Appendix D: Cable Sizes
Wire gauge, diameter, current capacity, and resistance at 20�C. These
values can vary from cable to cable. When in doubt, consult the
manufacturer's specifications.
AWG Gauge
Diameter (mm)
Ohms / Meter
Max Amperes
0000
11.68
0.000161
302
000
10.40
0.000203
239
00
9.27
0.000256
190
0
8.25
0.000322
150
1
7.35
0.000406
119
2
6.54
0.000513
94
3
5.83
0.000646
75
4
5.19
0.000815
60
5
4.62
0.001028
47
6
4.11
0.001296
37
7
3.67
0.001634
30
8
3.26
0.002060
24
9
2.91
0.002598
19
10
2.59
0.003276
15
