Lecture-23

Total DQM

TDQM in a DWH

Many DW projects do not deliver to full potential because they treat data quality as a one -time

undertaking as part of user acceptance testing (UAT) and then forgetting a out it. It is very

important that data quality management is undertaken as a continuous improvement process...not

a one-shot deal!

Use an iterative approach to achieve data quality. Start by defining the quality measurements, and

then take the measurements. Go through the cycle as shown in Figure 23.1, this will drive you to

the stable stage i.e. CMM -5, where you have a small amount of acceptable data quality defects.

Here acceptable is based on cost vs. the value.

Data Quality Management Process

Figure-23.1: Data Quality Management Process

1. Establish Data Quality Management Environment

Securing a commitment to the Data Quality Management process is accomplished by establishing

the data quality management environment between information system project managers and

establishing conditions to encourage team work between functional and information system

development professionals. Functional users of legacy information systems know data quality

problems of the current systems but do not know how to systematically improve existing data.

Information system developers know how to identify data quality problems but do not know how

to change the functional requirements that drive the systemic improvement of data. Given the

existing barriers to communication, establishing the data quality environment involves

participation of both functional users and information system administrators.

2. Scope Data Quality Projects & Develop Implementation Plan

For each data quality analysis project selected, the data quality project manager defines the scope

of the project and defines the level of analysis that will be the most beneficial for the project

under question. Draft an initial plan that addresses the following elements.

180

Task Summary: Project goals, scope, and potential benefits

Task Description: Describe data quality analysis tasks

Project Approach: Summarize tasks and tools used to provide a baseline of existing data

quality

Schedule: Identify task start, completion dates, and project milestones

Resources: Identify resources required to complete the data quality assessment. Include

costs connected with tools acquisition, labor hours (by labor category), training, travel,

and other direct and indirect costs

3. Implement Data Quality Projects (Define, Measure, Analyze, Improve)

A data quality analysis project consists of four activities. The data quality project manager

performs these activities with input from the functional users of the data, system developers, and

database administrators of the legac y and target database systems.

· Define: Identify functional user data quality requirements and establish data quality

metrics.

· Measure: Measure conformance to current business rules and develop exception reports.

· Analyze: Verify, validate, and assess poor d ta quality causes. Define improvement

opportunities.

· Improve: Select/prioritize data quality improvement opportunities.

Improving data quality may lead to changing data entry procedures, updating data validation

rules, and/or use of company data standards to prescribe a uniform representation of data used

throughout the company.

4. Evaluate Data Quality Management Methods

The last step in the Data Quality Management process is to evaluate and assess progress made in

implementing data quality initiatives and/or projects. All participants in the Data Quality

Management process (functional users, program managers, developers, and the Office of Data

Management) should review progress with respect to: (1) modifying or rejuvenating existing

methods to data qualit y management and/or (2) determining whether data quality projects have

helped to achieve demonstrable goals and benefits. Evaluating and assessing data quality work

reinforces the idea that Data Quality Management is not a program, but a new way of doing

business.

The House of Quality

In 1972 the Mitsubishi Shipyards in Kobe developed a technique in which customer wants were

linked to product specifications via a matrix format as shown in Figure 23.2. This technique is

known today as The House of Quality and is one of many techniques of Quality Function

Deployment, which can briefly be defined as "a system for translating customer requirements into

appropriate company requirements".

The purpose of the technique is to reduce two types of risk. First, the risk that the product

specification does not comply with the wants of the predetermined target group of customers.

Secondly, the risk that the final product does not comply with the product specification.

181

The House of Quality Matrix

Technical Correlation

Matrix

Customer

Technical Design

Requirements

Interrelationship

Matrix

Figure-23.2: The House of Quality Matrix

The House of Quality Data Model

The House of Quality concept was used and introduced with reference to data quality in 1988.

The idea is that the end user applications and the data characteristics for those applications such

as date of birth etc are tied together, such that for each application tolerances on data quality are

placed, including no needs. If the tolerances are not within (say) x%, then the corresponding data

can not be used. So we are looking at:

Establishing specifications for data in the data warehouse.

Establishing applications for data in the data warehouse.

Establishing tolerances for conformity to specifications for each combination of

applications and data specifications.

If it costs more to deliver th e tolerance than the value of the application then the company is not

ready to do the application yet. It means the company has to make a business decision not to do

the application with dirty data, or to do the application and pretend that the data is of high quality.

The House of Data Quality: Next Step

Getting more sophisticated, we can say that if you give me data withx% data quality, the value of

the application will be y millions of dollars. If you give me 2x% data quality, then the value of the

application is 3y millions of dollars. Why? Because now the predictive model is more accurate.

If you give me date of birth 90% of the time, then I can make you a million dollars on better

customer retention. But if you give me date of birth 95% of the time, then the accuracy goes

182

much higher, and how much is that worth to you? The question is. What is the value of the

application, relative to the specific data quality specifications?

How to improve Data Quality?

The four categories of Data Quality Imp rovement

Process

System

Policy & Procedure

Data Design

Process Improvement: Improve the functional processes used to create, manage, access, and use

data. Functional process changes may encourage centralized data entry, eliminate non -value

added activities, and place data quality responsibilities where data is entered into the data set

(e.g., certification of data)

System Improvement: Software, hardware, and telecommunication changes can improve data

quality. For example, security software can minimi ze damage done by malicious updates to

databases by unauthorized users. Hardware improvements may make batch loads faster and

thereby make it unnecessary to turn off edit and validation constraints when loading data to a

database. Telecommunications improv ements (e.g. increasing bandwidth) may provide easier

access to data and improve both the accuracy and timeliness of data. Other system improvements

may include updating end user, operation, and maintenance manuals, and providing additional

user training.

Policy and Procedure Improvement: Resolve conflicts in existing policies and procedures and

institutionalize behaviors that promote good data quality. Develop Standard Operating Procedures

for the information system to document the data quality rule sets/filters used to measure data

quality. Perform periodic data quality checks as part of the Standard Operating Procedures to

increase data quality.

Data Design Improvement: Improve the overall data design and use data standards. Adding

primary key constraints, indexes, unique key constraints, triggers, stored functions and

procedures, controlling administration of user privileges, enforcing security features, and

referential integrity constraints can improve database design.

183

Quality Management Maturity Grid

Table-23.1: Quality Management Maturity Grid

Table 23.1 shows the quality management maturity grid. Each of the five stages will be discussed

in detail.

Stage 1: Uncertainty

Stage-1 is denial. People don't think data quality is an issue. It is the responsibility of the people

collecting the data. It is their problem. There is no data quality inspection; nobody actually cares

about the data quality in the processes. The problems are handled on a fire fighting basis, you

discover problems (or they pop up) and you fix them using a band aid approach and the problems

are rarely resolved. There are a large number of companies in this stage. Some may not even have

a quality department, or even when they have one, not paying enough attention and committin g

resources.

Stage 2: Awakening

People think that data quality management does have a value. Management talks about it, but

does nothing. This is like all talk and no action stage. People go around giving presentations, but

really there is no action, just motivational stuff and not doing any thing. If there is a major

problem, the approach is to put together an ad hoc team, that team will attack and resolve the

problem. In the end they say that somebody messed up.

Stage 3: Enlightenment

A light goes on, may be there is a problem. The quality department starts reporting instead of

hiding the problems in the closet. You actually start to measure data quality and are reasonably

close. Actually the management is now committed, and have invested resources.

Stage 4: Wisdom

Value of quality is seen as something that is needful and meaningful. Data quality starts coming

on the performance evaluation of employees i.e. what are they doing for data quality. There is a

184

14 step program for continuous improvement. They actually start going through it, and start

taking proactive actions to prevent data quality defects from happening. So rather than fixing

problems AFTER they have occurred, you start taking steps BEFORE the problems occur i.e.

practicing prevention. Quality comes from prevention. And prevention is a result of training,

discipline, example, leadership, and more. So there is a fundamental shift. Now you are looking at

organizational processes, and changing them.

How do you know an organization is in stage 4? They should have looked at their data quality

processes and found out why data quality problems are reoccurring and fixed them. If they are

still discovering data quality problems, then certainly they are not in stage -4.

There are actually a very small number of organizations in stage-4. Usually they have a DW in

place and discovered how bad the quality of their data is before they start moving on this maturity

grid.

Stage 5: Certainty

The approach is "I know about the quality of my data" and/or "I am measuring it for real".

Quality improvement is NOT something that is done on ad-hoc basis, but is part of everything.

People know why they are doing it, and why they do not have data quality problems.

Misconceptions on Data Quality

1. You Can Fix Data

2. Data Quality is an IT Problem

1. You Can Fix Data

Fixing implies that there was something wrong with the original data, and you can fix it once and

be done with it. In reality, the problem may have been not with the data itself, but rather in the

way it was used. When you manage data you manage data quality. It's an ongoing process. Data

cleansing is not the answer to data quality issues. Yes, data cleansing does address some

important data quality problems has and offers a solid business value ROI, but it is only one

element of the data quality puzzle. Too often the business purchases a data cleansing tool and

thinks the problem is solved. In other cases, because the cost of data cleansing tools is high, a

business may decide that it is too expensive for them to deal with the problem.

2. Data Quality is an IT Problem

Data quality is a company problem that costs a business in many ways. Although IT can help

address the problem of data quality, the business has to own the data and the business processes

that create or use it. The business has to define the metrics for data quality - its completeness,

consistency, relevancy and timeliness. The business has to determine the threshold between data

quality and ROI. IT can enable the processes and manage data thro ugh technology, but the

business has to define it. For an enterprise-wide data quality effort to be initiated and successful

on an ongoing basis, it needs to be truly a joint business and IT effort.

Misconceptions on Data Quality

3. All) Problem is in the Data Sources or Data Entry

4. The Data Warehouse will provide a single source of truth

5. Compare with the master copy will fix the problem

185

3. The Problem is in the Data Sources or Data Entry

Data entry or operational systems are often blamed for data quality problems. Although

incorrectly entered or missing data is a problem, it is far from the only data quality problem. Also,

everyone blames their data quality problems on the systems that they sourced the data from.

Although some of that may be true, a large part of the data quality issue is the consistency,

relevancy and timeliness of the data. If two divisions are using different customer identifiers or

product numbers, does it mean that one of them has the wrong numbers or is the problem on e of

consistency between the divisions? If the problem is consistency, then it is an enterprise issue,

not a divisional issue. The long-term solution may be for all divisions to use the same codes, but

that has to be an enterprise decision.

4. The Data Warehouse will provide a Single Version of the Truth

In an ideal world, every report or analysis performed by the business exclusively uses data

sourced from the data warehouse - data that has gone through data cleansing and quality

processes and includes constant interpretations such as profit or sales calculations. If everyone

uses the data warehouse's data exclusively and it meets your data quality metrics then it is the

single version of the truth.

However, two significant conditions lessen the likelihood that the data warehouse solves your

data quality issues by itself. First, people get data for their reports and analysis from a variety of

data sources - data warehouse (sometimes there are multiple data warehouses in an enterprise),

data marts and cubes (that you hope were sourced from the data warehouse). They also get data

from systems such as ERP, CRM, and budgeting and planning systems that may be sourced into

the data warehouse themselves. In these cases, ensuring data quality in the data warehouse alone

is not enough. Multiple data silos mean multiple versions of the truth and multiple interpretations

of the truth. Data quality has to be addressed across these data silos, not just in the data

warehouse.

Second, data quality involves the source data and its transformation into information. That means

that even if every report and analysis gets data from the same data warehouse, if the business

transformations and interpretations in these reports are different then there still are significant

data quality issues. Data quality processes need to involve data creation; the staging of data in

data warehouses, data marts, cubes and data shadow systems; and information consumption in the

form of reports and business analysis. Applying data quality to the dat a itself and not its usage as

information is not sufficient.

Normally source system reconciliation is used to check if the ETL is working properly. This

technique is useful when you are doing test and validation of the ETL, but is not recommended on

a long term basis. This will only be done when major changes are made in the ETL. Since the

process is manual, it is human intensive, so it will be very expensive and inefficient.

All the other four techniques discussed in the previous sections can be automat ed by writing

scripts, and running them every month to collect statistics, generating reports, and identifying

problems and subsequently noting the progress of quality control. But one has to be very clever to

write scripts for source system reconciliation . It can turn out to be a nightmare. The main

problems are that you may have garbage in the DWH, garbage in the legacy system, and that does

not really tell you about the data quality. Recall Orr's Law #4 - "Data quality problems increase

with the age of t he system!"

186

TDQM: Successful Data Sourcing

Figure-23.3: TDQM: Successful Data Sourcing

If you take data from downstream data sources it's likely that not only you are going to

accumulate the data quality defects of the upstream sources, but also the compromises that the

downstream may have added, especially the summarizations. Once you summarize, you can not

trace back to detailed data. Go as high upstream for the gold copy of the data as possible as

shown in Figure 23.3.

You also h ave to be aware of the synchronization issues. You take the transaction data and the

accounts data and there are some transactions that don't exist in the accounts yet, so you have to

be careful of the order in which you take the data for synchronization. Synchronization is

probably the biggest reason we have referential integrity problems in a DWH i.e. lack of

synchronization between different extracts of the source system.

Misconceptions on Data Quality

It came from the legacy system so must be correct.

Another misconception is, "It came from the production transaction processing environment, so it

must be correct." However the reality is, the elements required for decision support are often

quite different than those required for transaction process ing. The objective of OLTP systems is

to ensure that all the sales data is in, the numbers sum up correctly, accounts are balanced etc. If

the gender data for some (or even most) sales is not present, it does not change the sales dollars.

Why bother? Why not enter some junk data in the gender field? This may be fine from the

operational point of view, but critical for decision support, when you are interested in determining

your market segmentation.

Redefines and other embedded logic in legacy programs often puts data quality delivered to data

warehouse in severe question. Y2K is a good example.

187

Table of Contents:
