protected static class PDestination

implements Destination {

private String label;

private PDestination(String whereTo) {

label = whereTo;

}

public String readLabel() { return label; }

// Static inner classes can contain

// other static elements:

public static void f() {}

static int x = 10;

static class AnotherLevel {

public static void f() {}

static int x = 10;

}

public static Destination dest(String s) {

return new PDestination(s);

}

public static Contents cont() {

return new PContents();

}

public static void main(String[] args) {

Contents c = cont();

Destination d = dest("Tanzania");

}

} ///:~

In main( ), no object of Parcel10 is necessary; instead you use the

normal syntax for selecting a static member to call the methods that

return references to Contents and Destination.

As you will see shortly, in an ordinary (non-static) inner class, the link to

the outer class object is achieved with a special this reference. A static

inner class does not have this special this reference, which makes it

analogous to a static method.

Normally you can't put any code inside an interface, but a static inner

class can be part of an interface. Since the class is static it doesn't

violate the rules for interfaces--the static inner class is only placed inside

the namespace of the interface:

380

Thinking in Java

//: c08:IInterface.java

// Static inner classes inside interfaces.

interface IInterface {

static class Inner {

int i, j, k;

public Inner() {}

void f() {}

}

} ///:~

Earlier in this book I suggested putting a main( ) in every class to act as a

test bed for that class. One drawback to this is the amount of extra

compiled code you must carry around. If this is a problem, you can use a

static inner class to hold your test code:

//: c08:TestBed.java

// Putting test code in a static inner class.

class TestBed {

TestBed() {}

void f() { System.out.println("f()"); }

public static class Tester {

public static void main(String[] args) {

TestBed t = new TestBed();

t.f();

}

} ///:~

This generates a separate class called TestBed$Tester (to run the

program, you say java TestBed$Tester). You can use this class for

testing, but you don't need to include it in your shipping product.

Referring to the outer class object

If you need to produce the reference to the outer class object, you name

the outer class followed by a dot and this. For example, in the class

Sequence.SSelector, any of its methods can produce the stored

reference to the outer class Sequence by saying Sequence.this. The

Chapter 8: Interfaces & Inner Classes

381

resulting reference is automatically the correct type. (This is known and

checked at compile-time, so there is no run-time overhead.)

Sometimes you want to tell some other object to create an object of one of

its inner classes. To do this you must provide a reference to the other

outer class object in the new expression, like this:

//: c08:Parcel11.java

// Creating instances of inner classes.

public class Parcel11 {

class Contents {

private int i = 11;

public int value() { return i; }

}

class Destination {

private String label;

Destination(String whereTo) {

label = whereTo;

}

String readLabel() { return label; }

}

public static void main(String[] args) {

Parcel11 p = new Parcel11();

// Must use instance of outer class

// to create an instances of the inner class:

Parcel11.Contents c = p.new Contents();

Parcel11.Destination d =

p.new Destination("Tanzania");

}

} ///:~

To create an object of the inner class directly, you don't follow the same

form and refer to the outer class name Parcel11 as you might expect, but

instead you must use an object of the outer class to make an object of the

inner class:

Parcel11.Contents c = p.new Contents();

Thus, it's not possible to create an object of the inner class unless you

already have an object of the outer class. This is because the object of the

inner class is quietly connected to the object of the outer class that it was

382

Thinking in Java

made from. However, if you make a static inner class, then it doesn't

need a reference to the outer class object.

Reaching outward from a multiply-

nested class

4It

doesn't matter how deeply an inner class may be nested--it can

transparently access all of the members of all the classes it is nested

within, as seen here:

//: c08:MultiNestingAccess.java

// Nested classes can access all members of all

// levels of the classes they are nested within.

class MNA {

private void f() {}

class A {

private void g() {}

public class B {

void h() {

g();

f();

}

public class MultiNestingAccess {

public static void main(String[] args) {

MNA mna = new MNA();

MNA.A mnaa = mna.new A();

MNA.A.B mnaab = mnaa.new B();

mnaab.h();

}

} ///:~

4 Thanks again to Martin Danner.

Chapter 8: Interfaces & Inner Classes

383

You can see that in MNA.A.B, the methods g( ) and f( ) are callable

without any qualification (despite the fact that they are private). This

example also demonstrates the syntax necessary to create objects of

multiply-nested inner classes when you create the objects in a different

class. The ".new" syntax produces the correct scope so you do not have to

qualify the class name in the constructor call.

Inheriting from inner classes

Because the inner class constructor must attach to a reference of the

enclosing class object, things are slightly complicated when you inherit

from an inner class. The problem is that the "secret" reference to the

enclosing class object must be initialized, and yet in the derived class

there's no longer a default object to attach to. The answer is to use a

syntax provided to make the association explicit:

//: c08:InheritInner.java

// Inheriting an inner class.

class WithInner {

class Inner {}

}

public class InheritInner

extends WithInner.Inner {

//! InheritInner() {} // Won't compile

InheritInner(WithInner wi) {

wi.super();

}

public static void main(String[] args) {

WithInner wi = new WithInner();

InheritInner ii = new InheritInner(wi);

}

} ///:~

You can see that InheritInner is extending only the inner class, not the

outer one. But when it comes time to create a constructor, the default one

is no good and you can't just pass a reference to an enclosing object. In

addition, you must use the syntax

enclosingClassReference.super();

384

Thinking in Java

inside the constructor. This provides the necessary reference and the

program will then compile.

Can inner classes be overridden?

What happens when you create an inner class, then inherit from the

enclosing class and redefine the inner class? That is, is it possible to

override an inner class? This seems like it would be a powerful concept,

but "overriding" an inner class as if it were another method of the outer

class doesn't really do anything:

//: c08:BigEgg.java

// An inner class cannot be overriden

// like a method.

class Egg {

protected class Yolk {

public Yolk() {

System.out.println("Egg.Yolk()");

}

private Yolk y;

public Egg() {

System.out.println("New Egg()");

y = new Yolk();

}

public class BigEgg extends Egg {

public class Yolk {

public Yolk() {

System.out.println("BigEgg.Yolk()");

}

public static void main(String[] args) {

new BigEgg();

}

} ///:~

The default constructor is synthesized automatically by the compiler, and

this calls the base-class default constructor. You might think that since a

Chapter 8: Interfaces & Inner Classes

385

BigEgg is being created, the "overridden" version of Yolk would be used,

but this is not the case. The output is:

New Egg()

Egg.Yolk()

This example simply shows that there isn't any extra inner class magic

going on when you inherit from the outer class. The two inner classes are

completely separate entities, each in their own namespace. However, it's

still possible to explicitly inherit from the inner class:

//: c08:BigEgg2.java

// Proper inheritance of an inner class.

class Egg2 {

protected class Yolk {

public Yolk() {

System.out.println("Egg2.Yolk()");

}

public void f() {

System.out.println("Egg2.Yolk.f()");

}

private Yolk y = new Yolk();

public Egg2() {

System.out.println("New Egg2()");

}

public void insertYolk(Yolk yy) { y = yy; }

public void g() { y.f(); }

}

public class BigEgg2 extends Egg2 {

public class Yolk extends Egg2.Yolk {

public Yolk() {

System.out.println("BigEgg2.Yolk()");

}

public void f() {

System.out.println("BigEgg2.Yolk.f()");

}

public BigEgg2() { insertYolk(new Yolk()); }

public static void main(String[] args) {

386

Thinking in Java

Egg2 e2 = new BigEgg2();

e2.g();

}

} ///:~

Now BigEgg2.Yolk explicitly extends Egg2.Yolk and overrides its

methods. The method insertYolk( ) allows BigEgg2 to upcast one of its

own Yolk objects into the y reference in Egg2, so when g( ) calls y.f( )

the overridden version of f( ) is used. The output is:

Egg2.Yolk()

New Egg2()

Egg2.Yolk()

BigEgg2.Yolk()

BigEgg2.Yolk.f()

The second call to Egg2.Yolk( ) is the base-class constructor call of the

BigEgg2.Yolk constructor. You can see that the overridden version of

f( ) is used when g( ) is called.

Inner class identifiers

Since every class produces a .class file that holds all the information

about how to create objects of this type (this information produces a

"meta-class" called the Class object), you might guess that inner classes

must also produce .class files to contain the information for their Class

objects. The names of these files/classes have a strict formula: the name

of the enclosing class, followed by a `$', followed by the name of the inner

class. For example, the .class files created by InheritInner.java

include:

InheritInner.class

WithInner$Inner.class

WithInner.class

If inner classes are anonymous, the compiler simply starts generating

numbers as inner class identifiers. If inner classes are nested within inner

classes, their names are simply appended after a `$' and the outer class

identifier(s).

Chapter 8: Interfaces & Inner Classes

387

Although this scheme of generating internal names is simple and

straightforward, it's also robust and handles most situations5. Since it is

the standard naming scheme for Java, the generated files are

automatically platform-independent. (Note that the Java compiler is

changing your inner classes in all sorts of other ways in order to make

them work.)

Why inner classes?

At this point you've seen a lot of syntax and semantics describing the way

inner classes work, but this doesn't answer the question of why they exist.

Why did Sun go to so much trouble to add this fundamental language

feature?

Typically, the inner class inherits from a class or implements an

interface, and the code in the inner class manipulates the outer class

object that it was created within. So you could say that an inner class

provides a kind of window into the outer class.

A question that cuts to the heart of inner classes is this: if I just need a

reference to an interface, why don't I just make the outer class

implement that interface? The answer is "If that's all you need, then

that's how you should do it." So what is it that distinguishes an inner class

implementing an interface from an outer class implementing the same

interface? The answer is that you can't always have the convenience of

interfaces--sometimes you're working with implementations. So the

most compelling reason for inner classes is:

Each inner class can independently inherit from an implementation.

Thus, the inner class is not limited by whether the outer class is

already inheriting from an implementation.

Without the ability that inner classes provide to inherit--in effect--from

more than one concrete or abstract class, some design and programming

problems would be intractable. So one way to look at the inner class is as

5 On the other hand, `$' is a meta-character to the Unix shell and so you'll sometimes have

trouble when listing the .class files. This is a bit strange coming from Sun, a Unix-based

company. My guess is that they weren't considering this issue, but instead thought you'd

naturally focus on the source-code files.

388

Thinking in Java

the completion of the solution of the multiple-inheritance problem.

Interfaces solve part of the problem, but inner classes effectively allow

"multiple implementation inheritance." That is, inner classes effectively

allow you to inherit from more than one non-interface.

To see this in more detail, consider a situation where you have two

interfaces that must somehow be implemented within a class. Because of

the flexibility of interfaces, you have two choices: a single class or an inner

class:

//: c08:MultiInterfaces.java

// Two ways that a class can

// implement multiple interfaces.

interface A {}

interface B {}

class X implements A, B {}

class Y implements A {

B makeB() {

// Anonymous inner class:

return new B() {};

}

public class MultiInterfaces {

static void takesA(A a) {}

static void takesB(B b) {}

public static void main(String[] args) {

X x = new X();

Y y = new Y();

takesA(x);

takesA(y);

takesB(x);

takesB(y.makeB());

}

} ///:~

Of course, this assumes that the structure of your code makes logical

sense either way. However, you'll ordinarily have some kind of guidance

Chapter 8: Interfaces & Inner Classes

389

from the nature of the problem about whether to use a single class or an

inner class. But without any other constraints, in the above example the

approach you take doesn't really make much difference from an

implementation standpoint. Both of them work.

However, if you have abstract or concrete classes instead of interfaces,

you are suddenly limited to using inner classes if your class must

somehow implement both of the others:

//: c08:MultiImplementation.java

// With concrete or abstract classes, inner

// classes are the only way to produce the effect

// of "multiple implementation inheritance."

class C {}

abstract class D {}

class Z extends C {

D makeD() { return new D() {}; }

}

public class MultiImplementation {

static void takesC(C c) {}

static void takesD(D d) {}

public static void main(String[] args) {

Z z = new Z();

takesC(z);

takesD(z.makeD());

}

} ///:~

If you didn't need to solve the "multiple implementation inheritance"

problem, you could conceivably code around everything else without the

need for inner classes. But with inner classes you have these additional

features:

The inner class can have multiple instances, each with its own state

information that is independent of the information in the outer

class object.

390

Thinking in Java

In a single outer class you can have several inner classes, each of

which implement the same interface or inherit from the same

class in a different way. An example of this will be shown shortly.

The point of creation of the inner class object is not tied to the

creation of the outer class object.

There is no potentially confusing "is-a" relationship with the inner

class; it's a separate entity.

As an example, if Sequence.java did not use inner classes, you'd have to

say "a Sequence is a Selector," and you'd only be able to have one

Selector in existence for a particular Sequence. Also, you can have a

second method, getRSelector( ), that produces a Selector that moves

backward through the sequence. This kind of flexibility is only available

with inner classes.

Closures & Callbacks

A closure is a callable object that retains information from the scope in

which it was created. From this definition, you can see that an inner class

is an object-oriented closure, because it doesn't just contain each piece of

information from the outer class object ("the scope in which it was

created"), but it automatically holds a reference back to the whole outer

class object, where it has permission to manipulate all the members, even

private ones.

One of the most compelling arguments made to include some kind of

pointer mechanism in Java was to allow callbacks. With a callback, some

other object is given a piece of information that allows it to call back into

the originating object at some later point. This is a very powerful concept,

as you will see in Chapters 13 and 16. If a callback is implemented using a

pointer, however, you must rely on the programmer to behave and not

misuse the pointer. As you've seen by now, Java tends to be more careful

than that, so pointers were not included in the language.

The closure provided by the inner class is a perfect solution; more flexible

and far safer than a pointer. Here's a simple example:

//: c08:Callbacks.java

// Using inner classes for callbacks

Chapter 8: Interfaces & Inner Classes

391

interface Incrementable {

void increment();

}

// Very simple to just implement the interface:

class Callee1 implements Incrementable {

private int i = 0;

public void increment() {

i++;

System.out.println(i);

}

class MyIncrement {

public void increment() {

System.out.println("Other operation");

}

public static void f(MyIncrement mi) {

mi.increment();

}

// If your class must implement increment() in

// some other way, you must use an inner class:

class Callee2 extends MyIncrement {

private int i = 0;

private void incr() {

i++;

System.out.println(i);

}

private class Closure implements Incrementable {

public void increment() { incr(); }

}

Incrementable getCallbackReference() {

return new Closure();

}

class Caller {

private Incrementable callbackReference;

392

Thinking in Java

Caller(Incrementable cbh) {

callbackReference = cbh;

}

void go() {

callbackReference.increment();

}

public class Callbacks {

public static void main(String[] args) {

Callee1 c1 = new Callee1();

Callee2 c2 = new Callee2();

MyIncrement.f(c2);

Caller caller1 = new Caller(c1);

Caller caller2 =

new Caller(c2.getCallbackReference());

caller1.go();

caller2.go();

}

} ///:~

This example also provides a further distinction between implementing

an interface in an outer class vs. doing so in an inner class. Callee1 is

clearly the simpler solution in terms of the code. Callee2 inherits from

MyIncrement which already has a different increment( ) method

which does something unrelated to that which is expected by the

Incrementable interface. When MyIncrement is inherited into

Callee2, increment( ) can't be overridden for use by Incrementable,

so you're forced to provide a separate implementation using an inner

class. Also note that when you create an inner class you do not add to or

modify the interface of the outer class.

Notice that everything except getCallbackReference( ) in Callee2 is

private. To allow any connection to the outside world, the interface

Incrementable is essential. Here you can see how interfaces allow for

a complete separation of interface from implementation.

The inner class Closure simply implements Incrementable to provide

a hook back into Callee2--but a safe hook. Whoever gets the

Chapter 8: Interfaces & Inner Classes

393

Incrementable reference can, of course, only call increment( ) and

has no other abilities (unlike a pointer, which would allow you to run

wild).

Caller takes an Incrementable reference in its constructor (although

the capturing of the callback reference could happen at any time) and

then, sometime latter, uses the reference to "call back" into the Callee

class.

The value of the callback is in its flexibility--you can dynamically decide

what functions will be called at run-time. The benefit of this will become

more evident in Chapter 13, where callbacks are used everywhere to

implement graphical user interface (GUI) functionality.

Inner classes & control frameworks

A more concrete example of the use of inner classes can be found in

something that I will refer to here as a control framework.

An application framework is a class or a set of classes that's designed to

solve a particular type of problem. To apply an application framework,

you inherit from one or more classes and override some of the methods.

The code you write in the overridden methods customizes the general

solution provided by that application framework, in order to solve your

specific problem. The control framework is a particular type of application

framework dominated by the need to respond to events; a system that

primarily responds to events is called an event-driven system. One of the

most important problems in application programming is the graphical

user interface (GUI), which is almost entirely event-driven. As you will see

in Chapter 13, the Java Swing library is a control framework that elegantly

solves the GUI problem and that heavily uses inner classes.

To see how inner classes allow the simple creation and use of control

frameworks, consider a control framework whose job is to execute events

whenever those events are "ready." Although "ready" could mean

anything, in this case the default will be based on clock time. What follows

is a control framework that contains no specific information about what

it's controlling. First, here is the interface that describes any control event.

It's an abstract class instead of an actual interface because the default

394

Thinking in Java

behavior is to perform the control based on time, so some of the

implementation can be included here:

//: c08:controller:Event.java

// The common methods for any control event.

package c08.controller;

abstract public class Event {

private long evtTime;

public Event(long eventTime) {

evtTime = eventTime;

}

public boolean ready() {

return System.currentTimeMillis() >= evtTime;

}

abstract public void action();

abstract public String description();

} ///:~

The constructor simply captures the time when you want the Event to

run, while ready( ) tells you when it's time to run it. Of course, ready( )

could be overridden in a derived class to base the Event on something

other than time.

action( ) is the method that's called when the Event is ready( ), and

description( ) gives textual information about the Event.

The following file contains the actual control framework that manages

and fires events. The first class is really just a "helper" class whose job is

to hold Event objects. You can replace it with any appropriate container,

and in Chapter 9 you'll discover other containers that will do the trick

without requiring you to write this extra code:

//: c08:controller:Controller.java

// Along with Event, the generic

// framework for all control systems:

package c08.controller;

// This is just a way to hold Event objects.

class EventSet {

private Event[] events = new Event[100];

private int index = 0;

Chapter 8: Interfaces & Inner Classes

395

private int next = 0;

public void add(Event e) {

if(index >= events.length)

return; // (In real life, throw exception)

events[index++] = e;

}

public Event getNext() {

boolean looped = false;

int start = next;

do {

next = (next + 1) % events.length;

// See if it has looped to the beginning:

if(start == next) looped = true;

// If it loops past start, the list

// is empty:

if((next == (start + 1) % events.length)

&& looped)

return null;

} while(events[next] == null);

return events[next];

}

public void removeCurrent() {

events[next] = null;

}

public class Controller {

private EventSet es = new EventSet();

public void addEvent(Event c) { es.add(c); }

public void run() {

Event e;

while((e = es.getNext()) != null) {

if(e.ready()) {

e.action();

System.out.println(e.description());

es.removeCurrent();

}

} ///:~

396

Thinking in Java

EventSet arbitrarily holds 100 Events. (If a "real" container from

Chapter 9 is used here you don't need to worry about its maximum size,

since it will resize itself). The index is used to keep track of the next

available space, and next is used when you're looking for the next Event

in the list, to see whether you've looped around. This is important during

a call to getNext( ), because Event objects are removed from the list

(using removeCurrent( )) once they're run, so getNext( ) will

encounter holes in the list as it moves through it.

Note that removeCurrent( ) doesn't just set some flag indicating that

the object is no longer in use. Instead, it sets the reference to null. This is

important because if the garbage collector sees a reference that's still in

use then it can't clean up the object. If you think your references might

hang around (as they would here), then it's a good idea to set them to null

to give the garbage collector permission to clean them up.

Controller is where the actual work goes on. It uses an EventSet to

hold its Event objects, and addEvent( ) allows you to add new events to

this list. But the important method is run( ). This method loops through

the EventSet, hunting for an Event object that's ready( ) to run. For

each one it finds ready( ), it calls the action( ) method, prints out the

description( ), and then removes the Event from the list.

Note that so far in this design you know nothing about exactly what an

Event does. And this is the crux of the design; how it "separates the

things that change from the things that stay the same." Or, to use my

term, the "vector of change" is the different actions of the various kinds of

Event objects, and you express different actions by creating different

Event subclasses.

This is where inner classes come into play. They allow two things:

To create the entire implementation of a control-framework

application in a single class, thereby encapsulating everything

that's unique about that implementation. Inner classes are used to

express the many different kinds of action( ) necessary to solve

the problem. In addition, the following example uses private inner

classes so the implementation is completely hidden and can be

changed with impunity.

Chapter 8: Interfaces & Inner Classes

397

Inner classes keep this implementation from becoming awkward,

since you're able to easily access any of the members in the outer

class. Without this ability the code might become unpleasant

enough that you'd end up seeking an alternative.

Consider a particular implementation of the control framework designed

to control greenhouse functions6. Each action is entirely different: turning

lights, water, and thermostats on and off, ringing bells, and restarting the

system. But the control framework is designed to easily isolate this

different code. Inner classes allow you to have multiple derived versions

of the same base class, Event, within a single class. For each type of

action you inherit a new Event inner class, and write the control code

inside of action( ).

As is typical with an application framework, the class

GreenhouseControls is inherited from Controller:

//: c08:GreenhouseControls.java

// This produces a specific application of the

// control system, all in a single class. Inner

// classes allow you to encapsulate different

// functionality for each type of event.

import c08.controller.*;

public class GreenhouseControls

extends Controller {

private boolean light = false;

private boolean water = false;

private String thermostat = "Day";

private class LightOn extends Event {

public LightOn(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here to

// physically turn on the light.

light = true;

6 For some reason this has always been a pleasing problem for me to solve; it came from

my earlier book C++ Inside & Out, but Java allows a much more elegant solution.

398

Thinking in Java

}

public String description() {

return "Light is on";

}

private class LightOff extends Event {

public LightOff(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here to

// physically turn off the light.

light = false;

}

public String description() {

return "Light is off";

}

private class WaterOn extends Event {

public WaterOn(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here

water = true;

}

public String description() {

return "Greenhouse water is on";

}

private class WaterOff extends Event {

public WaterOff(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here

water = false;

}

public String description() {

return "Greenhouse water is off";

}

Chapter 8: Interfaces & Inner Classes

399

}

private class ThermostatNight extends Event {

public ThermostatNight(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here

thermostat = "Night";

}

public String description() {

return "Thermostat on night setting";

}

private class ThermostatDay extends Event {

public ThermostatDay(long eventTime) {

super(eventTime);

}

public void action() {

// Put hardware control code here

thermostat = "Day";

}

public String description() {

return "Thermostat on day setting";

}

// An example of an action() that inserts a

// new one of itself into the event list:

private int rings;

private class Bell extends Event {

public Bell(long eventTime) {

super(eventTime);

}

public void action() {

// Ring every 2 seconds, 'rings' times:

System.out.println("Bing!");

if(--rings > 0)

addEvent(new Bell(

System.currentTimeMillis() + 2000));

}

public String description() {

return "Ring bell";

400

Thinking in Java

}

private class Restart extends Event {

public Restart(long eventTime) {

super(eventTime);

}

public void action() {

long tm = System.currentTimeMillis();

// Instead of hard-wiring, you could parse

// configuration information from a text

// file here:

rings = 5;

addEvent(new ThermostatNight(tm));

addEvent(new LightOn(tm + 1000));

addEvent(new LightOff(tm + 2000));

addEvent(new WaterOn(tm + 3000));

addEvent(new WaterOff(tm + 8000));

addEvent(new Bell(tm + 9000));

addEvent(new ThermostatDay(tm + 10000));

// Can even add a Restart object!

addEvent(new Restart(tm + 20000));

}

public String description() {

return "Restarting system";

}

public static void main(String[] args) {

GreenhouseControls gc =

new GreenhouseControls();

long tm = System.currentTimeMillis();

gc.addEvent(gc.new Restart(tm));

gc.run();

}

} ///:~

Note that light, water, thermostat, and rings all belong to the outer

class GreenhouseControls, and yet the inner classes can access those

fields without qualification or special permission. Also, most of the

action( ) methods involve some sort of hardware control, which would

most likely involve calls to non-Java code.

Chapter 8: Interfaces & Inner Classes

401

Most of the Event classes look similar, but Bell and Restart are special.

Bell rings, and if it hasn't yet rung enough times it adds a new Bell object

to the event list, so it will ring again later. Notice how inner classes almost

look like multiple inheritance: Bell has all the methods of Event and it

also appears to have all the methods of the outer class

GreenhouseControls.

Restart is responsible for initializing the system, so it adds all the

appropriate events. Of course, a more flexible way to accomplish this is to

avoid hard-coding the events and instead read them from a file. (An

exercise in Chapter 11 asks you to modify this example to do just that.)

Since Restart( ) is just another Event object, you can also add a

Restart object within Restart.action( ) so that the system regularly

restarts itself. And all you need to do in main( ) is create a

GreenhouseControls object and add a Restart object to get it going.

This example should move you a long way toward appreciating the value

of inner classes, especially when used within a control framework.

However, in Chapter 13 you'll see how elegantly inner classes are used to

describe the actions of a graphical user interface. By the time you finish

that chapter you should be fully convinced.

Summary

Interfaces and inner classes are more sophisticated concepts than what

you'll find in many OOP languages. For example, there's nothing like

them in C++. Together, they solve the same problem that C++ attempts to

solve with its multiple inheritance (MI) feature. However, MI in C++

turns out to be rather difficult to use, while Java interfaces and inner

classes are, by comparison, much more accessible.

Although the features themselves are reasonably straightforward, the use

of these features is a design issue, much the same as polymorphism. Over

time, you'll become better at recognizing situations where you should use

an interface, or an inner class, or both. But at this point in this book you

should at least be comfortable with the syntax and semantics. As you see

these language features in use you'll eventually internalize them.

402

Thinking in Java

Exercises

Solutions to selected exercises can be found in the electronic document The Thinking in Java

Annotated Solution Guide, available for a small fee from .

Prove that the fields in an interface are implicitly static and

final.

Create an interface containing three methods, in its own

package. Implement the interface in a different package.

Prove that all the methods in an interface are automatically

public.

In c07:Sandwich.java, create an interface called FastFood

(with appropriate methods) and change Sandwich so that it also

implements FastFood.

Create three interfaces, each with two methods. Inherit a new

interface from the three, adding a new method. Create a class by

implementing the new interface and also inheriting from a

concrete class. Now write four methods, each of which takes one of

the four interfaces as an argument. In main( ), create an object

of your class and pass it to each of the methods.

Modify Exercise 5 by creating an abstract class and inheriting

that into the derived class.

Modify Music5.java by adding a Playable interface. Remove

the play( ) declaration from Instrument. Add Playable to the

derived classes by including it in the implements list. Change

tune( ) so that it takes a Playable instead of an Instrument.

Change Exercise 6 in Chapter 7 so that Rodent is an interface.

In Adventure.java, add an interface called CanClimb,

following the form of the other interfaces.

10.

Write a program that imports and uses Month2.java.

11.

Following the example given in Month2.java, create an

enumeration of days of the week.

Chapter 8: Interfaces & Inner Classes

403

12.

Create an interface with at least one method, in its own package.

Create a class in a separate package. Add a protected inner class

that implements the interface. In a third package, inherit from

your class and, inside a method, return an object of the protected

inner class, upcasting to the interface during the return.

13.

Create an interface with at least one method, and implement that

interface by defining an inner class within a method, which

returns a reference to your interface.

14.

Repeat Exercise 13 but define the inner class within a scope within

a method.

15.

Repeat Exercise 13 using an anonymous inner class.

16.

Create a private inner class that implements a public interface.

Write a method that returns a reference to an instance of the

private inner class, upcast to the interface. Show that the inner

class is completely hidden by trying to downcast to it.

17.

Create a class with a nondefault constructor and no default

constructor. Create a second class that has a method which returns

a reference to the first class. Create the object to return by making

an anonymous inner class that inherits from the first class.

18.

Create a class with a private field and a private method. Create

an inner class with a method that modifies the outer class field and

calls the outer class method. In a second outer class method,

create an object of the inner class and call it's method, then show

the effect on the outer class object.

19.

Repeat Exercise 18 using an anonymous inner class.

20.

Create a class containing a static inner class. In main( ), create

an instance of the inner class.

21.

Create an interface containing a static inner class. Implement

this interface and create an instance of the inner class.

404

Thinking in Java

22.

Create a class containing an inner class that itself contains an

inner class. Repeat this using static inner classes. Note the names

of the .class files produced by the compiler.

23.

Create a class with an inner class. In a separate class, make an

instance of the inner class.

24.

Create a class with an inner class that has a nondefault

constructor. Create a second class with an inner class that inherits

from the first inner class.

25.

Repair the problem in WindError.java.

26.

Modify Sequence.java by adding a method getRSelector( )

that produces a different implementation of the Selector

interface that moves backward through the sequence from the

end to the beginning.

27.

Create an interface U with three methods. Create a class A with a

method that produces a reference to a U by building an

anonymous inner class. Create a second class B that contains an

array of U. B should have one method that accepts and stores a

reference to a U in the array, a second method that sets a reference

in the array (specified by the method argument) to null and a

third method that moves through the array and calls the methods

in U. In main( ), create a group of A objects and a single B. Fill

the B with U references produced by the A objects. Use the B to

call back into all the A objects. Remove some of the U references

from the B.

28.

In GreenhouseControls.java, add Event inner classes that

turn fans on and off.

29.

Show that an inner class has access to the private elements of its

outer class. Determine whether the reverse is true.

Chapter 8: Interfaces & Inner Classes

405

9: Holding

Your Objects

It's a fairly simple program that has only a fixed quantity

of objects with known lifetimes.

In general, your programs will always be creating new objects based on

some criteria that will be known only at the time the program is running.

You won't know until run-time the quantity or even the exact type of the

objects you need. To solve the general programming problem, you need to

be able to create any number of objects, anytime, anywhere. So you can't

rely on creating a named reference to hold each one of your objects:

MyObject myReference;

since you'll never know how many of these you'll actually need.

To solve this rather essential problem, Java has several ways to hold

objects (or rather, references to objects). The built-in type is the array,

which has been discussed before. Also, the Java utilities library has a

reasonably complete set of container classes (also known as collection

classes, but because the Java 2 libraries use the name Collection to refer

to a particular subset of the library, I shall use the more inclusive term

"container"). Containers provide sophisticated ways to hold and even

manipulate your objects.

Arrays

Most of the necessary introduction to arrays is in the last section of

Chapter 4, which showed how you define and initialize an array. Holding

objects is the focus of this chapter, and an array is just one way to hold

objects. But there are a number of other ways to hold objects, so what

makes an array special?

407

There are two issues that distinguish arrays from other types of

containers: efficiency and type. The array is the most efficient way that

Java provides to store and randomly access a sequence of objects

(actually, object references). The array is a simple linear sequence, which

makes element access fast, but you pay for this speed: when you create an

array object, its size is fixed and cannot be changed for the lifetime of that

array object. You might suggest creating an array of a particular size and

then, if you run out of space, creating a new one and moving all the

references from the old one to the new one. This is the behavior of the

ArrayList class, which will be studied later in this chapter. However,

because of the overhead of this size flexibility, an ArrayList is

measurably less efficient than an array.

The vector container class in C++ does know the type of objects it holds,

but it has a different drawback when compared with arrays in Java: the

C++ vector's operator[] doesn't do bounds checking, so you can run

past the end1. In Java, you get bounds checking regardless of whether

you're using an array or a container--you'll get a RuntimeException if

you exceed the bounds. As you'll learn in Chapter 10, this type of

exception indicates a programmer error, and thus you don't need to check

for it in your code. As an aside, the reason the C++ vector doesn't check

bounds with every access is speed--in Java you have the constant

performance overhead of bounds checking all the time for both arrays and

containers.

The other generic container classes that will be studied in this chapter,

List, Set, and Map, all deal with objects as if they had no specific type.

That is, they treat them as type Object, the root class of all classes in

Java. This works fine from one standpoint: you need to build only one

container, and any Java object will go into that container. (Except for

primitives--these can be placed in containers as constants using the Java

primitive wrapper classes, or as changeable values by wrapping in your

own class.) This is the second place where an array is superior to the

generic containers: when you create an array, you create it to hold a

specific type. This means that you get compile-time type checking to

1 It's possible, however, to ask how big the vector is, and the at( ) method does perform

bounds checking.

408

Thinking in Java

prevent you from putting the wrong type in, or mistaking the type that

you're extracting. Of course, Java will prevent you from sending an

inappropriate message to an object, either at compile-time or at run-time.

So it's not much riskier one way or the other, it's just nicer if the compiler

points it out to you, faster at run-time, and there's less likelihood that the

end user will get surprised by an exception.

For efficiency and type checking it's always worth trying to use an array if

you can. However, when you're trying to solve a more general problem

arrays can be too restrictive. After looking at arrays, the rest of this

chapter will be devoted to the container classes provided by Java.

Arrays are first-class objects

Regardless of what type of array you're working with, the array identifier

is actually a reference to a true object that's created on the heap. This is

the object that holds the references to the other objects, and it can be

created either implicitly, as part of the array initialization syntax, or

explicitly with a new expression. Part of the array object (in fact, the only

field or method you can access) is the read-only length member that tells

you how many elements can be stored in that array object. The `[]' syntax

is the only other access that you have to the array object.

The following example shows the various ways that an array can be

initialized, and how the array references can be assigned to different array

objects. It also shows that arrays of objects and arrays of primitives are

almost identical in their use. The only difference is that arrays of objects

hold references, while arrays of primitives hold the primitive values

directly.

//: c09:ArraySize.java

// Initialization & re-assignment of arrays.

class Weeble {} // A small mythical creature

public class ArraySize {

public static void main(String[] args) {

// Arrays of objects:

Weeble[] a; // Null reference

Weeble[] b = new Weeble[5]; // Null references

Chapter 9: Holding Your Objects

409

Weeble[] c = new Weeble[4];

for(int i = 0; i < c.length; i++)

c[i] = new Weeble();

// Aggregate initialization:

Weeble[] d = {

new Weeble(), new Weeble(), new Weeble()

};

// Dynamic aggregate initialization:

a = new Weeble[] {

new Weeble(), new Weeble()

};

System.out.println("a.length=" + a.length);

System.out.println("b.length = " + b.length);

// The references inside the array are

// automatically initialized to null:

for(int i = 0; i < b.length; i++)

System.out.println("b[" + i + "]=" + b[i]);

System.out.println("c.length = " + c.length);

System.out.println("d.length = " + d.length);

a = d;

System.out.println("a.length = " + a.length);

// Arrays of primitives:

int[] e; // Null reference

int[] f = new int[5];

int[] g = new int[4];

for(int i = 0; i < g.length; i++)

g[i] = i*i;

int[] h = { 11, 47, 93 };

// Compile error: variable e not initialized:

//!System.out.println("e.length=" + e.length);

System.out.println("f.length = " + f.length);

// The primitives inside the array are

// automatically initialized to zero:

for(int i = 0; i < f.length; i++)

System.out.println("f[" + i + "]=" + f[i]);

System.out.println("g.length = " + g.length);

System.out.println("h.length = " + h.length);

e = h;

System.out.println("e.length = " + e.length);

e = new int[] { 1, 2 };

410

Thinking in Java

System.out.println("e.length = " + e.length);

}

} ///:~

Here's the output from the program:

b.length =

b[0]=null

b[1]=null

b[2]=null

b[3]=null

b[4]=null

c.length =

d.length =

a.length =

f.length =

f[0]=0

f[1]=0

f[2]=0

f[3]=0

f[4]=0

g.length =

h.length =

e.length =

The array a is initially just a null reference, and the compiler prevents

you from doing anything with this reference until you've properly

initialized it. The array b is initialized to point to an array of Weeble

references, but no actual Weeble objects are ever placed in that array.

However, you can still ask what the size of the array is, since b is pointing

to a legitimate object. This brings up a slight drawback: you can't find out

how many elements are actually in the array, since length tells you only

how many elements can be placed in the array; that is, the size of the

array object, not the number of elements it actually holds. However, when

an array object is created its references are automatically initialized to

null, so you can see whether a particular array slot has an object in it by

checking to see whether it's null. Similarly, an array of primitives is

automatically initialized to zero for numeric types, (char)0 for char, and

false for boolean.

Chapter 9: Holding Your Objects

411

Array c shows the creation of the array object followed by the assignment

of Weeble objects to all the slots in the array. Array d shows the

"aggregate initialization" syntax that causes the array object to be created

(implicitly with new on the heap, just like for array c) and initialized with

Weeble objects, all in one statement.

The next array initialization could be thought of as a "dynamic aggregate

initialization." The aggregate initialization used by d must be used at the

point of d's definition, but with the second syntax you can create and

initialize an array object anywhere. For example, suppose hide( ) is a

method that takes an array of Weeble objects. You could call it by saying:

hide(d);

but you can also dynamically create the array you want to pass as the

argument:

hide(new Weeble[] { new Weeble(), new Weeble() });

In some situations this new syntax provides a more convenient way to

write code.

The expression

a = d;

shows how you can take a reference that's attached to one array object

and assign it to another array object, just as you can do with any other

type of object reference. Now both a and d are pointing to the same array

object on the heap.

The second part of ArraySize.java shows that primitive arrays work just

like object arrays except that primitive arrays hold the primitive values

directly.

Containers of primitives

Container classes can hold only references to objects. An array, however,

can be created to hold primitives directly, as well as references to objects.

It is possible to use the "wrapper" classes such as Integer, Double, etc.

to place primitive values inside a container, but the wrapper classes for

primitives can be awkward to use. In addition, it's much more efficient to

412

Thinking in Java

create and access an array of primitives than a container of wrapped

primitives.

Of course, if you're using a primitive type and you need the flexibility of a

container that automatically expands when more space is needed, the

array won't work and you're forced to use a container of wrapped

primitives. You might think that there should be a specialized type of

ArrayList for each of the primitive data types, but Java doesn't provide

this for you. Some sort of templatizing mechanism might someday

provide a better way for Java to handle this problem.2

Returning an array

Suppose you're writing a method and you don't just want to return just

one thing, but a whole bunch of things. Languages like C and C++ make

this difficult because you can't just return an array, only a pointer to an

array. This introduces problems because it becomes messy to control the

lifetime of the array, which easily leads to memory leaks.

Java takes a similar approach, but you just "return an array." Actually, of

course, you're returning a reference to an array, but with Java you never

worry about responsibility for that array--it will be around as long as you

need it, and the garbage collector will clean it up when you're done.

As an example, consider returning an array of String:

//: c09:IceCream.java

// Returning arrays from methods.

public class IceCream {

static String[] flav = {

"Chocolate", "Strawberry",

"Vanilla Fudge Swirl", "Mint Chip",

"Mocha Almond Fudge", "Rum Raisin",

"Praline Cream", "Mud Pie"

};

static String[] flavorSet(int n) {

2 This is one of the places where C++ is distinctly superior to Java, since C++ supports

parameterized types with the template keyword.

Chapter 9: Holding Your Objects

413

// Force it to be positive & within bounds:

n = Math.abs(n) % (flav.length + 1);

String[] results = new String[n];

boolean[] picked =

new boolean[flav.length];

for (int i = 0; i < n; i++) {

int t;

t = (int)(Math.random() * flav.length);

while (picked[t]);

results[i] = flav[t];

picked[t] = true;

}

return results;

}

public static void main(String[] args) {

for(int i = 0; i < 20; i++) {

System.out.println(

"flavorSet(" + i + ") = ");

String[] fl = flavorSet(flav.length);

for(int j = 0; j < fl.length; j++)

System.out.println("\t" + fl[j]);

}

} ///:~

The method flavorSet( ) creates an array of String called results. The

size of this array is n, determined by the argument you pass into the

method. Then it proceeds to choose flavors randomly from the array flav

and place them into results, which it finally returns. Returning an array

is just like returning any other object--it's a reference. It's not important

that the array was created within flavorSet( ), or that the array was

created anyplace else, for that matter. The garbage collector takes care of

cleaning up the array when you're done with it, and the array will persist

for as long as you need it.

As an aside, notice that when flavorSet( ) chooses flavors randomly, it

ensures that a random choice hasn't been picked before. This is

performed in a do loop that keeps making random choices until it finds

one that's not already in the picked array. (Of course, a String

comparison could also have been performed to see if the random choice

414

Thinking in Java

was already in the results array, but String comparisons are inefficient.)

If it's successful, it adds the entry and finds the next one (i gets

incremented).

main( ) prints out 20 full sets of flavors, so you can see that flavorSet( )

chooses the flavors in a random order each time. It's easiest to see this if

you redirect the output into a file. And while you're looking at the file,

remember, you just want the ice cream, you don't need it.

The Arrays class

In java.util, you'll find the Arrays class, which holds a set of static

methods that perform utility functions for arrays. There are four basic

functions: equals( ), to compare two arrays for equality; fill( ), to fill an

array with a value; sort( ), to sort the array; and binarySearch( ), to

find an element in a sorted array. All of these methods are overloaded for

all the primitive types and Objects. In addition, there's a single asList( )

method that takes any array and turns it into a List container--which

you'll learn about later in this chapter.

While useful, the Arrays class stops short of being fully functional. For

example, it would be nice to be able to easily print the elements of an

array without having to code a for loop by hand every time. And as you'll

see, the fill( ) method only takes a single value and places it in the array,

so if you wanted--for example--to fill an array with randomly generated

numbers, fill( ) is no help.

Thus it makes sense to supplement the Arrays class with some additional

utilities, which will be placed in the package com.bruceeckel.util for

convenience. These will print an array of any type, and fill an array with

values or objects that are created by an object called a generator that you

can define.

Because code needs to be created for each primitive type as well as

Object, there's a lot of nearly duplicated code3. For example, a

3 The C++ programmer will note how much the code could be collapsed with the use of

default arguments and templates. The Python programmer will note that this entire library

would be largely unnecessary in that language.

Chapter 9: Holding Your Objects

415

"generator" interface is required for each type because the return type of

next( ) must be different in each case:

//: com:bruceeckel:util:Generator.java

package com.bruceeckel.util;

public interface Generator {

Object next();

} ///:~

//: com:bruceeckel:util:BooleanGenerator.java

package com.bruceeckel.util;

public interface BooleanGenerator {

boolean next();

} ///:~

//: com:bruceeckel:util:ByteGenerator.java

package com.bruceeckel.util;

public interface ByteGenerator {

byte next();

} ///:~

//: com:bruceeckel:util:CharGenerator.java

package com.bruceeckel.util;

public interface CharGenerator {

char next();

} ///:~

//: com:bruceeckel:util:ShortGenerator.java

package com.bruceeckel.util;

public interface ShortGenerator {

short next();

} ///:~

//: com:bruceeckel:util:IntGenerator.java

package com.bruceeckel.util;

public interface IntGenerator {

int next();

} ///:~

//: com:bruceeckel:util:LongGenerator.java

package com.bruceeckel.util;

416

Thinking in Java

public interface LongGenerator {

long next();

} ///:~

//: com:bruceeckel:util:FloatGenerator.java

package com.bruceeckel.util;

public interface FloatGenerator {

float next();

} ///:~

//: com:bruceeckel:util:DoubleGenerator.java

package com.bruceeckel.util;

public interface DoubleGenerator {

double next();

} ///:~

Arrays2 contains a variety of print( ) functions, overloaded for each

type. You can simply print an array, you can add a message before the

array is printed, or you can print a range of elements within an array. The

print( ) code is self-explanatory:

//: com:bruceeckel:util:Arrays2.java

// A supplement to java.util.Arrays, to provide

// additional useful functionality when working

// with arrays. Allows any array to be printed,

// and to be filled via a user-defined

// "generator" object.

package com.bruceeckel.util;

import java.util.*;

public class Arrays2 {

private static void

start(int from, int to, int length) {

if(from != 0 || to != length)

System.out.print("["+ from +":"+ to +"] ");

System.out.print("(");

}

private static void end() {

System.out.println(")");

}

public static void print(Object[] a) {

Chapter 9: Holding Your Objects

417

print(a, 0, a.length);

}

public static void

print(String msg, Object[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(Object[] a, int from, int to){

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to -1)

System.out.print(", ");

}

end();

}

public static void print(boolean[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, boolean[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(boolean[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to -1)

System.out.print(", ");

}

end();

}

public static void print(byte[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, byte[] a) {

System.out.print(msg + " ");

418

Thinking in Java

print(a, 0, a.length);

}

public static void

print(byte[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to -1)

System.out.print(", ");

}

end();

}

public static void print(char[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, char[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(char[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to -1)

System.out.print(", ");

}

end();

}

public static void print(short[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, short[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(short[] a, int from, int to) {

start(from, to, a.length);

Chapter 9: Holding Your Objects

419

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to - 1)

System.out.print(", ");

}

end();

}

public static void print(int[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, int[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(int[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to - 1)

System.out.print(", ");

}

end();

}

public static void print(long[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, long[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(long[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to - 1)

System.out.print(", ");

}

420

Thinking in Java

end();

}

public static void print(float[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, float[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(float[] a, int from, int to) {

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to - 1)

System.out.print(", ");

}

end();

}

public static void print(double[] a) {

print(a, 0, a.length);

}

public static void

print(String msg, double[] a) {

System.out.print(msg + " ");

print(a, 0, a.length);

}

public static void

print(double[] a, int from, int to){

start(from, to, a.length);

for(int i = from; i < to; i++) {

System.out.print(a[i]);

if(i < to - 1)

System.out.print(", ");

}

end();

}

// Fill an array using a generator:

public static void

fill(Object[] a, Generator gen) {

Chapter 9: Holding Your Objects

421

fill(a, 0, a.length, gen);

}

public static void

fill(Object[] a, int from, int to,

Generator gen){

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(boolean[] a, BooleanGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(boolean[] a, int from, int to,

BooleanGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(byte[] a, ByteGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(byte[] a, int from, int to,

ByteGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(char[] a, CharGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(char[] a, int from, int to,

CharGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(short[] a, ShortGenerator gen) {

fill(a, 0, a.length, gen);

422

Thinking in Java

}

public static void

fill(short[] a, int from, int to,

ShortGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(int[] a, IntGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(int[] a, int from, int to,

IntGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(long[] a, LongGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(long[] a, int from, int to,

LongGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(float[] a, FloatGenerator gen) {

fill(a, 0, a.length, gen);

}

public static void

fill(float[] a, int from, int to,

FloatGenerator gen) {

for(int i = from; i < to; i++)

a[i] = gen.next();

}

public static void

fill(double[] a, DoubleGenerator gen) {

fill(a, 0, a.length, gen);

}

Chapter 9: Holding Your Objects

423

public static void

fill(double[] a, int from, int to,

DoubleGenerator gen){

for(int i = from; i < to; i++)

a[i] = gen.next();

}

private static Random r = new Random();

public static class RandBooleanGenerator

implements BooleanGenerator {

public boolean next() {

return r.nextBoolean();

}

public static class RandByteGenerator

implements ByteGenerator {

public byte next() {

return (byte)r.nextInt();

}

static String ssource =

"ABCDEFGHIJKLMNOPQRSTUVWXYZ" +

"abcdefghijklmnopqrstuvwxyz";

static char[] src = ssource.toCharArray();

public static class RandCharGenerator

implements CharGenerator {

public char next() {

int pos = Math.abs(r.nextInt());

return src[pos % src.length];

}

public static class RandStringGenerator

implements Generator {

private int len;

private RandCharGenerator cg =

new RandCharGenerator();

public RandStringGenerator(int length) {

len = length;

}

public Object next() {

char[] buf = new char[len];

for(int i = 0; i < len; i++)

424

Thinking in Java

buf[i] = cg.next();

return new String(buf);

}

public static class RandShortGenerator

implements ShortGenerator {

public short next() {

return (short)r.nextInt();

}

public static class RandIntGenerator

implements IntGenerator {

private int mod = 10000;

public RandIntGenerator() {}

public RandIntGenerator(int modulo) {

mod = modulo;

}

public int next() {

return r.nextInt() % mod;

}

public static class RandLongGenerator

implements LongGenerator {

public long next() { return r.nextLong(); }

}

public static class RandFloatGenerator

implements FloatGenerator {

public float next() { return r.nextFloat(); }

}

public static class RandDoubleGenerator

implements DoubleGenerator {

public double next() {return r.nextDouble();}

}

} ///:~

To fill an array of elements using a generator, the fill( ) method takes a

reference to an appropriate generator interface, which has a next( )

method that will somehow produce an object of the right type (depending

on how the interface is implemented). The fill( ) method simply calls

next( ) until the desired range has been filled. Now you can create any

Chapter 9: Holding Your Objects

425

generator by implementing the appropriate interface, and use your

generator with fill( ).

Random data generators are useful for testing, so a set of inner classes is

created to implement all the primitive generator interfaces, as well as a

String generator to represent Object. You can see that

RandStringGenerator uses RandCharGenerator to fill an array of

characters, which is then turned into a String. The size of the array is

determined by the constructor argument.

To generate numbers that aren't too large, RandIntGenerator defaults

to a modulus of 10,000, but the overloaded constructor allows you to

choose a smaller value.

Here's a program to test the library, and to demonstrate how it is used:

//: c09:TestArrays2.java

// Test and demonstrate Arrays2 utilities

import com.bruceeckel.util.*;

public class TestArrays2 {

public static void main(String[] args) {

int size = 6;

// Or get the size from the command line:

if(args.length != 0)

size = Integer.parseInt(args[0]);

boolean[] a1 = new boolean[size];

byte[] a2 = new byte[size];

char[] a3 = new char[size];

short[] a4 = new short[size];

int[] a5 = new int[size];

long[] a6 = new long[size];

float[] a7 = new float[size];

double[] a8 = new double[size];

String[] a9 = new String[size];

Arrays2.fill(a1,

new Arrays2.RandBooleanGenerator());

Arrays2.print(a1);

Arrays2.print("a1 = ", a1);

Arrays2.print(a1, size/3, size/3 + size/3);

Arrays2.fill(a2,

426

Thinking in Java

new Arrays2.RandByteGenerator());

Arrays2.print(a2);

Arrays2.print("a2 = ", a2);

Arrays2.print(a2, size/3, size/3 + size/3);

Arrays2.fill(a3,

new Arrays2.RandCharGenerator());

Arrays2.print(a3);

Arrays2.print("a3 = ", a3);

Arrays2.print(a3, size/3, size/3 + size/3);

Arrays2.fill(a4,

new Arrays2.RandShortGenerator());

Arrays2.print(a4);

Arrays2.print("a4 = ", a4);

Arrays2.print(a4, size/3, size/3 + size/3);

Arrays2.fill(a5,

new Arrays2.RandIntGenerator());

Arrays2.print(a5);

Arrays2.print("a5 = ", a5);

Arrays2.print(a5, size/3, size/3 + size/3);

Arrays2.fill(a6,

new Arrays2.RandLongGenerator());

Arrays2.print(a6);

Arrays2.print("a6 = ", a6);

Arrays2.print(a6, size/3, size/3 + size/3);

Arrays2.fill(a7,

new Arrays2.RandFloatGenerator());

Arrays2.print(a7);

Arrays2.print("a7 = ", a7);

Arrays2.print(a7, size/3, size/3 + size/3);

Arrays2.fill(a8,

new Arrays2.RandDoubleGenerator());

Arrays2.print(a8);

Arrays2.print("a8 = ", a8);

Arrays2.print(a8, size/3, size/3 + size/3);

Arrays2.fill(a9,

new Arrays2.RandStringGenerator(7));

Arrays2.print(a9);

Arrays2.print("a9 = ", a9);

Arrays2.print(a9, size/3, size/3 + size/3);

}

} ///:~

Chapter 9: Holding Your Objects

427

The size parameter has a default value, but you can also set it from the

command line.

Filling an array

The Java standard library Arrays also has a fill( ) method, but that is

rather trivial--it only duplicates a single value into each location, or in the

case of objects, copies the same reference into each location. Using

Arrays2.print( ), the Arrays.fill( ) methods can be easily

demonstrated:

//: c09:FillingArrays.java

// Using Arrays.fill()

import com.bruceeckel.util.*;

import java.util.*;

public class FillingArrays {

public static void main(String[] args) {

int size = 6;

// Or get the size from the command line:

if(args.length != 0)

size = Integer.parseInt(args[0]);

boolean[] a1 = new boolean[size];

byte[] a2 = new byte[size];

char[] a3 = new char[size];

short[] a4 = new short[size];

int[] a5 = new int[size];

long[] a6 = new long[size];

float[] a7 = new float[size];

double[] a8 = new double[size];

String[] a9 = new String[size];

Arrays.fill(a1, true);

Arrays2.print("a1 = ", a1);

Arrays.fill(a2, (byte)11);

Arrays2.print("a2 = ", a2);

Arrays.fill(a3, 'x');

Arrays2.print("a3 = ", a3);

Arrays.fill(a4, (short)17);

Arrays2.print("a4 = ", a4);

Arrays.fill(a5, 19);

Arrays2.print("a5 = ", a5);

428

Thinking in Java

Arrays.fill(a6, 23);

Arrays2.print("a6 = ", a6);

Arrays.fill(a7, 29);

Arrays2.print("a7 = ", a7);

Arrays.fill(a8, 47);

Arrays2.print("a8 = ", a8);

Arrays.fill(a9, "Hello");

Arrays2.print("a9 = ", a9);

// Manipulating ranges:

Arrays.fill(a9, 3, 5, "World");

Arrays2.print("a9 = ", a9);

}

} ///:~

You can either fill the entire array, or--as the last two statements show--a

range of elements. But since you can only provide a single value to use for

filling using Arrays.fill( ), the Arrays2.fill( ) methods produce much

more interesting results.

Copying an array

The Java standard library provides a static method,

System.arraycopy( ), which can make much faster copies of an array

than if you use a for loop to perform the copy by hand.

System.arraycopy( ) is overloaded to handle all types. Here's an

example that manipulates arrays of int:

//: c09:CopyingArrays.java

// Using System.arraycopy()

import com.bruceeckel.util.*;

import java.util.*;

public class CopyingArrays {

public static void main(String[] args) {

int[] i = new int[25];

int[] j = new int[25];

Arrays.fill(i, 47);

Arrays.fill(j, 99);

Arrays2.print("i = ", i);

Arrays2.print("j = ", j);

System.arraycopy(i, 0, j, 0, i.length);

Chapter 9: Holding Your Objects

429

Arrays2.print("j = ", j);

int[] k = new int[10];

Arrays.fill(k, 103);

System.arraycopy(i, 0, k, 0, k.length);

Arrays2.print("k = ", k);

Arrays.fill(k, 103);

System.arraycopy(k, 0, i, 0, k.length);

Arrays2.print("i = ", i);

// Objects:

Integer[] u = new Integer[10];

Integer[] v = new Integer[5];

Arrays.fill(u, new Integer(47));

Arrays.fill(v, new Integer(99));

Arrays2.print("u = ", u);

Arrays2.print("v = ", v);

System.arraycopy(v, 0,

u, u.length/2, v.length);

Arrays2.print("u = ", u);

}

} ///:~

The arguments to arraycopy( ) are the source array, the offset into the

source array from whence to start copying, the destination array, the

offset into the destination array where the copying begins, and the

number of elements to copy. Naturally, any violation of the array

boundaries will cause an exception.

The example shows that both primitive arrays and object arrays can be

copied. However, if you copy arrays of objects then only the references get

copied--there's no duplication of the objects themselves. This is called a

shallow copy (see Appendix A).

Comparing arrays

Arrays provides the overloaded method equals( ) to compare entire

arrays for equality. Again, these are overloaded for all the primitives, and

for Object. To be equal, the arrays must have the same number of

elements and each element must be equivalent to each corresponding

element in the other array, using the equals( ) for each element. (For

primitives, that primitive's wrapper class equals( ) is used; for example,

Integer.equals( ) for int.) Here's an example:

430

Thinking in Java

//: c09:ComparingArrays.java

// Using Arrays.equals()

import java.util.*;

public class ComparingArrays {

public static void main(String[] args) {

int[] a1 = new int[10];

int[] a2 = new int[10];

Arrays.fill(a1, 47);

Arrays.fill(a2, 47);

System.out.println(Arrays.equals(a1, a2));

a2[3] = 11;

System.out.println(Arrays.equals(a1, a2));

String[] s1 = new String[5];

Arrays.fill(s1, "Hi");

String[] s2 = {"Hi", "Hi", "Hi", "Hi", "Hi"};

System.out.println(Arrays.equals(s1, s2));

}

} ///:~

Originally, a1 and a2 are exactly equal, so the output is "true," but then

one of the elements is changed so the second line of output is "false." In

the last case, all the elements of s1 point to the same object, but s2 has

five unique objects. However, array equality is based on contents (via

Object.equals( )) and so the result is "true."

Array element comparisons

One of the missing features in the Java 1.0 and 1.1 libraries is algorithmic

operations--even simple sorting. This was a rather confusing situation to

someone expecting an adequate standard library. Fortunately, Java 2

remedies the situation, at least for the sorting problem.

A problem with writing generic sorting code is that sorting must perform

comparisons based on the actual type of the object. Of course, one

approach is to write a different sorting method for every different type,

but you should be able to recognize that this does not produce code that is

easily reused for new types.

A primary goal of programming design is to "separate things that change

from things that stay the same," and here, the code that stays the same is

Chapter 9: Holding Your Objects

431

the general sort algorithm, but the thing that changes from one use to the

next is the way objects are compared. So instead of hard-wiring the

comparison code into many different sort routines, the technique of the

callback is used. With a callback, the part of the code that varies from case

to case is encapsulated inside its own class, and the part of the code that's

always the same will call back to the code that changes. That way you can

make different objects to express different ways of comparison and feed

them to the same sorting code.

In Java 2, there are two ways to provide comparison functionality. The

first is with the natural comparison method that is imparted to a class by

implementing the java.lang.Comparable interface. This is a very

simple interface with a single method, compareTo( ). This method takes

another Object as an argument, and produces a negative value if the

argument is less than the current object, zero if the argument is equal, and

a positive value if the argument is greater than the current object.

Here's a class that implements Comparable and demonstrates the

comparability by using the Java standard library method Arrays.sort( ):

//: c09:CompType.java

// Implementing Comparable in a class.

import com.bruceeckel.util.*;

import java.util.*;

public class CompType implements Comparable {

int i;

int j;

public CompType(int n1, int n2) {

i = n1;

j = n2;

}

public String toString() {

return "[i = " + i + ", j = " + j + "]";

}

public int compareTo(Object rv) {

int rvi = ((CompType)rv).i;

return (i < rvi ? -1 : (i == rvi ? 0 : 1));

}

private static Random r = new Random();

private static int randInt() {

432

Thinking in Java

return Math.abs(r.nextInt()) % 100;

}

public static Generator generator() {

return new Generator() {

public Object next() {

return new CompType(randInt(),randInt());

}

};

}

public static void main(String[] args) {

CompType[] a = new CompType[10];

Arrays2.fill(a, generator());

Arrays2.print("before sorting, a = ", a);

Arrays.sort(a);

Arrays2.print("after sorting, a = ", a);

}

} ///:~

When you define the comparison function, you are responsible for

deciding what it means to compare one of your objects to another. Here,

only the i values are used in the comparison, and the j values are ignored.

The static randInt( ) method produces positive values between zero and

100, and the generator( ) method produces an object that implements

the Generator interface, by creating an anonymous inner class (see

Chapter 8). This builds CompType objects by initializing them with

random values. In main( ), the generator is used to fill an array of

CompType, which is then sorted. If Comparable hadn't been

implemented, then you'd get a compile-time error message when you

tried to call sort( ).

Now suppose someone hands you a class that doesn't implement

Comparable, or they hand you this class that does implement

Comparable, but you decide you don't like the way it works and would

rather have a different comparison function for the type. To do this, you

use the second approach for comparing objects, by creating a separate

class that implements an interface called Comparator. This has two

methods, compare( ) and equals( ). However, you don't have to

implement equals( ) except for special performance needs, because

anytime you create a class it is implicitly inherited from Object, which

Chapter 9: Holding Your Objects

433

has an equals( ). So you can just use the default Object equals( ) and

satisfy the contract imposed by the interface.

The Collections class (which we'll look at more later) contains a single

Comparator that reverses the natural sorting order. This can easily be

applied to the CompType:

//: c09:Reverse.java

// The Collecions.reverseOrder() Comparator.

import com.bruceeckel.util.*;

import java.util.*;

public class Reverse {

public static void main(String[] args) {

CompType[] a = new CompType[10];

Arrays2.fill(a, CompType.generator());

Arrays2.print("before sorting, a = ", a);

Arrays.sort(a, Collections.reverseOrder());

Arrays2.print("after sorting, a = ", a);

}

} ///:~

The call to Collections.reverseOrder( ) produces the reference to the

Comparator.

As a second example, the following Comparator compares CompType

objects based on their j values rather than their i values:

//: c09:ComparatorTest.java

// Implementing a Comparator for a class.

import com.bruceeckel.util.*;

import java.util.*;

class CompTypeComparator implements Comparator {

public int compare(Object o1, Object o2) {

int j1 = ((CompType)o1).j;

int j2 = ((CompType)o2).j;

return (j1 < j2 ? -1 : (j1 == j2 ? 0 : 1));

}

public class ComparatorTest {

434

Thinking in Java

public static void main(String[] args) {

CompType[] a = new CompType[10];

Arrays2.fill(a, CompType.generator());

Arrays2.print("before sorting, a = ", a);

Arrays.sort(a, new CompTypeComparator());

Arrays2.print("after sorting, a = ", a);

}

} ///:~

The compare( ) method must return a negative integer, zero, or a

positive integer if the first argument is less than, equal to, or greater than

the second, respectively.

Sorting an array

With the built-in sorting methods, you can sort any array of primitives,

and any array of objects that either implements Comparable or has an

associated Comparator. This fills a big hole in the Java libraries--

believe it or not, there was no support in Java 1.0 or 1.1 for sorting

Strings! Here's an example that generates random String objects and

sorts them:

//: c09:StringSorting.java

// Sorting an array of Strings.

import com.bruceeckel.util.*;

import java.util.*;

public class StringSorting {

public static void main(String[] args) {

String[] sa = new String[30];

Arrays2.fill(sa,

new Arrays2.RandStringGenerator(5));

Arrays2.print("Before sorting: ", sa);

Arrays.sort(sa);

Arrays2.print("After sorting: ", sa);

}

} ///:~

One thing you'll notice about the output in the String sorting algorithm is

that it's lexicographic, so it puts all the words starting with uppercase

letters first, followed by all the words starting with lowercase letters.

Chapter 9: Holding Your Objects

435

(Telephone books are typically sorted this way.) You may also want to

group the words together regardless of case, and you can do this by

defining a Comparator class, thereby overriding the default String

Comparable behavior. For reuse, this will be added to the "util"

package:

//: com:bruceeckel:util:AlphabeticComparator.java

// Keeping upper and lowercase letters together.

package com.bruceeckel.util;

import java.util.*;

public class AlphabeticComparator

implements Comparator{

public int compare(Object o1, Object o2) {

String s1 = (String)o1;

String s2 = (String)o2;

return s1.toLowerCase().compareTo(

s2.toLowerCase());

}

} ///:~

Each String is converted to lowercase before the comparison. String's

built-in compareTo( ) method provides the desired functionality.

Here's a test using AlphabeticComparator:

//: c09:AlphabeticSorting.java

// Keeping upper and lowercase letters together.

import com.bruceeckel.util.*;

import java.util.*;

public class AlphabeticSorting {

public static void main(String[] args) {

String[] sa = new String[30];

Arrays2.fill(sa,

new Arrays2.RandStringGenerator(5));

Arrays2.print("Before sorting: ", sa);

Arrays.sort(sa, new AlphabeticComparator());

Arrays2.print("After sorting: ", sa);

}

} ///:~

436

Thinking in Java

The sorting algorithm that's used in the Java standard library is designed

to be optimal for the particular type you're sorting--a Quicksort for

primitives, and a stable merge sort for objects. So you shouldn't need to

spend any time worrying about performance unless your profiling tool

points you to the sorting process as a bottleneck.

Searching a sorted array

Once an array is sorted, you can perform a fast search for a particular item

using Arrays.binarySearch( ). However, it's very important that you

do not try to use binarySearch( ) on an unsorted array; the results will

be unpredictable. The following example uses a RandIntGenerator to

fill an array, then to produces values to search for:

//: c09:ArraySearching.java

// Using Arrays.binarySearch().

import com.bruceeckel.util.*;

import java.util.*;

public class ArraySearching {

public static void main(String[] args) {

int[] a = new int[100];

Arrays2.RandIntGenerator gen =

new Arrays2.RandIntGenerator(1000);

Arrays2.fill(a, gen);

Arrays.sort(a);

Arrays2.print("Sorted array: ", a);

while(true) {

int r = gen.next();

int location = Arrays.binarySearch(a, r);

if(location >= 0) {

System.out.println("Location of " + r +

" is " + location + ", a[" +

location + "] = " + a[location]);

break; // Out of while loop

}

} ///:~

Chapter 9: Holding Your Objects

437

In the while loop, random values are generated as search items, until one

of them is found.

Arrays.binarySearch( ) produces a value greater than or equal to zero

if the search item is found. Otherwise, it produces a negative value

representing the place that the element should be inserted if you are

maintaining the sorted array by hand. The value produced is

-(insertion point) - 1

The insertion point is the index of the first element greater than the key,

or a.size( ), if all elements in the array are less than the specified key.

If the array contains duplicate elements, there is no guarantee which one

will be found. The algorithm is thus not really designed to support

duplicate elements, as much as tolerate them. If you need a sorted list of

nonduplicated elements, however, use a TreeSet, which will be

introduced later in this chapter. This takes care of all the details for you

automatically. Only in cases of performance bottlenecks should you

replace the TreeSet with a hand-maintained array.

If you have sorted an object array using a Comparator (primitive arrays

do not allow sorting with a Comparator), you must include that same

Comparator when you perform a binarySearch( ) (using the

overloaded version of the function that's provided). For example, the

AlphabeticSorting.java program can be modified to perform a search:

//: c09:AlphabeticSearch.java

// Searching with a Comparator.

import com.bruceeckel.util.*;

import java.util.*;

public class AlphabeticSearch {

public static void main(String[] args) {

String[] sa = new String[30];

Arrays2.fill(sa,

new Arrays2.RandStringGenerator(5));

AlphabeticComparator comp =

new AlphabeticComparator();

Arrays.sort(sa, comp);

int index =

438

Thinking in Java

Arrays.binarySearch(sa, sa[10], comp);

System.out.println("Index = " + index);

}

} ///:~

The Comparator must be passed to the overloaded binarySearch( ) as

the third argument. In the above example, success is guaranteed because

the search item is plucked out of the array itself.

Array summary

To summarize what you've seen so far, your first and most efficient choice

to hold a group of objects should be an array, and you're forced into this

choice if you want to hold a group of primitives. In the remainder of this

chapter we'll look at the more general case, when you don't know at the

time you're writing the program how many objects you're going to need,

or if you need a more sophisticated way to store your objects. Java

provides a library of container classes to solve this problem, the basic

types of which are List, Set, and Map. You can solve a surprising

number of problems using these tools.

Among their other characteristics--Set, for example, holds only one

object of each value, and Map is an associative array that lets you

associate any object with any other object--the Java container classes will

automatically resize themselves. So, unlike arrays, you can put in any

number of objects and you don't need to worry about how big to make the

container while you're writing the program.

Introduction to containers

To me, container classes are one of the most powerful tools for raw

development because they significantly increase your programming

muscle. The Java 2 containers represent a thorough redesign4 of the

rather poor showings in Java 1.0 and 1.1. Some of the redesign makes

things tighter and more sensible. It also fills out the functionality of the

4 By Joshua Bloch at Sun.

Chapter 9: Holding Your Objects

439

containers library, providing the behavior of linked lists, queues, and

deques (double-ended queues, pronounced "decks").

The design of a containers library is difficult (true of most library design

problems). In C++, the container classes covered the bases with many

different classes. This was better than what was available prior to the C++

container classes (nothing), but it didn't translate well into Java. On the

other extreme, I've seen a containers library that consists of a single class,

"container," which acts like both a linear sequence and an associative

array at the same time. The Java 2 container library strikes a balance: the

full functionality that you expect from a mature container library, but

easier to learn and use than the C++ container classes and other similar

container libraries. The result can seem a bit odd in places. Unlike some

of the decisions made in the early Java libraries, these oddities were not

accidents, but carefully considered decisions based on trade-offs in

complexity. It might take you a little while to get comfortable with some

aspects of the library, but I think you'll find yourself rapidly acquiring and

using these new tools.

The Java 2 container library takes the issue of "holding your objects" and

divides it into two distinct concepts:

Collection: a group of individual elements, often with some rule

applied to them. A List must hold the elements in a particular

sequence, and a Set cannot have any duplicate elements. (A bag,

which is not implemented in the Java container library--since

Lists provide you with enough of that functionality--has no such

rules.)

Map: a group of key-value object pairs. At first glance, this might

seem like it ought to be a Collection of pairs, but when you try to

implement it that way the design gets awkward, so it's clearer to

make it a separate concept. On the other hand, it's convenient to

look at portions of a Map by creating a Collection to represent

that portion. Thus, a Map can return a Set of its keys, a

Collection of its values, or a Set of its pairs. Maps, like arrays,

can easily be expanded to multiple dimensions without adding new

concepts: you simply make a Map whose values are Maps (and the

values of those Maps can be Maps, etc.).

440

Thinking in Java

We will first look at the general features of containers, then go into

details, and finally learn why there are different versions of some

containers, and how to choose between them.

Printing containers

Unlike arrays, the containers print nicely without any help. Here's an

example that also introduces you to the basic types of containers:

//: c09:PrintingContainers.java

// Containers print themselves automatically.

import java.util.*;

public class PrintingContainers {

static Collection fill(Collection c) {

c.add("dog");

c.add("cat");

return c;

}

static Map fill(Map m) {

m.put("dog", "Bosco");

m.put("dog", "Spot");

m.put("cat", "Rags");

return m;

}

public static void main(String[] args) {

System.out.println(fill(new ArrayList()));

System.out.println(fill(new HashSet()));

System.out.println(fill(new HashMap()));

}

} ///:~

As mentioned before, there are two basic categories in the Java container

library. The distinction is based on the number of items that are held in

each location of the container. The Collection category only holds one

item in each location (the name is a bit misleading since entire container

libraries are often called "collections"). It includes the List, which holds a

group of items in a specified sequence, and the Set, which only allows the

addition of one item of each type. The ArrayList is a type of List, and

Chapter 9: Holding Your Objects

441

HashSet is a type of Set. To add items to any Collection, there's an

add( ) method.

The Map holds key-value pairs, rather like a mini database. The above

program uses one flavor of Map, the HashMap. If you have a Map that

associates states with their capitals and you want to know the capital of

Ohio, you look it up--almost as if you were indexing into an array. (Maps

are also called associative arrays.) To add elements to a Map there's a

put( ) method that takes a key and a value as arguments. The above

example only shows adding elements and does not look the elements up

after they're added. That will be shown later.

The overloaded fill( ) methods fill Collections and Maps, respectively.

If you look at the output, you can see that the default printing behavior

(provided via the container's various toString( ) methods) produces

quite readable results, so no additional printing support is necessary as it

was with arrays:

[dog, dog, cat]

[cat, dog]

{cat=Rags, dog=Spot}

A Collection is printed surrounded by square braces, with each element

separated by a comma. A Map is surrounded by curly braces, with each

key and value associated with an equal sign (keys on the left, values on the

right).

You can also immediately see the basic behavior of the different

containers. The List holds the objects exactly as they are entered, without

any reordering or editing. The Set, however, only accepts one of each

object and it uses its own internal ordering method (in general, you are

only concerned with whether or not something is a member of the Set,

not the order in which it appears--for that you'd use a List). And the

Map also only accepts one of each type of item, based on the key, and it

also has its own internal ordering and does not care about the order in

which you enter the items.

Filling containers

Although the problem of printing the containers is taken care of, filling

containers suffers from the same deficiency as java.util.Arrays. Just

442

Thinking in Java

like Arrays, there is a companion class called Collections containing

static utility methods including one called fill( ). This fill( ) also just

duplicates a single object reference throughout the container, and also

only works for List objects and not Sets or Maps:

//: c09:FillingLists.java

// The Collections.fill() method.

import java.util.*;

public class FillingLists {

public static void main(String[] args) {

List list = new ArrayList();

for(int i = 0; i < 10; i++)

list.add("");

Collections.fill(list, "Hello");

System.out.println(list);

}

} ///:~

This method is made even less useful by the fact that it can only replace

elements that are already in the List, and will not add new elements.

To be able to create interesting examples, here is a complementary

Collections2 library (part of com.bruceeckel.util for convenience)

with a fill( ) method that uses a generator to add elements, and allows

you to specify the number of elements you want to add( ). The

Generator interface defined previously will work for Collections, but

the Map requires its own generator interface since a pair of objects (one

key and one value) must be produced by each call to next( ). Here is the

Pair class:

//: com:bruceeckel:util:Pair.java

package com.bruceeckel.util;

public class Pair {

public Object key, value;

Pair(Object k, Object v) {

key = k;

value = v;

}

} ///:~

Next, the generator interface that produces the Pair:

Chapter 9: Holding Your Objects

443

//: com:bruceeckel:util:MapGenerator.java

package com.bruceeckel.util;

public interface MapGenerator {

Pair next();

} ///:~

With these, a set of utilities for working with the container classes can be

developed:

//: com:bruceeckel:util:Collections2.java

// To fill any type of container

// using a generator object.

package com.bruceeckel.util;

import java.util.*;

public class Collections2 {

// Fill an array using a generator:

public static void

fill(Collection c, Generator gen, int count) {

for(int i = 0; i < count; i++)

c.add(gen.next());

}

public static void

fill(Map m, MapGenerator gen, int count) {

for(int i = 0; i < count; i++) {

Pair p = gen.next();

m.put(p.key, p.value);

}

public static class RandStringPairGenerator

implements MapGenerator {

private Arrays2.RandStringGenerator gen;

public RandStringPairGenerator(int len) {

gen = new Arrays2.RandStringGenerator(len);

}

public Pair next() {

return new Pair(gen.next(), gen.next());

}

// Default object so you don't have

// to create your own:

public static RandStringPairGenerator rsp =

444

Thinking in Java

new RandStringPairGenerator(10);

public static class StringPairGenerator

implements MapGenerator {

private int index = -1;

private String[][] d;

public StringPairGenerator(String[][] data) {

d = data;

}

public Pair next() {

// Force the index to wrap:

index = (index + 1) % d.length;

return new Pair(d[index][0], d[index][1]);

}

public StringPairGenerator reset() {

index = -1;

return this;

}

// Use a predefined dataset:

public static StringPairGenerator geography =

new StringPairGenerator(

CountryCapitals.pairs);

// Produce a sequence from a 2D array:

public static class StringGenerator

implements Generator {

private String[][] d;

private int position;

private int index = -1;

public

StringGenerator(String[][] data, int pos) {

d = data;

position = pos;

}

public Object next() {

// Force the index to wrap:

index = (index + 1) % d.length;

return d[index][position];

}

public StringGenerator reset() {

index = -1;

return this;

Chapter 9: Holding Your Objects

445

}

// Use a predefined dataset:

public static StringGenerator countries =

new StringGenerator(CountryCapitals.pairs,0);

public static StringGenerator capitals =

new StringGenerator(CountryCapitals.pairs,1);

} ///:~

Both versions of fill( ) take an argument that determines the number of

items to add to the container. In addition, there are two generators for the

map: RandStringPairGenerator, which creates any number of pairs of

gibberish Strings with length determined by the constructor argument;

and StringPairGenerator, which produces pairs of Strings given a

two-dimensional array of String. The StringGenerator also takes a

two-dimensional array of String but generates single items rather than

Pairs. The static rsp, geography, countries, and capitals objects

provide prebuilt generators, the last three using all the countries of the

world and their capitals. Note that if you try to create more pairs than are

available, the generators will loop around to the beginning, and if you are

putting the pairs into a Map, the duplicates will just be ignored.

Here is the predefined dataset, which consists of country names and their

capitals. It is set in a small font to prevent taking up unnecessary space:

//: com:bruceeckel:util:CountryCapitals.java

package com.bruceeckel.util;

public class CountryCapitals {

public static final String[][] pairs = {

// Africa

{"ALGERIA","Algiers"}, {"ANGOLA","Luanda"},

{"BENIN","Porto-Novo"}, {"BOTSWANA","Gaberone"},

{"BURKINA FASO","Ouagadougou"}, {"BURUNDI","Bujumbura"},

{"CAMEROON","Yaounde"}, {"CAPE VERDE","Praia"},

{"CENTRAL AFRICAN REPUBLIC","Bangui"},

{"CHAD","N'djamena"}, {"COMOROS","Moroni"},

{"CONGO","Brazzaville"}, {"DJIBOUTI","Dijibouti"},

{"EGYPT","Cairo"}, {"EQUATORIAL GUINEA","Malabo"},

{"ERITREA","Asmara"}, {"ETHIOPIA","Addis Ababa"},

{"GABON","Libreville"}, {"THE GAMBIA","Banjul"},

{"GHANA","Accra"}, {"GUINEA","Conakry"},

{"GUINEA","-"}, {"BISSAU","Bissau"},

{"CETE D'IVOIR (IVORY COAST)","Yamoussoukro"},

{"KENYA","Nairobi"}, {"LESOTHO","Maseru"},

{"LIBERIA","Monrovia"}, {"LIBYA","Tripoli"},

446

Thinking in Java

{"MADAGASCAR","Antananarivo"}, {"MALAWI","Lilongwe"},

{"MALI","Bamako"}, {"MAURITANIA","Nouakchott"},

{"MAURITIUS","Port Louis"}, {"MOROCCO","Rabat"},

{"MOZAMBIQUE","Maputo"}, {"NAMIBIA","Windhoek"},

{"NIGER","Niamey"}, {"NIGERIA","Abuja"},

{"RWANDA","Kigali"}, {"SAO TOME E PRINCIPE","Sao Tome"},

{"SENEGAL","Dakar"}, {"SEYCHELLES","Victoria"},

{"SIERRA LEONE","Freetown"}, {"SOMALIA","Mogadishu"},

{"SOUTH AFRICA","Pretoria/Cape Town"}, {"SUDAN","Khartoum"},

{"SWAZILAND","Mbabane"}, {"TANZANIA","Dodoma"},

{"TOGO","Lome"}, {"TUNISIA","Tunis"},

{"UGANDA","Kampala"},

{"DEMOCRATIC REPUBLIC OF THE CONGO (ZAIRE)","Kinshasa"},

{"ZAMBIA","Lusaka"}, {"ZIMBABWE","Harare"},

// Asia

{"AFGHANISTAN","Kabul"}, {"BAHRAIN","Manama"},

{"BANGLADESH","Dhaka"}, {"BHUTAN","Thimphu"},

{"BRUNEI","Bandar Seri Begawan"}, {"CAMBODIA","Phnom Penh"},

{"CHINA","Beijing"}, {"CYPRUS","Nicosia"},

{"INDIA","New Delhi"}, {"INDONESIA","Jakarta"},

{"IRAN","Tehran"}, {"IRAQ","Baghdad"},

{"ISRAEL","Jerusalem"}, {"JAPAN","Tokyo"},

{"JORDAN","Amman"}, {"KUWAIT","Kuwait City"},

{"LAOS","Vientiane"}, {"LEBANON","Beirut"},

{"MALAYSIA","Kuala Lumpur"}, {"THE MALDIVES","Male"},

{"MONGOLIA","Ulan Bator"}, {"MYANMAR (BURMA)","Rangoon"},

{"NEPAL","Katmandu"}, {"NORTH KOREA","P'yongyang"},

{"OMAN","Muscat"}, {"PAKISTAN","Islamabad"},

{"PHILIPPINES","Manila"}, {"QATAR","Doha"},

{"SAUDI ARABIA","Riyadh"}, {"SINGAPORE","Singapore"},

{"SOUTH KOREA","Seoul"}, {"SRI LANKA","Colombo"},

{"SYRIA","Damascus"}, {"TAIWAN (REPUBLIC OF CHINA)","Taipei"},

{"THAILAND","Bangkok"}, {"TURKEY","Ankara"},

{"UNITED ARAB EMIRATES","Abu Dhabi"}, {"VIETNAM","Hanoi"},

{"YEMEN","Sana'a"},

// Australia and Oceania

{"AUSTRALIA","Canberra"}, {"FIJI","Suva"},

{"KIRIBATI","Bairiki"},

{"MARSHALL ISLANDS","Dalap-Uliga-Darrit"},

{"MICRONESIA","Palikir"}, {"NAURU","Yaren"},

{"NEW ZEALAND","Wellington"}, {"PALAU","Koror"},

{"PAPUA NEW GUINEA","Port Moresby"},

{"SOLOMON ISLANDS","Honaira"}, {"TONGA","Nuku'alofa"},

{"TUVALU","Fongafale"}, {"VANUATU","< Port-Vila"},

{"WESTERN SAMOA","Apia"},

// Eastern Europe and former USSR

{"ARMENIA","Yerevan"}, {"AZERBAIJAN","Baku"},

{"BELARUS (BYELORUSSIA)","Minsk"}, {"GEORGIA","Tbilisi"},

{"KAZAKSTAN","Almaty"}, {"KYRGYZSTAN","Alma-Ata"},

{"MOLDOVA","Chisinau"}, {"RUSSIA","Moscow"},

{"TAJIKISTAN","Dushanbe"}, {"TURKMENISTAN","Ashkabad"},

{"UKRAINE","Kyiv"}, {"UZBEKISTAN","Tashkent"},

Chapter 9: Holding Your Objects

447

// Europe

{"ALBANIA","Tirana"}, {"ANDORRA","Andorra la Vella"},

{"AUSTRIA","Vienna"}, {"BELGIUM","Brussels"},

{"BOSNIA","-"}, {"HERZEGOVINA","Sarajevo"},

{"CROATIA","Zagreb"}, {"CZECH REPUBLIC","Prague"},

{"DENMARK","Copenhagen"}, {"ESTONIA","Tallinn"},

{"FINLAND","Helsinki"}, {"FRANCE","Paris"},

{"GERMANY","Berlin"}, {"GREECE","Athens"},

{"HUNGARY","Budapest"}, {"ICELAND","Reykjavik"},

{"IRELAND","Dublin"}, {"ITALY","Rome"},

{"LATVIA","Riga"}, {"LIECHTENSTEIN","Vaduz"},

{"LITHUANIA","Vilnius"}, {"LUXEMBOURG","Luxembourg"},

{"MACEDONIA","Skopje"}, {"MALTA","Valletta"},

{"MONACO","Monaco"}, {"MONTENEGRO","Podgorica"},

{"THE NETHERLANDS","Amsterdam"}, {"NORWAY","Oslo"},

{"POLAND","Warsaw"}, {"PORTUGAL","Lisbon"},

{"ROMANIA","Bucharest"}, {"SAN MARINO","San Marino"},

{"SERBIA","Belgrade"}, {"SLOVAKIA","Bratislava"},

{"SLOVENIA","Ljujiana"}, {"SPAIN","Madrid"},

{"SWEDEN","Stockholm"}, {"SWITZERLAND","Berne"},

{"UNITED KINGDOM","London"}, {"VATICAN CITY","---"},

// North and Central America

{"ANTIGUA AND BARBUDA","Saint John's"}, {"BAHAMAS","Nassau"},

{"BARBADOS","Bridgetown"}, {"BELIZE","Belmopan"},

{"CANADA","Ottawa"}, {"COSTA RICA","San Jose"},

{"CUBA","Havana"}, {"DOMINICA","Roseau"},

{"DOMINICAN REPUBLIC","Santo Domingo"},

{"EL SALVADOR","San Salvador"}, {"GRENADA","Saint George's"},

{"GUATEMALA","Guatemala City"}, {"HAITI","Port-au-Prince"},

{"HONDURAS","Tegucigalpa"}, {"JAMAICA","Kingston"},

{"MEXICO","Mexico City"}, {"NICARAGUA","Managua"},

{"PANAMA","Panama City"}, {"ST. KITTS","-"},

{"NEVIS","Basseterre"}, {"ST. LUCIA","Castries"},

{"ST. VINCENT AND THE GRENADINES","Kingstown"},

{"UNITED STATES OF AMERICA","Washington, D.C."},

// South America

{"ARGENTINA","Buenos Aires"},

{"BOLIVIA","Sucre (legal)/La Paz(administrative)"},

{"BRAZIL","Brasilia"}, {"CHILE","Santiago"},

{"COLOMBIA","Bogota"}, {"ECUADOR","Quito"},

{"GUYANA","Georgetown"}, {"PARAGUAY","Asuncion"},

{"PERU","Lima"}, {"SURINAME","Paramaribo"},

{"TRINIDAD AND TOBAGO","Port of Spain"},

{"URUGUAY","Montevideo"}, {"VENEZUELA","Caracas"},

};

} ///:~

448

Thinking in Java

This is simply a two-dimensional array of String data5. Here's a simple

test using the fill( ) methods and generators:

//: c09:FillTest.java

import com.bruceeckel.util.*;

import java.util.*;

public class FillTest {

static Generator sg =

new Arrays2.RandStringGenerator(7);

public static void main(String[] args) {

List list = new ArrayList();

Collections2.fill(list, sg, 25);

System.out.println(list + "\n");

List list2 = new ArrayList();

Collections2.fill(list2,

Collections2.capitals, 25);

System.out.println(list2 + "\n");

Set set = new HashSet();

Collections2.fill(set, sg, 25);

System.out.println(set + "\n");

Map m = new HashMap();

Collections2.fill(m, Collections2.rsp, 25);

System.out.println(m + "\n");

Map m2 = new HashMap();

Collections2.fill(m2,

Collections2.geography, 25);

System.out.println(m2);

}

} ///:~

With these tools you can easily test the various containers by filling them

with interesting data.

5 This data was found on the Internet, then processed by creating a Python program (see

www.Python.org).

Chapter 9: Holding Your Objects

449

Container disadvantage:

unknown type

The "disadvantage" to using the Java containers is that you lose type

information when you put an object into a container. This happens

because the programmer of that container class had no idea what specific

type you wanted to put in the container, and making the container hold

only your type would prevent it from being a general-purpose tool. So

instead, the container holds references to Object, which is the root of all

the classes so it holds any type. (Of course, this doesn't include primitive

types, since they aren't inherited from anything.) This is a great solution,

except:

Since the type information is thrown away when you put an object

reference into a container, there's no restriction on the type of

object that can be put into your container, even if you mean it to

hold only, say, cats. Someone could just as easily put a dog into the

container.

Since the type information is lost, the only thing the container

knows that it holds is a reference to an object. You must perform a

cast to the correct type before you use it.

On the up side, Java won't let you misuse the objects that you put into a

container. If you throw a dog into a container of cats and then try to treat

everything in the container as a cat, you'll get a run-time exception when

you pull the dog reference out of the cat container and try to cast it to a

cat.

Here's an example using the basic workhorse container, ArrayList. For

starters, you can think of ArrayList as "an array that automatically

expands itself." Using an ArrayList is straightforward: create one, put

objects in using add( ), and later get them out with get( ) using an

index--just like you would with an array but without the square brackets6.

6 This is a place where operator overloading would be nice.

450

Thinking in Java

ArrayList also has a method size( ) to let you know how many elements

have been added so you don't inadvertently run off the end and cause an

exception.

First, Cat and Dog classes are created:

//: c09:Cat.java

public class Cat {

private int catNumber;

Cat(int i) { catNumber = i; }

void print() {

System.out.println("Cat #" + catNumber);

}

} ///:~

//: c09:Dog.java

public class Dog {

private int dogNumber;

Dog(int i) { dogNumber = i; }

void print() {

System.out.println("Dog #" + dogNumber);

}

} ///:~

Cats and Dogs are placed into the container, then pulled out:

//: c09:CatsAndDogs.java

// Simple container example.

import java.util.*;

public class CatsAndDogs {

public static void main(String[] args) {

ArrayList cats = new ArrayList();

for(int i = 0; i < 7; i++)

cats.add(new Cat(i));

// Not a problem to add a dog to cats:

cats.add(new Dog(7));

for(int i = 0; i < cats.size(); i++)

((Cat)cats.get(i)).print();

// Dog is detected only at run-time

}

} ///:~

Chapter 9: Holding Your Objects

451

The classes Cat and Dog are distinct--they have nothing in common

except that they are Objects. (If you don't explicitly say what class you're

inheriting from, you automatically inherit from Object.) Since

ArrayList holds Objects, you can not only put Cat objects into this

container using the ArrayList method add( ), but you can also add Dog

objects without complaint at either compile-time or run-time. When you

go to fetch out what you think are Cat objects using the ArrayList

method get( ), you get back a reference to an object that you must cast to

a Cat. Then you need to surround the entire expression with parentheses

to force the evaluation of the cast before calling the print( ) method for

Cat, otherwise you'll get a syntax error. Then, at run-time, when you try

to cast the Dog object to a Cat, you'll get an exception.

This is more than just an annoyance. It's something that can create

difficult-to-find bugs. If one part (or several parts) of a program inserts

objects into a container, and you discover only in a separate part of the

program through an exception that a bad object was placed in the

container, then you must find out where the bad insert occurred. On the

upside, it's convenient to start with some standardized container classes

for programming, despite the scarcity and awkwardness.

Sometimes it works anyway

It turns out that in some cases things seem to work correctly without

casting back to your original type. One case is quite special: the String

class has some extra help from the compiler to make it work smoothly.

Whenever the compiler expects a String object and it hasn't got one, it

will automatically call the toString( ) method that's defined in Object

and can be overridden by any Java class. This method produces the

desired String object, which is then used wherever it was wanted.

Thus, all you need to do to make objects of your class print is to override

the toString( ) method, as shown in the following example:

//: c09:Mouse.java

// Overriding toString().

public class Mouse {

private int mouseNumber;

Mouse(int i) { mouseNumber = i; }

// Override Object.toString():

452

Thinking in Java

public String toString() {

return "This is Mouse #" + mouseNumber;

}

public int getNumber() {

return mouseNumber;

}

} ///:~

//: c09:WorksAnyway.java

// In special cases, things just

// seem to work correctly.

import java.util.*;

class MouseTrap {

static void caughtYa(Object m) {

Mouse mouse = (Mouse)m; // Cast from Object

System.out.println("Mouse: " +

mouse.getNumber());

}

public class WorksAnyway {

public static void main(String[] args) {

ArrayList mice = new ArrayList();

for(int i = 0; i < 3; i++)

mice.add(new Mouse(i));

for(int i = 0; i < mice.size(); i++) {

// No cast necessary, automatic

// call to Object.toString():

System.out.println(

"Free mouse: " + mice.get(i));

MouseTrap.caughtYa(mice.get(i));

}

} ///:~

You can see toString( ) overridden in Mouse. In the second for loop in

main( ) you find the statement:

System.out.println("Free mouse: " + mice.get(i));

Chapter 9: Holding Your Objects

453

After the `+' sign the compiler expects to see a String object. get( )

produces an Object, so to get the desired String the compiler implicitly

calls toString( ). Unfortunately, you can work this kind of magic only

with String; it isn't available for any other type.

A second approach to hiding the cast has been placed inside

MouseTrap. The caughtYa( ) method accepts not a Mouse, but an

Object, which it then casts to a Mouse. This is quite presumptuous, of

course, since by accepting an Object anything could be passed to the

method. However, if the cast is incorrect--if you passed the wrong type--

you'll get an exception at run-time. This is not as good as compile-time

checking but it's still robust. Note that in the use of this method:

MouseTrap.caughtYa(mice.get(i));

no cast is necessary.

Making a type-conscious ArrayList

You might not want to give up on this issue just yet. A more ironclad

solution is to create a new class using the ArrayList, such that it will

accept only your type and produce only your type:

//: c09:MouseList.java

// A type-conscious ArrayList.

import java.util.*;

public class MouseList {

private ArrayList list = new ArrayList();

public void add(Mouse m) {

list.add(m);

}

public Mouse get(int index) {

return (Mouse)list.get(index);

}

public int size() { return list.size(); }

} ///:~

Here's a test for the new container:

//: c09:MouseListTest.java

public class MouseListTest {

454

Thinking in Java

public static void main(String[] args) {

MouseList mice = new MouseList();

for(int i = 0; i < 3; i++)

mice.add(new Mouse(i));

for(int i = 0; i < mice.size(); i++)

MouseTrap.caughtYa(mice.get(i));

}

} ///:~

This is similar to the previous example, except that the new MouseList

class has a private member of type ArrayList, and methods just like

ArrayList. However, it doesn't accept and produce generic Objects, only

Mouse objects.

Note that if MouseList had instead been inherited from ArrayList, the

add(Mouse) method would simply overload the existing add(Object)

and there would still be no restriction on what type of objects could be

added. Thus, the MouseList becomes a surrogate to the ArrayList,

performing some activities before passing on the responsibility (see

Thinking in Patterns with Java, downloadable at ).

Because a MouseList will accept only a Mouse, if you say:

mice.add(new Pigeon());

you will get an error message at compile-time. This approach, while more

tedious from a coding standpoint, will tell you immediately if you're using

a type improperly.

Note that no cast is necessary when using get( )--it's always a Mouse.

Parameterized types

This kind of problem isn't isolated--there are numerous cases in which

you need to create new types based on other types, and in which it is

useful to have specific type information at compile-time. This is the

concept of a parameterized type. In C++, this is directly supported by the

language with templates. It is likely that a future version of Java will

support some variation of parameterized types; the current front-runner

automatically creates classes similar to MouseList.

Chapter 9: Holding Your Objects

455

Iterators

In any container class, you must have a way to put things in and a way to

get things out. After all, that's the primary job of a container--to hold

things. In the ArrayList, add( ) is the way that you insert objects, and

get( ) is one way to get things out. ArrayList is quite flexible--you can

select anything at any time, and select multiple elements at once using

different indexes.

If you want to start thinking at a higher level, there's a drawback: you

need to know the exact type of the container in order to use it. This might

not seem bad at first, but what if you start out using an ArrayList, and

later on in your program you discover that because of the way you are

using the container it would be much more efficient to use a LinkedList

instead? Or suppose you'd like to write a piece of generic code that doesn't

know or care what type of container it's working with, so that it could be

used on different types of containers without rewriting that code?

The concept of an iterator can be used to achieve this abstraction. An

iterator is an object whose job is to move through a sequence of objects

and select each object in that sequence without the client programmer

knowing or caring about the underlying structure of that sequence. In

addition, an iterator is usually what's called a "light-weight" object: one

that's cheap to create. For that reason, you'll often find seemingly strange

constraints for iterators; for example, some iterators can move in only one

direction.

The Java Iterator is an example of an iterator with these kinds of

constraints. There's not much you can do with one except:

Ask a container to hand you an Iterator using a method called

iterator( ). This Iterator will be ready to return the first element

in the sequence on your first call to its next( ) method.

Get the next object in the sequence with next( ).

See if there are any more objects in the sequence with hasNext( ).

Remove the last element returned by the iterator with remove( ).

456

Thinking in Java

That's all. It's a simple implementation of an iterator, but still powerful

(and there's a more sophisticated ListIterator for Lists). To see how it

works, let's revisit the CatsAndDogs.java program from earlier in this

chapter. In the original version, the method get( ) was used to select each

element, but in the following modified version an Iterator is used:

//: c09:CatsAndDogs2.java

// Simple container with Iterator.

import java.util.*;

public class CatsAndDogs2 {

public static void main(String[] args) {

ArrayList cats = new ArrayList();

for(int i = 0; i < 7; i++)

cats.add(new Cat(i));

Iterator e = cats.iterator();

while(e.hasNext())

((Cat)e.next()).print();

}

} ///:~

You can see that the last few lines now use an Iterator to step through

the sequence instead of a for loop. With the Iterator, you don't need to

worry about the number of elements in the container. That's taken care of

for you by hasNext( ) and next( ).

As another example, consider the creation of a general-purpose printing

method:

//: c09:HamsterMaze.java

// Using an Iterator.

import java.util.*;

class Hamster {

private int hamsterNumber;

Hamster(int i) { hamsterNumber = i; }

public String toString() {

return "This is Hamster #" + hamsterNumber;

}

Chapter 9: Holding Your Objects

457

class Printer {

static void printAll(Iterator e) {

while(e.hasNext())

System.out.println(e.next());

}

public class HamsterMaze {

public static void main(String[] args) {

ArrayList v = new ArrayList();

for(int i = 0; i < 3; i++)

v.add(new Hamster(i));

Printer.printAll(v.iterator());

}

} ///:~

Look closely at printAll( ). Note that there's no information about the

type of sequence. All you have is an Iterator, and that's all you need to

know about the sequence: that you can get the next object, and that you

can know when you're at the end. This idea of taking a container of

objects and passing through it to perform an operation on each one is

powerful, and will be seen throughout this book.

The example is even more generic, since it implicitly uses the

Object.toString( ) method. The println( ) method is overloaded for all

the primitive types as well as Object; in each case a String is

automatically produced by calling the appropriate toString( ) method.

Although it's unnecessary, you can be more explicit using a cast, which

has the effect of calling toString( ):

System.out.println((String)e.next());

In general, however, you'll want to do something more than call Object

methods, so you'll run up against the type-casting issue again. You must

assume you've gotten an Iterator to a sequence of the particular type

you're interested in, and cast the resulting objects to that type (getting a

run-time exception if you're wrong).

458

Thinking in Java

Unintended recursion

Because (like every other class), the Java standard containers are

inherited from Object, they contain a toString( ) method. This has been

overridden so that they can produce a String representation of

themselves, including the objects they hold. Inside ArrayList, for

example, the toString( ) steps through the elements of the ArrayList

and calls toString( ) for each one. Suppose you'd like to print the address

of your class. It seems to make sense to simply refer to this (in particular,

C++ programmers are prone to this approach):

//: c09:InfiniteRecursion.java

// Accidental recursion.

import java.util.*;

public class InfiniteRecursion {

public String toString() {

return " InfiniteRecursion address: "

+ this + "\n";

}

public static void main(String[] args) {

ArrayList v = new ArrayList();

for(int i = 0; i < 10; i++)

v.add(new InfiniteRecursion());

System.out.println(v);

}

} ///:~

If you simply create an InfiniteRecursion object and then print it,

you'll get an endless sequence of exceptions. This is also true if you place

the InfiniteRecursion objects in an ArrayList and print that

ArrayList as shown here. What's happening is automatic type

conversion for Strings. When you say:

"InfiniteRecursion address: " + this

The compiler sees a String followed by a `+' and something that's not a

String, so it tries to convert this to a String. It does this conversion by

calling toString( ), which produces a recursive call.

If you really do want to print the address of the object in this case, the

solution is to call the Object toString( ) method, which does just that.

Chapter 9: Holding Your Objects

459

So instead of saying this, you'd say super.toString( ). (This only works

if you're directly inheriting from Object, or if none of your parent classes

have overridden the toString( ) method.)

Container taxonomy

Collections and Maps may be implemented in different ways, according

to your programming needs. It's helpful to look at a diagram of the Java 2

containers:

Produces

Iterator

Collection

Map

AbstractMap

Produces

ListIterator

List

Set

SortedMap

AbstractCollection

SortedSet

HashMap

TreeMap

AbstractList

AbstractSet

Hashtable

WeakHashMap

(Legacy)

HashSet

TreeSet

Utilities

Collections

Vector

ArrayList

AbstractSequentialList

(Legacy)

Arrays

LinkedList

Stack

(Legacy)

Comparable

Comparator

This diagram can be a bit overwhelming at first, but you'll see that there

are really only three container components: Map, List, and Set, and only

two or three implementations of each one (with, typically, a preferred

version). When you see this, the containers are not so daunting.

460

Thinking in Java

The dotted boxes represent interfaces, the dashed boxes represent

abstract classes, and the solid boxes are regular (concrete) classes. The

dotted-line arrows indicate that a particular class is implementing an

interface (or in the case of an abstract class, partially implementing

that interface). The solid arrows show that a class can produce objects of

the class the arrow is pointing to. For example, any Collection can

produce an Iterator, while a List can produce a ListIterator (as well as

an ordinary Iterator, since List is inherited from Collection).

The interfaces that are concerned with holding objects are Collection,

List, Set, and Map. Ideally, you'll write most of your code to talk to these

interfaces, and the only place where you'll specify the precise type you're

using is at the point of creation. So you can create a List like this:

List x = new LinkedList();

Of course, you can also decide to make x a LinkedList (instead of a

generic List) and carry the precise type information around with x. The

beauty (and the intent) of using the interface is that if you decide you

want to change your implementation, all you need to do is change it at the

point of creation, like this:

List x = new ArrayList();

The rest of your code can remain untouched (some of this genericity can

also be achieved with iterators).

In the class hierarchy, you can see a number of classes whose names begin

with "Abstract," and these can seem a bit confusing at first. They are

simply tools that partially implement a particular interface. If you were

making your own Set, for example, you wouldn't start with the Set

interface and implement all the methods, instead you'd inherit from

AbstractSet and do the minimal necessary work to make your new class.

However, the containers library contains enough functionality to satisfy

your needs virtually all the time. So for our purposes, you can ignore any

class that begins with "Abstract."

Therefore, when you look at the diagram, you're really concerned with

only those interfaces at the top of the diagram and the concrete classes

(those with solid boxes around them). You'll typically make an object of a

concrete class, upcast it to the corresponding interface, and then use the

Chapter 9: Holding Your Objects

461

interface throughout the rest of your code. In addition, you do not need

to consider the legacy elements when writing new code. Therefore, the

diagram can be greatly simplified to look like this:

Iterator

Collection

Map

Produces

ListIterator

HashMap

TreeMap

Produces

List

Set

WeakHashMap

Utilities

ArrayList

LinkedList

HashSet

TreeSet

Collections

Comparable

Comparator

Arrays

Now it only includes the interfaces and classes that you will encounter on

a regular basis, and also the elements that we will focus on in this chapter.

Here's a simple example, which fills a Collection (represented here with

an ArrayList) with String objects, and then prints each element in the

Collection:

//: c09:SimpleCollection.java

// A simple example using Java 2 Collections.

import java.util.*;

public class SimpleCollection {

public static void main(String[] args) {

// Upcast because we just want to

// work with Collection features

Collection c = new ArrayList();

for(int i = 0; i < 10; i++)

c.add(Integer.toString(i));

Iterator it = c.iterator();

while(it.hasNext())

System.out.println(it.next());

}

462

Thinking in Java

} ///:~

The first line in main( ) creates an ArrayList object and then upcasts it

to a Collection. Since this example uses only the Collection methods,

any object of a class inherited from Collection would work, but

ArrayList is the typical workhorse Collection.

The add( ) method, as its name suggests, puts a new element in the

Collection. However, the documentation carefully states that add( )

"ensures that this Container contains the specified element." This is to

allow for the meaning of Set, which adds the element only if it isn't

already there. With an ArrayList, or any sort of List, add( ) always

means "put it in," because Lists don't care if there are duplicates.

All Collections can produce an Iterator via their iterator( ) method.

Here, an Iterator is created and used to traverse the Collection,

printing each element.

Collection functionality

The following table shows everything you can do with a Collection (not

including the methods that automatically come through with Object),

and thus, everything you can do with a Set or a List. (List also has

additional functionality.) Maps are not inherited from Collection, and

will be treated separately.

boolean add(Object)

Ensures that the container holds the

argument. Returns false if it doesn't add

the argument. (This is an "optional"

method, described later in this chapter.)

boolean

Adds all the elements in the argument.

addAll(Collection)

Returns true if any elements were

added. ("Optional.")

void clear( )

Removes all the elements in the

container. ("Optional.")

boolean

true if the container holds the

contains(Object)

argument.

boolean

true if the container holds all the

containsAll(Collection)

elements in the argument.

Chapter 9: Holding Your Objects

463

boolean isEmpty( )

true if the container has no elements.

Iterator iterator( )

Returns an Iterator that you can use to

move through the elements in the

container.

boolean

If the argument is in the container, one

remove(Object)

instance of that element is removed.

Returns true if a removal occurred.

("Optional.")

boolean

Removes all the elements that are

removeAll(Collection)

contained in the argument. Returns

true if any removals occurred.

("Optional.")

boolean

Retains only elements that are

retainAll(Collection)

contained in the argument (an

"intersection" from set theory). Returns

true if any changes occurred.

("Optional.")

int size( )

Returns the number of elements in the

container.

Object[] toArray( )

Returns an array containing all the

elements in the container.

Object[]

Returns an array containing all the

toArray(Object[] a)

elements in the container, whose type is

that of the array a rather than plain

Object (you must cast the array to the

right type).

Notice that there's no get( ) function for random-access element

selection. That's because Collection also includes Set, which maintains

its own internal ordering (and thus makes random-access lookup

meaningless). Thus, if you want to examine all the elements of a

Collection you must use an iterator; that's the only way to fetch things

back.

The following example demonstrates all of these methods. Again, these

work with anything that inherits from Collection, but an ArrayList is

used as a kind of "least-common denominator":

//: c09:Collection1.java

464

Thinking in Java

// Things you can do with all Collections.

import java.util.*;

import com.bruceeckel.util.*;

public class Collection1 {

public static void main(String[] args) {

Collection c = new ArrayList();

Collections2.fill(c,

Collections2.countries, 10);

c.add("ten");

c.add("eleven");

System.out.println(c);

// Make an array from the List:

Object[] array = c.toArray();

// Make a String array from the List:

String[] str =

(String[])c.toArray(new String[1]);

// Find max and min elements; this means

// different things depending on the way

// the Comparable interface is implemented:

System.out.println("Collections.max(c) = " +

Collections.max(c));

System.out.println("Collections.min(c) = " +

Collections.min(c));

// Add a Collection to another Collection

Collection c2 = new ArrayList();

Collections2.fill(c2,

Collections2.countries, 10);

c.addAll(c2);

System.out.println(c);

c.remove(CountryCapitals.pairs[0][0]);

System.out.println(c);

c.remove(CountryCapitals.pairs[1][0]);

System.out.println(c);

// Remove all components that are in the

// argument collection:

c.removeAll(c2);

System.out.println(c);

c.addAll(c2);

System.out.println(c);

// Is an element in this Collection?

Chapter 9: Holding Your Objects

465

String val = CountryCapitals.pairs[3][0];

System.out.println(

"c.contains(" + val + ") = "

+ c.contains(val));

// Is a Collection in this Collection?

System.out.println(

"c.containsAll(c2) = "+ c.containsAll(c2));

Collection c3 = ((List)c).subList(3, 5);

// Keep all the elements that are in both

// c2 and c3 (an intersection of sets):

c2.retainAll(c3);

System.out.println(c);

// Throw away all the elements

// in c2 that also appear in c3:

c2.removeAll(c3);

System.out.println("c.isEmpty() = " +

c.isEmpty());

c = new ArrayList();

Collections2.fill(c,

Collections2.countries, 10);

System.out.println(c);

c.clear(); // Remove all elements

System.out.println("after c.clear():");

System.out.println(c);

}

} ///:~

ArrayLists are created containing different sets of data and upcast to

Collection objects, so it's clear that nothing other than the Collection

interface is being used. main( ) uses simple exercises to show all of the

methods in Collection.

The following sections describe the various implementations of List, Set,

and Map and indicate in each case (with an asterisk) which one should be

your default choice. You'll notice that the legacy classes Vector, Stack,

and Hashtable are not included because in all cases there are preferred

classes within the Java 2 Containers.

466

Thinking in Java

List functionality

The basic List is quite simple to use, as you've seen so far with

ArrayList. Although most of the time you'll just use add( ) to insert

objects, get( ) to get them out one at a time, and iterator( ) to get an

Iterator to the sequence, there's also a set of other methods that can be

useful.

In addition, there are actually two types of List: the basic ArrayList,

which excels at randomly accessing elements, and the much more

powerful LinkedList (which is not designed for fast random access, but

has a much more general set of methods).

List

Order is the most important feature of a List; it

(interface)

promises to maintain elements in a particular

sequence. List adds a number of methods to

Collection that allow insertion and removal of

elements in the middle of a List. (This is

recommended only for a LinkedList.) A List will

produce a ListIterator, and using this you can

traverse the List in both directions, as well as insert

and remove elements in the middle of the List.

ArrayList*

A List implemented with an array. Allows rapid

random access to elements, but is slow when

inserting and removing elements from the middle of

a list. ListIterator should be used only for back-

and-forth traversal of an ArrayList, but not for

inserting and removing elements, which is

expensive compared to LinkedList.

LinkedList

Provides optimal sequential access, with

inexpensive insertions and deletions from the

middle of the List. Relatively slow for random

access. (Use ArrayList instead.) Also has

addFirst( ), addLast( ), getFirst( ), getLast( ),

removeFirst( ), and removeLast( ) (which are

not defined in any interfaces or base classes) to

allow it to be used as a stack, a queue, and a deque.

The methods in the following example each cover a different group of

activities: things that every list can do (basicTest( )), moving around

Chapter 9: Holding Your Objects

467

with an Iterator (iterMotion( )) versus changing things with an

Iterator (iterManipulation( )), seeing the effects of List manipulation

(testVisual( )), and operations available only to LinkedLists.

//: c09:List1.java

// Things you can do with Lists.

import java.util.*;

import com.bruceeckel.util.*;

public class List1 {

public static List fill(List a) {

Collections2.countries.reset();

Collections2.fill(a,

Collections2.countries, 10);

return a;

}

static boolean b;

static Object o;

static int i;

static Iterator it;

static ListIterator lit;

public static void basicTest(List a) {

a.add(1, "x"); // Add at location 1

a.add("x"); // Add at end

// Add a collection:

a.addAll(fill(new ArrayList()));

// Add a collection starting at location 3:

a.addAll(3, fill(new ArrayList()));

b = a.contains("1"); // Is it in there?

// Is the entire collection in there?

b = a.containsAll(fill(new ArrayList()));

// Lists allow random access, which is cheap

// for ArrayList, expensive for LinkedList:

o = a.get(1); // Get object at location 1

i = a.indexOf("1"); // Tell index of object

b = a.isEmpty(); // Any elements inside?

it = a.iterator(); // Ordinary Iterator

lit = a.listIterator(); // ListIterator

lit = a.listIterator(3); // Start at loc 3

i = a.lastIndexOf("1"); // Last match

a.remove(1); // Remove location 1

468

Thinking in Java

a.remove("3"); // Remove this object

a.set(1, "y"); // Set location 1 to "y"

// Keep everything that's in the argument

// (the intersection of the two sets):

a.retainAll(fill(new ArrayList()));

// Remove everything that's in the argument:

a.removeAll(fill(new ArrayList()));

i = a.size(); // How big is it?

a.clear(); // Remove all elements

}

public static void iterMotion(List a) {

ListIterator it = a.listIterator();

b = it.hasNext();

b = it.hasPrevious();

o = it.next();

i = it.nextIndex();

o = it.previous();

i = it.previousIndex();

}

public static void iterManipulation(List a) {

ListIterator it = a.listIterator();

it.add("47");

// Must move to an element after add():

it.next();

// Remove the element that was just produced:

it.remove();

// Must move to an element after remove():

it.next();

// Change the element that was just produced:

it.set("47");

}

public static void testVisual(List a) {

System.out.println(a);

List b = new ArrayList();

fill(b);

System.out.print("b = ");

System.out.println(b);

a.addAll(b);

a.addAll(fill(new ArrayList()));

System.out.println(a);

// Insert, remove, and replace elements

Chapter 9: Holding Your Objects

469

// using a ListIterator:

ListIterator x = a.listIterator(a.size()/2);

x.add("one");

System.out.println(a);

System.out.println(x.next());

x.remove();

System.out.println(x.next());

x.set("47");

System.out.println(a);

// Traverse the list backwards:

x = a.listIterator(a.size());

while(x.hasPrevious())

System.out.print(x.previous() + " ");

System.out.println();

System.out.println("testVisual finished");

}

// There are some things that only

// LinkedLists can do:

public static void testLinkedList() {

LinkedList ll = new LinkedList();

fill(ll);

System.out.println(ll);

// Treat it like a stack, pushing:

ll.addFirst("one");

ll.addFirst("two");

System.out.println(ll);

// Like "peeking" at the top of a stack:

System.out.println(ll.getFirst());

// Like popping a stack:

System.out.println(ll.removeFirst());

// Treat it like a queue, pulling elements

// off the tail end:

System.out.println(ll.removeLast());

// With the above operations, it's a dequeue!

System.out.println(ll);

}

public static void main(String[] args) {

// Make and fill a new list each time:

basicTest(fill(new LinkedList()));

basicTest(fill(new ArrayList()));

470

Thinking in Java

iterMotion(fill(new LinkedList()));

iterMotion(fill(new ArrayList()));

iterManipulation(fill(new LinkedList()));

iterManipulation(fill(new ArrayList()));

testVisual(fill(new LinkedList()));

testLinkedList();

}

} ///:~

In basicTest( ) and iterMotion( ) the calls are simply made to show

the proper syntax, and while the return value is captured, it is not used. In

some cases, the return value isn't captured since it isn't typically used.

You should look up the full usage of each of these methods in the online

documentation from java.sun.com before you use them.

Making a stack from a LinkedList

A stack is sometimes referred to as a "last-in, first-out" (LIFO) container.

That is, whatever you "push" on the stack last is the first item you can

"pop" out. Like all of the other containers in Java, what you push and pop

are Objects, so you must cast what you pop, unless you're just using

Object behavior.

The LinkedList has methods that directly implement stack functionality,

so you can also just use a LinkedList rather than making a stack class.

However, a stack class can sometimes tell the story better:

//: c09:StackL.java

// Making a stack from a LinkedList.

import java.util.*;

import com.bruceeckel.util.*;

public class StackL {

private LinkedList list = new LinkedList();

public void push(Object v) {

list.addFirst(v);

}

public Object top() { return list.getFirst(); }

public Object pop() {

return list.removeFirst();

}

Chapter 9: Holding Your Objects

471

public static void main(String[] args) {

StackL stack = new StackL();

for(int i = 0; i < 10; i++)

stack.push(Collections2.countries.next());

System.out.println(stack.top());

System.out.println(stack.pop());

}

} ///:~

If you want only stack behavior, inheritance is inappropriate here because

it would produce a class with all the rest of the LinkedList methods

(you'll see later that this very mistake was made by the Java 1.0 library

designers with Stack).

Making a queue from a LinkedList

A queue is a "first-in, first-out" (FIFO) container. That is, you put things

in at one end, and pull them out at the other. So the order in which you

put them in will be the same order that they come out. LinkedList has

methods to support queue behavior, so these can be used in a Queue

class:

//: c09:Queue.java

// Making a queue from a LinkedList.

import java.util.*;

public class Queue {

private LinkedList list = new LinkedList();

public void put(Object v) { list.addFirst(v); }

public Object get() {

return list.removeLast();

}

public boolean isEmpty() {

return list.isEmpty();

}

public static void main(String[] args) {

Queue queue = new Queue();

for(int i = 0; i < 10; i++)

472

Thinking in Java

queue.put(Integer.toString(i));

while(!queue.isEmpty())

System.out.println(queue.get());

}

} ///:~

You can also easily create a deque (double-ended queue) from a

LinkedList. This is like a queue, but you can add and remove elements

from either end.

Set functionality

Set has exactly the same interface as Collection, so there isn't any extra

functionality like there is with the two different Lists. Instead, the Set is

exactly a Collection, it just has different behavior. (This is the ideal use

of inheritance and polymorphism: to express different behavior.) A Set

refuses to hold more than one instance of each object value (what

constitutes the "value" of an object is more complex, as you shall see).

Set

Each element that you add to the Set must be

(interface)

unique; otherwise the Set doesn't add the duplicate

element. Objects added to a Set must define

equals( ) to establish object uniqueness. Set has

exactly the same interface as Collection. The Set

interface does not guarantee it will maintain its

elements in any particular order.

HashSet*

For Sets where fast lookup time is important.

Objects must also define hashCode( ).

TreeSet

An ordered Set backed by a tree. This way, you can

extract an ordered sequence from a Set.

The following example does not show everything you can do with a Set,

since the interface is the same as Collection, and so was exercised in the

previous example. Instead, this demonstrates the behavior that makes a

Set unique:

//: c09:Set1.java

// Things you can do with Sets.

import java.util.*;

import com.bruceeckel.util.*;

Chapter 9: Holding Your Objects

473

public class Set1 {

static Collections2.StringGenerator gen =

Collections2.countries;

public static void testVisual(Set a) {

Collections2.fill(a, gen.reset(), 10);

System.out.println(a); // No duplicates!

// Add another set to this one:

a.addAll(a);

a.add("one");

System.out.println(a);

// Look something up:

System.out.println("a.contains(\"one\"): " +

a.contains("one"));

}

public static void main(String[] args) {

System.out.println("HashSet");

testVisual(new HashSet());

System.out.println("TreeSet");

testVisual(new TreeSet());

}

} ///:~

Duplicate values are added to the Set, but when it is printed you'll see the

Set has accepted only one instance of each value.

When you run this program you'll notice that the order maintained by the

HashSet is different from TreeSet, since each has a different way of

storing elements so they can be located later. (TreeSet keeps them

sorted, while HashSet uses a hashing function, which is designed

specifically for rapid lookups.) When creating your own types, be aware

that a Set needs a way to maintain a storage order, which means you

must implement the Comparable interface and define the

compareTo( ) method. Here's an example:

//: c09:Set2.java

// Putting your own type in a Set.

474

Thinking in Java

import java.util.*;

class MyType implements Comparable {

private int i;

public MyType(int n) { i = n; }

public boolean equals(Object o) {

return

(o instanceof MyType)

&& (i == ((MyType)o).i);

}

public int hashCode() { return i; }

public String toString() { return i + " "; }

public int compareTo(Object o) {

int i2 = ((MyType)o).i;

return (i2 < i ? -1 : (i2 == i ? 0 : 1));

}

public class Set2 {

public static Set fill(Set a, int size) {

for(int i = 0; i < size; i++)

a.add(new MyType(i));

return a;

}

public static void test(Set a) {

fill(a, 10);

fill(a, 10); // Try to add duplicates

fill(a, 10);

a.addAll(fill(new TreeSet(), 10));

System.out.println(a);

}

public static void main(String[] args) {

test(new HashSet());

test(new TreeSet());

}

} ///:~

The form for the definitions for equals( ) and hashCode( ) will be

described later in this chapter. You must define an equals( ) in both

cases, but the hashCode( ) is absolutely necessary only if the class will

be placed in a HashSet (which is likely, since that should generally be

Chapter 9: Holding Your Objects

475

your first choice as a Set implementation). However, as a programming

style you should always override hashCode( ) when you override

equals( ). This process will be fully detailed later in this chapter.

In the compareTo( ), note that I did not use the "simple and obvious"

form return i-i2. Although this is a common programming error, it

would only work properly if i and i2 were "unsigned" ints (if Java had an

"unsigned" keyword, which it does not). It breaks for Java's signed int,

which is not big enough to represent the difference of two signed ints. If i

is a large positive integer and j is a large negative integer, i-j will overflow

and return a negative value, which will not work.

SortedSet

If you have a SortedSet (of which TreeSet is the only one available), the

elements are guaranteed to be in sorted order which allows additional

functionality to be provided with these methods in the SortedSet

interface:

Comparator comparator(): Produces the Comparator used for

this Set, or null for natural ordering.

Object first(): Produces the lowest element.

Object last(): Produces the highest element.

SortedSet subSet(fromElement, toElement): Produces a view

of this Set with elements from fromElement, inclusive, to

toElement, exclusive.

SortedSet headSet(toElement): Produces a view of this Set with

elements less than toElement.

SortedSet tailSet(fromElement): Produces a view of this Set

with elements greater than or equal to fromElement.

Map functionality

An ArrayList allows you to select from a sequence of objects using a

number, so in a sense it associates numbers to objects. But what if you'd

like to select from a sequence of objects using some other criterion? A

stack is an example: its selection criterion is "the last thing pushed on the

stack." A powerful twist on this idea of "selecting from a sequence" is

476

Thinking in Java

alternately termed a map, a dictionary, or an associative array.

Conceptually, it seems like an ArrayList, but instead of looking up

objects using a number, you look them up using another object! This is

often a key process in a program.

The concept shows up in Java as the Map interface. The put(Object

key, Object value) method adds a value (the thing you want), and

associates it with a key (the thing you look it up with). get(Object key)

produces the value given the corresponding key. You can also test a Map

to see if it contains a key or a value with containsKey( ) and

containsValue( ).

The standard Java library contains two different types of Maps:

HashMap and TreeMap. Both have the same interface (since they both

implement Map), but they differ in one distinct way: efficiency. If you

look at what must be done for a get( ), it seems pretty slow to search

through (for example) an ArrayList for the key. This is where HashMap

speeds things up. Instead of a slow search for the key, it uses a special

value called a hash code. The hash code is a way to take some information

in the object in question and turn it into a "relatively unique" int for that

object. All Java objects can produce a hash code, and hashCode( ) is a

method in the root class Object. A HashMap takes the hashCode( ) of

the object and uses it to quickly hunt for the key. This results in a

dramatic performance improvement7.

Map

Maintains key-value associations (pairs), so you can

(interface)

look up a value using a key.

HashMap*

Implementation based on a hash table. (Use this

instead of Hashtable.) Provides constant-time

performance for inserting and locating pairs.

Performance can be adjusted via constructors that

allow you to set the capacity and load factor of the

7 If these speedups still don't meet your performance needs, you can further accelerate

table lookup by writing your own Map and customizing it to your particular types to avoid

delays due to casting to and from Objects. To reach even higher levels of performance,

speed enthusiasts can use Donald Knuth's The Art of Computer Programming, Volume 3:

Sorting and Searching, Second Edition to replace overflow bucket lists with arrays that

have two additional benefits: they can be optimized for disk storage characteristics and

they can save most of the time of creating and garbage collecting individual records.

Chapter 9: Holding Your Objects

477

hash table.

TreeMap

Implementation based on a red-black tree. When

you view the keys or the pairs, they will be in sorted

order (determined by Comparable or

Comparator, discussed later). The point of a

TreeMap is that you get the results in sorted order.

TreeMap is the only Map with the subMap( )

method, which allows you to return a portion of the

tree.

Sometimes you'll also need to know the details of how hashing works, so

we'll look at that a little later.

The following example uses the Collections2.fill( ) method and the test

data sets that were previously defined:

//: c09:Map1.java

// Things you can do with Maps.

import java.util.*;

import com.bruceeckel.util.*;

public class Map1 {

static Collections2.StringPairGenerator geo =

Collections2.geography;

static Collections2.RandStringPairGenerator

rsp = Collections2.rsp;

// Producing a Set of the keys:

public static void printKeys(Map m) {

System.out.print("Size = " + m.size() +", ");

System.out.print("Keys: ");

System.out.println(m.keySet());

}

// Producing a Collection of the values:

public static void printValues(Map m) {

System.out.print("Values: ");

System.out.println(m.values());

}

public static void test(Map m) {

Collections2.fill(m, geo, 25);

// Map has 'Set' behavior for keys:

Collections2.fill(m, geo.reset(), 25);

478

Thinking in Java

printKeys(m);

printValues(m);

System.out.println(m);

String key = CountryCapitals.pairs[4][0];

String value = CountryCapitals.pairs[4][1];

System.out.println("m.containsKey(\"" + key +

"\"): " + m.containsKey(key));

System.out.println("m.get(\"" + key + "\"): "

+ m.get(key));

System.out.println("m.containsValue(\""

+ value + "\"): " +

m.containsValue(value));

Map m2 = new TreeMap();

Collections2.fill(m2, rsp, 25);

m.putAll(m2);

printKeys(m);

key = m.keySet().iterator().next().toString();

System.out.println("First key in map: "+key);

m.remove(key);

printKeys(m);

m.clear();

System.out.println("m.isEmpty(): "

+ m.isEmpty());

Collections2.fill(m, geo.reset(), 25);

// Operations on the Set change the Map:

m.keySet().removeAll(m.keySet());

System.out.println("m.isEmpty(): "

+ m.isEmpty());

}

public static void main(String[] args) {

System.out.println("Testing HashMap");

test(new HashMap());

System.out.println("Testing TreeMap");

test(new TreeMap());

}

} ///:~

The printKeys( ) and printValues( ) methods are not only useful

utilities, they also demonstrate how to produce Collection views of a

Map. The keySet( ) method produces a Set backed by the keys in the

Map. Similar treatment is given to values( ), which produces a

Chapter 9: Holding Your Objects

479

Collection containing all the values in the Map. (Note that keys must be

unique, while values may contain duplicates.) Since these Collections

are backed by the Map, any changes in a Collection will be reflected in

the associated Map.

The rest of the program provides simple examples of each Map operation,

and tests each type of Map.

As an example of the use of a HashMap, consider a program to check the

randomness of Java's Math.random( ) method. Ideally, it would

produce a perfect distribution of random numbers, but to test this you

need to generate a bunch of random numbers and count the ones that fall

in the various ranges. A HashMap is perfect for this, since it associates

objects with objects (in this case, the value object contains the number

produced by Math.random( ) along with the number of times that

number appears):

//: c09:Statistics.java

// Simple demonstration of HashMap.

import java.util.*;

class Counter {

int i = 1;

public String toString() {

return Integer.toString(i);

}

class Statistics {

public static void main(String[] args) {

HashMap hm = new HashMap();

for(int i = 0; i < 10000; i++) {

// Produce a number between 0 and 20:

Integer r =

new Integer((int)(Math.random() * 20));

if(hm.containsKey(r))

((Counter)hm.get(r)).i++;

else

hm.put(r, new Counter());

}

System.out.println(hm);

480

Thinking in Java

}

} ///:~

In main( ), each time a random number is generated it is wrapped inside

an Integer object so that reference can be used with the HashMap. (You

can't use a primitive with a container, only an object reference.) The

containsKey( ) method checks to see if this key is already in the

container. (That is, has the number been found already?) If so, the get( )

method produces the associated value for the key, which in this case is a

Counter object. The value i inside the counter is incremented to indicate

that one more of this particular random number has been found.

If the key has not been found yet, the method put( ) will place a new key-

value pair into the HashMap. Since Counter automatically initializes its

variable i to one when it's created, it indicates the first occurrence of this

particular random number.

To display the HashMap, it is simply printed. The HashMap

toString( ) method moves through all the key-value pairs and calls the

toString( ) for each one. The Integer.toString( ) is predefined, and

you can see the toString( ) for Counter. The output from one run (with

some line breaks added) is:

{19=526, 18=533, 17=460, 16=513, 15=521, 14=495,

13=512, 12=483, 11=488, 10=487, 9=514, 8=523,

7=497, 6=487, 5=480, 4=489, 3=509, 2=503, 1=475,

0=505}

You might wonder at the necessity of the class Counter, which seems like

it doesn't even have the functionality of the wrapper class Integer. Why

not use int or Integer? Well, you can't use an int because all of the

containers can hold only Object references. After seeing containers the

wrapper classes might begin to make a little more sense to you, since you

can't put any of the primitive types in containers. However, the only thing

you can do with the Java wrappers is to initialize them to a particular

value and read that value. That is, there's no way to change a value once a

wrapper object has been created. This makes the Integer wrapper

immediately useless to solve our problem, so we're forced to create a new

class that does satisfy the need.

Chapter 9: Holding Your Objects

481

SortedMap

If you have a SortedMap (of which TreeMap is the only one available),

the keys are guaranteed to be in sorted order which allows additional

functionality to be provided with these methods in the SortedMap

interface:

Comparator comparator(): Produces the comparator used for this

Map, or null for natural ordering.

Object firstKey(): Produces the lowest key.

Object lastKey(): Produces the highest key.

SortedMap subMap(fromKey, toKey): Produces a view of this

Map with keys from fromKey, inclusive, to toKey, exclusive.

SortedMap headMap(toKey): Produces a view of this Map with

keys less than toKey.

SortedMap tailMap(fromKey): Produces a view of this Map with

keys greater than or equal to fromKey.

Hashing and hash codes

In the previous example, a standard library class (Integer) was used as a

key for the HashMap. It worked fine as a key, because it has all the

necessary wiring to make it work correctly as a key. But a common pitfall

occurs with HashMaps when you create your own classes to be used as

keys. For example, consider a weather predicting system that matches

Groundhog objects to Prediction objects. It seems fairly

straightforward--you create the two classes, and use Groundhog as the

key and Prediction as the value:

//: c09:SpringDetector.java

// Looks plausible, but doesn't work.

import java.util.*;

class Groundhog {

int ghNumber;

Groundhog(int n) { ghNumber = n; }

}

class Prediction {

482

Thinking in Java

boolean shadow = Math.random() > 0.5;

public String toString() {

if(shadow)

return "Six more weeks of Winter!";

else

return "Early Spring!";

}

public class SpringDetector {

public static void main(String[] args) {

HashMap hm = new HashMap();

for(int i = 0; i < 10; i++)

hm.put(new Groundhog(i), new Prediction());

System.out.println("hm = " + hm + "\n");

System.out.println(

"Looking up prediction for Groundhog #3:");

Groundhog gh = new Groundhog(3);

if(hm.containsKey(gh))

System.out.println((Prediction)hm.get(gh));

else

System.out.println("Key not found: " + gh);

}

} ///:~

Each Groundhog is given an identity number, so you can look up a

Prediction in the HashMap by saying, "Give me the Prediction

associated with Groundhog number 3." The Prediction class contains

a boolean that is initialized using Math.random( ), and a toString( )

that interprets the result for you. In main( ), a HashMap is filled with

Groundhogs and their associated Predictions. The HashMap is

printed so you can see that it has been filled. Then a Groundhog with an

identity number of 3 is used as a key to look up the prediction for

Groundhog #3 (which you can see must be in the Map).

It seems simple enough, but it doesn't work. The problem is that

Groundhog is inherited from the common root class Object (which is

what happens if you don't specify a base class, thus all classes are

ultimately inherited from Object). It is Object's hashCode( ) method

that is used to generate the hash code for each object, and by default it

just uses the address of its object. Thus, the first instance of

Chapter 9: Holding Your Objects

483

Groundhog(3) does not produce a hash code equal to the hash code for

the second instance of Groundhog(3) that we tried to use as a lookup.

You might think that all you need to do is write an appropriate override

for hashCode( ). But it still won't work until you've done one more

thing: override the equals( ) that is also part of Object. This method is

used by the HashMap when trying to determine if your key is equal to

any of the keys in the table. Again, the default Object.equals( ) simply

compares object addresses, so one Groundhog(3) is not equal to

another Groundhog(3).

Thus, to use your own classes as keys in a HashMap, you must override

both hashCode( ) and equals( ), as shown in the following solution to

the problem above:

//: c09:SpringDetector2.java

// A class that's used as a key in a HashMap

// must override hashCode() and equals().

import java.util.*;

class Groundhog2 {

int ghNumber;

Groundhog2(int n) { ghNumber = n; }

public int hashCode() { return ghNumber; }

public boolean equals(Object o) {

return (o instanceof Groundhog2)

&& (ghNumber == ((Groundhog2)o).ghNumber);

}

public class SpringDetector2 {

public static void main(String[] args) {

HashMap hm = new HashMap();

for(int i = 0; i < 10; i++)

hm.put(new Groundhog2(i),new Prediction());

System.out.println("hm = " + hm + "\n");

System.out.println(

"Looking up prediction for groundhog #3:");

Groundhog2 gh = new Groundhog2(3);

if(hm.containsKey(gh))

System.out.println((Prediction)hm.get(gh));

484

Thinking in Java

}

} ///:~

Note that this uses the Prediction class from the previous example, so

SpringDetector.java must be compiled first or you'll get a compile-

time error when you try to compile SpringDetector2.java.

Groundhog2.hashCode( ) returns the groundhog number as an

identifier. In this example, the programmer is responsible for ensuring

that no two groundhogs exist with the same ID number. The

hashCode( ) is not required to return a unique identifier (something

you'll understand better later in this chapter), but the equals( ) method

must be able to strictly determine whether two objects are equivalent.

Even though it appears that the equals( ) method is only checking to see

whether the argument is an instance of Groundhog2 (using the

instanceof keyword, which is fully explained in Chapter 12), the

instanceof actually quietly does a second sanity check, to see if the

object is null, since instanceof produces false if the left-hand argument

is null. Assuming it's the correct type and not null, the comparison is

based on the actual ghNumbers. This time, when you run the program,

you'll see it produces the correct output.

When creating your own class to use in a HashSet, you must pay

attention to the same issues as when it is used as a key in a HashMap.

Understanding hashCode( )

The above example is only a start toward solving the problem correctly. It

shows that if you do not override hashCode( ) and equals( ) for your

key, the hashed data structure (HashSet or HashMap) will not be able

to deal with your key properly. However, to get a good solution for the

problem you need to understand what's going on inside the hashed data

structure.

First, consider the motivation behind hashing: you want to look up an

object using another object. But you can accomplish this with a TreeSet

or TreeMap, too. It's also possible to implement your own Map. To do

so, the Map.entrySet( ) method must be supplied to produce a set of

Map.Entry objects. MPair will be defined as the new type of

Chapter 9: Holding Your Objects

485

Map.Entry. In order for it to be placed in a TreeSet it must implement

equals( ) and be Comparable:

//: c09:MPair.java

// A Map implemented with ArrayLists.

import java.util.*;

public class MPair

implements Map.Entry, Comparable {

Object key, value;

MPair(Object k, Object v) {

key = k;

value = v;

}

public Object getKey() { return key; }

public Object getValue() { return value; }

public Object setValue(Object v){

Object result = value;

value = v;

return result;

}

public boolean equals(Object o) {

return key.equals(((MPair)o).key);

}

public int compareTo(Object rv) {

return ((Comparable)key).compareTo(

((MPair)rv).key);

}

} ///:~

Notice that the comparisons are only interested in the keys, so duplicate

values are perfectly acceptable.

The following example implements a Map using a pair of ArrayLists:

//: c09:SlowMap.java

// A Map implemented with ArrayLists.

import java.util.*;

import com.bruceeckel.util.*;

public class SlowMap extends AbstractMap {

private ArrayList

486

Thinking in Java

keys = new ArrayList(),

values = new ArrayList();

public Object put(Object key, Object value) {

Object result = get(key);

if(!keys.contains(key)) {

keys.add(key);

values.add(value);

} else

values.set(keys.indexOf(key), value);

return result;

}

public Object get(Object key) {

if(!keys.contains(key))

return null;

return values.get(keys.indexOf(key));

}

public Set entrySet() {

Set entries = new HashSet();

Iterator

ki = keys.iterator(),

vi = values.iterator();

while(ki.hasNext())

entries.add(new MPair(ki.next(), vi.next()));

return entries;

}

public static void main(String[] args) {

SlowMap m = new SlowMap();

Collections2.fill(m,

Collections2.geography, 25);

System.out.println(m);

}

} ///:~

The put( ) method simply places the keys and values in corresponding

ArrayLists. In main( ), a SlowMap is loaded and then printed to show

that it works.

This shows that it's not that hard to produce a new type of Map. But as

the name suggests, a SlowMap isn't very fast, so you probably wouldn't

use it if you had an alternative available. The problem is in the lookup of

Chapter 9: Holding Your Objects

487

the key: there is no order so a simple linear search is used, which is the

slowest way to look something up.

The whole point of hashing is speed: hashing allows the lookup to happen

quickly. Since the bottleneck is in the speed of the key lookup, one of the

solutions to the problem could be by keeping the keys sorted and then

using Collections.binarySearch( ) to perform the lookup (an exercise

at the end of this chapter will walk you through this process).

Hashing goes further by saying that all you want to do is to store the key

somewhere so that it can be quickly found. As you've seen in this chapter,

the fastest structure in which to store a group of elements is an array, so

that will be used for representing the key information (note carefully that

I said "key information," and not the key itself). Also seen in this chapter

was the fact that an array, once allocated, cannot be resized, so we have a

problem: we want to be able to store any number of values in the Map,

but if the number of keys is fixed by the array size, how can this be?

The answer is that the array will not hold the keys. From the key object, a

number will be derived that will index into the array. This number is the

hash code, produced by the hashCode( ) method (in computer science

parlance, this is the hash function) defined in Object and presumably

overridden by your class. To solve the problem of the fixed-size array,

more than one key may produce the same index. That is, there may be

collisions. Because of this, it doesn't matter how big the array is because

each key object will land somewhere in that array.

So the process of looking up a value starts by computing the hash code

and using it to index into the array. If you could guarantee that there were

no collisions (which could be possible if you have a fixed number of

values) then you'd have a perfect hashing function, but that's a special

case. In all other cases, collisions are handled by external chaining: the

array points not directly to a value, but instead to a list of values. These

values are searched in a linear fashion using the equals( ) method. Of

course, this aspect of the search is much slower, but if the hash function is

good there will only be a few values in each slot, at the most. So instead of

searching through the entire list, you quickly jump to a slot where you

have to compare a few entries to find the value. This is much faster, which

is why the HashMap is so quick.

488

Thinking in Java

Knowing the basics of hashing, it's possible to implement a simple hashed

Map:

//: c09:SimpleHashMap.java

// A demonstration hashed Map.

import java.util.*;

import com.bruceeckel.util.*;

public class SimpleHashMap extends AbstractMap {

// Choose a prime number for the hash table

// size, to achieve a uniform distribution:

private final static int SZ = 997;

private LinkedList[] bucket= new LinkedList[SZ];

public Object put(Object key, Object value) {

Object result = null;

int index = key.hashCode() % SZ;

if(index < 0) index = -index;

if(bucket[index] == null)

bucket[index] = new LinkedList();

LinkedList pairs = bucket[index];

MPair pair = new MPair(key, value);

ListIterator it = pairs.listIterator();

boolean found = false;

while(it.hasNext()) {

Object iPair = it.next();

if(iPair.equals(pair)) {

result = ((MPair)iPair).getValue();

it.set(pair); // Replace old with new

found = true;

break;

}

if(!found)

bucket[index].add(pair);

return result;

}

public Object get(Object key) {

int index = key.hashCode() % SZ;

if(index < 0) index = -index;

if(bucket[index] == null) return null;

LinkedList pairs = bucket[index];

Chapter 9: Holding Your Objects

489

MPair match = new MPair(key, null);

ListIterator it = pairs.listIterator();

while(it.hasNext()) {

Object iPair = it.next();

if(iPair.equals(match))

return ((MPair)iPair).getValue();

}

return null;

}

public Set entrySet() {

Set entries = new HashSet();

for(int i = 0; i < bucket.length; i++) {

if(bucket[i] == null) continue;

Iterator it = bucket[i].iterator();

while(it.hasNext())

entries.add(it.next());

}

return entries;

}

public static void main(String[] args) {

SimpleHashMap m = new SimpleHashMap();

Collections2.fill(m,

Collections2.geography, 25);

System.out.println(m);

}

} ///:~

Because the "slots" in a hash table are often referred to as buckets, the

array that represents the actual table is called bucket. To promote even

distribution, the number of buckets is typically a prime number. Notice

that it is an array of LinkedList, which automatically provides for

collisions--each new item is simply added to the end of the list.

The return value of put( ) is null or, if the key was already in the list, the

old value associated with that key. The return value is result, which is

initialized to null, but if a key is discovered in the list then result is

assigned to that key.

For both put( ) and get( ), the first thing that happens is that the

hashCode( ) is called for the key, and the result is forced to a positive

number. Then it is forced to fit into the bucket array using the modulus

490

Thinking in Java

operator and the size of the array. If that location is null, it means there

are no elements that hash to that location, so a new LinkedList is

created to hold the object that just did. However, the normal process is to

look through the list to see if there are duplicates, and if there are, the old

value is put into result and the new value replaces the old. The found

flag keeps track of whether an old key-value pair was found and, if not,

the new pair is appended to the end of the list.

In get( ), you'll see very similar code as that contained in put( ), but

simpler. The index is calculated into the bucket array, and if a

LinkedList exists it is searched for a match.

entrySet( ) must find and traverse all the lists, adding them to the result

Set. Once this method has been created, the Map can be tested by filling

it with values and then printing them.

HashMap performance factors

To understand the issues, some terminology is necessary:

Capacity: The number of buckets in the table.

Initial capacity: The number of buckets when the table is created.

HashMap and HashSet: have constructors that allow you to specify

the initial capacity.

Size: The number of entries currently in the table.

Load factor: size/capacity. A load factor of 0 is an empty table, 0.5

is a half-full table, etc. A lightly-loaded table will have few collisions

and so is optimal for insertions and lookups (but will slow down the

process of traversing with an iterator). HashMap and HashSet have

constructors that allow you to specify the load factor, which means

that when this load factor is reached the container will automatically

increase the capacity (the number of buckets) by roughly doubling it,

and will redistribute the existing objects into the new set of buckets

(this is called rehashing).

The default load factor used by HashMap is 0.75 (it doesn't rehash until

the table is ¾ full). This seems to be a good trade-off between time and

space costs. A higher load factor decreases the space required by the table

but increases the lookup cost, which is important because lookup is what

you do most of the time (including both get( ) and put( )).

Chapter 9: Holding Your Objects

491

If you know that you'll be storing many entries in a HashMap, creating it

with an appropriately large initial capacity will prevent the overhead of

automatic rehashing.

Overriding hashCode( )

Now that you understand what's involved in the function of the

HashMap, the issues involved in writing a hashCode( ) will make more

sense.

First of all, you don't have control of the creation of the actual value that's

used to index into the array of buckets. That is dependent on the capacity

of the particular HashMap object, and that capacity changes depending

on how full the container is, and what the load factor is. The value

produced by your hashCode( ) will be further processed in order to

create the bucket index (in SimpleHashMap the calculation is just a

modulo by the size of the bucket array).

The most important factor in creating a hashCode( ) is that, regardless

of when hashCode( ) is called, it produces the same value for a

particular object every time it is called. If you end up with an object that

produces one hashCode( ) value when it is put( ) into a HashMap, and

another during a get( ), you won't be able to retrieve the objects. So if

your hashCode( ) depends on mutable data in the object the user must

be made aware that changing the data will effectively produce a different

key by generating a different hashCode( ).

In addition, you will probably not want to generate a hashCode( ) that is

based on unique object information--in particular, the value of this

makes a bad hashCode( ) because then you can't generate a new

identical key to the one used to put( ) the original key-value pair. This

was the problem that occurred in SpringDetector.java because the

default implementation of hashCode( ) does use the object address. So

you'll want to use information in the object that identifies the object in a

meaningful way.

One example is found in the String class. Strings have the special

characteristic that if a program has several String objects that contain

identical character sequences, then those String objects all map to the

same memory (the mechanism for this is described in Appendix A). So it

492

Thinking in Java

makes sense that the hashCode( ) produced by two separate instances of

new String("hello") should be identical. You can see it by running this

program:

//: c09:StringHashCode.java

public class StringHashCode {

public static void main(String[] args) {

System.out.println("Hello".hashCode());

}

} ///:~

For this to work, the hashCode( ) for String must be based on the

contents of the String.

So for a hashCode( ) to be effective, it must be fast and it must be

meaningful: that is, it must generate a value based on the contents of the

object. Remember that this value doesn't have to be unique--you should

lean toward speed rather than uniqueness--but between hashCode( )

and equals( ) the identity of the object must be completely resolved.

Because the hashCode( ) is further processed before the bucket index is

produced, the range of values is not important; it just needs to generate

an int.

There's one other factor: a good hashCode( ) should result in an even

distribution of values. If the values tend to cluster, then the HashMap or

HashSet will be more heavily loaded in some areas and will not be as fast

as it could be with an evenly distributed hashing function.

Here's an example that follows these guidelines:

//: c09:CountedString.java

// Creating a good hashCode().

import java.util.*;

public class CountedString {

private String s;

private int id = 0;

private static ArrayList created =

new ArrayList();

public CountedString(String str) {

Chapter 9: Holding Your Objects

493

s = str;

created.add(s);

Iterator it = created.iterator();

// Id is the total number of instances

// of this string in use by CountedString:

while(it.hasNext())

if(it.next().equals(s))

id++;

}

public String toString() {

return "String: " + s + " id: " + id +

" hashCode(): " + hashCode() + "\n";

}

public int hashCode() {

return s.hashCode() * id;

}

public boolean equals(Object o) {

return (o instanceof CountedString)

&& s.equals(((CountedString)o).s)

&& id == ((CountedString)o).id;

}

public static void main(String[] args) {

HashMap m = new HashMap();

CountedString[] cs = new CountedString[10];

for(int i = 0; i < cs.length; i++) {

cs[i] = new CountedString("hi");

m.put(cs[i], new Integer(i));

}

System.out.println(m);

for(int i = 0; i < cs.length; i++) {

System.out.print("Looking up " + cs[i]);

System.out.println(m.get(cs[i]));

}

} ///:~

CountedString includes a String and an id that represents the number

of CountedString objects that contain an identical String. The counting

is accomplished in the constructor by iterating through the static

ArrayList where all the Strings are stored.

494

Thinking in Java

Both hashCode( ) and equals( ) produce results based on both fields; if

they were just based on the String alone or the id alone there would be

duplicate matches for distinct values.

Note how simple the hashCode( ) is: String's hashCode( ) is

multiplied by the id. Smaller is generally better (and faster) for

hashCode( ).

In main( ), a bunch of CountedString objects are created, using the

same String to show that the duplicates create unique values because of

the count id. The HashMap is displayed so that you can see how it is

stored internally (no discernible orders) and then each key is looked up

individually to demonstrate that the lookup mechanism is working

properly.

Holding references

The java.lang.ref library contains a set of classes that allow greater

flexibility in garbage collection, which are especially useful when you have

large objects that may cause memory exhaustion. There are three classes

inherited from the abstract class Reference: SoftReference,

WeakReference, and PhantomReference. Each of these provides a

different level of indirection for the garbage collector, if the object in

question is only reachable through one of these Reference objects.

If an object is reachable it means that somewhere in your program the

object can be found. This could mean that you have an ordinary reference

on the stack that goes right to the object, but you might also have a

reference to an object that has a reference to the object in question; there

could be many intermediate links. If an object is reachable, the garbage

collector cannot release it because it's still in use by your program. If an

object isn't reachable, there's no way for your program to use it so it's safe

to garbage-collect that object.

You use Reference objects when you want to continue to hold onto a

reference to that object--you want to be able to reach that object--but you

also want to allow the garbage collector to release that object. Thus, you

have a way to go on using the object, but if memory exhaustion is

imminent you allow that object to be released.

Chapter 9: Holding Your Objects

495

You accomplish this by using a Reference object as an intermediary

between you and the ordinary reference, and there must be no ordinary

references to the object (ones that are not wrapped inside Reference

objects). If the garbage collector discovers that an object is reachable

through an ordinary reference, it will not release that object.

In the order SoftReference, WeakReference, and

PhantomReference, each one is "weaker" than the last, and

corresponds to a different level of reachability. Soft references are for

implementing memory-sensitive caches. Weak references are for

implementing "canonicalizing mappings"--where instances of objects can

be simultaneously used in multiple places in a program, to save storage--

that do not prevent their keys (or values) from being reclaimed. Phantom

references are for scheduling pre-mortem cleanup actions in a more

flexible way than is possible with the Java finalization mechanism.

With SoftReferences and WeakReferences, you have a choice about

whether to place them on a ReferenceQueue (the device used for

premortem cleanup actions), but a PhantomReference can only be

built on a ReferenceQueue. Here's a simple demonstration:

//: c09:References.java

// Demonstrates Reference objects

import java.lang.ref.*;

class VeryBig {

static final int SZ = 10000;

double[] d = new double[SZ];

String ident;

public VeryBig(String id) { ident = id; }

public String toString() { return ident; }

public void finalize() {

System.out.println("Finalizing " + ident);

}

public class References {

static ReferenceQueue rq= new ReferenceQueue();

public static void checkQueue() {

Object inq = rq.poll();

if(inq != null)

496

Thinking in Java

System.out.println("In queue: " +

(VeryBig)((Reference)inq).get());

}

public static void main(String[] args) {

int size = 10;

// Or, choose size via the command line:

if(args.length > 0)

size = Integer.parseInt(args[0]);

SoftReference[] sa =

new SoftReference[size];

for(int i = 0; i < sa.length; i++) {

sa[i] = new SoftReference(

new VeryBig("Soft " + i), rq);

System.out.println("Just created: " +

(VeryBig)sa[i].get());

checkQueue();

}

WeakReference[] wa =

new WeakReference[size];

for(int i = 0; i < wa.length; i++) {

wa[i] = new WeakReference(

new VeryBig("Weak " + i), rq);

System.out.println("Just created: " +

(VeryBig)wa[i].get());

checkQueue();

}

SoftReference s = new SoftReference(

new VeryBig("Soft"));

WeakReference w = new WeakReference(

new VeryBig("Weak"));

System.gc();

PhantomReference[] pa =

new PhantomReference[size];

for(int i = 0; i < pa.length; i++) {

pa[i] = new PhantomReference(

new VeryBig("Phantom " + i), rq);

System.out.println("Just created: " +

(VeryBig)pa[i].get());

checkQueue();

}

Chapter 9: Holding Your Objects

497

} ///:~

When you run this program (you'll want to pipe the output through a

"more" utility so that you can view the output in pages), you'll see that the

objects are garbage-collected, even though you still have access to them

through the Reference object (to get the actual object reference, you use

get( )). You'll also see that the ReferenceQueue always produces a

Reference containing a null object. To make use of this, you can inherit

from the particular Reference class you're interested in and add more

useful methods to the new type of Reference.

The WeakHashMap

The containers library has a special Map to hold weak references: the

WeakHashMap. This class is designed to make the creation of

canonicalized mappings easier. In such a mapping, you are saving storage

by making only one instance of a particular value. When the program

needs that value, it looks up the existing object in the mapping and uses

that (rather than creating one from scratch). The mapping may make the

values as part of its initialization, but it's more likely that the values are

made on demand.

Since this is a storage-saving technique, it's very convenient that the

WeakHashMap allows the garbage collector to automatically clean up

the keys and values. You don't have to do anything special to the keys and

values you want to place in the WeakHashMap; these are automatically

wrapped in WeakReferences by the map. The trigger to allow cleanup is

if the key is no longer in use, as demonstrated here:

//: c09:CanonicalMapping.java

// Demonstrates WeakHashMap.

import java.util.*;

import java.lang.ref.*;

class Key {

String ident;

public Key(String id) { ident = id; }

public String toString() { return ident; }

public int hashCode() {

return ident.hashCode();

}

498

Thinking in Java

public boolean equals(Object r) {

return (r instanceof Key)

&& ident.equals(((Key)r).ident);

}

public void finalize() {

System.out.println("Finalizing Key "+ ident);

}

class Value {

String ident;

public Value(String id) { ident = id; }

public String toString() { return ident; }

public void finalize() {

System.out.println("Finalizing Value "+ident);

}

public class CanonicalMapping {

public static void main(String[] args) {

int size = 1000;

// Or, choose size via the command line:

if(args.length > 0)

size = Integer.parseInt(args[0]);

Key[] keys = new Key[size];

WeakHashMap whm = new WeakHashMap();

for(int i = 0; i < size; i++) {

Key k = new Key(Integer.toString(i));

Value v = new Value(Integer.toString(i));

if(i % 3 == 0)

keys[i] = k; // Save as "real" references

whm.put(k, v);

}

System.gc();

}

} ///:~

The Key class must have a hashCode( ) and an equals( ) since it is

being used as a key in a hashed data structure, as described previously in

this chapter.

Chapter 9: Holding Your Objects

499

When you run the program you'll see that the garbage collector will skip

every third key, because an ordinary reference to that key has also been

placed in the keys array and thus those objects cannot be garbage-

collected.

Iterators revisited

We can now demonstrate the true power of the Iterator: the ability to

separate the operation of traversing a sequence from the underlying

structure of that sequence. In the following example, the class PrintData

uses an Iterator to move through a sequence and call the toString( )

method for every object. Two different types of containers are created--an

ArrayList and a HashMap--and they are each filled with, respectively,

Mouse and Hamster objects. (These classes are defined earlier in this

chapter.) Because an Iterator hides the structure of the underlying

container, PrintData doesn't know or care what kind of container the

Iterator comes from:

//: c09:Iterators2.java

// Revisiting Iterators.

import java.util.*;

class PrintData {

static void print(Iterator e) {

while(e.hasNext())

System.out.println(e.next());

}

class Iterators2 {

public static void main(String[] args) {

ArrayList v = new ArrayList();

for(int i = 0; i < 5; i++)

v.add(new Mouse(i));

HashMap m = new HashMap();

for(int i = 0; i < 5; i++)

m.put(new Integer(i), new Hamster(i));

System.out.println("ArrayList");

PrintData.print(v.iterator());

System.out.println("HashMap");

500

Thinking in Java

PrintData.print(m.entrySet().iterator());

}

} ///:~

For the HashMap, the entrySet( ) method produces a Set of

Map.entry objects, which contain both the key and the value for each

entry, so you see both of them printed.

Note that PrintData.print( ) takes advantage of the fact that the objects

in these containers are of class Object so the call toString( ) by

System.out.println( ) is automatic. It's more likely that in your

problem, you must make the assumption that your Iterator is walking

through a container of some specific type. For example, you might assume

that everything in the container is a Shape with a draw( ) method. Then

you must downcast from the Object that Iterator.next( ) returns to

produce a Shape.

Choosing an

implementation

By now you should understand that there are really only three container

components: Map, List, and Set, and only two or three implementations

of each interface. If you need to use the functionality offered by a

particular interface, how do you decide which particular implementation

to use?

To understand the answer, you must be aware that each different

implementation has its own features, strengths, and weaknesses. For

example, you can see in the diagram that the "feature" of Hashtable,

Vector, and Stack is that they are legacy classes, so that old code doesn't

break. On the other hand, it's best if you don't use those for new (Java 2)

code.

The distinction between the other containers often comes down to what

they are "backed by"; that is, the data structures that physically

implement your desired interface. This means that, for example,

ArrayList and LinkedList implement the List interface so your

program will produce the same results regardless of the one you use.

Chapter 9: Holding Your Objects

501

However, ArrayList is backed by an array, while the LinkedList is

implemented in the usual way for a doubly linked list, as individual

objects each containing data along with references to the previous and

next elements in the list. Because of this, if you want to do many

insertions and removals in the middle of a list, a LinkedList is the

appropriate choice. (LinkedList also has additional functionality that is

established in AbstractSequentialList.) If not, an ArrayList is

typically faster.

As another example, a Set can be implemented as either a TreeSet or a

HashSet. A TreeSet is backed by a TreeMap and is designed to

produce a constantly sorted set. However, if you're going to have larger

quantities in your Set, the performance of TreeSet insertions will get

slow. When you're writing a program that needs a Set, you should choose

HashSet by default, and change to TreeSet when it's more important to

have a constantly sorted set.

Choosing between Lists

The most convincing way to see the differences between the

implementations of List is with a performance test. The following code

establishes an inner base class to use as a test framework, then creates an

array of anonymous inner classes, one for each different test. Each of

these inner classes is called by the test( ) method. This approach allows

you to easily add and remove new kinds of tests.

//: c09:ListPerformance.java

// Demonstrates performance differences in Lists.

import java.util.*;

import com.bruceeckel.util.*;

public class ListPerformance {

private abstract static class Tester {

String name;

int size; // Test quantity

Tester(String name, int size) {

this.name = name;

this.size = size;

}

abstract void test(List a, int reps);

502

Thinking in Java

}

private static Tester[] tests = {

new Tester("get", 300) {

void test(List a, int reps) {

for(int i = 0; i < reps; i++) {

for(int j = 0; j < a.size(); j++)

a.get(j);

}

new Tester("iteration", 300) {

void test(List a, int reps) {

for(int i = 0; i < reps; i++) {

Iterator it = a.iterator();

while(it.hasNext())

it.next();

}

new Tester("insert", 5000) {

void test(List a, int reps) {

int half = a.size()/2;

String s = "test";

ListIterator it = a.listIterator(half);

for(int i = 0; i < size * 10; i++)

it.add(s);

}

new Tester("remove", 5000) {

void test(List a, int reps) {

ListIterator it = a.listIterator(3);

while(it.hasNext()) {

it.next();

it.remove();

}

};

public static void test(List a, int reps) {

// A trick to print out the class name:

System.out.println("Testing " +

Chapter 9: Holding Your Objects

503

Table of Contents:
