Database Management System (CS403)

Lecture No. 17

Reading Material

"Database Systems Principles, Design and Implementation"

Chapter 6

written by Catherine Ricardo, Maxwell Macmillan.

Overview of Lecture:

o Five Basic Operators of Relational Algebra

o Join Operation

In the previous lecture we discussed about the transformation of conceptual database

design into relational database. In E-R data model we had number of constructs but in

relational data model it was only a relation or a table. We started discussion on data

manipulation languages (DML) of relational data model (SDM). We will now study

in detail the different operators being used in relational algebra.

The relational algebra is a procedural query language. It consists of a set of operations

that take one or two relations as input and produce a new relation as their result. There

are five basic operations of relational algebra. They are broadly divided into two

categories:

Unary Operations:

These are those operations, which involve only one relation or table. These are Select

and Project

Binary Operations:

These are those operations, which involve pairs of relations and are, therefore called

as binary operations. The input for these operations is two relations and they produce

a new relation without changing the original relations. These operations are:

o Union

148

Database Management System (CS403)

o Set Difference

o Cartesian Product

The Select Operation:

The select operation is performed to select certain rows or tuples of a table, so it

performs its action on the table horizontally. The tuples are selected through this

operation using a predicate or condition. This command works on a single table and

takes rows that meet a specified condition, copying them into a new table. Lower

Greek letter sigma (σ) is used to denote the selection. The predicate appears as

subscript to σ. The argument relation is given in parenthesis following theσ. As a

result of this operation a new table is formed, without changing the original table. As

a result of this operation all the attributes of the resulting table are same, which means

that degree of the new and old tables are same. Only selected rows / tuples are picked

up by the given condition. While processing a selection all the tuples of a table are

looked up and those tuples, which match a particular condition, are picked up for the

new table. The degree of the resulting relation will be the same as of the relation itself.

| σ | = | r(R) |

The select operation is commutative, which is as under: -

σc1 (σc2(R)) = σc2 (σc1(R))

If a condition 2 (c2) is applied on a relation R and then c1 is applied, the resulting

table would be equivalent even if this condition is reversed that is first c1 is applied

and then c2 is applied.

For example there is a table STUDENT with five attributes.

STUDENT

stId

stName

stAdr

prName

curSem

S1020

Sohail Dar

H#14, F/8-4,Islamabad.

MCS

S1038

Shoaib Ali

H#23, G/9-1,Islamabad

BCS

S1015

Tahira Ejaz

H#99, Lala Rukh Wah.

MCS

S1018

Arif Zia

H#10, E-8, Islamabad.

BIT

149

Database Management System (CS403)

Fig. 1: An example STDUDENT table

The following is an example of select operation on the table STUDENT:

σ Curr_Sem > 3 (STUDENT)

is the

The components of the select operations are clear from the above example;

symbol being used (operato), "curr_sem > 3" written in the subscript is the predicate

and STUDENT given in parentheses is the table name. The resulting relation of this

command would contain record of those students whose semester is greater than three

as under:

σ Curr_Sem > 3 (STUDENT)

stId

stName

stAdr

prName

curSem

S1020

Sohail Dar

H#14, F/8-4,Islamabad.

MCS

S1015

Tahira Ejaz H#99, Lala Rukh Wah.

MCS

S1018

Arif Zia

H#10, E-8, Islamabad.

BIT

Fig. 2: Output relation of a select operation

In selection operation the comparison operators like <, >, =, <=, >=, <> can be used in

the predicate. Similarly, we can also combine several simple predicates into a larger

predicate using the connectives and (∧) and or (∨). Some other examples of select

operation on the STUDENT table are given below:

σ stId = `S1015' (STUDENT)

σ prName <> `MCS' (STUDENT)

The Project Operator

The Select operation works horizontally on the table on the other hand the Project

operator operates on a single table vertically, that is, it produces a vertical subset of

the table, extracting the values of specified columns, eliminating duplicates, and

placing the values in a new table. It is unary operation that returns its argument

relation, with certain attributes left out. Since relation is a set any duplicate rows are

eliminated. Projection is denoted by a Greek letter (∏). While using this operator all

the rows of selected attributes of a relation are part of new relation. For example

consider a relation FACULTY with five attributes and certain number of rows.

150

Database Management System (CS403)

FACULTY

FacId

facName

Dept

Salary

Rank

F2345

Usman

CSE

21000

lecturer

F3456

Tahir

CSE

23000

Asst Prof

F4567

Ayesha

ENG

27000

Asst Prof

F5678

Samad

MATH

32000

Professor

Fig. 3: An example FACULY table

If we apply the projection operator on the table for the following commands all the

rows of selected attributes will be shown, for example:

∏

(FACULTY)

FacId, Salary

FacId

Salary

F2345

21000

F3456

23000

F4567

27000

F5678

32000

Fig. 4: Output relation of a project operation on table of figure 3

Some other examples of project operation on the same table can be:

∏ Fname, Rank (Faculty)

∏ Facid, Salary,Rank (Faculty)

151

Database Management System (CS403)

Composition of Relational Operators:

The relational operators like select and project can also be used in nested forms

iteratively. As the result of an operation is a relation so this result can be used as an

input for other operation. For Example if we want the names of faculty members

along with departments, who are assistant professors then we have to perform both the

select and project operations on the FACULTY table of figure 3. First selection

operator is applied for selecting the associate professors, the operation outputs a

relation that is given as input to the projection operation for the required attributes.

∏ facName, dept (σ rank='Asst Prof' (FACULTY))

The output of this command will be

facName

Dept

Tahir

CSE

Ayesha

ENG

Fig. 5: Output relation of nested operations' command

We have to be careful about the nested command sequence. For example in the above

nested operations example, if we change the sequence of operations and bring the

projection first then the relation provided to select operation as input will not have the

attribute of rank and so then selection operator can't be applied, so there would be an

error. So although the sequence can be changed, but the required attributes should be

there either for selection or projection.

The Union Operation:

We will now study the binary operations, which are also called as set operations. The

first requirement for union operator is that the both the relations should be union

compatible. It means that relations must meet the following two conditions:

Both the relations should be of same degree, which means that the number of

attributes in both relations should be exactly same

The domains of corresponding attributes in both the relations should be same.

Corresponding attributes means first attributes of both relations, then second and so

on.

It is denoted by U. If R and S are two relations, which are union compatible, if we

take union of these two relations then the resulting relation would be the set of tuples

either in R or S or both. Since it is set so there are no duplicate tuples. The union

operator is commutative which means: -

152

Database Management System (CS403)

RUS=SUR

For Example there are two relations COURSE1 and COURSE2 denoting the two

tables storing the courses being offered at different campuses of an institute? Now if

we want to know exactly what courses are being offered at both the campuses then we

will take the union of two tables:

COURSE1

crId

progId

credHrs

courseTitle

C2345

P1245

Operating Sytems

C3456

P1245

Database Systems

C4567

P9873

Financial Management

C5678

P9873

Money & Capital Market

COURSE2

crId

progId

credHrs

courseTitle

C4567

P9873

Financial Management

C8944

P4567

Electronics

COURSE1 U COURSE2

crId

progId

credHrs

courseTitle

C2345

P1245

Operating Sytems

C3456

P1245

Database Systems

C4567

P9873

Financial Management

C5678

P9873

Money & Capital Market

C8944

P4567

Electronics

Fig. 5: Two tables and output of union operation on those tables

So in the union of above two courses there are no repeated tuples and they are union

compatible as well

153

Database Management System (CS403)

The Intersection Operation:

The intersection operation also has the requirement that both the relations should be

union compatible, which means they are of same degree and same domains. It is

represented by∩. If R and S are two relations and we take intersection of these two

relations then the resulting relation would be the set of tuples, which are in both R and

S. Just like union intersection is also commutative.

R∩S=S∩R

For Example, if we take intersection of COURSE1 and COURSE2 of figure 5 then

the resulting relation would be set of tuples, which are common in both.

COURSE1 ∩ COURSE2

crId

progId

credHrs

courseTitle

C4567

P9873

Financial

Management

Fig. 6: Output of intersection operation on COURSE1 and COURSE 2 tables of figure

The union and intersection operators are used less as compared to selection and

projection operators.

The Set Difference Operator:

If R and S are two relations which are union compatible then difference of these two

relations will be set of tuples that appear in R but do not appear in S. It is denoted by

(-) for example if we apply difference operator on Course1 and Course2 then the

resulting relation would be as under:

COURSE1 COURSE2

CID

ProgID

Cred_Hrs

CourseTitle

C2345

P1245

Operating Sytems

C3456

P1245

Database Systems

C5678

P9873

Money & Capital Market

Fig. 7: Output of difference operation on COURSE1 and COURSE 2 tables of figure

Cartesian product:

154

Database Management System (CS403)

The Cartesian product needs not to be union compatible. It means they can be of

different degree. It is denoted by X. suppose there is a relation R with attributes (A1,

A2,...An) and S with attributes (B1, B2......Bn). The Cartesian product will be:

RX S

The resulting relation will be containing all the attributes of R and all of S. Moreover,

all the rows of R will be merged with all the rows of S. So if there are m attributes and

C rows in R and n attributes and D rows in S then the relations R x S will contain m +

n columns and C * D rows. It is also called as cross product. The Cartesian product is

also commutative and associative. For Example there are two relations COURSE and

STUEDNT

COURSE

STUDENT

crId

courseTitle

stId

stName

C3456

Database Systems

S101

Ali Tahir

C4567

Financial Management

S103

Farah Hasan

C5678

Money & Capital Market

COURSE X STUDENT

crId

courseTitle

stId

stName

C3456

Database Systems

S101

Ali Tahir

C4567

Financial Management

S101

AliTahr

C5678

Money & Capital Market

S101

Ali Tahir

C3456

Database Systems

S103

Farah Hasan

C4567

Financial Management

S103

Farah Hasan

C5678

Money & Capital Market

S103

Farah Hasan

Fig. 7: Input tables and output of Cartesian product

Join Operation:

Join is a special form of cross product of two tables. In Cartesian product we join a

tuple of one table with the tuples of the second table. But in join there is a special

requirement of relationship between tuples. For example if there is a relation

STUDENT and a relation BOOK then it may be required to know that how many

books have been issued to any particular student. Now in this case the primary key of

STUDENT that is stId is a foreign key in BOOK table through which the join can be

made. We will discuss in detail the different types of joins in our next lecture.

155

Database Management System (CS403)

In this lecture we discussed different types of relational algebra operations. We will

continue our discussion in the next lecture.

156

Table of Contents:
