Software Interrupts

8.1. INTERRUPTS

Interrupts in reality are events that occurred outside the processor and the

processor must be informed about them. Interrupts are asynchronous and

unpredictable. Asynchronous means that the interrupts occur, independent

of the working of the processor, i.e. independent of the instruction currently

executing. Synchronous events are those that occur side by side with

another activity. Interrupts must be asynchronous as they are generated by

the external world which is unaware of the happenings inside the processor.

True interrupts that occur in real time are asynchronous with the execution.

Also it is unpredictable at which time an interrupt will come. The two

concepts of being unpredictable and asynchronous are overlapping.

Unpredictable means the time at which an interrupt will come cannot be

predicted, while asynchronous means that the interrupt has nothing to do

with the currently executing instruction and the current state of the

processor.

The 8088 processor divides interrupts into two classes. Software interrupts

and hardware interrupts. Hardware interrupts are the real interrupts

generated by the external world as discussed above. Software interrupts on

the contrary are not generated from outside the processor. They just provide

an extended far call mechanism. Far all allows us to jump anywhere in the

whole megabyte of memory. To return from the target we place both the

segment and offset on the stack. Software interrupts show a similar

behavior. It however pushes one more thing before both the segment and

offset and that is the FLAGS register. Just like the far call loads new values

in CS and IP, the interrupt call loads new values in CS, IP, and FLAGS.

Therefore the only way to retain the value of original FLAGS register is to

push and pop as part of interrupt call and return instructions. Pushing and

popping inside the routine will not work as the routine started with an

already tampered value.

The discussion of real time interrupts is deferred till the next chapter. They

play the critical part in control applications where external hardware must

be control and events and changes therein must be appropriately responded

by the processor. To generate an interrupt the INT instruction is used. The

routine that executes in response to an INT instruction is called the interrupt

service routine (ISR) or the interrupt handler. Taking example from real time

interrupts the routine to instruct an external hardware to close the valve of a

boiler in response to an interrupt from the pressure sensor is an interrupt

routine.

The software interrupt mechanism in 8088 uses vectored interrupts

meaning that the address of the interrupt routine is not directly mentioned

in an interrupt call, rather the address is lookup up from a table. 8088

provides a mechanism for mapping interrupts to interrupt handlers.

Introducing a new entry in this mapping table is called hooking an interrupt.

Syntax of the INT instruction is very simple. It takes a single byte

argument varying from 0-255. This is the interrupt number informing the

processor, which interrupt is currently of interest. This number correlates to

the interrupt handler routine by a routing or vectoring mechanism. A few

interrupt numbers in the start are reserved and we generally do not use

them. They are related to the processor working. For example INT 0 is the

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

divide by zero interrupt. A list of all reserved interrupts is given later. Such

interrupts are programmed in the hardware to generate the designated

interrupt when the specified condition arises. The remaining interrupts are

provided by the processor for our use. Some of these were reserved by the

IBM PC designers to interface user programs with system software like DOS

and BIOS. This was the logical choice for them as interrupts provided a very

flexible architecture. The remaining interrupts are totally free for use in user

software.

The correlation process from the interrupt number to the interrupt handler

uses a table called interrupt vector table. Its location is fixed to physical

memory address zero. Each entry of the table is four bytes long containing

the segment and offset of the interrupt routine for the corresponding

interrupt number. The first two bytes in the entry contain the offset and the

next two bytes contain the segment. The little endian rule of putting the more

significant part (segment) at a higher address is seen here as well.

Mathematically offset of the interrupt n will be at nx4 while the segment will

be at nx4+2. One entry in this table is called a vector. If the vector is changed

for interrupt 0 then INT 0 will take execution to the new handler whose

address is now placed at those four bytes. INT 1 vector occupies location 4,

5, 6, and 7 and similarly vector for INT 2 occupies locations 8, 9, 10, and 11.

As the table is located in RAM it can be changed anytime. Immediately after

changing it the interrupt mapping is changed and now the interrupt will

result in execution of the new routine. This indirection gives the mechanism

extreme flexibility.

The operation of interrupt is same whether it is the result of an INT

instruction (software interrupt) or it is generated by an external hardware

which passes the interrupt number by a different mechanism. The currently

executing instruction is completed, the current value of FLAGS is pushed on

the stack, then the current code segment is pushed, then the offset of the

next instruction is pushed. After this it automatically clears the trap flag and

the interrupt flag to disallow further interrupts until the current routine

finishes. After this it loads the word at nx4 in IP and the word at nx4+2 in CS

if interrupt n was generated. As soon as these values are loaded in CS and IP

execution goes to the start of the interrupt handler. When the handler

finishes its work it uses the IRET instruction to return to the caller. IRET

pops IP, then CS, and then FLAGS. The original value of IF and TF is

restored which re-enables further interrupts. IF and TF will be discussed in

detail in the discussion of real time interrupts. We have discussed three

things till now.

1. The INT and IRET instruction format and syntax

2. The formation of IVT (interrupt vector table)

3. Operation of the processor when an interrupt in generated

Just as discussed in the subroutines chapter, the processor will not match

interrupt calls to interrupt returns. If a RETF is used in the end of an ISR the

processor will still return to the caller but the FLAGS will remain on the

stack which will destroy the expectations of the caller with the stack. If we

know what we are doing we may use such different combination of

instructions. Generally we will use IRET to return from an interrupt routine.

Apart from indirection the software interrupt mechanism is similar to CALL

and RET. Indirection is the major difference.

The operation of INT can be written as:

· sp ← sp+2

· [sp] ← flag

· sp ← sp+2

· if ← 0

· tf ← 0

· [sp] ← cs

· sp ← sp+2

· [sp] ← ip

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

· ip ← [0:N*4]

· cs ← [0:N*4+2]

The operation of IRET can be written as:

· ip ← [sp]

· sp ← sp-2

· cs ← [sp]

· sp ← sp-2

· flag ← [sp]

· sp ← sp-2

The above is the microcode description of INT and IRET. To obey an

assembly language instruction the processor breaks it down into small

operations. By reading the microcode of an instruction its working can be

completely understood.

The interrupt mechanism we have studied is an extended far call

mechanism. It pushes FLAGS in addition to CS and IP and it loads CS and IP

with a special mechanism of indirection. It is just like the table of contents

that is located at a fixed position and allows going directly to chapter 3, to

chapter 4 etc. If this association is changed in the table of contents the

direction of the reader changes. For example if Chapter 2 starts at page 220

while 240 is written in the table of contents, the reader will go to page 240

and not 220. The table of contents entry is a vector to point to map the

chapter number to page number. IVT has 256 chapters and the interrupt

mechanism looks up the appropriate chapter number to reach the desired

page to find the interrupt routine.

Another important similarity is that table of contents is always placed at

the start of the book, a well known place. Its physical position is fixed. If

some publishers put it at some place, others at another place, the reader will

be unable to find the desired chapter. Similarly in 8088 the physical memory

address zero is fixed for the IVT and it occupies exactly a kilobyte of memory

as the 256x4=1K where 256 is the number of possible interrupt vectors while

the size of one vector is 4 bytes.

Interrupts introduce temporary breakage in the program flow, sometimes

programmed (software interrupts) and un-programmed at other times

(hardware interrupts). By hooking interrupts various system functionalities

can be controlled. The interrupts reserved by the processor and having

special functions in 8088 are listed below:

· INT 0, Division by zero

Meaning the quotient did not fit in the destination register. This is a bit

different as this interrupt does not return to the next instruction,

rather it returns to the same instruction that generated it, a DIV

instruction of course. Here INT 0 is automatically generated by a DIV

when a specific situation arises, there is no INT 0 instruction.

· INT 1, Trap, Single step Interrupt

This interrupt is used in debugging with the trap flag. If the trap flag is

set the Single Step Interrupt is generated after every instruction. By

hooking this interrupt a debugger can get control after every

instruction and display the registers etc. 8088 was the first processor

that has this ability to support debugging.

· INT 2, NMI-Non Maskable Interrupt

Real interrupts come from outside the processor. INT 0 is not real as it

is generated from inside. For real interrupts there are two pins in the

processor, the INT pin and the NMI pin. The processor can be directed

to listen or not to listen to the INT pin. Consider a recording studio,

when the recording is going on, doors are closed so that no

interruption occurs, and when there is a break, the doors are opened

so that if someone is waiting outside can come it. However if there is an

urgency like fire outside then the door must be broken and the

recording must not be catered for. For such situations is the NMI pin

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

which informs about fatal hardware failures in the system and is tied

to interrupt 2. INT pin can be masked but NMI cannot be masked.

· INT 3, Debug Interrupt

The only special thing about this interrupt is that it has a single byte

opcode and not a two byte combination where the second byte tells the

interrupt number. This allows it to replace any instruction whatsoever.

It is also used by the debugger and will be discussed in detail with the

debugger working.

· INT 4, Arithmetic Overflow, change of sign bit

The overflow flag is set if the sign bit unexpectedly changes as a result

of a mathematical or logical instruction. However the overflow flag

signals a real overflow only if the numbers in question are treated as

signed numbers. So this interrupt is not automatically generated but

as a result of a special instruction INTO (interrupt on overflow) if the

overflow flag is set. Otherwise the INTO instruction behaves like a NOP

(no operation).

These are the five interrupts reserved by Intel and are generally not used in

our operations.

8.2. HOOKING AN INTERRUPT

To hook an interrupt we change the vector corresponding to that interrupt.

As soon as the interrupt vector changes, that interrupt will be routed to the

new handler. Our first example is with the divide by zero interrupt. The

normal system defined behavior in response to divide by zero is to display an

error message and terminate the program. We will change it to display our

own message.

Example 8.1

001

; hooking divide by zero interrupt

002

[org 0x0100]

003

jmp start

004

005

message:

'You divided something by zero.', 0

006

007-029

;;;;; COPY LINES 028-050 FROM EXAMPLE 7.4 (strlen) ;;;;;

030-049

;;;;; COPY LINES 005-024 FROM EXAMPLE 7.1 (clrscr) ;;;;;

050-090

;;;;; COPY LINES 050-090 FROM EXAMPLE 7.4 (printstr) ;;;;;

091

092

; divide by zero interrupt handler

093

myisrfor0:

push ax

; push all regs

094

push bx

095

push cx

096

push dx

097

push si

098

push di

099

push bp

100

push ds

101

push es

102

103

push cs

104

pop ds

; point ds to our data segment

105

106

call

clrscr

; clear the screen

107

mov

ax, 30

108

push

; push x position

109

mov

ax, 20

110

push

; push y position

111

mov

ax, 0x71

; white on blue attribute

112

push

; push attribute

113

mov

ax, message

114

push

; push offset of message

115

call

printstr

; print message

116

117

pop

118

pop

119

pop

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

120

pop

121

pop

123

pop

124

pop

125

pop

126

pop

127

iret

; return from interrupt

128

129

; subroutine to generate a divide by zero interrupt

130

genint0:

mov ax, 0x8432

; load a big number in ax

131

mov bl, 2

; use a very small divisor

132

div bl

; interrupt 0 will be generated

133

ret

134

135

start:

xor

ax, ax

136

mov

es, ax

; load zero in es

137

mov

word [es:0*4], myisrfor0 ; store offset at n*4

138

mov

[es:0*4+2], cs

; store segment at n*4+2

139

call

genint0

; generate interrupt 0

140

141

mov ax, 0x4c00

; terminate program

142

int 0x21

We often push all registers in an interrupt service routine just to be

93-101

sure that no unintentional modification to any register is made.

Since any code may be interrupted an unintentional modification

will be hard to debug

Since interrupt can be called from anywhere we are not sure about

103-104

the value in DS so we reset it to our code segment.

When this program is executed our desired message will be shown instead

of the default message and the computer will hang thereafter. The first thing

to observe is that there is no INT 0 call anywhere in the code. INT 0 was

invoked automatically by an internal mechanism of the processor as a result

of the DIV instruction producing a result that cannot fit in the destination

system to divide overflow situations.

However the system stuck instead of returning to the next instruction.

This is because divide overflow is a special type of interrupt that returns to

the same instruction instead of the next instruction. This is why the default

handler forcefully terminates the program instead of returning. Now the IRET

will take control back to the DIV instruction which will again generate the

same interrupt. So the computer is stuck in an infinite loop.

8.3. BIOS AND DOS INTERRUPTS

In IBM PC there are certain interrupts designated for user programs to

communicate with system software to access various standard services like

access to the floppy drive, hard drive, vga, clock etc. If the programmer does

not use these services he has to understand the hardware details like which

particular controller is used and how it works. To avoid this and provide

interoperability a software interface to basic hardware devices is provided

except in very early computers. Since the manufacturer knows the hardware

it burns the software to control its hardware in ROM. Such software is called

firmware and access to this firmware is provided through specified

interrupts.

This basic interface to the hardware is called BIOS (basic input output

services). When the computer is switched on, BIOS gets the control at a

specified address. The messages at boot time on the screen giving BIOS

version, detecting different hardware are from this code. BIOS has the

responsibility of testing the basic hardware including video, keyboard, floppy

drive, hard drive etc and a special program to bootstrap. Bootstrap means to

load OS from hard disk and from there OS takes control and proceeds to load

its components and display a command prompt in the end. There are two

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

important programs; BIOS and OS. OS services are high level and build upon

the BIOS services. BIOS services are very low level. A level further lower is

only directly controlling the hardware. BIOS services provide a hardware

independent layer above the hardware and OS services provide another

higher level layer over the BIOS services. We have practiced direct hardware

access with the video device directly without using BIOS or DOS. The layer of

BIOS provides services like display a character, clear the screen, etc. All

these layers are optional in that we can skip to whatever lower layer we want.

The most logical way to provide access to firmware is to use the interrupt

mechanism. Specific services are provided at specific interrupts. CALL could

also have been used but in that case every manufacturer would be required

to place specific routines at specific addresses, which is not a flexible

mechanism. Interrupts provide standard interrupt number for the caller and

flexibility to place the interrupt routine anywhere in the memory for the

manufacturer. Now for the programmer it is decided that video services will

be provided at INT 10 but the actual address of the video services can and do

vary on computers from different manufacturers. Any computer that is IBM

compatible must make the video services accessible through INT 10.

Similarly keyboard services are available at INT 16 and this is standard in

every IBM compatible. Manufacturers place the code wherever they want and

the services are exported through this interrupt.

BIOS exports its various services through different interrupts. Keyboard

services are exported through INT 16, parallel port services through INT 17

and similarly others through different interrupts. DOS has a single entry

point through INT 21 just like a pin hole camera, this single entry points

leads to a number of DOS services. So how one interrupt provides a number

of different services. A concept of service number is used here which is a

defecto standard in providing multiple services through an interrupt. INT 10

is for video services and each of character printing service, screen clearing

service, cursor movement service etc. has a service number associated to it.

So we say INT 10 service 0 is used for this purpose and INT 10 service 1 is

used for that purpose etc. Service numbers for different standard services are

also fixed for every IBM compatible. The concept of exported services through

interrupts is expanded with the service numbering scheme.

The service number is usually given in the AH register. Sometimes these

256 services seem less. For example DOS exports thousands of services. So

will be often seen an extension to a level further with sub-services. For

examples INT 10 character generator services are all provided through a

single service number and the services are distinguished with a sub-service

number.

The finally selected service would need some arguments for it to work. In

interrupts arguments are usually not given through stack, rather registers

are used. The BIOS and DOS specifications list which register contains

which argument for a particular service of a particular interrupt.

We will touch some important BIOS and DOS services and not cover it

completely neither is it possible to cover it in this space. A very

comprehensive reference of interrupts is the Ralph Brown List. It is just a

reference and not to be studied from end to end. All interrupts cannot be

remembered and there is no need to remember them.

The service number is almost always in AH while the sub-service number

is in AL or BL and sometimes in other registers. The documentation of the

service we are using will list which register should hold what when the

interrupt is invoked for that particular service.

Our first target using BIOS is video so let us proceed to our first program

that uses INT 10 service 13 to print a string on the screen. BIOS will work

even if the video memory is not at B8000 (a very old video card) since BIOS

knows everything about the hardware and is hardware specific.

100

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

Example 8.2

001

; print string using bios service

002

[org 0x0100]

003

jmp start

004

message:

'Hello World'

005

006

start:

mov

ah, 0x13

;

service 13 - print string

007

mov

al, 1

;

subservice 01 update cursor

008

mov

bh, 0

;

output on page 0

009

mov

bl, 7

;

normal attrib

010

mov

dx, 0x0A03

;

row 10 column 3

011

mov

cx, 11

;

length of string

012

push

013

pop

; segment of string

014

mov

bp, message

; offset of string

015

int

0x10

; call BIOS video service

016

017

mov

ax, 0x4c00

; terminate program

018

int

0x21

The sub-service are versions of printstring that update and do not

007

update the cursor after printing the string etc.

Text video screen is in the form of pages which can be upto 32. At

008

one time one page is visible which is by default the zeroth page

unless we change it.

When we execute it the string is printed and the cursor is updated as well.

With direct access to video memory we had no control over the cursor. To

control cursor a different mechanism to access the hardware was needed.

Our next example uses the keyboard service to read a key. The

combination of keyboard and video services is used in almost every program

that we see and use. We will wait for four key presses; clear the screen after

the first, and draw different strings after the next key presses and exiting

after the last. We will use INT 16 service 1 for this purpose. This is a blocking

service so it does not return until a key has been pressed. We also used the

blinking attribute in this example.

101

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

Example 8.3

001

; print string and keyboard wait using BIOS services

002

[org 0x100]

003

jmp start

004

005

msg1:

'hello world', 0

006

msg2:

'hello world again', 0

007

msg3:

'hello world again and again', 0

008

009-028

;;;;; COPY LINES 005-024 FROM EXAMPLE 7.1 (clrscr) ;;;;;

029-069

;;;;; COPY LINES 050-090 FROM EXAMPLE 7.4 (printstr) ;;;;;

070-092

;;;;; COPY LINES 028-050 FROM EXAMPLE 7.4 (strlen) ;;;;;

093

094

start:

mov

ah, 0x10

;

service 10 vga attributes

095

mov

al, 03

;

subservice 3 toggle blinking

096

mov

bl, 01

;

enable blinking bit

097

int

0x10

;

call BIOS video service

098

099

mov

ah, 0

; service 0 get keystroke

100

int

0x16

; call BIOS keyboard service

101

102

call clrscr

; clear the screen

103

104

mov

ah, 0

; service 0 get keystroke

105

int

0x16

; call BIOS keyboard service

106

107

mov

ax, 0

108

push

; push x position

109

mov

ax, 0

110

push

; push y position

111

mov

ax, 1

; blue on black

112

push

; push attribute

113

mov

ax, msg1

114

push

; push offset of string

115

call

printstr

; print the string

116

117

mov

ah, 0

; service 0 get keystroke

118

int

0x16

; call BIOS keyboard service

119

120

mov

ax, 0

121

push

; push x position

123

mov

ax, 0

124

push

; push y position

125

mov

ax, 0x71

; blue on white

126

push

; push attribute

127

mov

ax, msg2

128

push

; push offset of string

129

call

printstr

; print the string

130

131

mov

ah, 0

; service 0 get keystroke

132

int

0x16

; call BIOS keyboard service

133

134

mov

ax, 0

135

push

; push x position

136

mov

ax, 0

137

push

; push y position

138

mov

ax, 0xF4

; red on white blinking

139

push

; push attribute

140

mov

ax, msg3

141

push

; push offset of string

142

call

printstr

; print the string

143

144

mov

ah, 0

; service 0 get keystroke

145

int

0x16

; call BIOS keyboard service

146

147

mov

ax, 0x4c00

; terminate program

148

int

0x21

This service has no parameters so only the service number is

099-100

initialized in AH. This is the only service so there is no sub-service

number as well. The ASCII code of the char pressed is returned in

AL after this service.

102

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

EXERCISES

1. Write a TSR that forces a program to exit when it tries to become a

TSR using INT 21h/Service 31h by converting its call into INT

21h/Service 4Ch.

2. Write a function to clear the screen whose only parameter is always

zero. The function is hooked at interrupt 80h and may also be called

directly both as a near call and as a far call. The function should

detect how it is called and return appropriately. It is provided that the

direction flag will be set before the function is called.

3. Write a function that takes three parameters, the interrupt number

(N) and the segment and offset of an interrupt handler XISR. The

arguments are pushed in the order N, XISR's offset and XISR's

segment. It is known that the first two instructions of XISR are

PUSHF and CALL 0:0 followed by the rest of the interrupt handler.

PUSHF instruction is of one byte and far call is of 5 bytes with the

first byte being the op-code, the next two containing the target offset

and the last two containing the target segment. The function should

hook XISR at interrupt N and chain it to the interrupt handler

previously hooked at N by manipulating the call 0:0 instruction

placed near the start of XISR.

4. Write a TSR that provide the circular queue services via interrupt

0x80 using the code written in Exercise 5.XX. The interrupt

procedure should call one of qcreate, qdestroy, qempty, qadd,

qremove, and uninstall based on the value in AH. The uninstall

function should restore the old interrupt 0x80 handler and remove

the TSR from memory.

103

Table of Contents:
