Incremental Log with Deferred, Immediate Updates, Concurrency Control

<< Transactions and Schedules, Concurrent Execution, Serializability, Lock-Based Concurrency Control, Deadlocks

Serial Execution, Serializability, Locking, Inconsistent Analysis >>

Database Management System (CS403)

Lecture No. 43

Reading Material

"Database Systems Principles, Design and Implementation"

Chapter 12

written by Catherine Ricardo, Maxwell Macmillan.

"Database Management Systems" Second edition written by

Chapter 18

Raghu Ramakrishnan, Johannes Gehkre.

Overview of Lecture

o Incremental log with deferred updates

o Incremental log with immediate updates

o Introduction to concurrency control

Incremental Log with Deferred Updates

We are discussing the deferred updates approach regarding the database recovery

techniques. In the previous lecture we studied the structure of log file entries for the

deferred updates approach. In today's lecture we will discuss the recovery process.

Write Sequence:

First we see what the sequence of actions is when a write operation is performed. On

encountering a `write' operation, the DBMS places an entry in the log file buffer

mentioning the effect of the write operation. For example, if the transaction includes

the operations:

.......

X = X + 10

Write X

.......

Supposing that the value of X before the addition operation is 23 and after the

execution of operation it becomes 33. Now against the write operation, the entry made

in the log file will be

302

Database Management System (CS403)

<Tn, X, 33>

In the entry, Tn reflects the identity of the transaction, X is the object being updated

and 33 is the value that has to be placed in X. Important point to be noted here is that

the log entry is made only for the write operation. The assignment operation and any

other mathematical or relational operation is executed in RAM. For a `read' operation

the value may be read from the disk (database) or it may already be in RAM or cache.

But the log entry results only from a `write' operation.

The transaction proceeds in a similar fashion and entries keep on adding for the write

operations. When the `commit' statement is executed then, first, the database buffer

is updated, that is the new value is placed in the database buffer. After that the log file

is moved to disk log file which means that the log file entries have been made

permanent. Then write is performed, that is, the data from DB buffer is moved to disk.

There may be some delay between the execution of the commit statement and the

actual writing of data from database buffer to disk. Now, during this time if system

crashes then the problem is that the transaction has been declared as committed

whereas the final result of the object was still in RAM (in database buffer) and due to

system crash the contents of the RAM have been lost. The crash recovery procedure

takes care of this situation.

The Recovery Procedure

When crash occurs, the recovery manager (RM), on restart, examines the log file from

the disk. The transactions for which the RM finds both begin and commit operations,

are redone, that is, the `write' entries for such transactions are executed again. For

example, consider the example entries in a log file

Log File Entries

Here we find the begin entries for

<T1, begin >

T1, T2 and T3, however,

the

<T1, X, 33>

commit entry is only for T1. On

<T2, begin>

restart after the crash,

the RM

<T1, Y, 9>

performs the write operations of T1

<T2, A, 43>

again in the forward order, that is,

it writes the value 33 for object X,

<T1, X, 18>

then writes 9 for Y and writes 19

<T1, commit >

for X again. If some or all of these

<T2, abort>

operations

have been performed

<T3, begin>

already, writing them again will not

<T3, B, 12>

cause any harm.

303

Database Management System (CS403)

The RM does not any action for the transactions for which there is only a begin entry

or for which there are begin and abort entries, like T3 and T2 respectively.

A question arises here, that how far should the RM go backward in the log file to trace

the transactions affected from the crash that the RM needs to Redo or ignore. The log

file may contain so many entries and going too much back or starting right from the

start of the log file will be inefficient. For this purpose another concept of

`checkpoint' is used in the recovery procedure.

Checkpoint:

Checkpoint is also a record or an entry in the log file. It serves as a milestone or

reference point in the log file. At certain point in time the DBMS enters a log

entry/record in the log file and also performs certain operations listed below:

It moves modified database buffers to disk

All log records from buffer to disk

Writing a checkpoint record to log; log record mentions all active

transactions at the time

Now in case of crash, the RM monitors the log file up to the last checkpoint. The

checkpoint guarantees that any prior commit has been reflected in the database. The

RM has to decide which transactions to Redo and which to ignore and RM decides it

on the following bases:

Transactions ended before the checkpoint, are ignored altogether.

Transactions which have both begin and the commit entries, are Redone.

It does not matter if they are committed again.

Transactions that have begin and an abort entry are ignored.

Transactions that have a begin and no end entry (commit or rollback) are

ignored

This way checkpoint makes the recovery procedure efficient. We can summarize the

deferred approach as:

304

Database Management System (CS403)

Writes are deferred until commit for transaction is found

For recovery purpose, log file is maintained

Log file helps to redo the actions that may be lost due to system crash

Log file also contains checkpoint records

Next, we are going to discuss the other approach of crash recovery and that is

incremental log with immediate updates.

Incremental Log with Immediate Updates

Contrary to the deferred updates, the database buffers are updated immediately as the

`write' statement is executed and files are updated when convenient. The log file and

database buffers are maintained as in the deferred update approach. One effect of

immediate update is that the object updating process needs not to wait for the commit

statement; however, there is a problem that the transaction in which a `write'

statement has been executed (and the buffer has been updated accordingly) may be

aborted later. Now there needs to be some process that cancels the updation that has

been performed for the aborted transaction. This is achieved by a slightly different log

file entry/record. The structure of log file entry for immediate update technique is

<Tr, object, old_value, new_value>, where Tr represents the transaction Id, `object' is

the object to be updated, old_value represents the value of object before the execution

of `write' statement and new_value is the new value of object. Other entries of the log

file in immediate update approach are just like those of deferred update.

The sequence of steps on write statement is:

A log record of the form <T, X, old val, new val> is written in the log file

Database buffers are updated

Log record is moved from buffer to the file

Database is updated when convenient

On commit a log file entry is made in the log file as <T, commit>

Recovery Sequence

305

Database Management System (CS403)

In case of a crash, the RM detects the crash as before on restart and after that the

recovery procedure is initiated. The transactions for which the <Tr, begin> and <Tr,

commit> are found, those transactions are redone. The redo process is performed by

copying the new value of the objects in the forward order. If these transactions have

already been successfully executed even then this redo will not do any harm and the

final state of the objects will be the same. The transactions for which a <Tr, begin>

and <Tr, abort> are found or those transaction for which only <Ts, begin> is found,

such transactions are undone. The undo activity is performed by executing the write

statements in the reverse order till the start of the transaction. During this execution,

the old value of the objects are copied/placed so all the changes made by this

transaction are cancelled.

Log File Entries

Here we find the begin entries for

T1, T2 and T3, however,

the

commit entry is only for T1 and

<T1, begin>

also there is an abort entry for T2.

<T1, X, 25, 33>

On restart after the crash, the RM

<T2, begin>

<T1, Y, 5, 9>

performs the write operations of T1

<T2, A, 80, 43>

again in the forward order, that is,

<T1, X, 33, 18>

it writes the value 33 for object X,

<T1, commit>

then writes 9 for Y and writes 18

for X again. If some or all of these

<T2, A, 43, 10>

operations have been performed

<T3, B, 12, 9>

already, writing them again will not

<T2, abort>

cause any harm.

To undo the effects of T2 (which has been aborted) the write statements of T2 are

executed in the reverse order copying the old value from the entry/record. Like, here

the second write statement of T2 that had possibly written the value 10 over 43, now

43 will be placed for A. Moving backward we find another write statement of T2 that

places 43 replacing 80. Now we pick the old value, i.e., 80 and place this value for A.

After performing these operations the effects of executing an aborted T2 are

completely eliminated, that is, the object A contains value 80 that it had before the

execution of transaction T2. Same process is also applied for the transaction T3.

Checkpoints are used in immediate updates approach as well.

We have discussed recovery procedure both in deferred update and immediate update.

Crash recovery is an important aspect of a DBMS, since in spite of all precautions and

protections the crashes happen. We can minimize the frequency but they cannot be

avoided altogether. Once crash happens, the purpose of recovery mechanism is to

306

Database Management System (CS403)

reduce the effect of this crash as much as possible and to bring database in a

consistent state and we have studied how the DBMS performs this activity.

Concurrency Control

Concurrency control (CC) is the second part of the transaction management. The

objective of the CC is to control the concurrent access of database by multiple users at

the same time called the concurrent access.

First questions is that why to have the concurrent access. The answer to this question

refers to very basic objective of the database approach that is sharing of data. Now if

we are allowing multiple users to share the data stored in the database, then how will

they access this data. One user at a time? If so, it will be very inefficient, we cannot

expect the users to be that patient to wait so long. At the same time we have so

powerful and sophisticated computer hardware and software that it will be a very bad

under-utilization of the resources if allow one user access at one time. That is why

concurrent access of the data is very much required and essential.

We are convinced that concurrent access is required, but if not controlled properly the

concurrent access may cause certain problems and those problems may turn the

database into an inconsistent state and this is never every allowed in the database

processing. The objective of CC is to allow the concurrent access in such a way that

these problems due to concurrent access are not encountered or to maintain the

consistency of the database in the concurrent access. It is important to understand that

CC only takes care of the inconsistencies that may possibly be encountered due to

concurrent access. Inconsistency due to some other reasons is not the concern of CC.

Problems due to Concurrent Access

If not controlled properly, the concurrent access may introduce following three

problems in database:

Lost Update Problem

Uncommitted Update Problem

Inconsistent Analysis Problem

We discuss these problems one by one

307

Database Management System (CS403)

Lost Update Problem

This problem occurs when multiple users want to update same object at the same time.

This phenomenon is shown in the table below:

TIME

BAL

Read (BAL)

1000

.......

Read (BAL)

1000

BAL = BAL - 50

........

1000

Write (BAL)

950

.......

BAL = BAL + 10

950

........

Write (BAL)

1010

Table 1: Lost update problem

This first column represents the time that acts as reference for the execution of the

statements. As is shown in the table, at time t1 transaction TA reads the value of

object `BAL' that supposedly be 1000. At time t2, transaction TB reads the value of

same object `BAL' and also finds the value as 1000. Now at time t3, TA subtracts 50

of `BAL and writes it at time t4. On the other hand TB adds 10 into value of `BAL'

(that she has already read as 1000) and writes the value of `BAL'. Now since TB

wrote the value after TA, the update made by TA is lost, it has been overwritten by

value of TB. This is the situation that reflects the lost update problem.

This problem occurred because concurrent access to the same object was not

controlled properly, that is, concurrency control did not manage the things properly.

There are two more situations that reflect the problems of concurrent access that we

will discuss in the next lecture.

Summary

This lecture concluded the discussion on crash recovery where we studied that the

main tool used for recovery is the log file. The structure of records stored in the

different types of log files is almost the same, except for the record that stores the

record of the change made in the database as a result of a write statement. The

deferred update approach stores only the new value of the object in the log file.

Whereas the immediate update approach stores the previous as well as new value of

the object being updated. After the crash recovery we started the discussion on CC,

308

Database Management System (CS403)

where we were studying different problems of CC; first of them is the lost update

problem that we have discussed in today's lecture, rest two will be discussed in the

next lecture.

309

Table of Contents:
