Database Management System (CS403)

Lecture No. 21

Reading Material

"Database Systems Principles, Design and Implementation"

Page 238

written by Catherine Ricardo, Maxwell Macmillan.

"Modern Database Management", Fred McFadden, Jeffrey

Chapter 6

Hoffer, Benjamin/Cummings

Overview of Lecture:

o Summary of normalization

o A normalization example

o Introduction to physical DB design phase

Normalization Summary

Normalization is a step by step process to make DB design more efficient and

accurate. A normalized database helps the DBA to maintain the consistency of the

database. However, the normalization process is not a must, rather it is a strongly

recommended activity performed after the logical DB design phase. Not a must means,

that the consistency of the database can be maintained even with an un-normalized

database design, however, it will make it difficult for the designer. Un-normalized

relations are more prone to errors or inconsistencies.

The normalization is based on the FDs. The FDs are not created by the designer,

rather they exist in the system being developed and the designer identifies them.

Normalization forms exist up to 6NF starting from 1NF, however, for most of the

situations 3NF is sufficient.

Normalization is performed through Analysis or

Synthesis process. The input to the process is the logical database design and the FDs

that exist in the system. Each individual table is checked for the normalization

considering the relevant FDs; if any normalization requirement for a particular normal

form is being violated, then it is sorted out generally by splitting the table. The

176

Database Management System (CS403)

process is applied on all the tables of the design hence the database is called to be in a

particular normal form.

Normalization Example

In the following an example of normalization process has been discussed. This

example is taken from Ricardo book, page 238. The example comprehensively

explains the stages of the normalization process. The approach adopted for the

normalization is analysis approach, whereby a singe large table is assumed involving

all the attributes required in the system. Later, the table is decomposed into smaller

tables by considering the FDs existing in the system. As has been discussed before,

the FDs have to be identified by the designer they are not described as regular from b

y the users. So the example also explains the transforming of real-world scenarios into

FDs.

An example table is given containing all the attributes that are used in different

applications in the system under study. The table named WORK consists of the

attributes:

WORK (projName, projMgr, empId, hours, empName, budget, startDate, salary,

empMgr, empDept, rating)

The purpose of most of the attributes is clear from the name, however, they are

explained in the following facts about the system. The facts mentioned in the book are

italicized and numbered followed by the explanation.

1- Each project has a unique name, but names of employees and managers are not

unique.

This fact simply illustrates that values in the projName attribute will be unique so this

attribute can be used as identifier if required however the attributes empName,

empMgr and projMgr are not unique so they cannot be used as identifiers

2- Each project has one manager, whose name is stored in projMgr

177

Database Management System (CS403)

The projMgr is not unique as mentioned in 1, however, since there is only one

manager for a project and project name is unique, so we can say that if we know the

project name we can determine a single project manager, hence the FD

projName

projMgr

3- Many employees may be assigned to work on each project, and an employee may

be assigned to more than one project. The attribute `hours' tells the number of

hours per week that a particular employee is assigned to work on a particular

project.

Since there are many employees working on each project so the projName attribute

cannot determine the employee working on a project, same is the case with empId that

it cannot determine the particular project an employee is working since one employee

is working on many projects. However, if we combine both the empId and projName

then we can determine the number of hours that an employee worked on a particular

project within a week, so the FD

empId, projName

hours

4- Budget stores the budget allocated for a project and startDate stores the starting

date of a project

Since the project name is unique, so if we know the project name we can determine

the budget allocated for it and also the starting date of the project

projName

budget, startDate

5- Salary gives the annual salary of the employee

empId

salary, empName

Although empId has not been mentioned as unique, however, it is generally assumed

that attribute describing Id of something are unique, so we can define the above FD.

6- empMgr gives the name of the employee's manager, who is not the same as

project manager.

178

Database Management System (CS403)

Project name is determined by project name, however one employee may work on

many projects, so we can not determine the project manager of an employee thourgh

the Id of employee. However, empMgr is the manager of employee and can be known

from employee Id, so FD in 5 can be extended

empId

salary, empName, empMgr

7- empDept give the employee's department. Department names are unique. The

employee's manager is the manager of the employee's department.

empDept

empMgr

Because empDept is unique and there is one manager for each department. At the

same time, because each employee works in one department, we can also say that

empId

empDept

so the FD in 6 is further extended

empId

salary, empName, empMgr, empDept

8- Rating give the employee's rating for a particular project. The project manager

assigns the rating at the end of employee's work on that project

Like `hours' attribute, the attribute `rating' is also determined by two attributes, the

projName and empId, because many employees work on one project and one

employee may work on many projects. So to know the rating of an employee on a

particular project we need to know the both, so the FD

projName, empId

rating

In all we have the following four FDs:

1) empId

salary, empName, empMgr, empDept

2) projName, empId

rating, hours

3) projName

projMgr, budget, startDate

4) empDept

empMgr

Normalization

So we identified the FDs in our example scenario, now to perform the normalization

process. For this we have to apply the conditions of the normal forms on our tables.

Since we have got just one table to begin with so we start our process on this table:

179

Database Management System (CS403)

WORK(projName, projMgr, empId, hours, empName, budget, startDate, salary,

empMgr, empDept, rating)

First Normal Form:

Seeing the data in the example in the book or assuming otherwise that all attributes

contain the atomic value, we find out the table is in the 1NF.

Second Normal Form:

Seeing the FDs, we find out that the PK for the table is a composite one comprising of

empId, projName. We did not include the determinant of fourth FD, that is, the

empDept, in the PK because empDept is dependent on empId and empID is included

in our proposed PK. However, with this PK (empID, projName) we have got partial

dependencies in the table through FDs 1 and 3 where we see that some attributes are

being determined by subset of our PK which is the violation of the requirement for the

2NF. So we split our table based on the FDs 1 and 3 as follows:

PROJECT (projName, projMgr, startDate)

EMPLOYEE (empId, empName, salary, empMgr, empDept)

WORK (projName, empId, hours, rating)

All the above three tables are in 2NF since they are in 1NF and there is no partial

dependency in them.

Third Normal Form

Seeing the four FDs, we find out that the tables are in 2NF and there is no transitive

dependency in PROJECT and WORK tables, so these two tables are in 3NF. However,

there is a transitive dependency in EMNPLOYEE table since FD 1 say empId

empDept and FD 4 say empDept

empMgr. To remove this transitive dependency

we further split the EMPLOYEE table into following two:

EMPLOYEE (empId, empName, salary, empDept)

DEPT (empDept, empMgr)

Hence finally we got four tables

180

Database Management System (CS403)

PROJECT (projName, projMgr, startDate)

EMPLOYEE (empId, empName, salary, empDept)

WORK (projName, empId, hours, rating)

DEPT (empDept, empMgr)

These four tables are in 3NF based on the given FD, hence the database has been

normalized up to 3NF.

Physical Database Design

After completing the logical database design and then normalizing it, we have to

establish the physical database design. Throughout the processes of conceptual and

logical database designs and the normalization, the primary objective has been the

storage efficiency and the consistency of the database. So we have been following

good design principles. In the physical database design, however, the focus shifts

from storage efficiency to the efficiency in execution. So we deliberately violate some

of the rules that we studied earlier, however, this shift in focus should never ever lead

to incorrect state of the database. The correctness of the database we have to maintain

in any case. When we do not follow the good design principles then it makes it

difficult to maintain the consistency or correctness of the database. Since the violation

is deliberate, that is, we are aware of the dangers due to violations and we know the

reasons for these violations so we have to take care of the possible threats and adopt

appropriate measures. Finally, there are different possibilities and we as designers

have to adopt particular ones based on certain reasons or objectives. We have to be

clear about our objectives.

The physical DB design involves:

Transforms logical DB design into technical specifications for storing and

retrieving data

Does not include practically implementing the design however tool specific

decisions are involved

It requires the following input:

Normalized relations (the process performed just before)

181

Database Management System (CS403)

Definitions of each attribute (means the purpose or objective of the attributes.

Normally stored in some form of data dictionary or a case tool or may be on

paper)

Descriptions of data usage (how and by whom data will be used)

Requirements for response time, data security, backup etc.

Tool to be used

Decisions that are made during this process are:

Choosing data types (precise data types depend on the tool to be used)

Grouping attributes (although normalized)

Deciding file organizations

Selecting structures

Preparing strategies for efficient access

That is all about today's lecture, the discussion continues in the next lecture.

Summary

In today's lecture we summarized the normalization process and also saw an example

to practically implement the process. We have introduced our next topic that is the

physical DB design. We will discuss this topic in the lectures to be followed.
