Database Management System (CS403)

Lecture No. 14

Reading Material

"Database Systems Principles, Design and Implementation"

Section 6.1 6.3.3

written by Catherine Ricardo, Maxwell Macmillan.

"Database Management Systems", 2nd edition,

Raghu

Ramakrishnan, Johannes Gehrke, McGraw-Hill

Overview of Lecture

Logical Database Design

Introduction to Relational Data Model

Basic properties of a table

Mathematical and database relations

From this lecture we are going to discuss the logical database design phase of

database development process. Logical database design, like conceptual database

design is our database design; it represents the structure of data that we need to store

to fulfill the requirements of the users or organization for which we are developing the

system. However there are certain differences between the two that are presented in

the table below:

Conceptual Database Design

Logical Database Design

Developed in a semantic data model In legacy data models (relational

(generally E-R data model)

generally in current age)

Free of particular DBMS in which

Free of data model in which going to be

going to be implemented; many/any

implemented; many/any possible

possible

Obtained

translating

the

Results from Analysis Phase

conceptual

database

design

into

another data model

124

Database Management System (CS403)

Represented graphically

Descriptive

More expressive

Relatively less expressive

Going to be transformed and then

Going to be implemented

implemented

You can think more, give a try

Table 1: Differences between Conceptual and Logical Database Designs

As we have already discussed in previous lectures and as is given in row 2 of the

above table, the conceptual database design can be transformed into any data model,

like, hierarchical, network, relational or object-oriented. So the study of the logical

database design requires first involves the study of the data model/(s) that we can

possibly use for the purpose. However, in the current age, since early eighties, the

most popular choice for the logical database design is the relational data model; so

much popular that today it can be considered to be the only choice. Why? Because of

its features we are going to discuss in today's lecture. That is why rather than studying

different data models we will be studying only the relational data model. Once we

study this, the development of logical database design is transformation of conceptual

database design to relational one and the process is very simple and straightforward.

So from today's lecture our discussion starts on the relational data model. Just for the

sake of revision we repeat the definition of data model "a set of constructs/tools used

to develop a database design; generally consists of three components which are

constructs, manipulation language and integrity constraints". We have discussed it

earlier that the later part of the definition (three components) fits precisely with the

relational data model (RDM), that is, it has these components defined clearly.

Relational Data Model

The RDM is popular due to its two major strengths and they are:

o Simplicity

o Strong Mathematical Foundation

The RDM is simple, why, there is just one structure and that is a relation or a table.

Even this single structure is very easy to understand, so a user of even of a moderate

125

Database Management System (CS403)

genius can understand it easily. Secondly, it has a strong mathematical foundation that

gives many advantages, like:

o Anything included/defined in RDM has got a precise meaning since it is based

on mathematics, so there is no confusion.

o If we want to test something regarding RDM we can test it mathematically, if it

works mathematically it will work with RDM (apart from some exceptions).

o The mathematics not only provided the RDM the structure (relation) but also

well defined manipulation languages (relational algebra and relational calculus).

o It provided RDM certain boundaries, so any modification or addition we want to

make in RDM, we have to see if it complies with the relational mathematics or

not. We cannot afford to cross these boundaries since we will be losing the huge

advantages provided by the mathematical backup.

"An IBM scientist E.F. Codd proposed the relational data model in 1970. At that

time most database systems were based on one of two older data models (the

hierarchical model and the network model); the relational model revolutionized

the database field and largely replaced these earlier models. Prototype relational

database management systems were developed in pioneering research projects at

IBM and UC-Berkeley by the mid-70s, and several vendors were offering

relational database products shortly thereafter. Today, the relational model is by

far the dominant data model and is the foundation for the leading DBMS

products, including IBM's DB2 family, Informix, Oracle, Sybase, Microsoft's

Access and SQLServer, FoxBase, and Paradox. Relational database systems are

ubiquitous in the marketplace and represent a multibillion dollar industry" [1]

The RDM is mainly used for designing/defining external and conceptual schemas;

however to some extent physical schema is also specified in it. Separation of

conceptual and physical levels makes data and schema manipulation much easier,

contrary to previous data models. So the relational data model also truly supports

"Three Level Schema Architecture".

Introduction to the Relational Data model

The RDM is based on a single structure and that is a relation. Speaking in terms of the

E-R data model, both the entity types and relationships are represented using relations

126

Database Management System (CS403)

in RDM. The relation in RDM is similar to the mathematical relation however

database relation is also represented in a two dimensional structure called table. A

table consists of rows and columns. Rows of a table are also called tuples. A row or

tuple of a table represents a record or an entity instance, where as the columns of the

table represent the properties or attributes.

stID

stName

clName

doB

sex

S001

M. Suhail

MCS

12/6/84

S002

M. Shahid

BCS

3/9/86

S003

Naila S.

MCS

7/8/85

S004

Rubab A.

MBA

23/4/86

S005

Ehsan M.

BBA

22/7/88

Table 2: A database relation represented in the form of a table

In the above diagram, a table is shown that consists of five rows and five columns.

The top most rows contain the names of the columns or attributes whereas the rows

represent the records or entity instances. There are six basic properties of the database

relations which are:

Each cell of a table contains atomic/single value

A cell is the intersection of a row and a column, so it represents a value of an

attribute in a particular row. The property means that the value stored in a single cell

is considered as a single value. In real life we see many situations when a

property/attribute of any entity contains multiple values, like, degrees that a person

has, hobbies of a student, the cars owned by a person, the jobs of an employee. All

these attributes have multiple values; these values cannot be placed as the value of a

single attribute or in a cell of the table. It does not mean that the RDM cannot

handle such situations, however, there are some special means that we have to adopt

in these situations, and they can not be placed as the value of an attribute because an

attribute can contain only a single value. The values of attributes shown in table 1

are all atomic or single.

127

Database Management System (CS403)

Each column has a distinct name; the name of the attribute it represents

Each column has a heading that is basically the name of the attribute that the

column represents. It has to be unique, that is, a table cannot have duplicated

column/attribute names. In the table 2 above, the bold items in the first row

represent the column/attribute names.

The values of the attributes come from the same domain

Each attribute is assigned a domain along with the name when it is defined. The

domain represents the set of possible values that an attribute can have. Once the

domain has been assigned to an attribute, then all the rows that are added into the

table will have the values from the same domain for that particular column. For

example, in the table 2 shown above the attribute doB (date of birth) is assigned the

domain "Date", now all the rows have the date value against the attribute doB. This

attribute cannot have a text or numeric value.

The order of the columns is immaterial

If the order of the columns in a table is changed, the table still remains the same.

Order of the columns does not matter.

The order of the rows is immaterial

As with the columns, if rows' order is changed the table remains the same.

Each row/tuple/record is distinct, no two rows can be same

Two rows of a table cannot be same. The value of even a single attribute has to be

different that makes the entire row distinct.

There are three components of the RDM, which are, construct (relation), manipulation

language (SQL) and integrity constraints (two). We have discussed the relation so far;

the last two components will be discussed later. In the next section we are going to

128

Database Management System (CS403)

discuss the mathematical relations briefly that will help to link the mathematical

relations with the database relations and will help in a better understanding of the later.

Mathematical Relations

Consider two sets

A = {x, y}

B = {2, 4, 6}

Cartesian product of these sets (A x B) is a set that consists of ordered pairs where

first element of the ordered pair belongs to set A where as second element belongs to

set B, as shown below:

A X B= {(x,2), (x,4), (x,6), (y,2), (y,4), (y,6)}

A relation is some subset of this Cartesian product, For example,

R1= {(x,2), (y,2),(x,6),(x,4)}

R2 = {(x,4), (y,6), (y,4)}

The same notion of Cartesian product and relations can be applied to more than two

sets, e.g. in case of three sets, we will have a relation of ordered triplets

Applying the same concept in a real world scenario, consider two sets Name and Age

having the elements:

Name = {Ali, Sana, Ahmed, Sara}

Age = {15,16,17,18,.......,25}

Cartesian product of Name & Age

Name X Age= {(Ali,15), (Sana,15), (Ahmed,15), (Sara,15), ...., (Ahmed,25),

(Sara,25)}

Now consider a subset CLASS of this Cartesian product

CLASS = {(Ali, 18), (Sana, 17), (Ali, 20), (Ahmed, 19)}

This subset CLASS is a relation mathematically, however, it may represent a class in

the real world where each ordered pair represents a particular student mentioning the

name and age of a student. In the database context each ordered pair represents a tuple

and elements in the ordered pairs represent values of the attributes. Think in this way,

if Name and Age represent all possible values for names and ages of students, then

any class you consider that will definitely be a subset of the Cartesian product of the

Name and Age. That is, the name and age combination of all the students of any class

129

Database Management System (CS403)

will be included in the Cartesian product and if we take out particulars ordered pairs

that are related to a class then that will be a subset of the Cartesian product, a relation.

Database Relations

Let A1, A2, A3, ..., An be some attributes and D1, D2, D3,..., Dn be their domains A

relation scheme relates certain attributes with their domain in context of a relation. A

relation scheme can be represented as:

R = (A1:D1, A2:D2, ......, An:Dn), for example,

STD Scheme = (stId:Text, stName: Text, stAdres:Text, doB:Date) OR

STD(stId, stName, stAdres, doB)

Whereas the stId, stName, stAdres and doB are the attribute names and Text, Text,

Text and Date are their respective domains. A database relation as per this relation

scheme can be:

STD={(stId:S001,

stName:Ali, stAdres:

Lahore, doB:12/12/76),

(stId:S003,

stName:A. Rehman, stAdres: RWP, doB:2/12/77)} OR

STD={(S001, Ali, Lahore, 12/12/76), (S003, A. Rehman, RWP, 2/12/77)}

The above relation if represented in a two dimensional structure will be called a table

as is shown below:

stId

stName

stAdres doB

S001

Ali

Lahore 12/12/76

S002

A. Rehman RWP

2/12/77

With this, today's lecture is finished; the discussion on RDM will be continued in the

next lecture.

Summary

In this lecture we have started the discussion on the logical database design that we

develop from the conceptual database design. The later is generally developed using

E-R data model, whereas for the former RDM is used. RDM is based on the theory of

mathematical relations; a mathematical relation is subset of the Cartesian product of

two or more sets. Relations are physically represented in the form of two-dimensional

130

Database Management System (CS403)

structure called table, where rows/tuples represent records and columns represent the

attributes.

Exercise:

Define different attributes (assigning name and domain to each) for an entity

STUDENT, then apply the concept of Cartesian product on the domains of these

attributes, then consider the records of your class fellows and see if it is the subset of

the Cartesian product.

131

Table of Contents:
