Comparison with Other

Processors

We emphasized that assembly language has to be learned once and every

processor can be programmed by that person. To give a flavour of two

different widely popular processors we introduce the Motorolla 68K series

and the Sun SPARC processors. The Motorolla 68K processors are very

popular in high performance embedded applications while the Sun SPARC

processors are popular in very high end enterprise servers. We will compare

them with the Intel x86 series which is known for its success in the desktop

market.

17.1. MOTOROLLA 68K PROCESSORS

Motorolla 68K processors are very similar to Intel x86 series in their

architecture and instruction set. The both are of the same era and added

various features at the same time. The instructions are very similar however

the difference in architecture evident from a programmer's point of view must

be understood.

68K processors have 16 23bit general purpose registers named from A0-A7

and D0-D7. A0-A7 can hold addresses in indirect memory accesses. These

can also be used as software stack pointers. Stack in 68K is not as rigit a

structure as it is in x86. There is a 32bit program counter (PC) that holds the

address of currently executing instruction. The 8bit condition code register

(CCR) holds the X (Extend) N (Negative) Z (Zero) V (Overflow) C (Carry) flags.

X is set to C for extended operations (addition, subtraction, or shifting).

Motrolla processors allow bit addressing, that is a specific bit in a byte or a

bit field, i.e. a number of bits can be directly accessed. This is a very useful

feature especially in control applications. Other data types include byte,

word, long word, and quad word. A special MOVE16 instruction also accepts

a 16byte block.

68K allows indirect memory access using any A register. A special memory

access allows post increment or predecrement as part of memory access.

These forms are written as (An), (An)+, and (An). Other forms allow

addressing with another regiser as index and with constant displacement.

Using one of the A registers as the stack pointer and using the post

increment and pre decrement forms of addressing, stack is implemented.

Immediates can also be given as arguments and are preceded with a hash

sign (#). Addressing is indicated with parenthesis instead of brackets.

68K has no segmentation; it however has a paged memory model. It used

the big endian format in contrast to the little endian used by the Intel

processors. It has varying instruction lengths from 1-11 words. It has a

decrementing stack just like the Intel one. The format of instructions is

"operation source, destination" which is different from the Intel order of

operands. Some instructions from various instruction groups are given

below.

Data Movement

EXG D0, D2

MOVE.B (A1), (A2)

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

MOVEA (2222).L, A4

MOVEQ #12, D7

Arithmetic

ADD D7, (A4)

CLR (A3)

(set to zero)

CMP (A2), D1

ASL, ASR, LSL, LSR, ROR, ROL, ROXL, ROXR (shift operations)

Program Control

BRA label

JMP (A3)

BSR label

(CALL)

JSR (A2)

(indirect call)

RTD #4

(RET N)

Conditional Branch

BCC

(branch if carry clear)

BLS

(branch if Lower or Same)

BLT

(branch if Less Than)

BEQ

(branch if Equal)

BVC

(branch if Overflow clear)

17.2. SUN SPARC PROCESSOR

The Sun SPARC is a very popular processing belonging to the RISC

(reduced instruction set computer) family of processors. RISC processors

originally named because of the very few rudimentary instructions they

provided, are now providing almost as many instruction as CISC (complex

instruction set computer). However some properties like a fixed instruction

size and single clock execution for most instructions are there.

SPARC stands for Scalable Processor ARChitecture. SPARC is a 64bit

processor. It byte order is user settable and even on a per program basis. So

one program may be using little endian byte order and another may be using

big endian at the same time. Data types include byte, Halfword, Word (32bit),

and Double Word (64bits) and Quadword. It has a fixed 32bit instruction

size. It has a concept of ASI (Address Space Identifier); an 8bit number that

works similar to a segment.

There are 8 global registers and 8 alternate global registers. One of them is

active at a time and accessible as g0-g7. Apart from that it has 8 in registers

(i0-i7), 8 local registers (l0-l7), and 8 out registers (o0-o7). All registers are

64bit in size. The global registers can also be called r0-r7, in registers as r8-

r15, local registers as r16-r23, and out registers as r24-r31.

SPARC introduces a concept of register window. One window is 24

registers and the active window is pointed to by a special register called

Current Window Pointer (CWP). The actual number of registers in the

processor is in hundreds not restricted by the architecture definition. Two

instruction SAVE and RESTORE move this register window forward and

backward by 16 registers. Therefore one SAVE instruction makes the out

RESTORE instruction makes the in registers out registers and restores the

old local and in registers. This way parameters passing and returning can be

totally done in registers and there is no need to save and restore registers

inside subroutines.

The register o6 is conventionally used as the stack pointer. Return address

is stored in o7 by the CALL instruction. The register g0 (r0) is always 0 so

loading 0 in a register is made easy. SPARC is a totally register based

architecture, or it is called a load-store architecture where memory access is

only allowed in data movement instruction. Rest of the operations must be

done on registers.

184

Computer Architecture & Assembly Language Programming

Course Code: CS401

CS401@vu.edu.pk

SPARC instructions have two sources and a distinct destination. This

allows more flexibility in writing programs. Some examples of instructions of

this processor follow.

Data Movement

LDSB [rn], rn

(load signed byte)

LDUW [rn], rn

(load unsigned word)

STH [rn], rn

(store half word)

Arithmetic

source1 = rn

source2 = rn or simm13

dest = rn

ADD r2, r3, r4

SUB r2, 4000, r5

SLL, SRA, SRL

(shifting)

AND, OR, XOR

(logical)

Program Control

CALL

(direct call)

JMPL

(register indirect)

RET

SAVE

RESTORE

BA label

(Branch Always)

BE label

(branch if equal)

BCC label

(branch if carry clear)

BLE label

(branch if less or equal)

BVS label

(branch if overflow set)

185
