SOLUTION TO LINEAR PROGRAMMING PROBLEMS

Having formulated a linear programming problem, we have to find the solution for the same. To find the

solution to a linear programming model, we have the graphical and the algebraic methods that can be applied

successfully.

If the problem involves only two decision variables, graphical method of solution is quite adequate. Even

when three decision variables are involved, a graphical solution can be resorted to. But this involves three-

dimensional representation. Therefore we can conveniently restrict the graphical method to problems involving two

decision variables.

The second method is the algebraic procedure or simplex method, which involves an iterative procedure.

This can be applied to linear programming problems involving two or more variables. This is the most versatile

method of solving linear programming models. In this method, an initial solution is assumed and this solution s

modified progressively through a well-defined iterative process until we get the optimal solution. The procedure is

simple and so mechanical that it requires time and patience to execute it manually. However, an electronic computer

with the readymade programmes can be used as a handy tool for solving LP problems involving many variables.

Graphical solution to LPP

We all know that a point can be represented by two co-ordinates namely and x and y in a graph. From the

origin we have to go x units along x axis and y units along y-axis. If we plot two points in a graph and join them we

get a segment of a straight line. A minimum of two points is needed to a draw a straight line. In a linear

programming problem, the objective function and constraints are linear, so that we can plot the straight lines

representing constraints and the objectives function.

Let us take an algebraic equation 3x + 5y =15. This is a first-degree equation in x and y. Geometrically this

represents a straight line. If we want to represent the above equation geometrically, we require a minimum of two

points to plot a line. Let x = 0, we get y = 3 and let y = 0 we get x = 5. Hence we have two points A(0, 3) and B(5, 0)

and connect them to get a straight line

Fig 1

103

Operations Research (MTH601)

104

We normally come across, in linear programming problems, the linear constraints having inequalities either

'greater than equal to' or 'less than equal to' or strictly 'equal to'.

Consider the inequality

3x + 5y < 15

To plot the feasible area satisfying the above inequality, we consider the equation

3x + 5y = 15.

This has been plotted in the figure 1. This straight line has an area above the line and an area below the

line. To determine the appropriate area satisfying the inequality, 3x + 5y < 15,

Let us consider the origin (x = 0, y = 0) as a reference point. Left hand side for the reference point is 3.0 + 5.0 = 0.

The value '0' of the left hand side, is clearly less than 15 satisfying the constraint and therefore the origin

whose co-ordinates are (0, 0) is a point to be included in the feasible area. The origin is below the straight line and

the area A1 should also contain the trial point namely the origin. Hence the feasible area satisfying the constraint 3x

+ 5y < 15 is indicated as A1 in figure 2.

Fig. 2

Next consider the inequality

3x + 5y > 15

To find the feasible area satisfying the above inequality, we take once again the origin as a trial point and

see whether this has to be included in the area. Let x = 0 and y = 0, then we get the value of the left hand side is 0

and the right hand side is 15 and hence the area satisfying this space inequality 3x + 5y > 15, should not contain the

origin and hence the feasible solution space is as indicated by A2 in figure 3.

The constraints are linear in a linear programming problem, which can be plotted on a graph. The ingenuity

of graphical solution to a linear programming problem depends on fixing the proper solution space.

Consider the following inequality 4x - 5y < 20

To get the feasible space to satisfy the above constraint, first we plot the straight line 4 x - 5y = 20 as shown

in figure 4. The origin, which satisfies the constraint, should be included in the solution space.

104

Operations Research (MTH601)

105

Fig. 3

Fig. 4

Hence the area above the straight line shows the feasible solution space satisfying the inequality 4x - 5y <

20. The area below the line will correspond to the constraint 4x - 5y > 20.

Consider the inequality

-4x + 5y < 20

We plot the straight line -4x + 5y = 20 as shown in figure 5

The origin satisfies the inequality -4x + 5y < 20 and this should be included in the feasible solution space. Hence the

area below the straight line should represent the feasible solution space

Consider the inequality

-4x - 5y < 20

We plot the straight line -4x - 5y = 20 as shown in figure 6

Fig 5

Fig. 6

Since the origin satisfies the inequality -4x - 5y = 20 it should be included in the feasible solution space. Hence the

area above the straight line should be the solution space.

Procedure for Graphical Solution to LPP

Having explained how to fix the feasible solution space satisfying the constraint, we now give various steps

involved in arriving at a solution to a linear programming problem.

STEP 1:Consider all the constraints. Taking the equality relationship, plot all the straight lines in a graph and get

feasible solution space satisfying the inequality. Usually we get a bounded solution space.

105

Operations Research (MTH601)

106

STEP 2: Assign an arbitrary value for the objective function. Plot the straight line to represent the objective

function, with the arbitrary value for Z.

STEP 3: Move the objective line parallel in the appropriate direction in the solution space to maximize and in the

opposite direction to minimize the objective function under consideration.

STEP 4: In this process, the moving objective line may meet an extreme point (or corner point) beyond which we

cannot proceed as this violates the constraints. Note the co-ordinates of this extreme point, which will give

maximum or minimum value of the objective function.

The above steps are explained in the following example.

Example

Maximize Z = 4x + 7y

Subject to

x < 40, y < 30, x + y < 60,

x, y > 0

In the above example, we have three constraints and all of them are 'less than inequalities'. First step in the

graphical method of solution to the linear programming problem is to represent the constraints graphically. Consider

the first constraint

x < 40

This indicates that x can take a value 40 or less than 40, for all values of y. The equation x = 40 is a straight

line parallel to the y axis as in the figure 2.7 and the area to the left of this straight line is the solution space

satisfying the constraint x < 40.

Fig. 7

Fig. 8

Consider the second constraint y < 30. This demands that y can take a value of 30 or less than 30 for all the

values of x. The equation y = 30 is a line parallel to x-axis and is represented in figure 8.

Similarly consider the third constraint x + y < 60. To plot the straight line let x = 0, then y = 60 and let y =

0, then x = 60. Therefore the two points (0, 60) and (60, 0) represented in figure 9 will be connected, to get the

straight line x + y = 60. To get the solution space satisfying x + y < 60, let x = 0 and y = 0, then the left hand side

106

Operations Research (MTH601)

107

reduces to 0 which is clearly less than 60. Therefore the area below the line including (0, 0) represented by the

shaded portion in figure 9 represents the solution space satisfying the constraint x + y = 60.

Fig. 9

Consider the non-negative constraints for x an y and the feasible solution space is obtained by combining

all the constraints in one figure as shown in figure 10.

The shaded portion of the figure 10 represents the solution space as feasible region. The solution space in

figure 2.10 is a bounded figure with five corner points (otherwise called extreme points) namely A, B, C, D and E.

The solution space is bounded by segments of five straight lines. The co-ordinates of A, B, C, D and E are

determined by solving the appropriate simultaneous constraint equations.

Thus we have A at the origin, having xo-ordinates x = 0, y = 0.

The co-ordinates for B are x = 0, y = 30.

The co-ordinates of C are found by solving equations:

y = 30

x + y = 60

Fig 10

Fig 11

We get the co-ordinates of C as x = 30, y = 30.

Similarly the co-ordinates of D are determined by solving equations:

107

Operations Research (MTH601)

108

x = 40

x + y = 60

The co-ordinates of D are x = 40, y = 20

The co-ordinates of E are x = 40, y = 0.

The next step is to examine the value of the objective function at these points. This is done in the table

below:

Extreme point

Co-ordinates

Value of

or corner point

Z = 4x + 7y

(0, 0)

(0, 30)

210

(30, 30)

330*

(40, 20)

300

(40, 0)

160

From the above table we see that the objective function has a maximum value of 330 at C (30, 30). So, the

optimum Z denoted by Z* is given by Z* = 330 for x = 30 and y = 30.

Alternate Method:

Instead of evaluating the objective function at all the extreme points; a graphical optimum solution can be

obtained which is explained below.

Consider the objective function

Z = 4x + 7y

Assign a convenient arbitrary value for Z say Z = 140, then

Z = 4x + 7y = 140

This is a straight line, which can be represented in the solution space as shown in figure 11.

Consider Z = 4x + 7y = 140. If x = 0, we get y = 20 and if y = 0, we get x = 35. These two points are connected by a

straight line representing Z = 140.

Thus Z = 140 is called an iso-profit line since for all points in the straight line, Z = 140. With this value we

have obtained the slope and hence shape of the straight line.

Next step is to draw straight lines parallel to 4x + 7y = 140.

108

Operations Research (MTH601)

109

This results in moving the objective line with various values in the solution space in a proper direction

(upwards in this example for maximization and downwards for minimization). In this process, the objective line may

cross a corner point indicating the maximum or minimum value.

Drawing parallel lines we see that a line passing through C (30, 30) gives the maximum value for Z and

value of Z* = 330.

Example

Minimize

Z = 4x + 5y

Subject to

x + y > 10

2x + 5y > 35

x, y > 0

Solution

STEP 1 Represent the constraints graphically

Consider

x + y = 10

If x = 0, then y = 10

If y = 0, then x = 10

Consider

2x + 5y = 35

If x = 0, then y = 7

If y = 0, then x = 17.5

The above constraints are represented in figure 12.

STEP 2:

Mark the solution space in the graph satisfying all the constraints.

Fig. 12

Choose an arbitrary value of Z, say 100. Then

STEP 3

Z = 4x + 5y = 100

109

Operations Research (MTH601)

110

If x = 0, then y = 20

If y = 0, then x = 25

Represent Z = 100 in the graph.

Move down the line Z = 100 to minimize the total cost Z. Thus we get the minimum value of Z at the point B, which

is the intersection of two lines:

x + y = 10

2x + 5y = 35

Solving the two equations, we get x = 5, y = 5

The minimum value of Z = 4 x 5 + 5 x 5 = 45,

Therefore, Z* = 45, x = 5, y = 5

RESULT:

Certain Definitions:

A feasible solution is the value of all points for which all constraints are satisfied.

An optimal solution is a feasible solution, which maximizes or minimizes the objective function.

These terms can be interpreted in terms of the graphical representation. The feasible solution includes all

the points within the permissible region (or solution space) including the boundary points.

110

Operations Research (MTH601)

111

REVIEW QUESTIONS

The standard weight of a brick is 5 kg, and it

Solve Graphically

contains two basic ingredients B1 and B2.B1 costs Rs.

5/kg and B2 costs Rs. 8/kg Strength considerations

Maximize Z = 3x + 7y

dictate that the brick contains not more than 4 kg of

B1 and a minimum of 2 kg of B2. Since the demand

Subject to

for the product is likely to be related to the price of

x + 4y < 20

the brick, find out graphically the minimum cost of

2x + y < 30

the brick satisfying the above conditions.

x+y<8

and x, y > 0

Solve by graphical method the following

problem.

Maximize Z = 2x + 3y

Minimize

Subject to

-x + 2y < 16

Z = 5x1 + 4x2

Subject to

4x1 + x2 > 40

x + y < 24

x + 3y > 45

2x1 + 3x2 > 90

-4x + 10y > 20

and

x, y > 0

x1 > 0, x2 > 0

Maximize Z = 3x1 + 5x2

b) Food A contains 20 units of vitamin x and 40 units

Subject to

-3x1 + 4x2 < 12

of vitamin y per gram. Food B contains 30 units of

2x1 - x2 > -2

each of vitamins x and y. The daily minimum human

2x1 + 3x2 > 12

requirements of vitamin x and y are 900 units and

1200 units respectively. How many grams of each

x1 < 4

type of food should be consumed so as to minimize

x2 > 2

the cost, if food A costs 60 paise per gram and food B

x1 > 0

80 paise per gram.

Maximize

Z = 4x1 + 6x2

A company produces two types of products

say type A and type B. Product A is of superior

Subject to

x1 < 2

quality and product B is of a lower quality.

x2 < 4

Respective profits for the two types of products are

x1 + x2 > 3

Rs. 40/- and 30/-. The data on the resource required,

and

x1, x2 > 0

availability of resources are given below:

What are the four major types of allocation

Capacity

Requirements

problems, which could be solved using linear

Product A

Product B

available

programming technique? Briefly explain each one of

Per month

them with an example.

Raw materials

120

12000

(kg)

Minimize

Z = 4x1 + x2

Machining time

600

(hrs/piece)

Subject to

3x1 + 4x2 > 20

Assembly

500

-x1 - 5x2 < -15

(man-hour)

and

x1, x2 > 0

111

Table of Contents:
