3: The C in C++

Since C++ is based on C, you must be familiar with the

syntax of C in order to program in C++, just as you

must be reasonably fluent in algebra in order to tackle

calculus.

121

If you've never seen C before, this chapter will give you a decent

background in the style of C used in C++. If you are familiar with

the style of C described in the first edition of Kernighan & Ritchie

(often called K&R C), you will find some new and different features

in C++ as well as in Standard C. If you are familiar with Standard

C, you should skim through this chapter looking for features that

are particular to C++. Note that there are some fundamental C++

features introduced here, which are basic ideas that are akin to the

features in C or often modifications to the way that C does things.

The more sophisticated C++ features will not be introduced until

later chapters.

This chapter is a fairly fast coverage of C constructs and

introduction to some basic C++ constructs, with the understanding

that you've had some experience programming in another

language. A more gentle introduction to C is found in the CD ROM

packaged in the back of this book, titled Thinking in C: Foundations

for Java & C++ by Chuck Allison (published by MindView, Inc., and

also available at www.MindView.net). This is a seminar on a CD

ROM with the goal of taking you carefully through the

fundamentals of the C language. It focuses on the knowledge

necessary for you to be able to move on to the C++ or Java

languages rather than trying to make you an expert in all the dark

corners of C (one of the reasons for using a higher-level language

like C++ or Java is precisely so we can avoid many of these dark

corners). It also contains exercises and guided solutions. Keep in

mind that because this chapter goes beyond the Thinking in C CD,

the CD is not a replacement for this chapter, but should be used

instead as a preparation for this chapter and for the book.

Creating functions

In old (pre-Standard) C, you could call a function with any number

or type of arguments and the compiler wouldn't complain.

122

Thinking in C++

Everything seemed fine until you ran the program. You got

mysterious results (or worse, the program crashed) with no hints as

to why. The lack of help with argument passing and the enigmatic

bugs that resulted is probably one reason why C was dubbed a

"high-level assembly language." Pre-Standard C programmers just

adapted to it.

Standard C and C++ use a feature called function prototyping. With

function prototyping, you must use a description of the types of

arguments when declaring and defining a function. This

description is the "prototype." When the function is called, the

compiler uses the prototype to ensure that the proper arguments

are passed in and that the return value is treated correctly. If the

programmer makes a mistake when calling the function, the

compiler catches the mistake.

Essentially, you learned about function prototyping (without

naming it as such) in the previous chapter, since the form of

function declaration in C++ requires proper prototyping. In a

function prototype, the argument list contains the types of

arguments that must be passed to the function and (optionally for

the declaration) identifiers for the arguments. The order and type of

the arguments must match in the declaration, definition, and

function call. Here's an example of a function prototype in a

declaration:

int translate(float x, float y, float z);

You do not use the same form when declaring variables in function

prototypes as you do in ordinary variable definitions. That is, you

cannot say: float x, y, z You must indicate the type of each

argument. In a function declaration, the following form is also

acceptable:

int translate(float, float, float);

3: The C in C++

123

Since the compiler doesn't do anything but check for types when

the function is called, the identifiers are only included for clarity

when someone is reading the code.

In the function definition, names are required because the

arguments are referenced inside the function:

int translate(float x, float y, float z) {

x = y = z;

// ...

}

It turns out this rule applies only to C. In C++, an argument may be

unnamed in the argument list of the function definition. Since it is

unnamed, you cannot use it in the function body, of course.

Unnamed arguments are allowed to give the programmer a way to

"reserve space in the argument list." Whoever uses the function

must still call the function with the proper arguments. However,

the person creating the function can then use the argument in the

future without forcing modification of code that calls the function.

This option of ignoring an argument in the list is also possible if

you leave the name in, but you will get an annoying warning

message about the value being unused every time you compile the

function. The warning is eliminated if you remove the name.

C and C++ have two other ways to declare an argument list. If you

have an empty argument list, you can declare it as func( ) in C++,

which tells the compiler there are exactly zero arguments. You

should be aware that this only means an empty argument list in

C++. In C it means "an indeterminate number of arguments (which

is a "hole" in C since it disables type checking in that case). In both

C and C++, the declaration func(void);means an empty argument

list. The void keyword means "nothing" in this case (it can also

mean "no type" in the case of pointers, as you'll see later in this

chapter).

The other option for argument lists occurs when you don't know

how many arguments or what type of arguments you will have;

124

Thinking in C++

this is called a variable argument list. This "uncertain argument list"

is represented by ellipses (...). Defining a function with a variable

argument list is significantly more complicated than defining a

regular function. You can use a variable argument list for a function

that has a fixed set of arguments if (for some reason) you want to

disable the error checks of function prototyping. Because of this,

you should restrict your use of variable argument lists to C and

avoid them in C++ (in which, as you'll learn, there are much better

alternatives). Handling variable argument lists is described in the

library section of your local C guide.

Function return values

A C++ function prototype must specify the return value type of the

function (in C, if you leave off the return value type it defaults to

int). The return type specification precedes the function name. To

specify that no value is returned, use the void keyword. This will

generate an error if you try to return a value from the function.

Here are some complete function prototypes:

int f1(void); // Returns an int, takes no arguments

int f2(); // Like f1() in C++ but not in Standard C!

float f3(float, int, char, double); // Returns a float

void f4(void); // Takes no arguments, returns nothing

To return a value from a function, you use the return statement.

return exits the function back to the point right after the function

call. If return has an argument, that argument becomes the return

value of the function. If a function says that it will return a

particular type, then each return statement must return that type.

You can have more than one return statement in a function

definition:

//: C03:Return.cpp

// Use of "return"

#include <iostream>

using namespace std;

char cfunc(int i) {

3: The C in C++

125

if(i == 0)

return 'a';

if(i == 1)

return 'g';

if(i == 5)

return 'z';

return 'c';

}

int main() {

cout << "type an integer: ";

int val;

cin >> val;

cout << cfunc(val) << endl;

} ///:~

In cfunc( ) the first if that evaluates to true exits the function via

the return statement. Notice that a function declaration is not

necessary because the function definition appears before it is used

in main( ), so the compiler knows about it from that function

definition.

Using the C function library

All the functions in your local C function library are available while

you are programming in C++. You should look hard at the function

library before defining your own function there's a good chance

that someone has already solved your problem for you, and

probably given it a lot more thought and debugging.

A word of caution, though: many compilers include a lot of extra

functions that make life even easier and are tempting to use, but are

not part of the Standard C library. If you are certain you will never

want to move the application to another platform (and who is

certain of that?), go ahead use those functions and make your life

easier. If you want your application to be portable, you should

restrict yourself to Standard library functions. If you must perform

platform-specific activities, try to isolate that code in one spot so it

can be changed easily when porting to another platform. In C++,

126

Thinking in C++

platform-specific activities are often encapsulated in a class, which

is the ideal solution.

The formula for using a library function is as follows: first, find the

function in your programming reference (many programming

references will index the function by category as well as

alphabetically). The description of the function should include a

section that demonstrates the syntax of the code. The top of this

section usually has at least one #includeline, showing you the

header file containing the function prototype. Duplicate this

#includeline in your file so the function is properly declared. Now

you can call the function in the same way it appears in the syntax

section. If you make a mistake, the compiler will discover it by

comparing your function call to the function prototype in the

header and tell you about your error. The linker searches the

Standard library by default, so that's all you need to do: include the

header file and call the function.

Creating your own libraries with the librarian

You can collect your own functions together into a library. Most

programming packages come with a librarian that manages groups

of object modules. Each librarian has its own commands, but the

general idea is this: if you want to create a library, make a header

file containing the function prototypes for all the functions in your

library. Put this header file somewhere in the preprocessor's search

path, either in the local directory (so it can be found by #include

"header" or in the include directory (so it can be found by

)

#include <header> Now take all the object modules and hand

them to the librarian along with a name for the finished library

(most librarians require a common extension, such as .lib or .a).

Place the finished library where the other libraries reside so the

linker can find it. When you use your library, you will have to add

something to the command line so the linker knows to search the

library for the functions you call. You must find all the details in

your local manual, since they vary from system to system.

3: The C in C++

127

Controlling execution

This section covers the execution control statements in C++. You

must be familiar with these statements before you can read and

write C or C++ code.

C++ uses all of C's execution control statements. These include if-

else, while, do-while for, and a selection statement called switch.

C++ also allows the infamous goto, which will be avoided in this

book.

True and false

All conditional statements use the truth or falsehood of a

conditional expression to determine the execution path. An

example of a conditional expression is A == B. This uses the

conditional operator == to see if the variable A is equivalent to the

variable B. The expression produces a Boolean true or false (these

are keywords only in C++; in C an expression is "true" if it

evaluates to a nonzero value). Other conditional operators are >, <,

>=, etc. Conditional statements are covered more fully later in this

chapter.

if-else

The if-else statement can exist in two forms: with or without the

else. The two forms are:

if(expression)

statement

if(expression)

statement

else

statement

The "expression" evaluates to true or false. The "statement" means

either a simple statement terminated by a semicolon or a

128

Thinking in C++

compound statement, which is a group of simple statements

enclosed in braces. Any time the word "statement" is used, it

always implies that the statement is simple or compound. Note that

this statement can also be another if, so they can be strung together.

//: C03:Ifthen.cpp

// Demonstration of if and if-else conditionals

#include <iostream>

using namespace std;

int main() {

int i;

cout << "type a number and 'Enter'" << endl;

cin >> i;

if(i > 5)

cout << "It's greater than 5" << endl;

else

if(i < 5)

cout << "It's less than 5 " << endl;

else

cout << "It's equal to 5 " << endl;

cout << "type a number and 'Enter'" << endl;

cin >> i;

if(i < 10)

if(i > 5) // "if" is just another statement

cout << "5 < i < 10" << endl;

else

cout << "i <= 5" << endl;

else // Matches "if(i < 10)"

cout << "i >= 10" << endl;

} ///:~

It is conventional to indent the body of a control flow statement so

the reader may easily determine where it begins and ends1.

1 Note that all conventions seem to end after the agreement that some sort of

indentation take place. The feud between styles of code formatting is unending. See

Appendix A for the description of this book's coding style.

3: The C in C++

129

while

while, do-while,and for control looping. A statement repeats until

the controlling expression evaluates to false. The form of a while

loop is

while(expression)

statement

The expression is evaluated once at the beginning of the loop and

again before each further iteration of the statement.

This example stays in the body of the while loop until you type the

secret number or press control-C.

//: C03:Guess.cpp

// Guess a number (demonstrates "while")

#include <iostream>

using namespace std;

int main() {

int secret = 15;

int guess = 0;

// "!=" is the "not-equal" conditional:

while(guess != secret) { // Compound statement

cout << "guess the number: ";

cin >> guess;

}

cout << "You guessed it!" << endl;

} ///:~

The while's conditional expression is not restricted to a simple test

as in the example above; it can be as complicated as you like as long

as it produces a true or false result. You will even see code where

the loop has no body, just a bare semicolon:

while(/* Do a lot here */)

;

In these cases, the programmer has written the conditional

expression not only to perform the test but also to do the work.

130

Thinking in C++

do-while

The form of do-whileis

statement

while(expression);

The do-whileis different from the while because the statement

always executes at least once, even if the expression evaluates to

false the first time. In a regular while, if the conditional is false the

first time the statement never executes.

If a do-whileis used in Guess.cpp the variable guess does not

need an initial dummy value, since it is initialized by the cin

statement before it is tested:

//: C03:Guess2.cpp

// The guess program using do-while

#include <iostream>

using namespace std;

int main() {

int secret = 15;

int guess; // No initialization needed here

do {

cout << "guess the number: ";

cin >> guess; // Initialization happens

}

while(guess != secret);

cout << "You got it!" << endl;

} ///:~

For some reason, most programmers tend to avoid do-whileand

just work with while.

for

A for loop performs initialization before the first iteration. Then it

performs conditional testing and, at the end of each iteration, some

form of "stepping." The form of the for loop is:

for(initialization; conditional; step)

3: The C in C++

131

statement

Any of the expressions initialization, conditional, or step may be

empty. The initialization code executes once at the very beginning.

The conditional is tested before each iteration (if it evaluates to false

at the beginning, the statement never executes). At the end of each

loop, the step executes.

for loops are usually used for "counting" tasks:

//: C03:Charlist.cpp

// Display all the ASCII characters

// Demonstrates "for"

#include <iostream>

using namespace std;

int main() {

for(int i = 0; i < 128; i = i + 1)

if (i != 26) // ANSI Terminal Clear screen

cout << " value: " << i

<< " character: "

<< char(i) // Type conversion

<< endl;

} ///:~

You may notice that the variable i is defined at the point where it is

used, instead of at the beginning of the block denoted by the open

curly brace `{'. This is in contrast to traditional procedural

languages (including C), which require that all variables be defined

at the beginning of the block. This will be discussed later in this

chapter.

The break and continue keywords

Inside the body of any of the looping constructs while, do-while,or

for, you can control the flow of the loop using break and continue

break quits the loop without executing the rest of the statements in

the loop. continuestops the execution of the current iteration and

goes back to the beginning of the loop to begin a new iteration.

132

Thinking in C++

As an example of break and continue this program is a very

simple menu system:

//: C03:Menu.cpp

// Simple menu program demonstrating

// the use of "break" and "continue"

#include <iostream>

using namespace std;

int main() {

char c; // To hold response

while(true) {

cout << "MAIN MENU:" << endl;

cout << "l: left, r: right, q: quit -> ";

cin >> c;

if(c == 'q')

break; // Out of "while(1)"

if(c == 'l') {

cout << "LEFT MENU:" << endl;

cout << "select a or b: ";

cin >> c;

if(c == 'a') {

cout << "you chose 'a'" << endl;

continue; // Back to main menu

}

if(c == 'b') {

cout << "you chose 'b'" << endl;

continue; // Back to main menu

}

else {

cout << "you didn't choose a or b!"

<< endl;

continue; // Back to main menu

}

if(c == 'r') {

cout << "RIGHT MENU:" << endl;

cout << "select c or d: ";

cin >> c;

if(c == 'c') {

cout << "you chose 'c'" << endl;

continue; // Back to main menu

}

if(c == 'd') {

3: The C in C++

133

cout << "you chose 'd'" << endl;

continue; // Back to main menu

}

else {

cout << "you didn't choose c or d!"

<< endl;

continue; // Back to main menu

}

cout << "you must type l or r or q!" << endl;

}

cout << "quitting menu..." << endl;

} ///:~

If the user selects `q' in the main menu, the break keyword is used

to quit, otherwise the program just continues to execute

indefinitely. After each of the sub-menu selections, the continue

keyword is used to pop back up to the beginning of the while loop.

The while(true)statement is the equivalent of saying "do this loop

forever." The break statement allows you to break out of this

infinite while loop when the user types a `q.'

switch

A switch statement selects from among pieces of code based on the

value of an integral expression. Its form is:

switch(selector) {

case integral-value1

break;

statement;

case integral-value2

break;

statement;

case integral-value3

break;

statement;

case integral-value4

break;

statement;

case integral-value5

break;

statement;

(...)

default: statement;

}

Selector is an expression that produces an integral value. The switch

compares the result of selector to each integral value. If it finds a

match, the corresponding statement (simple or compound)

executes. If no match occurs, the default statement executes.

134

Thinking in C++

You will notice in the definition above that each case ends with a

break, which causes execution to jump to the end of the switch

body (the closing brace that completes the switch). This is the

conventional way to build a switch statement, but the break is

optional. If it is missing, your case "drops through" to the one after

it. That is, the code for the following case statements execute until a

break is encountered. Although you don't usually want this kind of

behavior, it can be useful to an experienced programmer.

The switch statement is a clean way to implement multi-way

selection (i.e., selecting from among a number of different

execution paths), but it requires a selector that evaluates to an

integral value at compile-time. If you want to use, for example, a

string object as a selector, it won't work in a switch statement. For

a string selector, you must instead use a series of if statements and

compare the string inside the conditional.

The menu example shown above provides a particularly nice

example of a switch:

//: C03:Menu2.cpp

// A menu using a switch statement

#include <iostream>

using namespace std;

int main() {

bool quit = false; // Flag for quitting

while(quit == false) {

cout << "Select a, b, c or q to quit: ";

char response;

cin >> response;

switch(response) {

case 'a' : cout << "you chose 'a'" << endl;

break;

case 'b' : cout << "you chose 'b'" << endl;

break;

case 'c' : cout << "you chose 'c'" << endl;

break;

case 'q' : cout << "quitting menu" << endl;

quit = true;

3: The C in C++

135

break;

default

: cout << "Please use a,b,c or q!"

<< endl;

}

} ///:~

The quit flag is a bool, short for "Boolean," which is a type you'll

find only in C++. It can have only the keyword values true or false.

Selecting `q' sets the quit flag to true. The next time the selector is

evaluated, quit == falsereturns false so the body of the while does

not execute.

Using and misusing goto

The goto keyword is supported in C++, since it exists in C. Using

goto is often dismissed as poor programming style, and most of the

time it is. Anytime you use goto, look at your code and see if

there's another way to do it. On rare occasions, you may discover

goto can solve a problem that can't be solved otherwise, but still,

consider it carefully. Here's an example that might make a

plausible candidate:

//: C03:gotoKeyword.cpp

// The infamous goto is supported in C++

#include <iostream>

using namespace std;

int main() {

long val = 0;

for(int i = 1; i < 1000; i++) {

for(int j = 1; j < 100; j += 10) {

val = i * j;

if(val > 47000)

goto bottom;

// Break would only go to the outer 'for'

}

bottom: // A label

cout << val << endl;

} ///:~

136

Thinking in C++

The alternative would be to set a Boolean that is tested in the outer

for loop, and then do a break from the inner for loop. However, if

you have several levels of for or while this could get awkward.

Recursion

Recursion is an interesting and sometimes useful programming

technique whereby you call the function that you're in. Of course, if

this is all you do, you'll keep calling the function you're in until

you run out of memory, so there must be some way to "bottom

out" the recursive call. In the following example, this "bottoming

out" is accomplished by simply saying that the recursion will go

only until the cat exceeds `Z':2

//: C03:CatsInHats.cpp

// Simple demonstration of recursion

#include <iostream>

using namespace std;

void removeHat(char cat) {

for(char c = 'A'; c < cat; c++)

cout << " ";

if(cat <= 'Z') {

cout << "cat " << cat << endl;

removeHat(cat + 1); // Recursive call

} else

cout << "VOOM!!!" << endl;

}

int main() {

removeHat('A');

} ///:~

In removeHat( ) you can see that as long as cat is less than `Z',

removeHat( )will be called from within removeHat( ) thus

effecting the recursion. Each time removeHat( )is called, its

2 Thanks to Kris C. Matson for suggesting this exercise topic.

3: The C in C++

137

argument is one greater than the current cat so the argument keeps

increasing.

Recursion is often used when evaluating some sort of arbitrarily

complex problem, since you aren't restricted to a particular "size"

for the solution the function can just keep recursing until it's

reached the end of the problem.

Introduction to operators

You can think of operators as a special type of function (you'll learn

that C++ operator overloading treats operators precisely that way).

An operator takes one or more arguments and produces a new

value. The arguments are in a different form than ordinary function

calls, but the effect is the same.

From your previous programming experience, you should be

reasonably comfortable with the operators that have been used so

far. The concepts of addition (+), subtraction and unary minus (-),

multiplication (*), division (/), and assignment(=) all have

essentially the same meaning in any programming language. The

full set of operators is enumerated later in this chapter.

Precedence

Operator precedence defines the order in which an expression

evaluates when several different operators are present. C and C++

have specific rules to determine the order of evaluation. The easiest

to remember is that multiplication and division happen before

addition and subtraction. After that, if an expression isn't

transparent to you it probably won't be for anyone reading the

code, so you should use parentheses to make the order of

evaluation explicit. For example:

A = X + Y - 2/2 + Z;

138

Thinking in C++

has a very different meaning from the same statement with a

particular grouping of parentheses:

A = X + (Y - 2)/(2 + Z);

(Try evaluating the result with X = 1, Y = 2, and Z = 3.)

Auto increment and decrement

C, and therefore C++, is full of shortcuts. Shortcuts can make code

much easier to type, and sometimes much harder to read. Perhaps

the C language designers thought it would be easier to understand

a tricky piece of code if your eyes didn't have to scan as large an

area of print.

One of the nicer shortcuts is the auto-increment and auto-

decrement operators. You often use these to change loop variables,

which control the number of times a loop executes.

The auto-decrement operator is `--' and means "decrease by one

unit." The auto-increment operator is `++' and means "increase by

one unit." If A is an int, for example, the expression ++A is

equivalent to (A = A + 1 Auto-increment and auto-decrement

operators produce the value of the variable as a result. If the

operator appears before the variable, (i.e., ++A), the operation is

first performed and the resulting value is produced. If the operator

appears after the variable (i.e. A++), the current value is produced,

and then the operation is performed. For example:

//: C03:AutoIncrement.cpp

// Shows use of auto-increment

// and auto-decrement operators.

#include <iostream>

using namespace std;

int main() {

int i = 0;

int j = 0;

cout << ++i << endl; // Pre-increment

cout << j++ << endl; // Post-increment

3: The C in C++

139

cout << --i << endl; // Pre-decrement

cout << j-- << endl; // Post decrement

} ///:~

If you've been wondering about the name "C++," now you

understand. It implies "one step beyond C."

Introduction to data types

Data types define the way you use storage (memory) in the

programs you write. By specifying a data type, you tell the

compiler how to create a particular piece of storage, and also how

to manipulate that storage.

Data types can be built-in or abstract. A built-in data type is one

that the compiler intrinsically understands, one that is wired

directly into the compiler. The types of built-in data are almost

identical in C and C++. In contrast, a user-defined data type is one

that you or another programmer create as a class. These are

commonly referred to as abstract data types. The compiler knows

how to handle built-in types when it starts up; it "learns" how to

handle abstract data types by reading header files containing class

declarations (you'll learn about this in later chapters).

Basic built-in types

The Standard C specification for built-in types (which C++ inherits)

doesn't say how many bits each of the built-in types must contain.

Instead, it stipulates the minimum and maximum values that the

built-in type must be able to hold. When a machine is based on

binary, this maximum value can be directly translated into a

minimum number of bits necessary to hold that value. However, if

a machine uses, for example, binary-coded decimal (BCD) to

represent numbers, then the amount of space in the machine

required to hold the maximum numbers for each data type will be

different. The minimum and maximum values that can be stored in

the various data types are defined in the system header files

140

Thinking in C++

limits.hand float.h (in C++ you will generally #include <climits>

and <cfloat>instead).

C and C++ have four basic built-in data types, described here for

binary-based machines. A char is for character storage and uses a

minimum of 8 bits (one byte) of storage, although it may be larger.

An int stores an integral number and uses a minimum of two bytes

of storage. The float and double types store floating-point

numbers, usually in IEEE floating-point format. float is for single-

precision floating point and double is for double-precision floating

point.

As mentioned previously, you can define variables anywhere in a

scope, and you can define and initialize them at the same time.

Here's how to define variables using the four basic data types:

//: C03:Basic.cpp

// Defining the four basic data

// types in C and C++

int main() {

// Definition without initialization:

char protein;

int carbohydrates;

float fiber;

double fat;

// Simultaneous definition & initialization:

char pizza = 'A', pop = 'Z';

int dongdings = 100, twinkles = 150,

heehos = 200;

float chocolate = 3.14159;

// Exponential notation:

double fudge_ripple = 6e-4;

} ///:~

The first part of the program defines variables of the four basic data

types without initializing them. If you don't initialize a variable, the

Standard says that its contents are undefined (usually, this means

they contain garbage). The second part of the program defines and

initializes variables at the same time (it's always best, if possible, to

3: The C in C++

141

provide an initialization value at the point of definition). Notice the

use of exponential notation in the constant 6e-4, meaning "6 times

10 to the minus fourth power."

bool, true, & false

Before bool became part of Standard C++, everyone tended to use

different techniques in order to produce Boolean-like behavior.

These produced portability problems and could introduce subtle

errors.

The Standard C++ bool type can have two states expressed by the

built-in constants true (which converts to an integral one) and false

(which converts to an integral zero). All three names are keywords.

In addition, some language elements have been adapted:

Element

Usage with bool

&& || !

Take bool arguments and

produce bool results.

< > <=

Produce bool results.

>= == !=

if, for,

Conditional expressions

while, do

convert to bool values.

First operand converts to bool

value.

Because there's a lot of existing code that uses an int to represent a

flag, the compiler will implicitly convert from an int to a bool

(nonzero values will produce true while zero values produce false).

Ideally, the compiler will give you a warning as a suggestion to

correct the situation.

An idiom that falls under "poor programming style" is the use of

++ to set a flag to true. This is still allowed, but deprecated, which

means that at some time in the future it will be made illegal. The

142

Thinking in C++

problem is that you're making an implicit type conversion from

bool to int, incrementing the value (perhaps beyond the range of

the normal bool values of zero and one), and then implicitly

converting it back again.

Pointers (which will be introduced later in this chapter) will also be

automatically converted to bool when necessary.

Specifiers

Specifiers modify the meanings of the basic built-in types and

expand them to a much larger set. There are four specifiers: long,

short, signed, and unsigned

long and short modify the maximum and minimum values that a

data type will hold. A plain int must be at least the size of a short.

The size hierarchy for integral types is: short int, int, long int. All

the sizes could conceivably be the same, as long as they satisfy the

minimum/maximum value requirements. On a machine with a 64-

bit word, for instance, all the data types might be 64 bits.

The size hierarchy for floating point numbers is: float, double, and

long double. "long float" is not a legal type. There are no short

floating-point numbers.

The signed and unsignedspecifiers tell the compiler how to use

the sign bit with integral types and characters (floating-point

numbers always contain a sign). An unsignednumber does not

keep track of the sign and thus has an extra bit available, so it can

store positive numbers twice as large as the positive numbers that

can be stored in a signed number. signed is the default and is only

necessary with char; char may or may not default to signed. By

specifying signed char, you force the sign bit to be used.

The following example shows the size of the data types in bytes by

using the sizeof operator, introduced later in this chapter:

//: C03:Specify.cpp

3: The C in C++

143

// Demonstrates the use of specifiers

#include <iostream>

using namespace std;

int main() {

char c;

unsigned char cu;

int i;

unsigned int iu;

short int is;

short iis; // Same as short int

unsigned short int isu;

unsigned short iisu;

long int il;

long iil; // Same as long int

unsigned long int ilu;

unsigned long iilu;

float f;

double d;

long double ld;

cout

<< "\n char= " << sizeof(c)

<< "\n unsigned char = " << sizeof(cu)

<< "\n int = " << sizeof(i)

<< "\n unsigned int = " << sizeof(iu)

<< "\n short = " << sizeof(is)

<< "\n unsigned short = " << sizeof(isu)

<< "\n long = " << sizeof(il)

<< "\n unsigned long = " << sizeof(ilu)

<< "\n float = " << sizeof(f)

<< "\n double = " << sizeof(d)

<< "\n long double = " << sizeof(ld)

<< endl;

} ///:~

Be aware that the results you get by running this program will

probably be different from one machine/operating

system/compiler to the next, since (as mentioned previously) the

only thing that must be consistent is that each different type hold

the minimum and maximum values specified in the Standard.

When you are modifying an int with short or long, the keyword int

is optional, as shown above.

144

Thinking in C++

Introduction to pointers

Whenever you run a program, it is first loaded (typically from disk)

into the computer's memory. Thus, all elements of your program

are located somewhere in memory. Memory is typically laid out as

a sequential series of memory locations; we usually refer to these

locations as eight-bit bytes but actually the size of each space

depends on the architecture of the particular machine and is

usually called that machine's word size. Each space can be uniquely

distinguished from all other spaces by its address. For the purposes

of this discussion, we'll just say that all machines use bytes that

have sequential addresses starting at zero and going up to however

much memory you have in your computer.

Since your program lives in memory while it's being run, every

element of your program has an address. Suppose we start with a

simple program:

//: C03:YourPets1.cpp

#include <iostream>

using namespace std;

int dog, cat, bird, fish;

void f(int pet) {

cout << "pet id number: " << pet << endl;

}

int main() {

int i, j, k;

} ///:~

Each of the elements in this program has a location in storage when

the program is running. Even the function occupies storage. As

you'll see, it turns out that what an element is and the way you

define it usually determines the area of memory where that

element is placed.

There is an operator in C and C++ that will tell you the address of

an element. This is the `&' operator. All you do is precede the

3: The C in C++

145

identifier name with `&' and it will produce the address of that

identifier. YourPets1.cppcan be modified to print out the addresses

of all its elements, like this:

//: C03:YourPets2.cpp

#include <iostream>

using namespace std;

int dog, cat, bird, fish;

void f(int pet) {

cout << "pet id number: " << pet << endl;

}

int main() {

int i, j, k;

cout << "f(): " << (long)&f << endl;

cout << "dog: " << (long)&dog << endl;

cout << "cat: " << (long)&cat << endl;

cout << "bird: " << (long)&bird << endl;

cout << "fish: " << (long)&fish << endl;

cout << "i: " << (long)&i << endl;

cout << "j: " << (long)&j << endl;

cout << "k: " << (long)&k << endl;

} ///:~

The (long) is a cast. It says "Don't treat this as if it's normal type,

instead treat it as a long." The cast isn't essential, but if it wasn't

there, the addresses would have been printed out in hexadecimal

instead, so casting to a long makes things a little more readable.

The results of this program will vary depending on your computer,

OS, and all sorts of other factors, but it will always give you some

interesting insights. For a single run on my computer, the results

looked like this:

f(): 4198736

dog: 4323632

cat: 4323636

bird: 4323640

fish: 4323644

i: 6684160

146

Thinking in C++

j: 6684156

k: 6684152

You can see how the variables that are defined inside main( ) are in

a different area than the variables defined outside of main( ); you'll

understand why as you learn more about the language. Also, f( )

appears to be in its own area; code is typically separated from data

in memory.

Another interesting thing to note is that variables defined one right

after the other appear to be placed contiguously in memory. They

are separated by the number of bytes that are required by their data

type. Here, the only data type used is int, and cat is four bytes

away from dog, bird is four bytes away from cat, etc. So it would

appear that, on this machine, an int is four bytes long.

Other than this interesting experiment showing how memory is

mapped out, what can you do with an address? The most

important thing you can do is store it inside another variable for

later use. C and C++ have a special type of variable that holds an

address. This variable is called a pointer.

The operator that defines a pointer is the same as the one used for

multiplication: `*'. The compiler knows that it isn't multiplication

because of the context in which it is used, as you will see.

When you define a pointer, you must specify the type of variable it

points to. You start out by giving the type name, then instead of

immediately giving an identifier for the variable, you say "Wait, it's

a pointer" by inserting a star between the type and the identifier. So

a pointer to an int looks like this:

int* ip; // ip points to an int variable

The association of the `*' with the type looks sensible and reads

easily, but it can actually be a bit deceiving. Your inclination might

be to say "intpointer" as if it is a single discrete type. However,

with an int or other basic data type, it's possible to say:

3: The C in C++

147

int a, b, c;

whereas with a pointer, you'd like to say:

int* ipa, ipb, ipc;

C syntax (and by inheritance, C++ syntax) does not allow such

sensible expressions. In the definitions above, only ipa is a pointer,

but ipb and ipc are ordinary ints (you can say that "* binds more

tightly to the identifier"). Consequently, the best results can be

achieved by using only one definition per line; you still get the

sensible syntax without the confusion:

int* ipa;

int* ipb;

int* ipc;

Since a general guideline for C++ programming is that you should

always initialize a variable at the point of definition, this form

actually works better. For example, the variables above are not

initialized to any particular value; they hold garbage. It's much

better to say something like:

int a = 47;

int* ipa = &a;

Now both a and ipa have been initialized, and ipa holds the

address of a.

Once you have an initialized pointer, the most basic thing you can

do with it is to use it to modify the value it points to. To access a

variable through a pointer, you dereference the pointer using the

same operator that you used to define it, like this:

*ipa = 100;

Now a contains the value 100 instead of 47.

These are the basics of pointers: you can hold an address, and you

can use that address to modify the original variable. But the

148

Thinking in C++

question still remains: why do you want to modify one variable

using another variable as a proxy?

For this introductory view of pointers, we can put the answer into

two broad categories:

To change "outside objects" from within a function. This is

perhaps the most basic use of pointers, and it will be

examined here.

To achieve many other clever programming techniques,

which you'll learn about in portions of the rest of the book.

Modifying the outside object

Ordinarily, when you pass an argument to a function, a copy of

that argument is made inside the function. This is referred to as

pass-by-value. You can see the effect of pass-by-value in the

following program:

//: C03:PassByValue.cpp

#include <iostream>

using namespace std;

void f(int a) {

cout << "a = " << a << endl;

a = 5;

cout << "a = " << a << endl;

}

int main() {

int x = 47;

cout << "x = " << x << endl;

f(x);

cout << "x = " << x << endl;

} ///:~

In f( ), a is a local variable, so it exists only for the duration of the

function call to f( ). Because it's a function argument, the value of a

is initialized by the arguments that are passed when the function is

3: The C in C++

149

called; in main( ) the argument is x, which has a value of 47, so this

value is copied into a when f( ) is called.

When you run this program you'll see:

Initially, of course, x is 47. When f( ) is called, temporary space is

created to hold the variable a for the duration of the function call,

and a is initialized by copying the value of x, which is verified by

printing it out. Of course, you can change the value of a and show

that it is changed. But when f( ) is completed, the temporary space

that was created for a disappears, and we see that the only

connection that ever existed between a and x happened when the

value of x was copied into a.

When you're inside f( ), x is the outside object (my terminology), and

changing the local variable does not affect the outside object,

naturally enough, since they are two separate locations in storage.

But what if you do want to modify the outside object? This is where

pointers come in handy. In a sense, a pointer is an alias for another

variable. So if we pass a pointer into a function instead of an

ordinary value, we are actually passing an alias to the outside

object, enabling the function to modify that outside object, like this:

//: C03:PassAddress.cpp

#include <iostream>

using namespace std;

void f(int* p) {

cout << "p = " << p << endl;

cout << "*p = " << *p << endl;

*p = 5;

cout << "p = " << p << endl;

}

int main() {

150

Thinking in C++

int x =

47;

cout <<

"x = " << x << endl;

cout <<

"&x = " << &x << endl;

f(&x);

cout <<

"x = " << x << endl;

} ///:~

Now f( ) takes a pointer as an argument and dereferences the

pointer during assignment, and this causes the outside object x to

be modified. The output is:

x = 47

&x = 0065FE00

p = 0065FE00

*p = 47

p = 0065FE00

x=5

Notice that the value contained in p is the same as the address of x

the pointer p does indeed point to x. If that isn't convincing

enough, when p is dereferenced to assign the value 5, we see that

the value of x is now changed to 5 as well.

Thus, passing a pointer into a function will allow that function to

modify the outside object. You'll see plenty of other uses for

pointers later, but this is arguably the most basic and possibly the

most common use.

Introduction to C++ references

Pointers work roughly the same in C and in C++, but C++ adds an

additional way to pass an address into a function. This is pass-by-

reference and it exists in several other programming languages so it

was not a C++ invention.

Your initial perception of references may be that they are

unnecessary, that you could write all your programs without

references. In general, this is true, with the exception of a few

important places that you'll learn about later in the book. You'll

also learn more about references later, but the basic idea is the same

3: The C in C++

151

as the demonstration of pointer use above: you can pass the

address of an argument using a reference. The difference between

references and pointers is that calling a function that takes

references is cleaner, syntactically, than calling a function that takes

pointers (and it is exactly this syntactic difference that makes

references essential in certain situations). If PassAddress.cppis

modified to use references, you can see the difference in the

function call in main( ):

//: C03:PassReference.cpp

#include <iostream>

using namespace std;

void f(int& r) {

cout << "r = " << r << endl;

cout << "&r = " << &r << endl;

r = 5;

cout << "r = " << r << endl;

}

int main() {

int x = 47;

cout << "x = " << x << endl;

cout << "&x = " << &x << endl;

f(x); // Looks like pass-by-value,

// is actually pass by reference

cout << "x = " << x << endl;

} ///:~

In f( )'s argument list, instead of saying int* to pass a pointer, you

say int& to pass a reference. Inside f( ), if you just say `r' (which

would produce the address if r were a pointer) you get the value in

the variable that r references. If you assign to r, you actually assign to

the variable that r references. In fact, the only way to get the

address that's held inside r is with the `&' operator.

In main( ), you can see the key effect of references in the syntax of

the call to f( ), which is just f(x). Even though this looks like an

ordinary pass-by-value, the effect of the reference is that it actually

152

Thinking in C++

takes the address and passes it in, rather than making a copy of the

value. The output is:

x = 47

&x = 0065FE00

r = 47

&r = 0065FE00

r=5

x=5

So you can see that pass-by-reference allows a function to modify

the outside object, just like passing a pointer does (you can also

observe that the reference obscures the fact that an address is being

passed; this will be examined later in the book). Thus, for this

simple introduction you can assume that references are just a

syntactically different way (sometimes referred to as "syntactic

sugar") to accomplish the same thing that pointers do: allow

functions to change outside objects.

Pointers and references as modifiers

So far, you've seen the basic data types char, int, float, and double,

along with the specifiers signed, unsigned short, and long, which

can be used with the basic data types in almost any combination.

Now we've added pointers and references that are orthogonal to

the basic data types and specifiers, so the possible combinations

have just tripled:

//: C03:AllDefinitions.cpp

// All possible combinations of basic data types,

// specifiers, pointers and references

#include <iostream>

using namespace std;

void f1(char c, int i, float f, double d);

void f2(short int si, long int li, long double ld);

void f3(unsigned char uc, unsigned int ui,

unsigned short int usi, unsigned long int uli);

void f4(char* cp, int* ip, float* fp, double* dp);

void f5(short int* sip, long int* lip,

long double* ldp);

3: The C in C++

153

void f6(unsigned char* ucp, unsigned int* uip,

unsigned short int* usip,

unsigned long int* ulip);

void f7(char& cr, int& ir, float& fr, double& dr);

void f8(short int& sir, long int& lir,

long double& ldr);

void f9(unsigned char& ucr, unsigned int& uir,

unsigned short int& usir,

unsigned long int& ulir);

int main() {} ///:~

Pointers and references also work when passing objects into and

out of functions; you'll learn about this in a later chapter.

There's one other type that works with pointers: void. If you state

that a pointer is a void*, it means that any type of address at all can

be assigned to that pointer (whereas if you have an int*, you can

assign only the address of an int variable to that pointer). For

example:

//: C03:VoidPointer.cpp

int main() {

void* vp;

char c;

int i;

float f;

double d;

// The address of ANY type can be

// assigned to a void pointer:

vp = &c;

vp = &i;

vp = &f;

vp = &d;

} ///:~

Once you assign to a void* you lose any information about what

type it is. This means that before you can use the pointer, you must

cast it to the correct type:

//: C03:CastFromVoidPointer.cpp

int main() {

int i = 99;

154

Thinking in C++

void* vp = &i;

// Can't dereference a void pointer:

// *vp = 3; // Compile-time error

// Must cast back to int before dereferencing:

*((int*)vp) = 3;

} ///:~

The cast (int*)vptakes the void* and tells the compiler to treat it as

an int*, and thus it can be successfully dereferenced. You might

observe that this syntax is ugly, and it is, but it's worse than that

the void* introduces a hole in the language's type system. That is, it

allows, or even promotes, the treatment of one type as another

type. In the example above, I treat an int as an int by casting vp to

an int*, but there's nothing that says I can't cast it to a char* or

double*, which would modify a different amount of storage that

had been allocated for the int, possibly crashing the program. In

general, void pointers should be avoided, and used only in rare

special cases, the likes of which you won't be ready to consider

until significantly later in the book.

You cannot have a void reference, for reasons that will be explained

in Chapter 11.

Scoping

Scoping rules tell you where a variable is valid, where it is created,

and where it gets destroyed (i.e., goes out of scope). The scope of a

variable extends from the point where it is defined to the first

closing brace that matches the closest opening brace before the

variable was defined. That is, a scope is defined by its "nearest" set

of braces. To illustrate:

//: C03:Scope.cpp

// How variables are scoped

int main() {

int scp1;

// scp1 visible here

{

// scp1 still visible here

3: The C in C++

155

//.....

int scp2;

// scp2 visible here

//.....

{

// scp1 & scp2 still visible here

//..

int scp3;

// scp1, scp2 & scp3 visible here

// ...

} // <-- scp3 destroyed here

// scp3 not available here

// scp1 & scp2 still visible here

// ...

} // <-- scp2 destroyed here

// scp3 & scp2 not available here

// scp1 still visible here

//..

} // <-- scp1 destroyed here

///:~

The example above shows when variables are visible and when

they are unavailable (that is, when they go out of scope). A variable

can be used only when inside its scope. Scopes can be nested,

indicated by matched pairs of braces inside other matched pairs of

braces. Nesting means that you can access a variable in a scope that

encloses the scope you are in. In the example above, the variable

scp1 is available inside all of the other scopes, while scp3 is

available only in the innermost scope.

Defining variables on the fly

As noted earlier in this chapter, there is a significant difference

between C and C++ when defining variables. Both languages

require that variables be defined before they are used, but C (and

many other traditional procedural languages) forces you to define

all the variables at the beginning of a scope, so that when the

compiler creates a block it can allocate space for those variables.

While reading C code, a block of variable definitions is usually the

first thing you see when entering a scope. Declaring all variables at

156

Thinking in C++

the beginning of the block requires the programmer to write in a

particular way because of the implementation details of the

language. Most people don't know all the variables they are going

to use before they write the code, so they must keep jumping back

to the beginning of the block to insert new variables, which is

awkward and causes errors. These variable definitions don't

usually mean much to the reader, and they actually tend to be

confusing because they appear apart from the context in which they

are used.

C++ (not C) allows you to define variables anywhere in a scope, so

you can define a variable right before you use it. In addition, you

can initialize the variable at the point you define it, which prevents

a certain class of errors. Defining variables this way makes the code

much easier to write and reduces the errors you get from being

forced to jump back and forth within a scope. It makes the code

easier to understand because you see a variable defined in the

context of its use. This is especially important when you are

defining and initializing a variable at the same time you can see

the meaning of the initialization value by the way the variable is

used.

You can also define variables inside the control expressions of for

loops and while loops, inside the conditional of an if statement,

and inside the selector statement of a switch. Here's an example

showing on-the-fly variable definitions:

//: C03:OnTheFly.cpp

// On-the-fly variable definitions

#include <iostream>

using namespace std;

int main() {

//..

{ // Begin a new scope

int q = 0; // C requires definitions here

//..

// Define at point of use:

for(int i = 0; i < 100; i++) {

3: The C in C++

157

q++; // q comes from a larger scope

// Definition at the end of the scope:

int p = 12;

}

int p = 1; // A different p

} // End scope containing q & outer p

cout << "Type characters:" << endl;

while(char c = cin.get() != 'q') {

cout << c << " wasn't it" << endl;

if(char x = c == 'a' || c == 'b')

cout << "You typed a or b" << endl;

else

cout << "You typed " << x << endl;

}

cout << "Type A, B, or C" << endl;

switch(int i = cin.get()) {

case 'A': cout << "Snap" << endl; break;

case 'B': cout << "Crackle" << endl; break;

case 'C': cout << "Pop" << endl; break;

default: cout << "Not A, B or C!" << endl;

}

} ///:~

In the innermost scope, p is defined right before the scope ends, so

it is really a useless gesture (but it shows you can define a variable

anywhere). The p in the outer scope is in the same situation.

The definition of i in the control expression of the for loop is an

example of being able to define a variable exactly at the point you

need it (you can do this only in C++). The scope of i is the scope of

the expression controlled by the for loop, so you can turn around

and re-use i in the next for loop. This is a convenient and

commonly-used idiom in C++; i is the classic name for a loop

counter and you don't have to keep inventing new names.

Although the example also shows variables defined within while,

if, and switch statements, this kind of definition is much less

common than those in for expressions, possibly because the syntax

is so constrained. For example, you cannot have any parentheses.

That is, you cannot say:

158

Thinking in C++

while((char c = cin.get()) != 'q')

The addition of the extra parentheses would seem like an innocent

and useful thing to do, and because you cannot use them, the

results are not what you might like. The problem occurs because

`!=' has a higher precedence than `=', so the char c ends up

containing a bool converted to char. When that's printed, on many

terminals you'll see a smiley-face character.

In general, you can consider the ability to define variables within

while, if, and switch statements as being there for completeness,

but the only place you're likely to use this kind of variable

definition is in a for loop (where you'll use it quite often).

Specifying storage allocation

When creating a variable, you have a number of options to specify

the lifetime of the variable, how the storage is allocated for that

variable, and how the variable is treated by the compiler.

Global variables

Global variables are defined outside all function bodies and are

available to all parts of the program (even code in other files).

Global variables are unaffected by scopes and are always available

(i.e., the lifetime of a global variable lasts until the program ends). If

the existence of a global variable in one file is declared using the

extern keyword in another file, the data is available for use by the

second file. Here's an example of the use of global variables:

//: C03:Global.cpp

//{L} Global2

// Demonstration of global variables

#include <iostream>

using namespace std;

int globe;

void func();

int main() {

3: The C in C++

159

globe =

12;

cout <<

globe << endl;

func();

// Modifies globe

cout <<

globe << endl;

} ///:~

Here's a file that accesses globe as an extern:

//: C03:Global2.cpp {O}

// Accessing external global variables

extern int globe;

// (The linker resolves the reference)

void func() {

globe = 47;

} ///:~

Storage for the variable globe is created by the definition in

Global.cpp and that same variable is accessed by the code in

Global2.cpp Since the code in Global2.cppis compiled separately

from the code in Global.cpp the compiler must be informed that

the variable exists elsewhere by the declaration

extern int globe;

When you run the program, you'll see that the call to func( ) does

indeed affect the single global instance of globe.

In Global.cpp you can see the special comment tag (which is my

own design):

//{L} Global2

This says that to create the final program, the object file with the

name Global2 must be linked in (there is no extension because the

extension names of object files differ from one system to the next).

In Global2.cpp the first line has another special comment tag {O},

which says "Don't try to create an executable out of this file, it's

being compiled so that it can be linked into some other executable."

The ExtractCode.cppprogram in Volume 2 of this book

(downloadable at ) reads these tags and creates

160

Thinking in C++

the appropriate makefileso everything compiles properly (you'll

learn about makefile at the end of this chapter).

Local variables

Local variables occur within a scope; they are "local" to a function.

They are often called automatic variables because they automatically

come into being when the scope is entered and automatically go

away when the scope closes. The keyword auto makes this explicit,

but local variables default to auto so it is never necessary to declare

something as an auto.

Register variables

A register variable is a type of local variable. The registerkeyword

tells the compiler "Make accesses to this variable as fast as

possible." Increasing the access speed is implementation

dependent, but, as the name suggests, it is often done by placing

the variable in a register. There is no guarantee that the variable

will be placed in a register or even that the access speed will

increase. It is a hint to the compiler.

There are restrictions to the use of registervariables. You cannot

take or compute the address of a registervariable. A register

variable can be declared only within a block (you cannot have

global or static registervariables). You can, however, use a register

variable as a formal argument in a function (i.e., in the argument

list).

In general, you shouldn't try to second-guess the compiler's

optimizer, since it will probably do a better job than you can. Thus,

the registerkeyword is best avoided.

static

The static keyword has several distinct meanings. Normally,

variables defined local to a function disappear at the end of the

function scope. When you call the function again, storage for the

3: The C in C++

161

variables is created anew and the values are re-initialized. If you

want a value to be extant throughout the life of a program, you can

define a function's local variable to be static and give it an initial

value. The initialization is performed only the first time the

function is called, and the data retains its value between function

calls. This way, a function can "remember" some piece of

information between function calls.

You may wonder why a global variable isn't used instead. The

beauty of a static variable is that it is unavailable outside the scope

of the function, so it can't be inadvertently changed. This localizes

errors.

Here's an example of the use of static variables:

//: C03:Static.cpp

// Using a static variable in a function

#include <iostream>

using namespace std;

void func() {

static int i = 0;

cout << "i = " << ++i << endl;

}

int main() {

for(int x = 0; x < 10; x++)

func();

} ///:~

Each time func( ) is called in the for loop, it prints a different value.

If the keyword static is not used, the value printed will always be

`1'.

The second meaning of static is related to the first in the

"unavailable outside a certain scope" sense. When static is applied

to a function name or to a variable that is outside of all functions, it

means "This name is unavailable outside of this file." The function

name or variable is local to the file; we say it has file scope. As a

162

Thinking in C++

demonstration, compiling and linking the following two files will

cause a linker error:

//: C03:FileStatic.cpp

// File scope demonstration. Compiling and

// linking this file with FileStatic2.cpp

// will cause a linker error

// File scope means only available in this file:

static int fs;

int main() {

fs = 1;

} ///:~

Even though the variable fs is claimed to exist as an extern in the

following file, the linker won't find it because it has been declared

static in FileStatic.cpp

//: C03:FileStatic2.cpp {O}

// Trying to reference fs

extern int fs;

void func() {

fs = 100;

} ///:~

The static specifier may also be used inside a class. This

explanation will be delayed until you learn to create classes, later in

the book.

extern

The extern keyword has already been briefly described and

demonstrated. It tells the compiler that a variable or a function

exists, even if the compiler hasn't yet seen it in the file currently

being compiled. This variable or function may be defined in

another file or further down in the current file. As an example of

the latter:

//: C03:Forward.cpp

// Forward function & data declarations

3: The C in C++

163

#include <iostream>

using namespace std;

// This is not actually external, but the

// compiler must be told it exists somewhere:

extern int i;

extern void func();

int main() {

i = 0;

func();

}

int i; // The data definition

void func() {

i++;

cout << i;

} ///:~

When the compiler encounters the declaration `extern int i it

knows that the definition for i must exist somewhere as a global

variable. When the compiler reaches the definition of i, no other

declaration is visible, so it knows it has found the same i declared

earlier in the file. If you were to define i as static, you would be

telling the compiler that i is defined globally (via the extern), but it

also has file scope (via the static), so the compiler will generate an

error.

Linkage

To understand the behavior of C and C++ programs, you need to

know about linkage. In an executing program, an identifier is

represented by storage in memory that holds a variable or a

compiled function body. Linkage describes this storage as it is seen

by the linker. There are two types of linkage: internal linkage and

external linkage.

Internal linkage means that storage is created to represent the

identifier only for the file being compiled. Other files may use the

same identifier name with internal linkage, or for a global variable,

and no conflicts will be found by the linker separate storage is

created for each identifier. Internal linkage is specified by the

keyword static in C and C++.

164

Thinking in C++

External linkage means that a single piece of storage is created to

represent the identifier for all files being compiled. The storage is

created once, and the linker must resolve all other references to that

storage. Global variables and function names have external linkage.

These are accessed from other files by declaring them with the

keyword extern. Variables defined outside all functions (with the

exception of const in C++) and function definitions default to

external linkage. You can specifically force them to have internal

linkage using the static keyword. You can explicitly state that an

identifier has external linkage by defining it with the extern

keyword. Defining a variable or function with extern is not

necessary in C, but it is sometimes necessary for const in C++.

Automatic (local) variables exist only temporarily, on the stack,

while a function is being called. The linker doesn't know about

automatic variables, and so these have no linkage.

Constants

In old (pre-Standard) C, if you wanted to make a constant, you had

to use the preprocessor:

#define PI 3.14159

Everywhere you used PI, the value 3.14159 was substituted by the

preprocessor (you can still use this method in C and C++).

When you use the preprocessor to create constants, you place

control of those constants outside the scope of the compiler. No

type checking is performed on the name PI and you can't take the

address of PI (so you can't pass a pointer or a reference to PI). PI

cannot be a variable of a user-defined type. The meaning of PI lasts

from the point it is defined to the end of the file; the preprocessor

doesn't recognize scoping.

C++ introduces the concept of a named constant that is just like a

variable, except that its value cannot be changed. The modifier

const tells the compiler that a name represents a constant. Any data

3: The C in C++

165

type, built-in or user-defined, may be defined as const. If you

define something as const and then attempt to modify it, the

compiler will generate an error.

You must specify the type of a const, like this:

const int x = 10;

In Standard C and C++, you can use a named constant in an

argument list, even if the argument it fills is a pointer or a reference

(i.e., you can take the address of a const). A const has a scope, just

like a regular variable, so you can "hide" a const inside a function

and be sure that the name will not affect the rest of the program.

The const was taken from C++ and incorporated into Standard C,

albeit quite differently. In C, the compiler treats a const just like a

variable that has a special tag attached that says "Don't change

me." When you define a const in C, the compiler creates storage for

it, so if you define more than one const with the same name in two

different files (or put the definition in a header file), the linker will

generate error messages about conflicts. The intended use of const

in C is quite different from its intended use in C++ (in short, it's

nicer in C++).

Constant values

In C++, a const must always have an initialization value (in C, this

is not true). Constant values for built-in types are expressed as

decimal, octal, hexadecimal, or floating-point numbers (sadly,

binary numbers were not considered important), or as characters.

In the absence of any other clues, the compiler assumes a constant

value is a decimal number. The numbers 47, 0, and 1101 are all

treated as decimal numbers.

A constant value with a leading 0 is treated as an octal number

(base 8). Base 8 numbers can contain only digits 0-7; the compiler

flags other digits as an error. A legitimate octal number is 017 (15 in

base 10).

166

Thinking in C++

A constant value with a leading 0x is treated as a hexadecimal

number (base 16). Base 16 numbers contain the digits 0-9 and a-f or

A-F. A legitimate hexadecimal number is 0x1fe (510 in base 10).

Floating point numbers can contain decimal points and exponential

powers (represented by e, which means "10 to the power of"). Both

the decimal point and the e are optional. If you assign a constant to

a floating-point variable, the compiler will take the constant value

and convert it to a floating-point number (this process is one form

of what's called implicit type conversion). However, it is a good idea

to use either a decimal point or an e to remind the reader that you

are using a floating-point number; some older compilers also need

the hint.

Legitimate floating-point constant values are: 1e4, 1.0001, 47.0, 0.0,

and -1.159e-77. You can add suffixes to force the type of floating-

point number: f or F forces a float, L or l forces a long double;

otherwise the number will be a double.

Character constants are characters surrounded by single quotes, as:

`A', `0', ` `. Notice there is a big difference between the character `0'

(ASCII 96) and the value 0. Special characters are represented with

the "backslash escape": `\n' (newline), `\t' (tab), `\\' (backslash),

`\r' (carriage return), `\"' (double quotes), `\'' (single quote), etc.

You can also express char constants in octal: `\17' or hexadecimal:

`\xff'.

volatile

Whereas the qualifier const tells the compiler "This never changes"

(which allows the compiler to perform extra optimizations), the

qualifier volatiletells the compiler "You never know when this will

change," and prevents the compiler from performing any

optimizations based on the stability of that variable. Use this

keyword when you read some value outside the control of your

code, such as a register in a piece of communication hardware. A

3: The C in C++

167

volatilevariable is always read whenever its value is required,

even if it was just read the line before.

A special case of some storage being "outside the control of your

code" is in a multithreaded program. If you're watching a

particular flag that is modified by another thread or process, that

flag should be volatileso the compiler doesn't make the

assumption that it can optimize away multiple reads of the flag.

Note that volatilemay have no effect when a compiler is not

optimizing, but may prevent critical bugs when you start

optimizing the code (which is when the compiler will begin looking

for redundant reads).

The const and volatilekeywords will be further illuminated in a

later chapter.

Operators and their use

This section covers all the operators in C and C++.

All operators produce a value from their operands. This value is

produced without modifying the operands, except with the

assignment, increment, and decrement operators. Modifying an

operand is called a side effect. The most common use for operators

that modify their operands is to generate the side effect, but you

should keep in mind that the value produced is available for your

use just as in operators without side effects.

Assignment

Assignment is performed with the operator =. It means "Take the

right-hand side (often called the rvalue) and copy it into the left-

hand side (often called the lvalue)." An rvalue is any constant,

variable, or expression that can produce a value, but an lvalue must

be a distinct, named variable (that is, there must be a physical space

in which to store data). For instance, you can assign a constant

168

Thinking in C++

value to a variable (A = 4;), but you cannot assign anything to

constant value it cannot be an lvalue (you can't say 4 = A;).

Mathematical operators

The basic mathematical operators are the same as the ones available

in most programming languages: addition (+), subtraction (-),

division (/), multiplication (*), and modulus (%; this produces the

remainder from integer division). Integer division truncates the

result (it doesn't round). The modulus operator cannot be used

with floating-point numbers.

C and C++ also use a shorthand notation to perform an operation

and an assignment at the same time. This is denoted by an operator

followed by an equal sign, and is consistent with all the operators

in the language (whenever it makes sense). For example, to add 4 to

the variable x and assign x to the result, you say: x += 4;.

This example shows the use of the mathematical operators:

//: C03:Mathops.cpp

// Mathematical operators

#include <iostream>

using namespace std;

// A macro to display a string and a value.

#define PRINT(STR, VAR) \

cout << STR " = " << VAR << endl

int main() {

int i, j, k;

float u, v, w; // Applies to doubles, too

cout << "enter an integer: ";

cin >> j;

cout << "enter another integer: ";

cin >> k;

PRINT("j",j); PRINT("k",k);

i = j + k; PRINT("j + k",i);

i = j - k; PRINT("j - k",i);

i = k / j; PRINT("k / j",i);

i = k * j; PRINT("k * j",i);

3: The C in C++

169

i = k % j; PRINT("k % j",i);

// The following only works with integers:

j %= k; PRINT("j %= k", j);

cout << "Enter a floating-point number: ";

cin >> v;

cout << "Enter another floating-point number:";

cin >> w;

PRINT("v",v); PRINT("w",w);

u = v + w; PRINT("v + w", u);

u = v - w; PRINT("v - w", u);

u = v * w; PRINT("v * w", u);

u = v / w; PRINT("v / w", u);

// The following works for ints, chars,

// and doubles too:

PRINT("u", u); PRINT("v", v);

u += v; PRINT("u += v", u);

u -= v; PRINT("u -= v", u);

u *= v; PRINT("u *= v", u);

u /= v; PRINT("u /= v", u);

} ///:~

The rvalues of all the assignments can, of course, be much more

complex.

Introduction to preprocessor macros

Notice the use of the macro PRINT( )to save typing (and typing

errors!). Preprocessor macros are traditionally named with all

uppercase letters so they stand out you'll learn later that macros

can quickly become dangerous (and they can also be very useful).

The arguments in the parenthesized list following the macro name

are substituted in all the code following the closing parenthesis.

The preprocessor removes the name PRINT and substitutes the

code wherever the macro is called, so the compiler cannot generate

any error messages using the macro name, and it doesn't do any

type checking on the arguments (the latter can be beneficial, as

shown in the debugging macros at the end of the chapter).

170

Thinking in C++

Relational operators

Relational operators establish a relationship between the values of

the operands. They produce a Boolean (specified with the bool

keyword in C++) true if the relationship is true, and false if the

relationship is false. The relational operators are: less than (<),

greater than (>), less than or equal to (<=), greater than or equal to

(>=), equivalent (==), and not equivalent (!=). They may be used

with all built-in data types in C and C++. They may be given

special definitions for user-defined data types in C++ (you'll learn

about this in Chapter 12, which covers operator overloading).

Logical operators

The logical operators and (&&) and or (||) produce a true or false

based on the logical relationship of its arguments. Remember that

in C and C++, a statement is true if it has a non-zero value, and

false if it has a value of zero. If you print a bool, you'll typically see

a `1' for true and `0' for false.

This example uses the relational and logical operators:

//: C03:Boolean.cpp

// Relational and logical operators.

#include <iostream>

using namespace std;

int main() {

int i,j;

cout << "Enter an integer: ";

cin >> i;

cout << "Enter another integer: ";

cin >> j;

cout << "i > j is " << (i > j) << endl;

cout << "i < j is " << (i < j) << endl;

cout << "i >= j is " << (i >= j) << endl;

cout << "i <= j is " << (i <= j) << endl;

cout << "i == j is " << (i == j) << endl;

cout << "i != j is " << (i != j) << endl;

cout << "i && j is " << (i && j) << endl;

cout << "i || j is " << (i || j) << endl;

3: The C in C++

171

cout << " (i < 10) && (j < 10) is "

<< ((i < 10) && (j < 10)) << endl;

} ///:~

You can replace the definition for int with float or double in the

program above. Be aware, however, that the comparison of a

floating-point number with the value of zero is strict; a number that

is the tiniest fraction different from another number is still "not

equal." A floating-point number that is the tiniest bit above zero is

still true.

Bitwise operators

The bitwise operators allow you to manipulate individual bits in a

number (since floating point values use a special internal format,

the bitwise operators work only with integral types: char, int and

long). Bitwise operators perform Boolean algebra on the

corresponding bits in the arguments to produce the result.

The bitwise and operator (&) produces a one in the output bit if

both input bits are one; otherwise it produces a zero. The bitwise or

operator (|) produces a one in the output bit if either input bit is a

one and produces a zero only if both input bits are zero. The

bitwise exclusive or, or xor (^) produces a one in the output bit if one

or the other input bit is a one, but not both. The bitwise not (~, also

called the ones complement operator) is a unary operator it only

takes one argument (all other bitwise operators are binary

operators). Bitwise not produces the opposite of the input bit a

one if the input bit is zero, a zero if the input bit is one.

Bitwise operators can be combined with the = sign to unite the

operation and assignment: &=, |=, and ^= are all legitimate

operations (since ~ is a unary operator it cannot be combined with

the = sign).

172

Thinking in C++

Shift operators

The shift operators also manipulate bits. The left-shift operator (<<)

produces the operand to the left of the operator shifted to the left

by the number of bits specified after the operator. The right-shift

operator (>>) produces the operand to the left of the operator

shifted to the right by the number of bits specified after the

operator. If the value after the shift operator is greater than the

number of bits in the left-hand operand, the result is undefined. If

the left-hand operand is unsigned, the right shift is a logical shift so

the upper bits will be filled with zeros. If the left-hand operand is

signed, the right shift may or may not be a logical shift (that is, the

behavior is undefined).

Shifts can be combined with the equal sign (<<= and >>=). The

lvalue is replaced by the lvalue shifted by the rvalue.

What follows is an example that demonstrates the use of all the

operators involving bits. First, here's a general-purpose function

that prints a byte in binary format, created separately so that it may

be easily reused. The header file declares the function:

//: C03:printBinary.h

// Display a byte in binary

void printBinary(const unsigned char val);

///:~

Here's the implementation of the function:

//: C03:printBinary.cpp {O}

#include <iostream>

void printBinary(const unsigned char val) {

for(int i = 7; i >= 0; i--)

if(val & (1 << i))

std::cout << "1";

else

std::cout << "0";

} ///:~

The printBinary( )function takes a single byte and displays it bit-

by-bit. The expression

3: The C in C++

173

(1 << i)

produces a one in each successive bit position; in binary: 00000001,

00000010, etc. If this bit is bitwise anded with val and the result is

nonzero, it means there was a one in that position in val.

Finally, the function is used in the example that shows the bit-

manipulation operators:

//: C03:Bitwise.cpp

//{L} printBinary

// Demonstration of bit manipulation

#include "printBinary.h"

#include <iostream>

using namespace std;

// A macro to save typing:

#define PR(STR, EXPR) \

cout << STR; printBinary(EXPR); cout << endl;

int main() {

unsigned int getval;

unsigned char a, b;

cout << "Enter a number between 0 and 255: ";

cin >> getval; a = getval;

PR("a in binary: ", a);

cout << "Enter a number between 0 and 255: ";

cin >> getval; b = getval;

PR("b in binary: ", b);

PR("a | b = ", a | b);

PR("a & b = ", a & b);

PR("a ^ b = ", a ^ b);

PR("~a = ", ~a);

PR("~b = ", ~b);

// An interesting bit pattern:

unsigned char c = 0x5A;

PR("c in binary: ", c);

a |= c;

PR("a |= c; a = ", a);

b &= c;

PR("b &= c; b = ", b);

b ^= a;

PR("b ^= a; b = ", b);

} ///:~

174

Thinking in C++

Once again, a preprocessor macro is used to save typing. It prints

the string of your choice, then the binary representation of an

expression, then a newline.

In main( ), the variables are unsigned This is because, in general,

you don't want signs when you are working with bytes. An int

must be used instead of a char for getval because the "cin >>"

statement will otherwise treat the first digit as a character. By

assigning getval to a and b, the value is converted to a single byte

(by truncating it).

The << and >> provide bit-shifting behavior, but when they shift

bits off the end of the number, those bits are lost (it's commonly

said that they fall into the mythical bit bucket, a place where

discarded bits end up, presumably so they can be reused...). When

manipulating bits you can also perform rotation, which means that

the bits that fall off one end are inserted back at the other end, as if

they're being rotated around a loop. Even though most computer

processors provide a machine-level rotate command (so you'll see

it in the assembly language for that processor), there is no direct

support for "rotate" in C or C++. Presumably the designers of C felt

justified in leaving "rotate" off (aiming, as they said, for a minimal

language) because you can build your own rotate command. For

example, here are functions to perform left and right rotations:

//: C03:Rotation.cpp {O}

// Perform left and right rotations

unsigned char rol(unsigned char val) {

int highbit;

if(val & 0x80) // 0x80 is the high bit only

highbit = 1;

else

highbit = 0;

// Left shift (bottom bit becomes 0):

val <<= 1;

// Rotate the high bit onto the bottom:

val |= highbit;

return val;

3: The C in C++

175

}

unsigned char ror(unsigned char val) {

int lowbit;

if(val & 1) // Check the low bit

lowbit = 1;

else

lowbit = 0;

val >>= 1; // Right shift by one position

// Rotate the low bit onto the top:

val |= (lowbit << 7);

return val;

} ///:~

Try using these functions in Bitwise.cpp Notice the definitions (or

at least declarations) of rol( ) and ror( ) must be seen by the

compiler in Bitwise.cppbefore the functions are used.

The bitwise functions are generally extremely efficient to use

because they translate directly into assembly language statements.

Sometimes a single C or C++ statement will generate a single line

of assembly code.

Unary operators

Bitwise not isn't the only operator that takes a single argument. Its

companion, the logical not (!), will take a true value and produce a

false value. The unary minus (-) and unary plus (+) are the same

operators as binary minus and plus; the compiler figures out which

usage is intended by the way you write the expression. For

instance, the statement

x = -a;

has an obvious meaning. The compiler can figure out:

x = a * -b;

but the reader might get confused, so it is safer to say:

x = a * (-b);

176

Thinking in C++

The unary minus produces the negative of the value. Unary plus

provides symmetry with unary minus, although it doesn't actually

do anything.

The increment and decrement operators (++ and --) were

introduced earlier in this chapter. These are the only operators

other than those involving assignment that have side effects. These

operators increase or decrease the variable by one unit, although

"unit" can have different meanings according to the data type this

is especially true with pointers.

The last unary operators are the address-of (&), dereference (* and -

>), and cast operators in C and C++, and new and delete in C++.

Address-of and dereference are used with pointers, described in

this chapter. Casting is described later in this chapter, and new and

delete are introduced in Chapter 4.

The ternary operator

The ternary if-else is unusual because it has three operands. It is

truly an operator because it produces a value, unlike the ordinary

if-else statement. It consists of three expressions: if the first

expression (followed by a ?) evaluates to true, the expression

following the ? is evaluated and its result becomes the value

produced by the operator. If the first expression is false, the third

expression (following a :) is executed and its result becomes the

value produced by the operator.

The conditional operator can be used for its side effects or for the

value it produces. Here's a code fragment that demonstrates both:

a = --b ? b : (b = -99);

Here, the conditional produces the rvalue. a is assigned to the value

of b if the result of decrementing b is nonzero. If b became zero, a

and b are both assigned to -99. b is always decremented, but it is

assigned to -99 only if the decrement causes b to become 0. A

3: The C in C++

177

similar statement can be used without the "a =" just for its side

effects:

--b ? b : (b = -99);

Here the second B is superfluous, since the value produced by the

operator is unused. An expression is required between the ? and :.

In this case, the expression could simply be a constant that might

make the code run a bit faster.

The comma operator

The comma is not restricted to separating variable names in

multiple definitions, such as

int i, j, k;

Of course, it's also used in function argument lists. However, it can

also be used as an operator to separate expressions in this case it

produces only the value of the last expression. All the rest of the

expressions in the comma-separated list are evaluated only for their

side effects. This example increments a list of variables and uses the

last one as the rvalue:

//: C03:CommaOperator.cpp

#include <iostream>

using namespace std;

int main() {

int a = 0, b = 1, c = 2, d = 3, e = 4;

a = (b++, c++, d++, e++);

cout << "a = " << a << endl;

// The parentheses are critical here. Without

// them, the statement will evaluate to:

(a = b++), c++, d++, e++;

cout << "a = " << a << endl;

} ///:~

In general, it's best to avoid using the comma as anything other

than a separator, since people are not used to seeing it as an

operator.

178

Thinking in C++

Common pitfalls when using operators

As illustrated above, one of the pitfalls when using operators is

trying to get away without parentheses when you are even the least

bit uncertain about how an expression will evaluate (consult your

local C manual for the order of expression evaluation).

Another extremely common error looks like this:

//: C03:Pitfall.cpp

// Operator mistakes

int main() {

int a = 1, b = 1;

while(a = b) {

// ....

}

} ///:~

The statement a = b will always evaluate to true when b is non-

zero. The variable a is assigned to the value of b, and the value of b

is also produced by the operator =. In general, you want to use the

equivalence operator == inside a conditional statement, not

assignment. This one bites a lot of programmers (however, some

compilers will point out the problem to you, which is helpful).

A similar problem is using bitwise and and or instead of their

logical counterparts. Bitwise and and or use one of the characters (&

or |), while logical and and or use two (&& and ||). Just as with =

and ==, it's easy to just type one character instead of two. A useful

mnemonic device is to observe that "Bits are smaller, so they don't

need as many characters in their operators."

Casting operators

The word cast is used in the sense of "casting into a mold." The

compiler will automatically change one type of data into another if

it makes sense. For instance, if you assign an integral value to a

floating-point variable, the compiler will secretly call a function (or

more probably, insert code) to convert the int to a float. Casting

3: The C in C++

179

allows you to make this type conversion explicit, or to force it when

it wouldn't normally happen.

To perform a cast, put the desired data type (including all

modifiers) inside parentheses to the left of the value. This value can

be a variable, a constant, the value produced by an expression, or

the return value of a function. Here's an example:

//: C03:SimpleCast.cpp

int main() {

int b = 200;

unsigned long a = (unsigned long int)b;

} ///:~

Casting is powerful, but it can cause headaches because in some

situations it forces the compiler to treat data as if it were (for

instance) larger than it really is, so it will occupy more space in

memory; this can trample over other data. This usually occurs

when casting pointers, not when making simple casts like the one

shown above.

C++ has an additional casting syntax, which follows the function

call syntax. This syntax puts the parentheses around the argument,

like a function call, rather than around the data type:

//: C03:FunctionCallCast.cpp

int main() {

float a = float(200);

// This is equivalent to:

float b = (float)200;

} ///:~

Of course in the case above you wouldn't really need a cast; you

could just say 200f (in effect, that's typically what the compiler will

do for the above expression). Casts are generally used instead with

variables, rather than constants.

180

Thinking in C++

C++ explicit casts

Casts should be used carefully, because what you are actually

doing is saying to the compiler "Forget type checking treat it as

this other type instead." That is, you're introducing a hole in the

C++ type system and preventing the compiler from telling you that

you're doing something wrong with a type. What's worse, the

compiler believes you implicitly and doesn't perform any other

checking to catch errors. Once you start casting, you open yourself

up for all kinds of problems. In fact, any program that uses a lot of

casts should be viewed with suspicion, no matter how much you

are told it simply "must" be done that way. In general, casts should

be few and isolated to the solution of very specific problems.

Once you understand this and are presented with a buggy

program, your first inclination may be to look for casts as culprits.

But how do you locate C-style casts? They are simply type names

inside of parentheses, and if you start hunting for such things you'll

discover that it's often hard to distinguish them from the rest of

your code.

Standard C++ includes an explicit cast syntax that can be used to

completely replace the old C-style casts (of course, C-style casts

cannot be outlawed without breaking code, but compiler writers

could easily flag old-style casts for you). The explicit cast syntax is

such that you can easily find them, as you can see by their names:

static_cast

For "well-behaved" and

"reasonably well-behaved" casts,

including things you might now

do without a cast (such as an

automatic type conversion).

const_cast

To cast away const and/or

volatile

reinterpret_cast

To cast to a completely different

meaning. The key is that you'll

3: The C in C++

181

need to cast back to the original

type to use it safely. The type you

cast to is typically used only for

bit twiddling or some other

mysterious purpose. This is the

most dangerous of all the casts.

dynamic_cast

For type-safe downcasting (this

cast will be described in Chapter

15).

The first three explicit casts will be described more completely in

the following sections, while the last one can be demonstrated only

after you've learned more, in Chapter 15.

static_cast

A static_castis used for all conversions that are well-defined. These

include "safe" conversions that the compiler would allow you to do

without a cast and less-safe conversions that are nonetheless well-

defined. The types of conversions covered by static_castinclude

typical castless conversions, narrowing (information-losing)

conversions, forcing a conversion from a void*, implicit type

conversions, and static navigation of class hierarchies (since you

haven't seen classes and inheritance yet, this last topic will be

delayed until Chapter 15):

//: C03:static_cast.cpp

void func(int) {}

int main() {

int i = 0x7fff; // Max pos value = 32767

long l;

float f;

// (1) Typical castless conversions:

l = i;

f = i;

// Also works:

l = static_cast<long>(i);

f = static_cast<float>(i);

182

Thinking in C++

// (2) Narrowing conversions:

i = l; // May lose digits

i = f; // May lose info

// Says "I know," eliminates warnings:

i = static_cast<int>(l);

i = static_cast<int>(f);

char c = static_cast<char>(i);

// (3) Forcing a conversion from void* :

void* vp = &i;

// Old way produces a dangerous conversion:

float* fp = (float*)vp;

// The new way is equally dangerous:

fp = static_cast<float*>(vp);

// (4) Implicit type conversions, normally

// performed by the compiler:

double d = 0.0;

int x = d; // Automatic type conversion

x = static_cast<int>(d); // More explicit

func(d); // Automatic type conversion

func(static_cast<int>(d)); // More explicit

} ///:~

In Section (1), you see the kinds of conversions you're used to

doing in C, with or without a cast. Promoting from an int to a long

or float is not a problem because the latter can always hold every

value that an int can contain. Although it's unnecessary, you can

use static_castto highlight these promotions.

Converting back the other way is shown in (2). Here, you can lose

data because an int is not as "wide" as a long or a float; it won't

hold numbers of the same size. Thus these are called narrowing

conversions. The compiler will still perform these, but will often give

you a warning. You can eliminate this warning and indicate that

you really did mean it using a cast.

Assigning from a void* is not allowed without a cast in C++ (unlike

C), as seen in (3). This is dangerous and requires that programmers

3: The C in C++

183

know what they're doing. The static_cast at least, is easier to locate

than the old standard cast when you're hunting for bugs.

Section (4) of the program shows the kinds of implicit type

conversions that are normally performed automatically by the

compiler. These are automatic and require no casting, but again

static_casthighlights the action in case you want to make it clear

what's happening or hunt for it later.

const_cast

If you want to convert from a const to a nonconst or from a volatile

to a nonvolatile you use const_cast This is the only conversion

allowed with const_cast if any other conversion is involved it must

;

be done using a separate expression or you'll get a compile-time

error.

//: C03:const_cast.cpp

int main() {

const int i = 0;

int* j = (int*)&i; // Deprecated form

j = const_cast<int*>(&i); // Preferred

// Can't do simultaneous additional casting:

//! long* l = const_cast<long*>(&i); // Error

volatile int k = 0;

int* u = const_cast<int*>(&k);

} ///:~

If you take the address of a const object, you produce a pointer to a

const, and this cannot be assigned to a nonconst pointer without a

cast. The old-style cast will accomplish this, but the const_castis

the appropriate one to use. The same holds true for volatile

reinterpret_cast

This is the least safe of the casting mechanisms, and the one most

likely to produce bugs. A reinterpret_cast

pretends that an object is

just a bit pattern that can be treated (for some dark purpose) as if it

were an entirely different type of object. This is the low-level bit

twiddling that C is notorious for. You'll virtually always need to

184

Thinking in C++

reinterpret_cast

back to the original type (or otherwise treat the

variable as its original type) before doing anything else with it.

//: C03:reinterpret_cast.cpp

#include <iostream>

using namespace std;

const int sz = 100;

struct X { int a[sz]; };

void print(X* x) {

for(int i = 0; i < sz; i++)

cout << x->a[i] << ' ';

cout << endl << "--------------------" << endl;

}

int main() {

X x;

print(&x);

int* xp = reinterpret_cast<int*>(&x);

for(int* i = xp; i < xp + sz; i++)

*i = 0;

// Can't use xp as an X* at this point

// unless you cast it back:

print(reinterpret_cast<X*>(xp));

// In this example, you can also just use

// the original identifier:

print(&x);

} ///:~

In this simple example, struct Xjust contains an array of int, but

when you create one on the stack as in X x, the values of each of the

ints are garbage (this is shown using the print( )function to display

the contents of the struct). To initialize them, the address of the X is

taken and cast to an int pointer, which is then walked through the

array to set each int to zero. Notice how the upper bound for i is

calculated by "adding" sz to xp; the compiler knows that you

actually want sz pointer locations greater than xp and it does the

correct pointer arithmetic for you.

The idea of reinterpret_cast that when you use it, what you get is

so foreign that it cannot be used for the type's original purpose

3: The C in C++

185

unless you cast it back. Here, we see the cast back to an X* in the

call to print, but of course since you still have the original identifier

you can also use that. But the xp is only useful as an int*, which is

truly a "reinterpretation" of the original X.

A reinterpret_cast

often indicates inadvisable and/or nonportable

programming, but it's available when you decide you have to use

it.

sizeof an operator by itself

The sizeof operator stands alone because it satisfies an unusual

need. sizeof gives you information about the amount of memory

allocated for data items. As described earlier in this chapter, sizeof

tells you the number of bytes used by any particular variable. It can

also give the size of a data type (with no variable name):

//: C03:sizeof.cpp

#include <iostream>

using namespace std;

int main() {

cout << "sizeof(double) = " << sizeof(double);

cout << ", sizeof(char) = " << sizeof(char);

} ///:~

By definition, the sizeof any type of char (signed, unsignedor

plain) is always one, regardless of whether the underlying storage

for a char is actually one byte. For all other types, the result is the

size in bytes.

Note that sizeof is an operator, not a function. If you apply it to a

type, it must be used with the parenthesized form shown above,

but if you apply it to a variable you can use it without parentheses:

//: C03:sizeofOperator.cpp

int main() {

int x;

int i = sizeof x;

} ///:~

186

Thinking in C++

sizeof can also give you the sizes of user-defined data types. This is

used later in the book.

The asm keyword

This is an escape mechanism that allows you to write assembly

code for your hardware within a C++ program. Often you're able

to reference C++ variables within the assembly code, which means

you can easily communicate with your C++ code and limit the

assembly code to that necessary for efficiency tuning or to use

special processor instructions. The exact syntax that you must use

when writing the assembly language is compiler-dependent and

can be discovered in your compiler's documentation.

Explicit operators

These are keywords for bitwise and logical operators. Non-U.S.

programmers without keyboard characters like &, |, ^, and so on,

were forced to use C's horrible trigraphs, which were not only

annoying to type, but obscure when reading. This is repaired in

C++ with additional keywords:

Keyword

Meaning

and

&& (logical and)

|| (logical or)

not

! (logical NOT)

not_eq

!= (logical not-equivalent)

bitand

& (bitwise and)

and_eq

&= (bitwise and-assignment)

bitor

| (bitwise or)

or_eq

|= (bitwise or-assignment)

xor

^ (bitwise exclusive-or)

3: The C in C++

187

Keyword

Meaning

xor_eq

^= (bitwise exclusive-or-

assignment)

compl

~ (ones complement)

If your compiler complies with Standard C++, it will support these

keywords.

Composite type creation

The fundamental data types and their variations are essential, but

rather primitive. C and C++ provide tools that allow you to

compose more sophisticated data types from the fundamental data

types. As you'll see, the most important of these is struct, which is

the foundation for class in C++. However, the simplest way to

create more sophisticated types is simply to alias a name to another

name via typedef.

Aliasing names with typedef

This keyword promises more than it delivers: typedef suggests

"type definition" when "alias" would probably have been a more

accurate description, since that's what it really does. The syntax is:

typedef existing-type-description alias-name

People often use typedef when data types get slightly complicated,

just to prevent extra keystrokes. Here is a commonly-used typedef:

typedef unsigned long ulong;

Now if you say ulong the compiler knows that you mean unsigned

long. You might think that this could as easily be accomplished

using preprocessor substitution, but there are key situations in

which the compiler must be aware that you're treating a name as if

it were a type, so typedef is essential.

188

Thinking in C++

One place where typedef comes in handy is for pointer types. As

previously mentioned, if you say:

int* x, y;

This actually produces an int* which is x and an int (not an int*)

which is y. That is, the `*' binds to the right, not the left. However,

if you use a typedef:

typedef int* IntPtr;

IntPtr x, y;

Then both x and y are of type int*.

You can argue that it's more explicit and therefore more readable to

avoid typedefs for primitive types, and indeed programs rapidly

become difficult to read when many typedefs are used. However,

typedefs become especially important in C when used with struct.

Combining variables with struct

A struct is a way to collect a group of variables into a structure.

Once you create a struct, then you can make many instances of this

"new" type of variable you've invented. For example:

//: C03:SimpleStruct.cpp

struct Structure1 {

char c;

int i;

float f;

double d;

};

int main() {

struct Structure1 s1, s2;

s1.c = 'a'; // Select an element using a '.'

s1.i = 1;

s1.f = 3.14;

s1.d = 0.00093;

s2.c = 'a';

s2.i = 1;

s2.f = 3.14;

3: The C in C++

189

s2.d = 0.00093;

} ///:~

The struct declaration must end with a semicolon. In main( ), two

instances of Structure1are created: s1 and s2. Each of these has

their own separate versions of c, i, f, and d. So s1 and s2 represent

clumps of completely independent variables. To select one of the

elements within s1 or s2, you use a `.', syntax you've seen in the

previous chapter when using C++ class objects since classes

evolved from structs, this is where that syntax arose from.

One thing you'll notice is the awkwardness of the use of Structure1

(as it turns out, this is only required by C, not C++). In C, you can't

just say Structure1when you're defining variables, you must say

struct Structure1This is where typedef becomes especially handy

in C:

//: C03:SimpleStruct2.cpp

// Using typedef with struct

typedef struct {

char c;

int i;

float f;

double d;

} Structure2;

int main() {

Structure2 s1, s2;

s1.c = 'a';

s1.i = 1;

s1.f = 3.14;

s1.d = 0.00093;

s2.c = 'a';

s2.i = 1;

s2.f = 3.14;

s2.d = 0.00093;

} ///:~

By using typedef in this way, you can pretend (in C; try removing

the typedef for C++) that Structure2is a built-in type, like int or

float, when you define s1 and s2 (but notice it only has data

190

Thinking in C++

characteristics and does not include behavior, which is what we

get with real objects in C++). You'll notice that the struct identifier

has been left off at the beginning, because the goal is to create the

typedef. However, there are times when you might need to refer to

the struct during its definition. In those cases, you can actually

repeat the name of the struct as the struct name and as the typedef:

//: C03:SelfReferential.cpp

// Allowing a struct to refer to itself

typedef struct SelfReferential {

int i;

SelfReferential* sr; // Head spinning yet?

} SelfReferential;

int main() {

SelfReferential sr1, sr2;

sr1.sr = &sr2;

sr2.sr = &sr1;

sr1.i = 47;

sr2.i = 1024;

} ///:~

If you look at this for awhile, you'll see that sr1 and sr2 point to

each other, as well as each holding a piece of data.

Actually, the struct name does not have to be the same as the

typedef name, but it is usually done this way as it tends to keep

things simpler.

Pointers and structs

In the examples above, all the structs are manipulated as objects.

However, like any piece of storage, you can take the address of a

struct object (as seen in SelfReferential.cpp

above). To select the

elements of a particular struct object, you use a `.', as seen above.

However, if you have a pointer to a struct object, you must select

an element of that object using a different operator: the `->'. Here's

an example:

//: C03:SimpleStruct3.cpp

3: The C in C++

191

// Using pointers to structs

typedef struct Structure3 {

char c;

int i;

float f;

double d;

} Structure3;

int main() {

Structure3 s1, s2;

Structure3* sp = &s1;

sp->c = 'a';

sp->i = 1;

sp->f = 3.14;

sp->d = 0.00093;

sp = &s2; // Point to a different struct object

sp->c = 'a';

sp->i = 1;

sp->f = 3.14;

sp->d = 0.00093;

} ///:~

In main( ), the struct pointer sp is initially pointing to s1, and the

members of s1 are initialized by selecting them with the `->' (and

you use this same operator in order to read those members). But

then sp is pointed to s2, and those variables are initialized the same

way. So you can see that another benefit of pointers is that they can

be dynamically redirected to point to different objects; this

provides more flexibility in your programming, as you will learn.

For now, that's all you need to know about structs, but you'll

become much more comfortable with them (and especially their

more potent successors, classes) as the book progresses.

Clarifying programs with enum

An enumerated data type is a way of attaching names to numbers,

thereby giving more meaning to anyone reading the code. The

enum keyword (from C) automatically enumerates any list of

identifiers you give it by assigning them values of 0, 1, 2, etc. You

can declare enum variables (which are always represented as

192

Thinking in C++

integral values). The declaration of an enum looks similar to a

struct declaration.

An enumerated data type is useful when you want to keep track of

some sort of feature:

//: C03:Enum.cpp

// Keeping track of shapes

enum ShapeType {

circle,

square,

rectangle

}; // Must end with a semicolon like a struct

int main() {

ShapeType shape = circle;

// Activities here....

// Now do something based on what the shape is:

switch(shape) {

case circle: /* circle stuff */ break;

case square: /* square stuff */ break;

case rectangle: /* rectangle stuff */ break;

}

} ///:~

shape is a variable of the ShapeTypeenumerated data type, and its

value is compared with the value in the enumeration. Since shape

is really just an int, however, it can be any value an int can hold

(including a negative number). You can also compare an int

variable with a value in the enumeration.

You should be aware that the example above of switching on type

turns out to be a problematic way to program. C++ has a much

better way to code this sort of thing, the explanation of which must

be delayed until much later in the book.

If you don't like the way the compiler assigns values, you can do it

yourself, like this:

enum ShapeType {

3: The C in C++

193

circle = 10, square = 20, rectangle = 50

};

If you give values to some names and not to others, the compiler

will use the next integral value. For example,

enum snap { crackle = 25, pop };

The compiler gives pop the value 26.

You can see how much more readable the code is when you use

enumerated data types. However, to some degree this is still an

attempt (in C) to accomplish the things that we can do with a class

in C++, so you'll see enum used less in C++.

Type checking for enumerations

C's enumerations are fairly primitive, simply associating integral

values with names, but they provide no type checking. In C++, as

you may have come to expect by now, the concept of type is

fundamental, and this is true with enumerations. When you create

a named enumeration, you effectively create a new type just as you

do with a class: The name of your enumeration becomes a reserved

word for the duration of that translation unit.

In addition, there's stricter type checking for enumerations in C++

than in C. You'll notice this in particular if you have an instance of

an enumeration color called a. In C you can say a++, but in C++

you can't. This is because incrementing an enumeration is

performing two type conversions, one of them legal in C++ and one

of them illegal. First, the value of the enumeration is implicitly cast

from a color to an int, then the value is incremented, then the int is

cast back into a color. In C++ this isn't allowed, because color is a

distinct type and not equivalent to an int. This makes sense,

because how do you know the increment of blue will even be in the

list of colors? If you want to increment a color, then it should be a

class (with an increment operation) and not an enum, because the

class can be made to be much safer. Any time you write code that

194

Thinking in C++

assumes an implicit conversion to an enum type, the compiler will

flag this inherently dangerous activity.

Unions (described next) have similar additional type checking in

C++.

Saving memory with union

Sometimes a program will handle different types of data using the

same variable. In this situation, you have two choices: you can

create a struct containing all the possible different types you might

need to store, or you can use a union. A union piles all the data

into a single space; it figures out the amount of space necessary for

the largest item you've put in the union, and makes that the size of

the union. Use a union to save memory.

Anytime you place a value in a union, the value always starts in

the same place at the beginning of the union, but only uses as much

space as is necessary. Thus, you create a "super-variable" capable

of holding any of the union variables. All the addresses of the

union variables are the same (in a class or struct, the addresses are

different).

Here's a simple use of a union. Try removing various elements and

see what effect it has on the size of the union. Notice that it makes

no sense to declare more than one instance of a single data type in a

union (unless you're just doing it to use a different name).

//: C03:Union.cpp

// The size and simple use of a union

#include <iostream>

using namespace std;

union Packed { // Declaration similar to a class

char i;

short j;

int k;

long l;

float f;

3: The C in C++

195

double d;

// The union will be the size of a

// double, since that's the largest element

}; // Semicolon ends a union, like a struct

int main() {

cout << "sizeof(Packed) = "

<< sizeof(Packed) << endl;

Packed x;

x.i = 'c';

cout << x.i << endl;

x.d = 3.14159;

cout << x.d << endl;

} ///:~

The compiler performs the proper assignment according to the

union member you select.

Once you perform an assignment, the compiler doesn't care what

you do with the union. In the example above, you could assign a

floating-point value to x:

x.f = 2.222;

and then send it to the output as if it were an int:

cout << x.i;

This would produce garbage.

Arrays

Arrays are a kind of composite type because they allow you to

clump a lot of variables together, one right after the other, under a

single identifier name. If you say:

int a[10];

You create storage for 10 int variables stacked on top of each other,

but without unique identifier names for each variable. Instead, they

are all lumped under the name a.

196

Thinking in C++

To access one of these array elements, you use the same square-

bracket syntax that you use to define an array:

a[5] = 47;

However, you must remember that even though the size of a is 10,

you select array elements starting at zero (this is sometimes called

zero indexing), so you can select only the array elements 0-9, like

this:

//: C03:Arrays.cpp

#include <iostream>

using namespace std;

int main() {

int a[10];

for(int i = 0; i < 10; i++) {

a[i] = i * 10;

cout << "a[" << i << "] = " << a[i] << endl;

}

} ///:~

Array access is extremely fast. However, if you index past the end

of the array, there is no safety net you'll step on other variables.

The other drawback is that you must define the size of the array at

compile time; if you want to change the size at runtime you can't

do it with the syntax above (C does have a way to create an array

dynamically, but it's significantly messier). The C++ vector,

introduced in the previous chapter, provides an array-like object

that automatically resizes itself, so it is usually a much better

solution if your array size cannot be known at compile time.

You can make an array of any type, even of structs:

//: C03:StructArray.cpp

// An array of struct

typedef struct {

int i, j, k;

} ThreeDpoint;

3: The C in C++

197

int main() {

ThreeDpoint p[10];

for(int i = 0; i < 10; i++) {

p[i].i = i + 1;

p[i].j = i + 2;

p[i].k = i + 3;

}

} ///:~

Notice how the struct identifier i is independent of the for loop's i.

To see that each element of an array is contiguous with the next,

you can print out the addresses like this:

//: C03:ArrayAddresses.cpp

#include <iostream>

using namespace std;

int main() {

int a[10];

cout << "sizeof(int) = "<< sizeof(int) << endl;

for(int i = 0; i < 10; i++)

cout << "&a[" << i << "] = "

<< (long)&a[i] << endl;

} ///:~

When you run this program, you'll see that each element is one int

size away from the previous one. That is, they are stacked one on

top of the other.

Pointers and arrays

The identifier of an array is unlike the identifiers for ordinary

variables. For one thing, an array identifier is not an lvalue; you

cannot assign to it. It's really just a hook into the square-bracket

syntax, and when you give the name of an array, without square

brackets, what you get is the starting address of the array:

//: C03:ArrayIdentifier.cpp

#include <iostream>

using namespace std;

int main() {

198

Thinking in C++

int a[10];

cout << "a = " << a << endl;

cout << "&a[0] =" << &a[0] << endl;

} ///:~

When you run this program you'll see that the two addresses

(which will be printed in hexadecimal, since there is no cast to

long) are the same.

So one way to look at the array identifier is as a read-only pointer

to the beginning of an array. And although we can't change the

array identifier to point somewhere else, we can create another

pointer and use that to move around in the array. In fact, the

square-bracket syntax works with regular pointers as well:

//: C03:PointersAndBrackets.cpp

int main() {

int a[10];

int* ip = a;

for(int i = 0; i < 10; i++)

ip[i] = i * 10;

} ///:~

The fact that naming an array produces its starting address turns

out to be quite important when you want to pass an array to a

function. If you declare an array as a function argument, what

you're really declaring is a pointer. So in the following example,

func1( )and func2( )effectively have the same argument lists:

//: C03:ArrayArguments.cpp

#include <iostream>

#include <string>

using namespace std;

void func1(int a[], int size) {

for(int i = 0; i < size; i++)

a[i] = i * i - i;

}

void func2(int* a, int size) {

for(int i = 0; i < size; i++)

a[i] = i * i + i;

3: The C in C++

199

}

void print(int a[], string name, int size) {

for(int i = 0; i < size; i++)

cout << name << "[" << i << "] = "

<< a[i] << endl;

}

int main() {

int a[5], b[5];

// Probably garbage values:

print(a, "a", 5);

print(b, "b", 5);

// Initialize the arrays:

func1(a, 5);

func1(b, 5);

print(a, "a", 5);

print(b, "b", 5);

// Notice the arrays are always modified:

func2(a, 5);

func2(b, 5);

print(a, "a", 5);

print(b, "b", 5);

} ///:~

Even though func1( )and func2( )declare their arguments

differently, the usage is the same inside the function. There are

some other issues that this example reveals: arrays cannot be

passed by value3, that is, you never automatically get a local copy

of the array that you pass into a function. Thus, when you modify

an array, you're always modifying the outside object. This can be a

bit confusing at first, if you're expecting the pass-by-value

provided with ordinary arguments.

3 Unless you take the very strict approach that "all argument passing in C/C++ is by

value, and the `value' of an array is what is produced by the array identifier: it's

address." This can be seen as true from the assembly-language standpoint, but I don't

think it helps when trying to work with higher-level concepts. The addition of

references in C++ makes the "all passing is by value" argument more confusing, to

the point where I feel it's more helpful to think in terms of "passing by value" vs.

"passing addresses."

200

Thinking in C++

You'll notice that print( )uses the square-bracket syntax for array

arguments. Even though the pointer syntax and the square-bracket

syntax are effectively the same when passing arrays as arguments,

the square-bracket syntax makes it clearer to the reader that you

mean for this argument to be an array.

Also note that the size argument is passed in each case. Just passing

the address of an array isn't enough information; you must always

be able to know how big the array is inside your function, so you

don't run off the end of that array.

Arrays can be of any type, including arrays of pointers. In fact,

when you want to pass command-line arguments into your

program, C and C++ have a special argument list for main( ),

which looks like this:

int main(int argc, char* argv[]) { // ...

The first argument is the number of elements in the array, which is

the second argument. The second argument is always an array of

char*, because the arguments are passed from the command line as

character arrays (and remember, an array can be passed only as a

pointer). Each whitespace-delimited cluster of characters on the

command line is turned into a separate array argument. The

following program prints out all its command-line arguments by

stepping through the array:

//: C03:CommandLineArgs.cpp

#include <iostream>

using namespace std;

int main(int argc, char* argv[]) {

cout << "argc = " << argc << endl;

for(int i = 0; i < argc; i++)

cout << "argv[" << i << "] = "

<< argv[i] << endl;

} ///:~

3: The C in C++

201

You'll notice that argv[0] is the path and name of the program

itself. This allows the program to discover information about itself.

It also adds one more to the array of program arguments, so a

common error when fetching command-line arguments is to grab

argv[0] when you want argv[1].

You are not forced to use argc and argv as identifiers in main( );

those identifiers are only conventions (but it will confuse people if

you don't use them). Also, there is an alternate way to declare argv:

int main(int argc, char** argv) { // ...

Both forms are equivalent, but I find the version used in this book

to be the most intuitive when reading the code, since it says,

directly, "This is an array of character pointers."

All you get from the command-line is character arrays; if you want

to treat an argument as some other type, you are responsible for

converting it inside your program. To facilitate the conversion to

numbers, there are some helper functions in the Standard C library,

declared in <cstdlib> The simplest ones to use are atoi( ), atol( ),

and atof( ) to convert an ASCII character array to an int, long, and

double floating-point value, respectively. Here's an example using

atoi( ) (the other two functions are called the same way):

//: C03:ArgsToInts.cpp

// Converting command-line arguments to ints

#include <iostream>

#include <cstdlib>

using namespace std;

int main(int argc, char* argv[]) {

for(int i = 1; i < argc; i++)

cout << atoi(argv[i]) << endl;

} ///:~

In this program, you can put any number of arguments on the

command line. You'll notice that the for loop starts at the value 1 to

skip over the program name at argv[0]. Also, if you put a floating-

202

Thinking in C++

point number containing a decimal point on the command line,

atoi( ) takes only the digits up to the decimal point. If you put non-

numbers on the command line, these come back from atoi( ) as

zero.

Exploring floating-point format

The printBinary( )function introduced earlier in this chapter is

handy for delving into the internal structure of various data types.

The most interesting of these is the floating-point format that

allows C and C++ to store numbers representing very large and

very small values in a limited amount of space. Although the

details can't be completely exposed here, the bits inside of floats

and doubles are divided into three regions: the exponent, the

mantissa, and the sign bit; thus it stores the values using scientific

notation. The following program allows you to play around by

printing out the binary patterns of various floating point numbers

so you can deduce for yourself the scheme used in your compiler's

floating-point format (usually this is the IEEE standard for floating

point numbers, but your compiler may not follow that):

//: C03:FloatingAsBinary.cpp

//{L} printBinary

//{T} 3.14159

#include "printBinary.h"

#include <cstdlib>

#include <iostream>

using namespace std;

int main(int argc, char* argv[]) {

if(argc != 2) {

cout << "Must provide a number" << endl;

exit(1);

}

double d = atof(argv[1]);

unsigned char* cp =

reinterpret_cast<unsigned char*>(&d);

for(int i = sizeof(double); i > 0 ; i -= 2) {

printBinary(cp[i-1]);

printBinary(cp[i]);

}

3: The C in C++

203

} ///:~

First, the program guarantees that you've given it an argument by

checking the value of argc, which is two if there's a single argument

(it's one if there are no arguments, since the program name is

always the first element of argv). If this fails, a message is printed

and the Standard C Library function exit( ) is called to terminate

the program.

The program grabs the argument from the command line and

converts the characters to a double using atof( ). Then the double is

treated as an array of bytes by taking the address and casting it to

an unsigned char* Each of these bytes is passed to printBinary( )

for display.

This example has been set up to print the bytes in an order such

that the sign bit appears first on my machine. Yours may be

different, so you might want to re-arrange the way things are

printed. You should also be aware that floating-point formats are

not trivial to understand; for example, the exponent and mantissa

are not generally arranged on byte boundaries, but instead a

number of bits is reserved for each one and they are packed into the

memory as tightly as possible. To truly see what's going on, you'd

need to find out the size of each part of the number (sign bits are

always one bit, but exponents and mantissas are of differing sizes)

and print out the bits in each part separately.

Pointer arithmetic

If all you could do with a pointer that points at an array is treat it as

if it were an alias for that array, pointers into arrays wouldn't be

very interesting. However, pointers are more flexible than this,

since they can be modified to point somewhere else (but remember,

the array identifier cannot be modified to point somewhere else).

Pointer arithmetic refers to the application of some of the arithmetic

operators to pointers. The reason pointer arithmetic is a separate

subject from ordinary arithmetic is that pointers must conform to

204

Thinking in C++

special constraints in order to make them behave properly. For

example, a common operator to use with pointers is ++, which

"adds one to the pointer." What this actually means is that the

pointer is changed to move to "the next value," whatever that

means. Here's an example:

//: C03:PointerIncrement.cpp

#include <iostream>

using namespace std;

int main() {

int i[10];

double d[10];

int* ip = i;

double* dp = d;

cout << "ip = "

<< (long)ip << endl;

ip++;

cout << "ip = "

<< (long)ip << endl;

cout << "dp = "

<< (long)dp << endl;

dp++;

cout << "dp = "

<< (long)dp << endl;

} ///:~

For one run on my machine, the output is:

6684124

6684128

6684044

6684052

What's interesting here is that even though the operation ++

appears to be the same operation for both the int* and the double*,

you can see that the pointer has been changed only 4 bytes for the

int* but 8 bytes for the double*. Not coincidentally, these are the

sizes of int and double on my machine. And that's the trick of

pointer arithmetic: the compiler figures out the right amount to

change the pointer so that it's pointing to the next element in the

array (pointer arithmetic is only meaningful within arrays). This

even works with arrays of structs:

//: C03:PointerIncrement2.cpp

3: The C in C++

205

#include <iostream>

using namespace std;

typedef struct {

char c;

short s;

int i;

long l;

float f;

double d;

long double ld;

} Primitives;

int main() {

Primitives p[10];

Primitives* pp = p;

cout << "sizeof(Primitives) = "

<< sizeof(Primitives) << endl;

cout << "pp = " << (long)pp << endl;

pp++;

cout << "pp = " << (long)pp << endl;

} ///:~

The output for one run on my machine was:

sizeof(Primitives) = 40

pp = 6683764

pp = 6683804

So you can see the compiler also does the right thing for pointers to

structs (and classes and unions).

Pointer arithmetic also works with the operators --, +, and -, but the

latter two operators are limited: you cannot add two pointers, and

if you subtract pointers the result is the number of elements

between the two pointers. However, you can add or subtract an

integral value and a pointer. Here's an example demonstrating the

use of pointer arithmetic:

//: C03:PointerArithmetic.cpp

#include <iostream>

using namespace std;

206

Thinking in C++

#define P(EX) cout << #EX << ": " << EX << endl;

int main() {

int a[10];

for(int i = 0; i < 10; i++)

a[i] = i; // Give it index values

int* ip = a;

P(*ip);

P(*++ip);

P(*(ip + 5));

int* ip2 = ip + 5;

P(*ip2);

P(*(ip2 - 4));

P(*--ip2);

P(ip2 - ip); // Yields number of elements

} ///:~

It begins with another macro, but this one uses a preprocessor

feature called stringizing (implemented with the `#' sign before an

expression) that takes any expression and turns it into a character

array. This is quite convenient, since it allows the expression to be

printed, followed by a colon, followed by the value of the

expression. In main( ) you can see the useful shorthand that is

produced.

Although pre- and postfix versions of ++ and -- are valid with

pointers, only the prefix versions are used in this example because

they are applied before the pointers are dereferenced in the

expressions above, so they allow us to see the effects of the

operations. Note that only integral values are being added and

subtracted; if two pointers were combined this way the compiler

would not allow it.

Here is the output of the program above:

*ip: 0

*++ip: 1

*(ip + 5): 6

*ip2: 6

*(ip2 - 4): 2

*--ip2: 5

3: The C in C++

207

In all cases, the pointer arithmetic results in the pointer being

adjusted to point to the "right place," based on the size of the

elements being pointed to.

If pointer arithmetic seems a bit overwhelming at first, don't worry.

Most of the time you'll only need to create arrays and index into

them with [ ], and the most sophisticated pointer arithmetic you'll

usually need is ++ and --. Pointer arithmetic is generally reserved

for more clever and complex programs, and many of the containers

in the Standard C++ library hide most of these clever details so you

don't have to worry about them.

Debugging hints

In an ideal environment, you have an excellent debugger available

that easily makes the behavior of your program transparent so you

can quickly discover errors. However, most debuggers have blind

spots, and these will require you to embed code snippets in your

program to help you understand what's going on. In addition, you

may be developing in an environment (such as an embedded

system, which is where I spent my formative years) that has no

debugger available, and perhaps very limited feedback (i.e. a one-

line LED display). In these cases you become creative in the ways

you discover and display information about the execution of your

program. This section suggests some techniques for doing this.

Debugging flags

If you hard-wire debugging code into a program, you can run into

problems. You start to get too much information, which makes the

bugs difficult to isolate. When you think you've found the bug you

start tearing out debugging code, only to find you need to put it

back in again. You can solve these problems with two types of

flags: preprocessor debugging flags and runtime debugging flags.

208

Thinking in C++

Preprocessor debugging flags

By using the preprocessor to #define one or more debugging flags

(preferably in a header file), you can test a flag using an #ifdef

statement and conditionally include debugging code. When you

think your debugging is finished, you can simply #undef the

flag(s) and the code will automatically be removed (and you'll

reduce the size and runtime overhead of your executable file).

It is best to decide on names for debugging flags before you begin

building your project so the names will be consistent. Preprocessor

flags are traditionally distinguished from variables by writing them

in all upper case. A common flag name is simply DEBUG (but be

careful you don't use NDEBUG, which is reserved in C). The

sequence of statements might be:

#define DEBUG // Probably in a header file

//...

#ifdef DEBUG // Check to see if flag is defined

/* debugging code here */

#endif // DEBUG

Most C and C++ implementations will also let you #define and

#undef flags from the compiler command line, so you can re-

compile code and insert debugging information with a single

command (preferably via the makefile, a tool that will be described

shortly). Check your local documentation for details.

Runtime debugging flags

In some situations it is more convenient to turn debugging flags on

and off during program execution, especially by setting them when

the program starts up using the command line. Large programs are

tedious to recompile just to insert debugging code.

To turn debugging code on and off dynamically, create bool flags:

//: C03:DynamicDebugFlags.cpp

#include <iostream>

#include <string>

using namespace std;

3: The C in C++

209

// Debug flags aren't necessarily global:

bool debug = false;

int main(int argc, char* argv[]) {

for(int i = 0; i < argc; i++)

if(string(argv[i]) == "--debug=on")

debug = true;

bool go = true;

while(go) {

if(debug) {

// Debugging code here

cout << "Debugger is now on!" << endl;

} else {

cout << "Debugger is now off." << endl;

}

cout << "Turn debugger [on/off/quit]: ";

string reply;

cin >> reply;

if(reply == "on") debug = true; // Turn it on

if(reply == "off") debug = false; // Off

if(reply == "quit") break; // Out of 'while'

}

} ///:~

This program continues to allow you to turn the debugging flag on

and off until you type "quit" to tell it you want to exit. Notice it

requires that full words are typed in, not just letters (you can

shorten it to letter if you wish). Also, a command-line argument can

optionally be used to turn debugging on at startup this argument

can appear anyplace in the command line, since the startup code in

main( ) looks at all the arguments. The testing is quite simple

because of the expression:

string(argv[i])

This takes the argv[i] character array and creates a string, which

then can be easily compared to the right-hand side of the ==. The

program above searches for the entire string --debug=on You can

also look for --debug=and then see what's after that, to provide

more options. Volume 2 (available from )

devotes a chapter to the Standard C++ string class.

210

Thinking in C++

Although a debugging flag is one of the relatively few areas where

it makes a lot of sense to use a global variable, there's nothing that

says it must be that way. Notice that the variable is in lower case

letters to remind the reader it isn't a preprocessor flag.

Turning variables and expressions into strings

When writing debugging code, it is tedious to write print

expressions consisting of a character array containing the variable

name, followed by the variable. Fortunately, Standard C includes

the stringize operator `#', which was used earlier in this chapter.

When you put a # before an argument in a preprocessor macro, the

preprocessor turns that argument into a character array. This,

combined with the fact that character arrays with no intervening

punctuation are concatenated into a single character array, allows

you to make a very convenient macro for printing the values of

variables during debugging:

#define PR(x) cout << #x " = " << x << "\n";

If you print the variable a by calling the macro PR(a), it will have

the same effect as the code:

cout << "a = " << a << "\n";

This same process works with entire expressions. The following

program uses a macro to create a shorthand that prints the

stringized expression and then evaluates the expression and prints

the result:

//: C03:StringizingExpressions.cpp

#include <iostream>

using namespace std;

#define P(A) cout << #A << ": " << (A) << endl;

int main() {

int a = 1, b = 2, c = 3;

P(a); P(b); P(c);

P(a + b);

3: The C in C++

211

P((c - a)/b);

} ///:~

You can see how a technique like this can quickly become

indispensable, especially if you have no debugger (or must use

multiple development environments). You can also insert an #ifdef

to cause P(A) to be defined as "nothing" when you want to strip

out debugging.

The C assert( ) macro

In the standard header file <cassert>you'll find assert( ) which is a

convenient debugging macro. When you use assert( ) you give it

an argument that is an expression you are "asserting to be true."

The preprocessor generates code that will test the assertion. If the

assertion isn't true, the program will stop after issuing an error

message telling you what the assertion was and that it failed.

Here's a trivial example:

//: C03:Assert.cpp

// Use of the assert() debugging macro

#include <cassert> // Contains the macro

using namespace std;

int main() {

int i = 100;

assert(i != 100); // Fails

} ///:~

The macro originated in Standard C, so it's also available in the

header file assert.h

When you are finished debugging, you can remove the code

generated by the macro by placing the line:

#define NDEBUG

in the program before the inclusion of <cassert> or by defining

NDEBUG on the compiler command line. NDEBUG is a flag used

in <cassert>to change the way code is generated by the macros.

212

Thinking in C++

Later in this book, you'll see some more sophisticated alternatives

to assert( )

Function addresses

Once a function is compiled and loaded into the computer to be

executed, it occupies a chunk of memory. That memory, and thus

the function, has an address.

C has never been a language to bar entry where others fear to tread.

You can use function addresses with pointers just as you can use

variable addresses. The declaration and use of function pointers

looks a bit opaque at first, but it follows the format of the rest of the

language.

Defining a function pointer

To define a pointer to a function that has no arguments and no

return value, you say:

void (*funcPtr)();

When you are looking at a complex definition like this, the best

way to attack it is to start in the middle and work your way out.

"Starting in the middle" means starting at the variable name, which

is funcPtr. "Working your way out" means looking to the right for

the nearest item (nothing in this case; the right parenthesis stops

you short), then looking to the left (a pointer denoted by the

asterisk), then looking to the right (an empty argument list

indicating a function that takes no arguments), then looking to the

left (void, which indicates the function has no return value). This

right-left-right motion works with most declarations.

To review, "start in the middle" ("funcPtr is a ..."), go to the right

(nothing there you're stopped by the right parenthesis), go to the

left and find the `*' ("... pointer to a ..."), go to the right and find the

empty argument list ("... function that takes no arguments ... "), go

3: The C in C++

213

to the left and find the void ("funcPtr is a pointer to a function that

takes no arguments and returns void").

You may wonder why *funcPtrrequires parentheses. If you didn't

use them, the compiler would see:

void *funcPtr();

You would be declaring a function (that returns a void*) rather

than defining a variable. You can think of the compiler as going

through the same process you do when it figures out what a

declaration or definition is supposed to be. It needs those

parentheses to "bump up against" so it goes back to the left and

finds the `*', instead of continuing to the right and finding the

empty argument list.

Complicated declarations & definitions

As an aside, once you figure out how the C and C++ declaration

syntax works you can create much more complicated items. For

instance:

//: C03:ComplicatedDefinitions.cpp

/* 1. */

void * (*(*fp1)(int))[10];

/* 2. */

float (*(*fp2)(int,int,float))(int);

/* 3. */

typedef double (*(*(*fp3)())[10])();

fp3 a;

/* 4. */

int (*(*f4())[10])();

int main() {} ///:~

Walk through each one and use the right-left guideline to figure it

out. Number 1 says "fp1 is a pointer to a function that takes an

integer argument and returns a pointer to an array of 10 void

pointers."

214

Thinking in C++

Number 2 says "fp2 is a pointer to a function that takes three

arguments (int, int, and float) and returns a pointer to a function

that takes an integer argument and returns a float."

If you are creating a lot of complicated definitions, you might want

to use a typedef. Number 3 shows how a typedef saves typing the

complicated description every time. It says "An fp3 is a pointer to a

function that takes no arguments and returns a pointer to an array

of 10 pointers to functions that take no arguments and return

doubles." Then it says "a is one of these fp3 types." typedef is

generally useful for building complicated descriptions from simple

ones.

Number 4 is a function declaration instead of a variable definition.

It says "f4 is a function that returns a pointer to an array of 10

pointers to functions that return integers."

You will rarely if ever need such complicated declarations and

definitions as these. However, if you go through the exercise of

figuring them out you will not even be mildly disturbed with the

slightly complicated ones you may encounter in real life.

Using a function pointer

Once you define a pointer to a function, you must assign it to a

function address before you can use it. Just as the address of an

array arr[10] is produced by the array name without the brackets

(arr), the address of a function func() is produced by the function

name without the argument list (func). You can also use the more

explicit syntax &func(). To call the function, you dereference the

pointer in the same way that you declared it (remember that C and

C++ always try to make definitions look the same as the way they

are used). The following example shows how a pointer to a

function is defined and used:

//: C03:PointerToFunction.cpp

// Defining and using a pointer to a function

#include <iostream>

3: The C in C++

215

using namespace std;

void func() {

cout << "func() called..." << endl;

}

int main() {

void (*fp)(); // Define a function pointer

fp = func; // Initialize it

(*fp)();

// Dereferencing calls the function

void (*fp2)() = func; // Define and initialize

(*fp2)();

} ///:~

After the pointer to function fp is defined, it is assigned to the

address of a function func() using fp = func(notice the argument

list is missing on the function name). The second case shows

simultaneous definition and initialization.

Arrays of pointers to functions

One of the more interesting constructs you can create is an array of

pointers to functions. To select a function, you just index into the

array and dereference the pointer. This supports the concept of

table-driven code; instead of using conditionals or case statements,

you select functions to execute based on a state variable (or a

combination of state variables). This kind of design can be useful if

you often add or delete functions from the table (or if you want to

create or change such a table dynamically).

The following example creates some dummy functions using a

preprocessor macro, then creates an array of pointers to those

functions using automatic aggregate initialization. As you can see,

it is easy to add or remove functions from the table (and thus,

functionality from the program) by changing a small amount of

code:

//: C03:FunctionTable.cpp

// Using an array of pointers to functions

#include <iostream>

216

Thinking in C++

using namespace std;

// A macro to define dummy functions:

#define DF(N) void N() { \

cout << "function " #N " called..." << endl; }

DF(a); DF(b); DF(c); DF(d); DF(e); DF(f); DF(g);

void (*func_table[])() = { a, b, c, d, e, f, g };

int main() {

while(1) {

cout << "press a key from 'a' to 'g' "

"or q to quit" << endl;

char c, cr;

cin.get(c); cin.get(cr); // second one for CR

if ( c == 'q' )

break; // ... out of while(1)

if ( c < 'a' || c > 'g' )

continue;

(*func_table[c - 'a'])();

}

} ///:~

At this point, you might be able to imagine how this technique

could be useful when creating some sort of interpreter or list

processing program.

Make: managing separate

compilation

When using separate compilation (breaking code into a number of

translation units), you need some way to automatically compile

each file and to tell the linker to build all the pieces along with the

appropriate libraries and startup code into an executable file.

Most compilers allow you to do this with a single command-line

statement. For the GNU C++ compiler, for example, you might say

g++ SourceFile1.cpp SourceFile2.cpp

3: The C in C++

217

The problem with this approach is that the compiler will first

compile each individual file, regardless of whether that file needs to

be rebuilt or not. With many files in a project, it can become

prohibitive to recompile everything if you've changed only a single

file.

The solution to this problem, developed on Unix but available

everywhere in some form, is a program called make. The make

utility manages all the individual files in a project by following the

instructions in a text file called a makefile When you edit some of

the files in a project and type make, the make program follows the

guidelines in the makefileto compare the dates on the source code

files to the dates on the corresponding target files, and if a source

code file date is more recent than its target file, make invokes the

compiler on the source code file. make only recompiles the source

code files that were changed, and any other source-code files that

are affected by the modified files. By using make, you don't have to

re-compile all the files in your project every time you make a

change, nor do you have to check to see that everything was built

properly. The makefilecontains all the commands to put your

project together. Learning to use make will save you a lot of time

and frustration. You'll also discover that make is the typical way

that you install new software on a Linux/Unix machine (although

those makefile tend to be far more complicated than the ones

presented in this book, and you'll often automatically generate a

makefilefor your particular machine as part of the installation

process).

Because make is available in some form for virtually all C++

compilers (and even if it isn't, you can use freely-available makes

with any compiler), it will be the tool used throughout this book.

However, compiler vendors have also created their own project

building tools. These tools ask you which files are in your project

and determine all the relationships themselves. These tools use

something similar to a makefile generally called a project file, but

the programming environment maintains this file so you don't

218

Thinking in C++

have to worry about it. The configuration and use of project files

varies from one development environment to another, so you must

find the appropriate documentation on how to use them (although

project file tools provided by compiler vendors are usually so

simple to use that you can learn them by playing around my

favorite form of education).

The makefile used within this book should work even if you are

also using a specific vendor's project-building tool.

Make activities

When you type make (or whatever the name of your "make"

program happens to be), the make program looks in the current

directory for a file named makefile which you've created if it's

your project. This file lists dependencies between source code files.

make looks at the dates on files. If a dependent file has an older

date than a file it depends on, make executes the rule given after the

dependency.

All comments in makefile start with a # and continue to the end of

the line.

As a simple example, the makefilefor a program called "hello"

might contain:

# A comment

hello.exe: hello.cpp

mycompiler hello.cpp

This says that hello.exe(the target) depends on hello.cpp When

hello.cpphas a newer date than hello.exe make executes the

"rule" mycompiler hello.cppThere may be multiple dependencies

and multiple rules. Many make programs require that all the rules

begin with a tab. Other than that, whitespace is generally ignored

so you can format for readability.

3: The C in C++

219

The rules are not restricted to being calls to the compiler; you can

call any program you want from within make. By creating groups

of interdependent dependency-rule sets, you can modify your

source code files, type make and be certain that all the affected files

will be rebuilt correctly.

Macros

A makefilemay contain macros (note that these are completely

different from C/C++ preprocessor macros). Macros allow

convenient string replacement. The makefile in this book use a

macro to invoke the C++ compiler. For example,

CPP = mycompiler

hello.exe: hello.cpp

$(CPP) hello.cpp

The = is used to identify CPP as a macro, and the $ and parentheses

expand the macro. In this case, the expansion means that the macro

call $(CPP) will be replaced with the string mycompiler With the

macro above, if you want to change to a different compiler called

cpp, you just change the macro to:

CPP = cpp

You can also add compiler flags, etc., to the macro, or use separate

macros to add compiler flags.

Suffix Rules

It becomes tedious to tell make how to invoke the compiler for

every single cpp file in your project, when you know it's the same

basic process each time. Since make is designed to be a time-saver,

it also has a way to abbreviate actions, as long as they depend on

file name suffixes. These abbreviations are called suffix rules. A

suffix rule is the way to teach make how to convert a file with one

type of extension (.cpp, for example) into a file with another type of

extension (.obj or .exe). Once you teach make the rules for

producing one kind of file from another, all you have to do is tell

make which files depend on which other files. When make finds a

220

Thinking in C++

file with a date earlier than the file it depends on, it uses the rule to

create a new file.

The suffix rule tells make that it doesn't need explicit rules to build

everything, but instead it can figure out how to build things based

on their file extension. In this case it says "To build a file that ends

in exe from one that ends in cpp, invoke the following command."

Here's what it looks like for the example above:

CPP = mycompiler

.SUFFIXES: .exe .cpp

.cpp.exe:

$(CPP) $<

The .SUFFIXESdirective tells make that it should watch out for

any of the following file-name extensions because they have special

meaning for this particular makefile. Next you see the suffix rule

.cpp.exe,which says "Here's how to convert any file with an

extension of cpp to one with an extension of exe" (when the cpp file

is more recent than the exe file). As before, the $(CPP) macro is

used, but then you see something new: $<. Because this begins with

a `$' it's a macro, but this is one of make's special built-in macros.

The $< can be used only in suffix rules, and it means "whatever

prerequisite triggered the rule" (sometimes called the dependent),

which in this case translates to "the cpp file that needs to be

compiled."

Once the suffix rules have been set up, you can simply say, for

example, "make Union.exe and the suffix rule will kick in, even

though there's no mention of "Union" anywhere in the makefile

Default targets

After the macros and suffix rules, make looks for the first "target"

in a file, and builds that, unless you specify differently. So for the

following makefile

CPP = mycompiler

.SUFFIXES: .exe .cpp

.cpp.exe:

3: The C in C++

221

$(CPP) $<

target1.exe:

target2.exe:

If you just type `make', then target1.exewill be built (using the

default suffix rule) because that's the first target that make

encounters. To build target2.exeyou'd have to explicitly say `make

target2.exe This becomes tedious, so you normally create a default

"dummy" target that depends on all the rest of the targets, like this:

CPP = mycompiler

.SUFFIXES: .exe .cpp

.cpp.exe:

$(CPP) $<

all: target1.exe target2.exe

Here, `all' does not exist and there's no file called `all', so every

time you type make, the program sees `all' as the first target in the

list (and thus the default target), then it sees that `all' does not exist

so it had better make it by checking all the dependencies. So it looks

at target1.exeand (using the suffix rule) sees whether (1)

target1.exeexists and (2) whether target1.cppis more recent than

target1.exe and if so runs the suffix rule (if you provide an explicit

rule for a particular target, that rule is used instead). Then it moves

on to the next file in the default target list. Thus, by creating a

default target list (typically called `all' by convention, but you can

call it anything) you can cause every executable in your project to

be made simply by typing `make'. In addition, you can have other

non-default target lists that do other things for example, you

could set it up so that typing `make debug rebuilds all your files

with debugging wired in.

Makefiles in this book

Using the program ExtractCode.cppfrom Volume 2 of this book,

all the code listings in this book are automatically extracted from

the ASCII text version of this book and placed in subdirectories

according to their chapters. In addition, ExtractCode.cppcreates

several makefile in each subdirectory (with different names) so

222

Thinking in C++

you can simply move into that subdirectory and type make -f

mycompiler.makefile

(substituting the name of your compiler for

`mycompiler the `-f' flag says "use what follows as the

makefile Finally, ExtractCode.cppcreates a "master" makefile

").

in the root directory where the book's files have been expanded,

and this makefiledescends into each subdirectory and calls make

with the appropriate makefile This way you can compile all the

code in the book by invoking a single make command, and the

process will stop whenever your compiler is unable to handle a

particular file (note that a Standard C++ conforming compiler

should be able to compile all the files in this book). Because

implementations of make vary from system to system, only the

most basic, common features are used in the generated makefile

An example makefile

As mentioned, the code-extraction tool ExtractCode.cpp

automatically generates makefile for each chapter. Because of this,

the makefile for each chapter will not be placed in the book (all

the makefiles are packaged with the source code, which you can

download from ). However, it's useful to see an

example of a makefile What follows is a shortened version of the

one that was automatically generated for this chapter by the book's

extraction tool. You'll find more than one makefilein each

subdirectory (they have different names; you invoke a specific one

with `make -f'). This one is for GNU C++:

CPP = g++

OFLAG = -o

.SUFFIXES : .o .cpp .c

.cpp.o :

$(CPP) $(CPPFLAGS) -c $<

.c.o :

$(CPP) $(CPPFLAGS) -c $<

all: \

Return \

Declare \

Ifthen \

3: The C in C++

223

Guess \

Guess2

# Rest of the files for this chapter not shown

Return: Return.o

$(CPP) $(OFLAG)Return Return.o

Declare: Declare.o

$(CPP) $(OFLAG)Declare Declare.o

Ifthen: Ifthen.o

$(CPP) $(OFLAG)Ifthen Ifthen.o

Guess: Guess.o

$(CPP) $(OFLAG)Guess Guess.o

Guess2: Guess2.o

$(CPP) $(OFLAG)Guess2 Guess2.o

Return.o: Return.cpp

Declare.o: Declare.cpp

Ifthen.o: Ifthen.cpp

Guess.o: Guess.cpp

Guess2.o: Guess2.cpp

The macro CPP is set to the name of the compiler. To use a different

compiler, you can either edit the makefileor change the value of

the macro on the command line, like this:

make CPP=cpp

Note, however, that ExtractCode.cpphas an automatic scheme to

automatically build makefile for additional compilers.

The second macro OFLAG is the flag that's used to indicate the

name of the output file. Although many compilers automatically

assume the output file has the same base name as the input file,

others don't (such as Linux/Unix compilers, which default to

creating a file called a.out).

You can see that there are two suffix rules here, one for cpp files

and one for .c files (in case any C source code needs to be

224

Thinking in C++

compiled). The default target is all, and each line for this target is

"continued" by using the backslash, up until Guess2, which is the

last one in the list and thus has no backslash. There are many more

files in this chapter, but only these are shown here for the sake of

brevity.

The suffix rules take care of creating object files (with a .o

extension) from cpp files, but in general you need to explicitly state

rules for creating the executable, because normally an executable is

created by linking many different object files and make cannot

guess what those are. Also, in this case (Linux/Unix) there is no

standard extension for executables so a suffix rule won't work for

these simple situations. Thus, you see all the rules for building the

final executables explicitly stated.

This makefiletakes the absolute safest route of using as few make

features as possible; it only uses the basic make concepts of targets

and dependencies, as well as macros. This way it is virtually

assured of working with as many make programs as possible. It

tends to produce a larger makefile but that's not so bad since it's

automatically generated by ExtractCode.cpp

There are lots of other make features that this book will not use, as

well as newer and cleverer versions and variations of make with

advanced shortcuts that can save a lot of time. Your local

documentation may describe the further features of your particular

make, and you can learn more about make from Managing Projects

with Make by Oram and Talbott (O'Reilly, 1993). Also, if your

compiler vendor does not supply a make or it uses a non-standard

make, you can find GNU make for virtually any platform in

existence by searching the Internet for GNU archives (of which

there are many).

3: The C in C++

225

Summary

This chapter was a fairly intense tour through all the fundamental

features of C++ syntax, most of which are inherited from and in

common with C (and result in C++'s vaunted backwards

compatibility with C). Although some C++ features were

introduced here, this tour is primarily intended for people who are

conversant in programming, and simply need to be given an

introduction to the syntax basics of C and C++. If you're already a

C programmer, you may have even seen one or two things about C

here that were unfamiliar, aside from the C++ features that were

most likely new to you. However, if this chapter has still seemed a

bit overwhelming, you should go through the CD ROM course

Thinking in C: Foundations for C++ and Java (which contains lectures,

exercises, and guided solutions), which is bound into this book, and

also available at .

Exercises

Solutions to selected exercises can be found in the electronic document The Thinking in C++ Annotated

Solution Guide, available for a small fee from .

Create a header file (with an extension of `.h'). In this file,

declare a group of functions by varying the argument

lists and return values from among the following: void,

char, int, and float. Now create a .cpp file that includes

your header file and creates definitions for all of these

functions. Each definition should simply print out the

function name, argument list, and return type so you

know it's been called. Create a second .cpp file that

includes your header file and defines int main( )

containing calls to all of your functions. Compile and run

your program.

Write a program that uses two nested for loops and the

modulus operator (%) to detect and print prime numbers

(integral numbers that are not evenly divisible by any

other numbers except for themselves and 1).

226

Thinking in C++

Write a program that uses a while loop to read words

from standard input (cin) into a string. This is an

"infinite" while loop, which you break out of (and exit

the program) using a break statement. For each word

that is read, evaluate it by first using a sequence of if

statements to "map" an integral value to the word, and

then use a switch statement that uses that integral value

as its selector (this sequence of events is not meant to be

good programming style; it's just supposed to give you

exercise with control flow). Inside each case, print

something meaningful. You must decide what the

"interesting" words are and what the meaning is. You

must also decide what word will signal the end of the

program. Test the program by redirecting a file into the

program's standard input (if you want to save typing,

this file can be your program's source file).

Modify Menu.cppto use switch statements instead of if

statements.

Write a program that evaluates the two expressions in

the section labeled "precedence."

Modify YourPets2.cppso that it uses various different

data types (char, int, float, double, and their variants).

Run the program and create a map of the resulting

memory layout. If you have access to more than one kind

of machine, operating system, or compiler, try this

experiment with as many variations as you can manage.

Create two functions, one that takes a string* and one

that takes a string&. Each of these functions should

modify the outside string object in its own unique way.

In main( ), create and initialize a string object, print it,

then pass it to each of the two functions, printing the

results.

Write a program that uses all the trigraphs to see if your

compiler supports them.

3: The C in C++

227

Compile and run Static.cpp Remove the static keyword

from the code, compile and run it again, and explain

what happens.

10.

Try to compile and link FileStatic.cppwith

FileStatic2.cpp What does the resulting error message

mean?

11.

Modify Boolean.cppso that it works with double values

instead of ints.

12.

Modify Boolean.cppand Bitwise.cppso they use the

explicit operators (if your compiler is conformant to the

C++ Standard it will support these).

13.

Modify Bitwise.cppto use the functions from

Rotation.cpp Make sure you display the results in such a

way that it's clear what's happening during rotations.

14.

Modify Ifthen.cppto use the ternary if-else operator (?:).

15.

Create a struct that holds two string objects and one int.

Use a typedef for the struct name. Create an instance of

the struct, initialize all three values in your instance, and

print them out. Take the address of your instance and

assign it to a pointer to your struct type. Change the

three values in your instance and print them out, all

using the pointer.

16.

Create a program that uses an enumeration of colors.

Create a variable of this enum type and print out all the

numbers that correspond with the color names, using a

for loop.

17.

Experiment with Union.cppby removing various union

elements to see the effects on the size of the resulting

union. Try assigning to one element (thus one type) of

the union and printing out a via a different element (thus

a different type) to see what happens.

18.

Create a program that defines two int arrays, one right

after the other. Index off the end of the first array into the

second, and make an assignment. Print out the second

array to see the changes cause by this. Now try defining a

228

Thinking in C++

char variable between the first array definition and the

second, and repeat the experiment. You may want to

create an array printing function to simplify your coding.

19.

Modify ArrayAddresses.cpp work with the data types

char, long int float, and double.

20.

Apply the technique in ArrayAddresses.cpp print out

the size of the struct and the addresses of the array

elements in StructArray.cpp

21.

Create an array of string objects and assign a string to

each element. Print out the array using a for loop.

22.

Create two new programs starting from ArgsToInts.cpp

so they use atol( ) and atof( ), respectively.

23.

Modify PointerIncrement2.cpp it uses a union instead

of a struct.

24.

Modify PointerArithmetic.cpp work with long and

long double

25.

Define a float variable. Take its address, cast that address

to an unsigned char and assign it to an unsigned char

pointer. Using this pointer and [ ], index into the float

variable and use the printBinary( )function defined in

this chapter to print out a map of the float (go from 0 to

sizeof(float) Change the value of the float and see if

you can figure out what's going on (the float contains

encoded data).

26.

Define an array of int. Take the starting address of that

array and use static_castto convert it into an void*.

Write a function that takes a void*, a number (indicating

a number of bytes), and a value (indicating the value to

which each byte should be set) as arguments. The

function should set each byte in the specified range to the

specified value. Try out the function on your array of int.

27.

Create a const array of double and a volatilearray of

double. Index through each array and use const_castto

cast each element to non-const and non-volatile

respectively, and assign a value to each element.

3: The C in C++

229

28.

Create a function that takes a pointer to an array of

double and a value indicating the size of that array. The

function should print each element in the array. Now

create an array of double and initialize each element to

zero, then use your function to print the array. Next use

reinterpret_cast cast the starting address of your array

to an unsigned char* and set each byte of the array to 1

(hint: you'll need to use sizeof to calculate the number of

bytes in a double). Now use your array-printing function

to print the results. Why do you think each element was

not set to the value 1.0?

29.

(Challenging) Modify FloatingAsBinary.cpp that it

prints out each part of the double as a separate group of

bits. You'll have to replace the calls to printBinary( )with

your own specialized code (which you can derive from

printBinary( ) in order to do this, and you'll also have to

look up and understand the floating-point format along

with the byte ordering for your compiler (this is the

challenging part).

30.

Create a makefile that not only compiles YourPets1.cpp

and YourPets2.cpp(for your particular compiler) but

also executes both programs as part of the default target

behavior. Make sure you use suffix rules.

31.

Modify StringizingExpressions.cpp that P(A) is

conditionally #ifdefed to allow the debugging code to be

automatically stripped out by setting a command-line

flag. You will need to consult your compiler's

documentation to see how to define and undefine

preprocessor values on the compiler command line.

32.

Define a function that takes a double argument and

returns an int. Create and initialize a pointer to this

function, and call the function through your pointer.

33.

Declare a pointer to a function taking an int argument

and returning a pointer to a function that takes a char

argument and returns a float.

230

Thinking in C++

34.

Modify FunctionTable.cpp that each function returns

a string (instead of printing out a message) and so that

this value is printed inside of main( ).

35.

Create a makefilefor one of the previous exercises (of

your choice) that allows you to type make for a

production build of the program, and make debugfor a

build of the program including debugging information.

3: The C in C++

231

232

Table of Contents:
