MTH001 Elementary Mathematics

LECTURE # 08

ORDERED PAIR:

An ordered pair (a, b) consists of two elements "a" and "b" in which "a" is the

first

element and "b" is the second element.

The ordered pairs (a, b) and (c, d) are equal if, and only if, a= c and b = d.

Note that (a, b) and (b, a) are not equal unless a = b.

EXERCISE:

Find x and y given (2x, x + y) = (6, 2)

SOLUTION:

Two ordered pairs are equal if and only if the

corresponding components are equal. Hence, we obtain the equations:

2x = 6 ..................(1)

and

x + y = 2 .................(2)

Solving equation (1) we get x = 3 and when substituted in (2) we get y = -1.

ORDERED n-TUPLE:

The ordered n-tuple, (a1, a2, ..., an) consists of elements a1, a2, ..an together with the

ordering: first a1, second a2, and so forth up to an. In particular, an ordered 2-

tuple is

called an ordered pair, and an ordered 3-tuple is called an ordered

triple.

Two ordered n-tuples (a1, a2, ..., an) and (b1, b2, ..., bn) are equal if

and only if each corresponding pair of their elements is equal, i.e., ai = bj, for all

i = 1, 2... n.

CARTESIAN PRODUCT OF TWO SETS:

denoted A × B (read "A

Let A and B be sets. The Cartesian product of A and B,

cross B") is the set of all ordered

pairs (a, b), where a is in A and b is in B.

Symbolically:

A ×B = {(a, b)| a ∈ A and b ∈ B}

NOTE

A ×B has m × n

If set A has m elements and set B has n elements then

elements.

EXAMPLE:

Let A = {1, 2}, B = {a, b, c} then

A ×B = {(1,a), (1,b), (1,c), (2,a), (2, b), (2, c)}

B ×A = {(a,1), (a,2), (b, 1), (b, 2), (c, 1), (c, 2)}

A ×A = {(1, 1), (1,2), (2, 1), (2, 2)}

B ×B = {(a, a), (a, b), (a, c), (b, a), (b, b), (b, c), (c, a), (c, b),(c, c)}

REMARK:

1. A × B≠B × A for non-empty and unequal sets A and B.

2. A × φ = φ × A = φ

3. | A × B| = |A| × |B|

CARTESIAN PRODUCT OF MORE THAN TWO SETS:

The Cartesian product of sets A1, A2, ..., An, denoted A1× A2 × ... ×An, is the set of

all ordered n-tuples (a1, a2, ..., an) where a1 ∈A1, a2 ∈A2,..., an ∈An.

Symbolically:

A1× A2 × ... ×An ={(a1, a2, ..., an) | ai ∈Ai, for i=1, 2, ..., n}

BINARY RELATION:

Let A and B be sets. A (binary) relation R from A to B is a subset of A × B.

When (a, b) ∈R, we say a is related to b by R, written a R b.

Otherwise if (a, b) ∉R, we write a R b.

EXAMPLE:

Page 36

MTH001 Elementary Mathematics

Let A = {1, 2}, B = {1, 2, 3}

Then A × B = {(1, 1), (1, 2), (1, 3), (2, 1), (2, 2), (2, 3)}

Let

R1={(1,1), (1, 3), (2, 2)}

R2={(1, 2), (2, 1), (2, 2), (2, 3)}

R3={(1, 1)}

R4= A × B

R5= ∅

All being subsets of A × B are relations from A to B.

DOMAIN OF A RELATION:

The domain of a relation R from A to B is the set of all first elements of the

ordered pairs which belong to R denoted

Dom(R).

Symbolically:

Dom (R) = {a ∈A| (a,b) ∈R}

RANGE OF A RELATION:

The range of A relation R from A to B is the set of all second

elements of

the

ordered pairs which belong to R denoted

Ran(R).

Symbolically:

Ran(R) = {b ∈B|(a,b) ∈ R}

EXERCISE:

Let

A = {1, 2},

B = {1, 2, 3},

Define a binary relation R from A to B as follows:

R = {(a, b) ∈A × B | a < b}

Then

a. Find the ordered pairs in R.

b. Find the Domain and Range of R.

c. Is 1R3, 2R2?

SOLUTION:

Given A = {1, 2}, B = {1, 2, 3},

A × B = {(1,1), (1,2), (1,3), (2,1), (2,2), (2,3)}

a. R = {(a, b) ∈A × B | a < b}

R = {(1,2), (1,3), (2,3)}

b. Dom(R) = {1,2} and Ran(R) = {2, 3}

a. Since (1,3) ∈R so 1R3

But (2, 2) ∉R so 2 is not related with3.

EXAMPLE:

Let A = {eggs, milk, corn} and B = {cows, goats, hens}

Define a relation R from A to B by (a, b) ∈R iff a is produced by b.

Then R = {(eggs, hens), (milk, cows), (milk, goats)}

Thus, with respect to this relation eggs R hens , milk R cows, etc.

EXERCISE :

Find all binary relations from {0,1} to {1}

SOLUTION:

Let A = {0,1} &

B = {1}

Then A × B = {(0,1), (1,1)}

All binary relations from A to B are in fact all subsets of

A ×B, which are:

R1= ∅

R2={(0,1)}

R3={(1,1)}

Page 37

MTH001 Elementary Mathematics

R4={(0,1), (1,1)} = A × B

REMARK:

If |A| = m and |B| = n

Then as we know that the number of elements in A × B are m × n. Now as we

m×n

know that the total number of and the total number of relations from A to B are2

RELATION ON A SET:

A relation on the set A is a relation from A to A.

In other words, a relation on a set A is a subset of A × A.

EXAMPLE: :

Let A = {1, 2, 3, 4}

Define a relation R on A as

(a,b) ∈ R iff a divides b {symbolically written as a | b}

Then R = {(1,1), (1,2), (1,3), (1,4), (2,2), (2,4), (3,3),

(4,4)}

REMARK:

For any set A

1. A × A is known as the universal relation.

2. ∅ is known as the empty relation.

EXERCISE:

Define a binary relation E on the set of the integers Z, as

follows:

for all m,n ∈Z, m E n ⇔ m n is even.

Is (6,6) ∈E? Is (-1,7) ∈E?

a. Is 0E0?

Is 5E2?

b. Prove that for any even integer n, nE0.

SOLUTION

E = {(m,n) ∈Z ×Z | m n is even}

a. (i) (0,0) ∈ Z ×Z and

0-0 = 0 is even

Therefore

0E0.

(5,2) ∈ Z ×Z but 5-2 = 3 is not even

(ii)

5E2

(6,6) ∈ E

(iii)

since 6-6 = 0 is an even integer.

(-1,7) ∈E

(iv)

since (-1) 7 = -8 is an even integer.

a. For any even integer, n, we have

n 0 = n,

an even integer

so (n, 0) ∈E or

equivalently n E 0

COORDINATE DIAGRAM (GRAPH) OF A RELATION:

Let A = {1, 2, 3} and B = {x, y}

Let R be a relation from A to B defined as

R = {(1, y), (2, x), (2, y), (3, x)}

The relation may be represented in a coordinate diagram as

follows:

123

Page 38

MTH001 Elementary Mathematics

EXAMPLE:

Draw the graph of the binary relation C from R to

R defined

follows:

(x, y) ∈C ⇔ x2 + y2 = 1

for all (x, y) ∈R × R,

SOLUTION

x2+y2=1,

All ordered pairs (x, y) in relation C satisfies the equation

which when solved for y gives

Clearly y is real, whenever 1 ≤ x ≤ 1

Similarly x is real, whenever 1 ≤ y ≤ 1

Hence the graph is limited in the range 1 ≤ x ≤ 1 and 1 ≤ y ≤ 1

The graph of relation is

(0,1)

(1,0)

(0,0)

(-1,0)

(0,-1)

ARROW DIAGRAM OF A RELATION:

Let

A = {1, 2, 3}, B = {x, y} and

R = {1,y), (2,x), (2,y), (3,x)}

be a relation from A to B.

The arrow diagram of R is:

DIRECTED GRAPH OF A RELATION:

Page 39

MTH001 Elementary Mathematics

Let A = {0, 1, 2, 3}

and R = {(0,0), (1,3), (2,1), (2,2), (3,0), (3,1)}

be a binary relation on A.

DIRECTED GRAPH

MATRIX REPRESENTATION OF A RELATION

Let

A = {a1, a2, ..., an} and B = {b1, b2, ..., bm}. Let R be a

relation from A to

B. Define the n × m order matrix M by

⎧1 if (ai , bi ) ∈ R

m(i, j) = ⎨

⎩0 if (ai , bi ) ∉ R

for

i=1,2,...,n and

j=1,2,...,m

EXAMPLE:

Let A = {1, 2, 3} and B = {x, y}

Let R be a relation from A to B defined as

R ={(1,y), (2,x), (2,y), (3,x)}

1 ⎡0

1⎤

M = 2 ⎢1

1⎥

⎢

⎥

3 ⎢1

0⎥ 3×2

⎣

⎦

EXAMPLE:

For the relation matrix.

1 2 3

1 ⎡1 0 1⎤

M = 2 ⎢1 0 0⎥

⎢

⎥

3 ⎢0 1 1⎥

⎣

⎦

1. List the set of ordered pairs represented by M.

2. Draw the directed graph of the relation.

Page 40

MTH001 Elementary Mathematics

SOLUTION:

The relation corresponding to the given Matrix is

R = {(1,1), (1,3), (2,1), (3,1), (3,2), (3,3)}

And its Directed graph is given below

EXERCISE:

Let A = {2, 4} and B = {6, 8, 10} and define relations R and S

from A to B as follows:

for all (x,y) ∈A × B, x R y ⇔ x | y

for all (x,y) ∈A × B, x S y ⇔ y 4 = x

State explicitly which ordered pairs are in A × B, R, S, R∪S and R∩S.

SOLUTION

A × B = {(2,6), (2,8), (2,10), (4,6), (4,8), (4,10)}

R = {(2,6), (2,8), (2,10), (4,8)}

S = {(2,6), (4,8)}

R ∪ S = {(2,6), (2,8), (2,10), (4,8)}= R

R ∩ S = {(2,6), (4,8)}= S

Page 41
