Web Design & Development CS506

Lesson 42

Expression Language

Sun Microsystems introduced the Servlet API, in the later half of 1997, positioning it as a powerful

alternative for CGI developers who were looking around for an elegant solution that was more efficient and

portable than CGI (Common Gateway Interface) programming. However, it soon became clear that the

Servlet API had its own drawbacks, with developers finding the solution difficult to implement, from the

perspective of code maintainability and extensibility. It is in some ways, this drawback that prompted the

community to explore a solution that would allow embedding Java Code in HTML Java Server Pages

(JSP) emerged as a result of this exploration.

Java as the scripting language in JSP scares many people particularly web page designers which have

enough knowledge to work with HTML and some scripting language, faced lot of difficulties in writing

some simple lines of java code. Can we simplify this problem to ease the life of web designer? Yes, by

using Expression Language (EL).

JavaServer Pages Standard Tag Library (JSTL) 1.0 introduced the concept of the EL but it was constrained

to only the JSTL tags. With JSP 2.0 you can use the EL with template text.

Note: - JSTL will be discussed in the following Handout.

Overview

The Expression Language, not a programming or scripting language, provides a way to simplify

expressions in JSP. It is a simple language that is geared towards looking up objects, their properties and

performing simple operations on them. It is inspired form both the ECMAScript and the XPath expression

language.

JSP Before and After EL

To add in motivational factor so that you start learning EL with renewed zeal and zest, a comparison is

given below that illustrates how EL affects the JSPs.

The following figure depicts the situation of a JSP before EL. We have to declare a variable before using it,

data type must be known in advance and most importantly have to use awkward syntax and many more. All

these problems are highlighted in the following figure:

Contrary to the above figure, have a look on the subsequent figure that gives you a hint how useful EL can

be?

Person Name: $ { p.name }

...

<c:if test = "$ {p.address == param.add }" >

Expression Language Nuggets

We'll discuss the following important pieces of EL. These are:

Syntax of EL

331

Web Design & Development CS506

Expressions & identifiers

Arithmetic, logical & relational operators

Automatic type conversion

Access to beans, arrays, lists & maps

Access to set of implicit objects

EL Syntax

The format of writing any EL expression is:

$ { validExpression }

The valid expressions can consist on these individuals or combination of these given below:

Literals

Operators

Variables (object references)

Implicit call to function using property name

EL Literals

The list of literals that can be used as an EL expression and their possible values are given in the tabular

format below:

Literals

Literal Values

Boolean

true or false

Integer

Similar to Java e.g. 243, -9642

Floating Point

Similar to Java e.g. 54.67, 1.83

Any string delimited by single or double quote e.g.

String

"hello" , `hello'

Null

Examples of using EL literals are: . ${ false } <%-- evaluates to false --%> . ${ 8*3 } <%-- evaluates to 24

--%>

EL Operators

The lists of operators that can be used in EL expression are given below:

Type

Operator

Arithmetic

+ -* / (div) % (mod)

Grouping

()

Logical

&&(and) ||( or) !(not)

Relational

== (eq) != (ne) < (lt) > (gt) <= (le) >= (ge)

The empty operator is a prefix operation used to determine if a

Empty

value is null or empty. It returns a Boolean value.

Conditional

332

Web Design & Development CS506

Let us look at some examples that use operators as valid expression:

${ (6*5) + 5 } <%-- evaluate to 35 --%>

${ (x >= min) && (x <= max) }

${ empty name }

Returns true if name is

Empty string (""),

Null etc.

EL Identifiers

Identifiers in the expression language represent the names of objects stored in one of the JSP scopes:

page, request, session, or application. These types of objects are referred to scoped variables throughout

this handout.

EL has 11 reserved identifiers, corresponding to 11 implicit objects. All other identifiers assumed to refer

to scoped variables.

EL implicit Objects

The Expression Language defines a set of implicit objects given below in tabular format:

Category

Implicit Object

Operator

The context for the JSP page, used to access the JSP

JSP

pageContext

implicit objects such as request, response, session,

out, servletContext etc.

A Map associating names & values of page scoped

pageScope

attributes

A Map associating names & values of request

requestScope

scoped attributes

Scopes

A Map associating names & values of session

sessionScope

scoped attributes

A Map associating names & values of application

applicationScope

scoped attributes

Maps a request parameter name to a single String

param

parameter value.

Request

Parameters

Maps a request parameter name to an array of

paramValues

values

Maps a request header name to a single header

header

Request

value.

Headers

headerValues

Maps a request header name to an array of value.

A Map storing the cookies accompanying the

request by name

A Map storing the context initialization parameters

Initialization

initParam

Parameters

of the web application by name

Examples of using implicit objects are:

333

Web Design & Development CS506

. ${ pageContext.response } -Evaluates to response implicit object of JSP

. ${ param.name } -This expression is equivalent to calling

request.getParameter("name");

${ cookie.name.value } -Returns the value of the first cookie with the given

name

-Equivalent to if (cookie.getName().equals("name"){ String val =

cookie.getValue(); }

Example Code: Summation of Two Numbers using EL

This simple example demonstrates you the capabilities of EL. index.jsp is used to collect input for two

numbers and their sum is displayed on result.jsp using EL. Let's first see the code of index.jsp

index.jsp

<html>

<body> Enter two numbers to see their sum

First Number : <input type="text" name="num1" />

<br> Second Number: <input type="text" name="num2" />

</form>

</body>

</html>result.jsp

<html>

<body>

<%-- The code to sum two numbers if we used scriptlet

String no1 = request .getParameter("num1");

String no2 = request .getParameter("num2");

int num1 = Integer.parseInt(no1);

int num2 = Integer.parseInt(no2);

Result is: <%= num1 + num2 %>

--%>

<%-- implicit Object param is used to access request

parameters By Using EL summing two numbers --

%> Result is: ${param.num1 + param.num2}

</body> </html>

EL Identifiers (cont.)

We had started our discussion on EL identifiers. Let's find out how these identifiers (variables) can be

stored/retrieved in/from different scopes.

Storing Scoped Variables

By using java code, either in pure servlet or in a scriptlet of JSP, we can store variables in a particular

scope. For example,

. Storing a variable in session scope using Java code

Assume that we have PersonInfo class and we want to store its object pin session scope then we can write

the following lines of code to accomplish that:

334

Web Design & Development CS506

HttpSession ses = request.getSession(true); PersonInfo p = new PersonInfo();

p.setName("ali"); ses.setAttribute("person" , p);

. Storing a variable in request scope using Java code

For the following lines of code, assume that request is of HttpServletRequest type. To store PersonInfo

object p in request scope, we'll write:

PersonInfo p = new PersonInfo(); p.setName("ali");

request.setAttribute("person" , p);

You must be thinking of some another method (with which you are already familiar) to store a variable in a

scope, certainly by using JSP action tags, we learned how to store a variable in any particular scope.

. Storing a variable in request scope using JSP action tag

If we want to store p of type PersonInfo in request scope by using JSP action tags, then we'll

write:

<jsp:useBean id="p" class="PersonInfo" scope="request"/>

Later, you can change the properties of object p by using action tag as well. For example

<jsp:setProperty name="p" property="name" value="ali" />

Retrieving Scoped Variables

You are already very much familiar of retrieving any stored scoped variable by using java code and JSP

action tags. Here, we'll discuss how EL retrieves scoped variables. As already mentioned, identifiers in the

valid expression represent the names of objects stored in one of the JSP scopes: page, request, session and

application.

When the expression language encounters an identifier, it searches for a scoped variable with that name

first

in page scope,

then in request scope,

then in session scope

and finally in application scope

Note: - If no such object is located in four scopes, null is returned.

For example, if we've stored PersonInfo object p in session scope by mean of any mechanism discussed

previously and have written the following EL expression to access the name property of p ${p.name}

Then EL searches for p first in page scope, then in request scope, then in session scope where it found p.

After that it calls p.getName() method. This is also shown in pictorial form below:

335

Web Design & Development CS506

336

Web Design & Development CS506

$ { "Hello" ${user.firstName} ${user.lastName} }

EL also supports automatic type conversion; as a result primitive can implicitly wrap and unwrap

into/from their corresponding java classes. For example

Most importantly, if object/identifier is null, no NullPointerException would be thrown☺. For

example. If the expression written is:

${person.name}

Assume that person is null, then no exception would be thrown and the result would also be null.

Using Expression Language

Expression Language can be used in following situations

As attribute values in standard & custom actions. E.g.

<jsp:setProperty id = "person" value = ${....} />

In template text the value of the expression is inserted into the current output. E.g.

With JSTL (discussed in the next handout)

Example Code: AddressBook using EL

So far, we have shown you implementation of AddressBook example in number of different ways. This

time EL will be incorporated in this example. AddressBook code example consists on searchperson.jsp,

showperson.jsp, ControllerServlet, PersonInfo and PersonDAO classes. Let's look on the code of each of

these components:

PersonInfo.java

The JavaBean used to represent one person record.

package vu;

import java.io.*;

public class PersonInfo implements Serializable{

private String name;

private String address;

private int phoneNum;

// no argument constructor

public PersonInfo() {

name = "";

address = "";

phoneNum = 0;

}

// setters

public void setName(String n){

name = n;

}

public void setAddress(String a){

address = a;

}

public void setPhoneNum(int pNo){

phoneNum = pNo;

}

337

Web Design & Development CS506

// getters

public String getName( ){

return name;

}

public String getAddress( ){

return address;

}

public int getPhoneNum( ){

return phoneNum;

}

PersonDAO.java

It is used to retrieve/search person records from database.

package vu; import java.util.*; import

java.sql.*; public class PersonDAO{

private Connection con;

// constructor

public PersonDAO() throws ClassNotFoundException , SQLException {

establishConnection();

}

//used to establish connection with database

private void establishConnection() throws

ClassNotFoundException , SQLException

{

// establishing connection

Class.forName("sun.jdbc.odbc.JdbcOdbcDriver");

String conUrl = "jdbc:odbc:PersonDSN";

con = DriverManager.getConnection(conUrl);

}

// used to search person records against name

public ArrayList retrievePersonList(Strin g pName)

throws SQLException {

ArrayList personList = new ArrayList();

String sql = " SELECT * FROM Person WHERE name = ?";

PreparedStatement pStmt = con.prepareStatement(sql);

pStmt.setString( 1, pName);

System.out.println("retrieve person list");

ResultSet rs = pStmt.executeQuery();

String name;

String add;

int pNo;

while ( rs.next() ) {

338

Web Design & Development CS506

name = rs.getString("name");

add = rs.getString("address");

pNo = rs.getInt("phoneNumber");

// creating a PersonInfo object

PersonInfo personBean = new PersonInfo();

personBean.setName(name); personBean.setAddress(add);

personBean.setPhoneNum(pNo);

// adding a bean to arraylist

personList.add(personBean);

} // end while

return personList;

} // end retrievePersonList

//overriding finalize method to release resources

public void finalize( ) {

try{

if(con != null){

con.close();

}

}catch(SQLException sex){

System.out.println(sex);

}

} // end finalize

} // end class

searchperson.jsp

This JSP is used to gather person's name from the user and submits this data to the ControllerServlet.

<html>

<body>

<h2> Address Book </h2>

<h3> Search Person</h3>

<FORM name ="search" action="controllerservlet" />

<TR>

</TR>

<input type="submit" value="search" /> <input type="reset"

value="clear" />

</TD>

</TR>

</TABLE>

</FORM>

</center>

</body>

</html>

ControllerServlet.java

The Controller Servlet receives request from searchperson.jsp and after fetching search results from

database, forwards the request to showperson.jsp.

package controller;

339

Web Design & Development CS506

import vu.*;

import java.io.*;

import java.net.*;

import javax.servlet.*;

import javax.servlet.http.*;

public class ControllerServlet extends HttpServlet {

} // end processRequest()

// This method only calls processRequest()

protected void doGet(HttpServletRequest request,

HttpServletResponse response) throws ServletException,

IOException {

processRequest(request, response);

}

// This method only calls processRequest()

protected void doPost(HttpServletRequest request,

HttpServletResponse response) throws ServletException,

IOException {

processRequest(request, response);

}

protected void processRequest(HttpServletRequest request,

HttpServletResponse response) throws

ServletException, IOException {

// defined below

searchPerson(request, response);

} // end ControllerServlet

protected void searchPerson(HttpServletRequest request,

HttpServletResponse response) throws

ServletException, IOException {

try {

// creating PersonDAO object

PersonDAO pDAO = new PersonDAO();

// retrieving request parameter "name" entered on showperson.jsp

String pName = request.getParameter("name");

// calling DAO method to retrieve personlist from database // against the name entered

by the user

ArrayList personList = pDAO.retrievePersonList(pName);

// storing personlist in request scope, later it is retrieved // back on showperson.jsp

request.setAttribute("plist", personList);

// forwarding request to showperson, so it renders personlist

340

Web Design & Development CS506

RequestDispatcher rd = request.getRequestDispatcher("showperson.jsp");

rd.forward(request, response);

}catch (Exception ex) {

System.out.println("Exception is" + ex);

}

} // end searchPerson

showperson.jsp

This page is used to display the search results. To do so, it reclaims the stored ArrayList (personList) from

the request scope. Furthermore, this page also uses the Expression Language to display records.

<%-- importing required packages--%>

<%@page import="java.util.*" %>

<%@page import="vu.*" %>

<html>

<body>

<h2> Address Book </h2>

<h3> Following results meet your search criteria</h3>

<TR>

<TH>Address</TH>

<TH>PhoneNum</TH>

</TR>

<%-- start of scriptlet --%>

// retrieving ArrayList from request scope

ArrayList personList =(ArrayList)request.getAttribute("plist");

PersonInfo person = null;

for(int i=0; i<personList.size(); i++) {

person = (PersonInfo)personList.get(i);

// storing PersonInfo object in request scope /* As mentioned, an object must be

stored in some scope to work with Expression Language*/

request.setAttribute("p", person);

<%-- end of scriptlet --%>

<TR>

<%-- accessing properties of stored PersonInfo object with name "p" using EL --%>

<TD> ${ p.name } </TD> <TD> ${ p.address} </TD>

<TD> ${ p.phoneNum} </TD>

<%-- The following expressions are now replaced by EL statements written above--%>

<%--<%= person.getName()%> --%> <%--<%=

person.getAddress()%> --%> <%--<%=

341

Web Design & Development CS506

person.getPhoneNum()%> --%>

</TR>

} // end for

</TABLE >

</center>

</body>

</html>

web.xml

<?xml version="1.0" encoding="UTF-8"?>

<web-app>

<servlet-name> ControllerServlet </servlet-name>

<servlet-class> controller.ControllerServlet </servlet-class>

</servlet>

<servlet-mapping>

<servlet-name> ControllerServlet </servlet-name>

<url-pattern> /controllerservlet </url-pattern>

</servlet-mapping>

</web-app>

References:

. Java A Lab Course by Umair Javed.

. Expression Language Tutorial by Sun

http://java.sun.com/j2ee/1.4/docs/tutorial/doc/JSPIntro7.html

The JSTL Expression Language by David M. Geary

http://www.informit.com/articles/article.asp?p=30946&rl=1

342

Table of Contents:
