following rules are checked when transaction T attempts to change a data item. If

the rule indicates ABORT, then transaction T is rolled back and aborted (and perhaps

restarted).

If T attempts to read a data item which has already been written to by a

younger transaction then ABORT T.

If T attempts to write a data item which has been seen or written to by a

younger transaction then ABORT T.

If transaction T aborts, then all other transactions which have seen a data item written

to by T must also abort. In addition, other aborting transactions can cause further

aborts on other transactions. This is a `cascading rollback'.

Summary

In today's lecture we have read the locking mechanism and prevention of deadlocks.

With this we are finished with our course. Locking is a natural part of any application.

However, if the design of the applications and transactions is not done correctly, you

can run into severe blocking issues that can manifest themselves in severe

performance and scalability issues by resulting in contention on resources.

Controlling blocking in an application is a matter of the right application design, the

correct transaction architecture, a correct set of parameter settings, and testing your

application under heavy load with volume data to make sure that the application

scales well.

324
