class Wind extends Instrument {

public void play() {

System.out.println("Wind.play()");

}

public String what() { return "Wind"; }

public void adjust() {}

}

class Percussion extends Instrument {

public void play() {

System.out.println("Percussion.play()");

}

public String what() { return "Percussion"; }

public void adjust() {}

}

class Stringed extends Instrument {

public void play() {

System.out.println("Stringed.play()");

}

public String what() { return "Stringed"; }

public void adjust() {}

}

class Brass extends Wind {

public void play() {

System.out.println("Brass.play()");

}

public void adjust() {

System.out.println("Brass.adjust()");

}

class Woodwind extends Wind {

public void play() {

System.out.println("Woodwind.play()");

}

public String what() { return "Woodwind"; }

}

322

Thinking in Java

public class Music3 {

// Doesn't care about type, so new types

// added to the system still work right:

static void tune(Instrument i) {

// ...

i.play();

}

static void tuneAll(Instrument[] e) {

for(int i = 0; i < e.length; i++)

tune(e[i]);

}

public static void main(String[] args) {

Instrument[] orchestra = new Instrument[5];

int i = 0;

// Upcasting during addition to the array:

orchestra[i++] = new Wind();

orchestra[i++] = new Percussion();

orchestra[i++] = new Stringed();

orchestra[i++] = new Brass();

orchestra[i++] = new Woodwind();

tuneAll(orchestra);

}

} ///:~

The new methods are what( ), which returns a String reference with a

description of the class, and adjust( ), which provides some way to adjust

each instrument.

In main( ), when you place something inside the Instrument array you

automatically upcast to Instrument.

You can see that the tune( ) method is blissfully ignorant of all the code

changes that have happened around it, and yet it works correctly. This is

exactly what polymorphism is supposed to provide. Your code changes

don't cause damage to parts of the program that should not be affected.

Put another way, polymorphism is one of the most important techniques

that allow the programmer to "separate the things that change from the

things that stay the same."

Chapter 7: Polymorphism

323

Overriding vs. overloading

Let's take a different look at the first example in this chapter. In the

following program, the interface of the method play( ) is changed in the

process of overriding it, which means that you haven't overridden the

method, but instead overloaded it. The compiler allows you to overload

methods so it gives no complaint. But the behavior is probably not what

you want. Here's the example:

//: c07:WindError.java

// Accidentally changing the interface.

class NoteX {

public static final int

MIDDLE_C = 0, C_SHARP = 1, C_FLAT = 2;

}

class InstrumentX {

public void play(int NoteX) {

System.out.println("InstrumentX.play()");

}

class WindX extends InstrumentX {

// OOPS! Changes the method interface:

public void play(NoteX n) {

System.out.println("WindX.play(NoteX n)");

}

public class WindError {

public static void tune(InstrumentX i) {

// ...

i.play(NoteX.MIDDLE_C);

}

public static void main(String[] args) {

WindX flute = new WindX();

tune(flute); // Not the desired behavior!

}

} ///:~

324

Thinking in Java

There's another confusing aspect thrown in here. In InstrumentX, the

play( ) method takes an int that has the identifier NoteX. That is, even

though NoteX is a class name, it can also be used as an identifier without

complaint. But in WindX, play( ) takes a NoteX reference that has an

identifier n. (Although you could even say play(NoteX NoteX) without

an error.) Thus it appears that the programmer intended to override

play( ) but mistyped the method a bit. The compiler, however, assumed

that an overload and not an override was intended. Note that if you follow

the standard Java naming convention, the argument identifier would be

noteX (lowercase `n'), which would distinguish it from the class name.

In tune, the InstrumentX i is sent the play( ) message, with one of

NoteX's members (MIDDLE_C) as an argument. Since NoteX contains

int definitions, this means that the int version of the now-overloaded

play( ) method is called, and since that has not been overridden the base-

class version is used.

The output is:

InstrumentX.play()

This certainly doesn't appear to be a polymorphic method call. Once you

understand what's happening, you can fix the problem fairly easily, but

imagine how difficult it might be to find the bug if it's buried in a program

of significant size.

Abstract classes

and methods

In all the instrument examples, the methods in the base class

Instrument were always "dummy" methods. If these methods are ever

called, you've done something wrong. That's because the intent of

Instrument is to create a common interface for all the classes derived

from it.

The only reason to establish this common interface is so it can be

expressed differently for each different subtype. It establishes a basic

form, so you can say what's in common with all the derived classes.

Chapter 7: Polymorphism

325

Another way of saying this is to call Instrument an abstract base class

(or simply an abstract class). You create an abstract class when you want

to manipulate a set of classes through this common interface. All derived-

class methods that match the signature of the base-class declaration will

be called using the dynamic binding mechanism. (However, as seen in the

last section, if the method's name is the same as the base class but the

arguments are different, you've got overloading, which probably isn't what

you want.)

If you have an abstract class like Instrument, objects of that class almost

always have no meaning. That is, Instrument is meant to express only

the interface, and not a particular implementation, so creating an

Instrument object makes no sense, and you'll probably want to prevent

the user from doing it. This can be accomplished by making all the

methods in Instrument print error messages, but that delays the

information until run-time and requires reliable exhaustive testing on the

user's part. It's always better to catch problems at compile-time.

Java provides a mechanism for doing this called the abstract method1.

This is a method that is incomplete; it has only a declaration and no

method body. Here is the syntax for an abstract method declaration:

abstract void f();

A class containing abstract methods is called an abstract class. If a class

contains one or more abstract methods, the class must be qualified as

abstract. (Otherwise, the compiler gives you an error message.)

If an abstract class is incomplete, what is the compiler supposed to do

when someone tries to make an object of that class? It cannot safely create

an object of an abstract class, so you get an error message from the

compiler. This way the compiler ensures the purity of the abstract class,

and you don't need to worry about misusing it.

If you inherit from an abstract class and you want to make objects of the

new type, you must provide method definitions for all the abstract

methods in the base class. If you don't (and you may choose not to), then

1 For C++ programmers, this is the analogue of C++'s pure virtual function.

326

Thinking in Java

the derived class is also abstract and the compiler will force you to qualify

that class with the abstract keyword.

It's possible to create a class as abstract without including any abstract

methods. This is useful when you've got a class in which it doesn't make

sense to have any abstract methods, and yet you want to prevent any

instances of that class.

The Instrument class can easily be turned into an abstract class. Only

some of the methods will be abstract, since making a class abstract

doesn't force you to make all the methods abstract. Here's what it looks

like:

abstract Instrument

abstract void play();

String what() { /* ... */ }

abstract void adjust();

extends

Wind

Percussion

Stringed

void play()

String what()

void adjust()

extends

Woodwind

Brass

void play()

String what()

void adjust()

Here's the orchestra example modified to use abstract classes and

methods:

//: c07:music4:Music4.java

Chapter 7: Polymorphism

327

// Abstract classes and methods.

import java.util.*;

abstract class Instrument {

int i; // storage allocated for each

public abstract void play();

public String what() {

return "Instrument";

}

public abstract void adjust();

}

class Wind extends Instrument {

public void play() {

System.out.println("Wind.play()");

}

public String what() { return "Wind"; }

public void adjust() {}

}

class Percussion extends Instrument {

public void play() {

System.out.println("Percussion.play()");

}

public String what() { return "Percussion"; }

public void adjust() {}

}

class Stringed extends Instrument {

public void play() {

System.out.println("Stringed.play()");

}

public String what() { return "Stringed"; }

public void adjust() {}

}

class Brass extends Wind {

public void play() {

System.out.println("Brass.play()");

}

public void adjust() {

328

Thinking in Java

System.out.println("Brass.adjust()");

}

class Woodwind extends Wind {

public void play() {

System.out.println("Woodwind.play()");

}

public String what() { return "Woodwind"; }

}

public class Music4 {

// Doesn't care about type, so new types

// added to the system still work right:

static void tune(Instrument i) {

// ...

i.play();

}

static void tuneAll(Instrument[] e) {

for(int i = 0; i < e.length; i++)

tune(e[i]);

}

public static void main(String[] args) {

Instrument[] orchestra = new Instrument[5];

int i = 0;

// Upcasting during addition to the array:

orchestra[i++] = new Wind();

orchestra[i++] = new Percussion();

orchestra[i++] = new Stringed();

orchestra[i++] = new Brass();

orchestra[i++] = new Woodwind();

tuneAll(orchestra);

}

} ///:~

You can see that there's really no change except in the base class.

It's helpful to create abstract classes and methods because they make the

abstractness of a class explicit, and tell both the user and the compiler

how it was intended to be used.

Chapter 7: Polymorphism

329

Constructors and

polymorphism

As usual, constructors are different from other kinds of methods. This is

also true when polymorphism is involved. Even though constructors are

not polymorphic (although you can have a kind of "virtual constructor," as

you will see in Chapter 12), it's important to understand the way

constructors work in complex hierarchies and with polymorphism. This

understanding will help you avoid unpleasant entanglements.

Order of constructor calls

The order of constructor calls was briefly discussed in Chapter 4 and

again in Chapter 6, but that was before polymorphism was introduced.

A constructor for the base class is always called in the constructor for a

derived class, chaining up the inheritance hierarchy so that a constructor

for every base class is called. This makes sense because the constructor

has a special job: to see that the object is built properly. A derived class

has access to its own members only, and not to those of the base class

(whose members are typically private). Only the base-class constructor

has the proper knowledge and access to initialize its own elements.

Therefore, it's essential that all constructors get called, otherwise the

entire object wouldn't be constructed. That's why the compiler enforces a

constructor call for every portion of a derived class. It will silently call the

default constructor if you don't explicitly call a base-class constructor in

the derived-class constructor body. If there is no default constructor, the

compiler will complain. (In the case where a class has no constructors, the

compiler will automatically synthesize a default constructor.)

Let's take a look at an example that shows the effects of composition,

inheritance, and polymorphism on the order of construction:

//: c07:Sandwich.java

// Order of constructor calls.

class Meal {

Meal() { System.out.println("Meal()"); }

330

Thinking in Java

}

class Bread {

Bread() { System.out.println("Bread()"); }

}

class Cheese {

Cheese() { System.out.println("Cheese()"); }

}

class Lettuce {

Lettuce() { System.out.println("Lettuce()"); }

}

class Lunch extends Meal {

Lunch() { System.out.println("Lunch()");}

}

class PortableLunch extends Lunch {

PortableLunch() {

System.out.println("PortableLunch()");

}

class Sandwich extends PortableLunch {

Bread b = new Bread();

Cheese c = new Cheese();

Lettuce l = new Lettuce();

Sandwich() {

System.out.println("Sandwich()");

}

public static void main(String[] args) {

new Sandwich();

}

} ///:~

This example creates a complex class out of other classes, and each class

has a constructor that announces itself. The important class is

Sandwich, which reflects three levels of inheritance (four, if you count

the implicit inheritance from Object) and three member objects. When a

Sandwich object is created in main( ), the output is:

Chapter 7: Polymorphism

331

Meal()

Lunch()

PortableLunch()

Bread()

Cheese()

Lettuce()

Sandwich()

This means that the order of constructor calls for a complex object is as

follows:

The base-class constructor is called. This step is repeated

recursively such that the root of the hierarchy is constructed first,

followed by the next-derived class, etc., until the most-derived class

is reached.

Member initializers are called in the order of declaration.

The body of the derived-class constructor is called.

The order of the constructor calls is important. When you inherit, you

know all about the base class and can access any public and protected

members of the base class. This means that you must be able to assume

that all the members of the base class are valid when you're in the derived

class. In a normal method, construction has already taken place, so all the

members of all parts of the object have been built. Inside the constructor,

however, you must be able to assume that all members that you use have

been built. The only way to guarantee this is for the base-class constructor

to be called first. Then when you're in the derived-class constructor, all

the members you can access in the base class have been initialized.

"Knowing that all members are valid" inside the constructor is also the

reason that, whenever possible, you should initialize all member objects

(that is, objects placed in the class using composition) at their point of

definition in the class (e.g., b, c, and l in the example above). If you follow

this practice, you will help ensure that all base class members and

member objects of the current object have been initialized. Unfortunately,

this doesn't handle every case, as you will see in the next section.

332

Thinking in Java

Inheritance and finalize( )

When you use composition to create a new class, you never worry about

finalizing the member objects of that class. Each member is an

independent object, and thus is garbage collected and finalized regardless

of whether it happens to be a member of your class. With inheritance,

however, you must override finalize( ) in the derived class if you have

any special cleanup that must happen as part of garbage collection. When

you override finalize( ) in an inherited class, it's important to remember

to call the base-class version of finalize( ), since otherwise the base-class

finalization will not happen. The following example proves this:

//: c07:Frog.java

// Testing finalize with inheritance.

class DoBaseFinalization {

public static boolean flag = false;

}

class Characteristic {

String s;

Characteristic(String c) {

s = c;

System.out.println(

"Creating Characteristic " + s);

}

protected void finalize() {

System.out.println(

"finalizing Characteristic " + s);

}

class LivingCreature {

Characteristic p =

new Characteristic("is alive");

LivingCreature() {

System.out.println("LivingCreature()");

}

protected void finalize() throws Throwable {

System.out.println(

"LivingCreature finalize");

Chapter 7: Polymorphism

333

// Call base-class version LAST!

if(DoBaseFinalization.flag)

super.finalize();

}

class Animal extends LivingCreature {

Characteristic p =

new Characteristic("has heart");

Animal() {

System.out.println("Animal()");

}

protected void finalize() throws Throwable {

System.out.println("Animal finalize");

if(DoBaseFinalization.flag)

super.finalize();

}

class Amphibian extends Animal {

Characteristic p =

new Characteristic("can live in water");

Amphibian() {

System.out.println("Amphibian()");

}

protected void finalize() throws Throwable {

System.out.println("Amphibian finalize");

if(DoBaseFinalization.flag)

super.finalize();

}

public class Frog extends Amphibian {

Frog() {

System.out.println("Frog()");

}

protected void finalize() throws Throwable {

System.out.println("Frog finalize");

if(DoBaseFinalization.flag)

super.finalize();

}

334

Thinking in Java

public static void main(String[] args) {

if(args.length != 0 &&

args[0].equals("finalize"))

DoBaseFinalization.flag = true;

else

System.out.println("Not finalizing bases");

new Frog(); // Instantly becomes garbage

System.out.println("Bye!");

// Force finalizers to be called:

System.gc();

}

} ///:~

The class DoBaseFinalization simply holds a flag that indicates to each

class in the hierarchy whether to call super.finalize( ). This flag is set

based on a command-line argument, so you can view the behavior with

and without base-class finalization.

Each class in the hierarchy also contains a member object of class

Characteristic. You will see that regardless of whether the base class

finalizers are called, the Characteristic member objects are always

finalized.

Each overridden finalize( ) must have access to at least protected

members since the finalize( ) method in class Object is protected and

the compiler will not allow you to reduce the access during inheritance.

("Friendly" is less accessible than protected.)

In Frog.main( ), the DoBaseFinalization flag is configured and a

single Frog object is created. Remember that garbage collection--and in

particular finalization--might not happen for any particular object, so to

enforce this, the call to System.gc( ) triggers garbage collection, and

thus finalization. Without base-class finalization, the output is:

Not finalizing bases

Creating Characteristic is alive

LivingCreature()

Creating Characteristic has heart

Animal()

Creating Characteristic can live in water

Amphibian()

Chapter 7: Polymorphism

335

Frog()

Bye!

Frog finalize

finalizing Characteristic is alive

finalizing Characteristic has heart

finalizing Characteristic can live in water

You can see that, indeed, no finalizers are called for the base classes of

Frog (the member objects are finalized, as you would expect). But if you

add the "finalize" argument on the command line, you get:

Creating Characteristic is alive

LivingCreature()

Creating Characteristic has heart

Animal()

Creating Characteristic can live in water

Amphibian()

Frog()

bye!

Frog finalize

Amphibian finalize

Animal finalize

LivingCreature finalize

finalizing Characteristic is alive

finalizing Characteristic has heart

finalizing Characteristic can live in water

Although the order the member objects are finalized is the same order

that they are created, technically the order of finalization of objects is

unspecified. With base classes, however, you have control over the order

of finalization. The best order to use is the one that's shown here, which is

the reverse of the order of initialization. Following the form that's used in

C++ for destructors, you should perform the derived-class finalization

first, then the base-class finalization. That's because the derived-class

finalization could call some methods in the base class that require that the

base-class components are still alive, so you must not destroy them

prematurely.

336

Thinking in Java

Behavior of polymorphic methods

inside constructors

The hierarchy of constructor calls brings up an interesting dilemma. What

happens if you're inside a constructor and you call a dynamically bound

method of the object being constructed? Inside an ordinary method you

can imagine what will happen--the dynamically bound call is resolved at

run-time because the object cannot know whether it belongs to the class

that the method is in or some class derived from it. For consistency, you

might think this is what should happen inside constructors.

This is not exactly the case. If you call a dynamically bound method inside

a constructor, the overridden definition for that method is used. However,

the effect can be rather unexpected, and can conceal some difficult-to-find

bugs.

Conceptually, the constructor's job is to bring the object into existence

(which is hardly an ordinary feat). Inside any constructor, the entire

object might be only partially formed--you can know only that the base-

class objects have been initialized, but you cannot know which classes are

inherited from you. A dynamically bound method call, however, reaches

"outward" into the inheritance hierarchy. It calls a method in a derived

class. If you do this inside a constructor, you call a method that might

manipulate members that haven't been initialized yet--a sure recipe for

disaster.

You can see the problem in the following example:

//: c07:PolyConstructors.java

// Constructors and polymorphism

// don't produce what you might expect.

abstract class Glyph {

abstract void draw();

Glyph() {

System.out.println("Glyph() before draw()");

draw();

System.out.println("Glyph() after draw()");

}

Chapter 7: Polymorphism

337

class RoundGlyph extends Glyph {

int radius = 1;

RoundGlyph(int r) {

radius = r;

System.out.println(

"RoundGlyph.RoundGlyph(), radius = "

+ radius);

}

void draw() {

System.out.println(

"RoundGlyph.draw(), radius = " + radius);

}

public class PolyConstructors {

public static void main(String[] args) {

new RoundGlyph(5);

}

} ///:~

In Glyph, the draw( ) method is abstract, so it is designed to be

overridden. Indeed, you are forced to override it in RoundGlyph. But

the Glyph constructor calls this method, and the call ends up in

RoundGlyph.draw( ), which would seem to be the intent. But look at

the output:

Glyph() before draw()

RoundGlyph.draw(), radius = 0

Glyph() after draw()

RoundGlyph.RoundGlyph(), radius = 5

When Glyph's constructor calls draw( ), the value of radius isn't even

the default initial value 1. It's 0. This would probably result in either a dot

or nothing at all being drawn on the screen, and you'd be left staring,

trying to figure out why the program won't work.

The order of initialization described in the previous section isn't quite

complete, and that's the key to solving the mystery. The actual process of

initialization is:

338

Thinking in Java

The storage allocated for the object is initialized to binary zero

before anything else happens.

The base-class constructors are called as described previously. At

this point, the overridden draw( ) method is called (yes, before the

RoundGlyph constructor is called), which discovers a radius

value of zero, due to step 1.

Member initializers are called in the order of declaration.

The body of the derived-class constructor is called.

There's an upside to this, which is that everything is at least initialized to

zero (or whatever zero means for that particular data type) and not just

left as garbage. This includes object references that are embedded inside a

class via composition, which become null. So if you forget to initialize

that reference you'll get an exception at run-time. Everything else gets

zero, which is usually a telltale value when looking at output.

On the other hand, you should be pretty horrified at the outcome of this

program. You've done a perfectly logical thing, and yet the behavior is

mysteriously wrong, with no complaints from the compiler. (C++

produces more rational behavior in this situation.) Bugs like this could

easily be buried and take a long time to discover.

As a result, a good guideline for constructors is, "Do as little as possible to

set the object into a good state, and if you can possibly avoid it, don't call

any methods." The only safe methods to call inside a constructor are those

that are final in the base class. (This also applies to private methods,

which are automatically final.) These cannot be overridden and thus

cannot produce this kind of surprise.

Designing with inheritance

Once you learn about polymorphism, it can seem that everything ought to

be inherited because polymorphism is such a clever tool. This can burden

your designs; in fact if you choose inheritance first when you're using an

existing class to make a new class, things can become needlessly

complicated.

Chapter 7: Polymorphism

339

A better approach is to choose composition first, when it's not obvious

which one you should use. Composition does not force a design into an

inheritance hierarchy. But composition is also more flexible since it's

possible to dynamically choose a type (and thus behavior) when using

composition, whereas inheritance requires an exact type to be known at

compile-time. The following example illustrates this:

//: c07:Transmogrify.java

// Dynamically changing the behavior of

// an object via composition.

abstract class Actor {

abstract void act();

}

class HappyActor extends Actor {

public void act() {

System.out.println("HappyActor");

}

class SadActor extends Actor {

public void act() {

System.out.println("SadActor");

}

class Stage {

Actor a = new HappyActor();

void change() { a = new SadActor(); }

void go() { a.act(); }

}

public class Transmogrify {

public static void main(String[] args) {

Stage s = new Stage();

s.go(); // Prints "HappyActor"

s.change();

s.go(); // Prints "SadActor"

}

} ///:~

340

Thinking in Java

A Stage object contains a reference to an Actor, which is initialized to a

HappyActor object. This means go( ) produces a particular behavior.

But since a reference can be rebound to a different object at run-time, a

reference for a SadActor object can be substituted in a and then the

behavior produced by go( ) changes. Thus you gain dynamic flexibility at

run-time. (This is also called the State Pattern. See Thinking in Patterns

with Java, downloadable at .) In contrast, you can't

decide to inherit differently at run-time; that must be completely

determined at compile-time.

A general guideline is "Use inheritance to express differences in behavior,

and fields to express variations in state." In the above example, both are

used: two different classes are inherited to express the difference in the

act( ) method, and Stage uses composition to allow its state to be

changed. In this case, that change in state happens to produce a change in

behavior.

Pure inheritance vs. extension

When studying inheritance, it would seem that the cleanest way to create

an inheritance hierarchy is to take the "pure" approach. That is, only

methods that have been established in the base class or interface are to

be overridden in the derived class, as seen in this diagram:

Shape

draw()

erase()

Circle

Square

Triangle

draw()

erase()

This can be termed a pure "is-a" relationship because the interface of a

class establishes what it is. Inheritance guarantees that any derived class

Chapter 7: Polymorphism

341

will have the interface of the base class and nothing less. If you follow the

above diagram, derived classes will also have no more than the base class

interface.

This can be thought of as pure substitution, because derived class objects

can be perfectly substituted for the base class, and you never need to

know any extra information about the subclasses when you're using them:

Circle, Square,

Talks to Shape

Message

Line, or new type

"Is-a"

of Shape

relationship

That is, the base class can receive any message you can send to the

derived class because the two have exactly the same interface. All you

need to do is upcast from the derived class and never look back to see

what exact type of object you're dealing with. Everything is handled

through polymorphism.

When you see it this way, it seems like a pure "is-a" relationship is the

only sensible way to do things, and any other design indicates muddled

thinking and is by definition broken. This too is a trap. As soon as you

start thinking this way, you'll turn around and discover that extending the

interface (which, unfortunately, the keyword extends seems to

encourage) is the perfect solution to a particular problem. This could be

termed an "is-like-a" relationship because the derived class is like the base

class--it has the same fundamental interface--but it has other features

that require additional methods to implement:

342

Thinking in Java

Useful

Assume this

}

void f()

represents a big

void g()

interface

"Is-like-a"

MoreUseful

void f()

void g()

}

void u()

Extending

void v()

the interface

void w()

While this is also a useful and sensible approach (depending on the

situation) it has a drawback. The extended part of the interface in the

derived class is not available from the base class, so once you upcast you

can't call the new methods:

Talks to Useful

Useful part

object

Message

MoreUseful

part

If you're not upcasting in this case, it won't bother you, but often you'll get

into a situation in which you need to rediscover the exact type of the

object so you can access the extended methods of that type. The following

section shows how this is done.

Downcasting and run-time

type identification

Since you lose the specific type information via an upcast (moving up the

inheritance hierarchy), it makes sense that to retrieve the type

information--that is, to move back down the inheritance hierarchy--you

use a downcast. However, you know an upcast is always safe; the base

Chapter 7: Polymorphism

343

class cannot have a bigger interface than the derived class, therefore every

message you send through the base class interface is guaranteed to be

accepted. But with a downcast, you don't really know that a shape (for

example) is actually a circle. It could instead be a triangle or square or

some other type.

Useful

Assume this

}

void f()

represents a big

void g()

interface

"Is-like-a"

MoreUseful

void f()

void g()

}

void u()

Extending

void v()

the interface

void w()

To solve this problem there must be some way to guarantee that a

downcast is correct, so you won't accidentally cast to the wrong type and

then send a message that the object can't accept. This would be quite

unsafe.

In some languages (like C++) you must perform a special operation in

order to get a type-safe downcast, but in Java every cast is checked! So

even though it looks like you're just performing an ordinary parenthesized

cast, at run-time this cast is checked to ensure that it is in fact the type

you think it is. If it isn't, you get a ClassCastException. This act of

checking types at run-time is called run-time type identification (RTTI).

The following example demonstrates the behavior of RTTI:

//: c07:RTTI.java

// Downcasting & Run-time Type

// Identification (RTTI).

import java.util.*;

class Useful {

public void f() {}

344

Thinking in Java

public void g() {}

}

class MoreUseful extends Useful {

public void f() {}

public void g() {}

public void u() {}

public void v() {}

public void w() {}

}

public class RTTI {

public static void main(String[] args) {

Useful[] x = {

new Useful(),

new MoreUseful()

};

x[0].f();

x[1].g();

// Compile-time: method not found in Useful:

//! x[1].u();

((MoreUseful)x[1]).u(); // Downcast/RTTI

((MoreUseful)x[0]).u(); // Exception thrown

}

} ///:~

As in the diagram, MoreUseful extends the interface of Useful. But

since it's inherited, it can also be upcast to a Useful. You can see this

happening in the initialization of the array x in main( ). Since both

objects in the array are of class Useful, you can send the f( ) and g( )

methods to both, and if you try to call u( ) (which exists only in

MoreUseful) you'll get a compile-time error message.

If you want to access the extended interface of a MoreUseful object, you

can try to downcast. If it's the correct type, it will be successful. Otherwise,

you'll get a ClassCastException. You don't need to write any special

code for this exception, since it indicates a programmer error that could

happen anywhere in a program.

There's more to RTTI than a simple cast. For example, there's a way to see

what type you're dealing with before you try to downcast it. All of Chapter

Chapter 7: Polymorphism

345

12 is devoted to the study of different aspects of Java run-time type

identification.

Summary

Polymorphism means "different forms." In object-oriented programming,

you have the same face (the common interface in the base class) and

different forms using that face: the different versions of the dynamically

bound methods.

You've seen in this chapter that it's impossible to understand, or even

create, an example of polymorphism without using data abstraction and

inheritance. Polymorphism is a feature that cannot be viewed in isolation

(like a switch statement can, for example), but instead works only in

concert, as part of a "big picture" of class relationships. People are often

confused by other, non-object-oriented features of Java, like method

overloading, which are sometimes presented as object-oriented. Don't be

fooled: If it isn't late binding, it isn't polymorphism.

To use polymorphism--and thus object-oriented techniques--effectively

in your programs you must expand your view of programming to include

not just members and messages of an individual class, but also the

commonality among classes and their relationships with each other.

Although this requires significant effort, it's a worthy struggle, because

the results are faster program development, better code organization,

extensible programs, and easier code maintenance.

Exercises

Solutions to selected exercises can be found in the electronic document The Thinking in Java

Annotated Solution Guide, available for a small fee from .

Add a new method in the base class of Shapes.java that prints a

message, but don't override it in the derived classes. Explain what

happens. Now override it in one of the derived classes but not the

others, and see what happens. Finally, override it in all the derived

classes.

346

Thinking in Java

Add a new type of Shape to Shapes.java and verify in main( )

that polymorphism works for your new type as it does in the old

types.

Change Music3.java so that what( ) becomes the root Object

method toString( ). Try printing the Instrument objects using

System.out.println( ) (without any casting).

Add a new type of Instrument to Music3.java and verify that

polymorphism works for your new type.

Modify Music3.java so that it randomly creates Instrument

objects the way Shapes.java does.

Create an inheritance hierarchy of Rodent: Mouse, Gerbil,

Hamster, etc. In the base class, provide methods that are

common to all Rodents, and override these in the derived classes

to perform different behaviors depending on the specific type of

Rodent. Create an array of Rodent, fill it with different specific

types of Rodents, and call your base-class methods to see what

happens.

Modify Exercise 6 so that Rodent is an abstract class. Make the

methods of Rodent abstract whenever possible.

Create a class as abstract without including any abstract

methods, and verify that you cannot create any instances of that

class.

Add class Pickle to Sandwich.java.

10.

Modify Exercise 6 so that it demonstrates the order of

initialization of the base classes and derived classes. Now add

member objects to both the base and derived classes, and show the

order in which their initialization occurs during construction.

11.

Create a 3-level inheritance hierarchy. Each class in the hierarchy

should have a finalize( ) method, and it should properly call the

base-class version of finalize( ). Demonstrate that your hierarchy

works properly.

Chapter 7: Polymorphism

347

12.

Create a base class with two methods. In the first method, call the

second method. Inherit a class and override the second method.

Create an object of the derived class, upcast it to the base type, and

call the first method. Explain what happens.

13.

Create a base class with an abstract print( ) method that is

overridden in a derived class. The overridden version of the

method prints the value of an int variable defined in the derived

class. At the point of definition of this variable, give it a nonzero

value. In the base-class constructor, call this method. In main( ),

create an object of the derived type, and then call its print( )

method. Explain the results.

14.

Following the example in Transmogrify.java, create a Starship

class containing an AlertStatus reference that can indicate three

different states. Include methods to change the states.

15.

Create an abstract class with no methods. Derive a class and add

a method. Create a static method that takes a reference to the

base class, downcasts it to the derived class, and calls the method.

In main( ), demonstrate that it works. Now put the abstract

declaration for the method in the base class, thus eliminating the

need for the downcast.

348

Thinking in Java

8: Interfaces &

Inner Classes

Interfaces and inner classes provide more sophisticated

ways to organize and control the objects in your system.

C++, for example, does not contain such mechanisms, although the clever

programmer may simulate them. The fact that they exist in Java indicates

that they were considered important enough to provide direct support

through language keywords.

In Chapter 7, you learned about the abstract keyword, which allows you

to create one or more methods in a class that have no definitions--you

provide part of the interface without providing a corresponding

implementation, which is created by inheritors. The interface keyword

produces a completely abstract class, one that provides no

implementation at all. You'll learn that the interface is more than just an

abstract class taken to the extreme, since it allows you to perform a

variation on C++'s "multiple inheritance," by creating a class that can be

upcast to more than one base type.

At first, inner classes look like a simple code-hiding mechanism: you place

classes inside other classes. You'll learn, however, that the inner class

does more than that--it knows about and can communicate with the

surrounding class--and that the kind of code you can write with inner

classes is more elegant and clear, although it is a new concept to most. It

takes some time to become comfortable with design using inner classes.

Interfaces

The interface keyword takes the abstract concept one step further. You

could think of it as a "pure" abstract class. It allows the creator to

establish the form for a class: method names, argument lists, and return

types, but no method bodies. An interface can also contain fields, but

349

these are implicitly static and final. An interface provides only a form,

but no implementation.

An interface says: "This is what all classes that implement this particular

interface will look like." Thus, any code that uses a particular interface

knows what methods might be called for that interface, and that's all. So

the interface is used to establish a "protocol" between classes. (Some

object-oriented programming languages have a keyword called protocol

to do the same thing.)

To create an interface, use the interface keyword instead of the class

keyword. Like a class, you can add the public keyword before the

interface keyword (but only if that interface is defined in a file of the

same name) or leave it off to give "friendly" status so that it is only usable

within the same package.

To make a class that conforms to a particular interface (or group of

interfaces) use the implements keyword. You're saying "The

interface is what it looks like but now I'm going to say how it works."

Other than that, it looks like inheritance. The diagram for the instrument

example shows this:

350

Thinking in Java

interface Instrument

void play();

String what();

void adjust();

implements

Wind

Percussion

Stringed

void play()

String what()

void adjust()

extends

Woodwind

Brass

void play()

String what()

void adjust()

Once you've implemented an interface, that implementation becomes an

ordinary class that can be extended in the regular way.

You can choose to explicitly declare the method declarations in an

interface as public. But they are public even if you don't say it. So

when you implement an interface, the methods from the interface

must be defined as public. Otherwise they would default to "friendly,"

and you'd be reducing the accessibility of a method during inheritance,

which is not allowed by the Java compiler.

You can see this in the modified version of the Instrument example.

Note that every method in the interface is strictly a declaration, which is

the only thing the compiler allows. In addition, none of the methods in

Instrument are declared as public, but they're automatically public

anyway:

//: c08:music5:Music5.java

Chapter 8: Interfaces & Inner Classes

351

// Interfaces.

import java.util.*;

interface Instrument {

// Compile-time constant:

int i = 5; // static & final

// Cannot have method definitions:

void play(); // Automatically public

String what();

void adjust();

}

class Wind implements Instrument {

public void play() {

System.out.println("Wind.play()");

}

public String what() { return "Wind"; }

public void adjust() {}

}

class Percussion implements Instrument {

public void play() {

System.out.println("Percussion.play()");

}

public String what() { return "Percussion"; }

public void adjust() {}

}

class Stringed implements Instrument {

public void play() {

System.out.println("Stringed.play()");

}

public String what() { return "Stringed"; }

public void adjust() {}

}

class Brass extends Wind {

public void play() {

System.out.println("Brass.play()");

}

public void adjust() {

352

Thinking in Java

System.out.println("Brass.adjust()");

}

class Woodwind extends Wind {

public void play() {

System.out.println("Woodwind.play()");

}

public String what() { return "Woodwind"; }

}

public class Music5 {

// Doesn't care about type, so new types

// added to the system still work right:

static void tune(Instrument i) {

// ...

i.play();

}

static void tuneAll(Instrument[] e) {

for(int i = 0; i < e.length; i++)

tune(e[i]);

}

public static void main(String[] args) {

Instrument[] orchestra = new Instrument[5];

int i = 0;

// Upcasting during addition to the array:

orchestra[i++] = new Wind();

orchestra[i++] = new Percussion();

orchestra[i++] = new Stringed();

orchestra[i++] = new Brass();

orchestra[i++] = new Woodwind();

tuneAll(orchestra);

}

} ///:~

The rest of the code works the same. It doesn't matter if you are upcasting

to a "regular" class called Instrument, an abstract class called

Instrument, or to an interface called Instrument. The behavior is the

same. In fact, you can see in the tune( ) method that there isn't any

evidence about whether Instrument is a "regular" class, an abstract

Chapter 8: Interfaces & Inner Classes

353

class, or an interface. This is the intent: Each approach gives the

programmer different control over the way objects are created and used.

"Multiple inheritance" in Java

The interface isn't simply a "more pure" form of abstract class. It has a

higher purpose than that. Because an interface has no implementation

at all--that is, there is no storage associated with an interface--there's

nothing to prevent many interfaces from being combined. This is

valuable because there are times when you need to say "An x is an a and a

b and a c." In C++, this act of combining multiple class interfaces is called

multiple inheritance, and it carries some rather sticky baggage because

each class can have an implementation. In Java, you can perform the

same act, but only one of the classes can have an implementation, so the

problems seen in C++ do not occur with Java when combining multiple

interfaces:

interface 1

Abstract or Concrete

Base Class

...

interface 2

...

interface n

...

Base Class Functions

interface 1

interface 2

interface n

In a derived class, you aren't forced to have a base class that is either an

abstract or "concrete" (one with no abstract methods). If you do inherit

from a non-interface, you can inherit from only one. All the rest of the

base elements must be interfaces. You place all the interface names after

the implements keyword and separate them with commas. You can have

as many interfaces as you want--each one becomes an independent type

that you can upcast to. The following example shows a concrete class

combined with several interfaces to produce a new class:

//: c08:Adventure.java

// Multiple interfaces.

import java.util.*;

354

Thinking in Java

interface CanFight {

void fight();

}

interface CanSwim {

void swim();

}

interface CanFly {

void fly();

}

class ActionCharacter {

public void fight() {}

}

class Hero extends ActionCharacter

implements CanFight, CanSwim, CanFly {

public void swim() {}

public void fly() {}

}

public class Adventure {

static void t(CanFight x) { x.fight(); }

static void u(CanSwim x) { x.swim(); }

static void v(CanFly x) { x.fly(); }

static void w(ActionCharacter x) { x.fight(); }

public static void main(String[] args) {

Hero h = new Hero();

t(h); // Treat it as a CanFight

u(h); // Treat it as a CanSwim

v(h); // Treat it as a CanFly

w(h); // Treat it as an ActionCharacter

}

} ///:~

You can see that Hero combines the concrete class ActionCharacter

with the interfaces CanFight, CanSwim, and CanFly. When you

combine a concrete class with interfaces this way, the concrete class must

come first, then the interfaces. (The compiler gives an error otherwise.)

Chapter 8: Interfaces & Inner Classes

355

Note that the signature for fight( ) is the same in the interface

CanFight and the class ActionCharacter, and that fight( ) is not

provided with a definition in Hero. The rule for an interface is that you

can inherit from it (as you will see shortly), but then you've got another

interface. If you want to create an object of the new type, it must be a

class with all definitions provided. Even though Hero does not explicitly

provide a definition for fight( ), the definition comes along with

ActionCharacter so it is automatically provided and it's possible to

create objects of Hero.

In class Adventure, you can see that there are four methods that take as

arguments the various interfaces and the concrete class. When a Hero

object is created, it can be passed to any of these methods, which means it

is being upcast to each interface in turn. Because of the way interfaces

are designed in Java, this works without a hitch and without any

particular effort on the part of the programmer.

Keep in mind that the core reason for interfaces is shown in the above

example: to be able to upcast to more than one base type. However, a

second reason for using interfaces is the same as using an abstract base

class: to prevent the client programmer from making an object of this

class and to establish that it is only an interface. This brings up a

question: Should you use an interface or an abstract class? An

interface gives you the benefits of an abstract class and the benefits of

an interface, so if it's possible to create your base class without any

method definitions or member variables you should always prefer

interfaces to abstract classes. In fact, if you know something is going to

be a base class, your first choice should be to make it an interface, and

only if you're forced to have method definitions or member variables

should you change to an abstract class, or if necessary a concrete class.

Name collisions when combining interfaces

You can encounter a small pitfall when implementing multiple interfaces.

In the above example, both CanFight and ActionCharacter have an

identical void fight( ) method. This is no problem because the method is

identical in both cases, but what if it's not? Here's an example:

//: c08:InterfaceCollision.java

356

Thinking in Java

interface

I1 { void f(); }

interface

I2 { int f(int i); }

interface

I3 { int f(); }

class C {

public int f() { return 1; } }

class C2 implements I1, I2 {

public void f() {}

public int f(int i) { return 1; } // overloaded

}

class C3 extends C implements I2 {

public int f(int i) { return 1; } // overloaded

}

class C4 extends C implements I3 {

// Identical, no problem:

public int f() { return 1; }

}

// Methods differ only by return type:

//! class C5 extends C implements I1 {}

//! interface I4 extends I1, I3 {} ///:~

The difficulty occurs because overriding, implementation, and

overloading get unpleasantly mixed together, and overloaded functions

cannot differ only by return type. When the last two lines are

uncommented, the error messages say it all:

InterfaceCollision.java:23: f() in C cannot

implement f() in I1; attempting to use

incompatible return type

found

: int

required: void

InterfaceCollision.java:24: interfaces I3 and I1 are

incompatible; both define f

(), but with different return type

Using the same method names in different interfaces that are intended to

be combined generally causes confusion in the readability of the code, as

well. Strive to avoid it.

Chapter 8: Interfaces & Inner Classes

357

Extending an interface

with inheritance

You can easily add new method declarations to an interface using

inheritance, and you can also combine several interfaces into a new

interface with inheritance. In both cases you get a new interface, as

seen in this example:

//: c08:HorrorShow.java

// Extending an interface with inheritance.

interface Monster {

void menace();

}

interface DangerousMonster extends Monster {

void destroy();

}

interface Lethal {

void kill();

}

class DragonZilla implements DangerousMonster {

public void menace() {}

public void destroy() {}

}

interface Vampire

extends DangerousMonster, Lethal {

void drinkBlood();

}

class HorrorShow {

static void u(Monster b) { b.menace(); }

static void v(DangerousMonster d) {

d.menace();

d.destroy();

}

public static void main(String[] args) {

358

Thinking in Java

DragonZilla if2 = new DragonZilla();

u(if2);

v(if2);

}

} ///:~

DangerousMonster is a simple extension to Monster that produces a

new interface. This is implemented in DragonZilla.

The syntax used in Vampire works only when inheriting interfaces.

Normally, you can use extends with only a single class, but since an

interface can be made from multiple other interfaces, extends can refer

to multiple base interfaces when building a new interface. As you can

see, the interface names are simply separated with commas.

Grouping constants

Because any fields you put into an interface are automatically static and

final, the interface is a convenient tool for creating groups of constant

values, much as you would with an enum in C or C++. For example:

//: c08:Months.java

// Using interfaces to create groups of constants.

package c08;

public interface Months {

int

JANUARY = 1, FEBRUARY = 2, MARCH = 3,

APRIL = 4, MAY = 5, JUNE = 6, JULY = 7,

AUGUST = 8, SEPTEMBER = 9, OCTOBER = 10,

NOVEMBER = 11, DECEMBER = 12;

} ///:~

Notice the Java style of using all uppercase letters (with underscores to

separate multiple words in a single identifier) for static finals that have

constant initializers.

The fields in an interface are automatically public, so it's unnecessary

to specify that.

Now you can use the constants from outside the package by importing

c08.* or c08.Months just as you would with any other package, and

Chapter 8: Interfaces & Inner Classes

359

referencing the values with expressions like Months.JANUARY. Of

course, what you get is just an int, so there isn't the extra type safety that

C++'s enum has, but this (commonly used) technique is certainly an

improvement over hard-coding numbers into your programs. (That

approach is often referred to as using "magic numbers" and it produces

very difficult-to-maintain code.)

If you do want extra type safety, you can build a class like this1:

//: c08:Month2.java

// A more robust enumeration system.

package c08;

public final class Month2 {

private String name;

private Month2(String nm) { name = nm; }

public String toString() { return name; }

public final static Month2

JAN = new Month2("January"),

FEB = new Month2("February"),

MAR = new Month2("March"),

APR = new Month2("April"),

MAY = new Month2("May"),

JUN = new Month2("June"),

JUL = new Month2("July"),

AUG = new Month2("August"),

SEP = new Month2("September"),

OCT = new Month2("October"),

NOV = new Month2("November"),

DEC = new Month2("December");

public final static Month2[] month = {

JAN, JAN, FEB, MAR, APR, MAY, JUN,

JUL, AUG, SEP, OCT, NOV, DEC

};

public static void main(String[] args) {

Month2 m = Month2.JAN;

System.out.println(m);

m = Month2.month[12];

1 This approach was inspired by an e-mail from Rich Hoffarth.

360

Thinking in Java

System.out.println(m);

System.out.println(m == Month2.DEC);

System.out.println(m.equals(Month2.DEC));

}

} ///:~

The class is called Month2, since there's already a Month in the

standard Java library. It's a final class with a private constructor so no

one can inherit from it or make any instances of it. The only instances are

the final static ones created in the class itself: JAN, FEB, MAR, etc.

These objects are also used in the array month, which lets you choose

months by number instead of by name. (Notice the extra JAN in the array

to provide an offset by one, so that December is month 12.) In main( )

you can see the type safety: m is a Month2 object so it can be assigned

only to a Month2. The previous example Months.java provided only

int values, so an int variable intended to represent a month could

actually be given any integer value, which wasn't very safe.

This approach also allows you to use == or equals( ) interchangeably, as

shown at the end of main( ).

Initializing fields in interfaces

Fields defined in interfaces are automatically static and final. These

cannot be "blank finals," but they can be initialized with nonconstant

expressions. For example:

//: c08:RandVals.java

// Initializing interface fields with

// non-constant initializers.

import java.util.*;

public interface RandVals {

int rint = (int)(Math.random() * 10);

long rlong = (long)(Math.random() * 10);

float rfloat = (float)(Math.random() * 10);

double rdouble = Math.random() * 10;

} ///:~

Chapter 8: Interfaces & Inner Classes

361

Since the fields are static, they are initialized when the class is first

loaded, which happens when any of the fields are accessed for the first

time. Here's a simple test:

//: c08:TestRandVals.java

public class TestRandVals {

public static void main(String[] args) {

System.out.println(RandVals.rint);

System.out.println(RandVals.rlong);

System.out.println(RandVals.rfloat);

System.out.println(RandVals.rdouble);

}

} ///:~

The fields, of course, are not part of the interface but instead are stored in

the static storage area for that interface.

Nesting interfaces

2Interfaces

may be nested within classes and within other interfaces. This

reveals a number of very interesting features:

//: c08:NestingInterfaces.java

class A {

interface B {

void f();

}

public class BImp implements B {

public void f() {}

}

private class BImp2 implements B {

public void f() {}

}

public interface C {

void f();

}

2 Thanks to Martin Danner for asking this question during a seminar.

362

Thinking in Java

class CImp implements C {

public void f() {}

}

private class CImp2 implements C {

public void f() {}

}

private interface D {

void f();

}

private class DImp implements D {

public void f() {}

}

public class DImp2 implements D {

public void f() {}

}

public D getD() { return new DImp2(); }

private D dRef;

public void receiveD(D d) {

dRef = d;

dRef.f();

}

interface E {

interface G {

void f();

}

// Redundant "public":

public interface H {

void f();

}

void g();

// Cannot be private within an interface:

//! private interface I {}

}

public class NestingInterfaces {

public class BImp implements A.B {

public void f() {}

}

class CImp implements A.C {

Chapter 8: Interfaces & Inner Classes

363

public void f() {}

}

// Cannot implement a private interface except

// within that interface's defining class:

//! class DImp implements A.D {

//! public void f() {}

//! }

class EImp implements E {

public void g() {}

}

class EGImp implements E.G {

public void f() {}

}

class EImp2 implements E {

public void g() {}

class EG implements E.G {

public void f() {}

}

public static void main(String[] args) {

A a = new A();

// Can't access A.D:

//! A.D ad = a.getD();

// Doesn't return anything but A.D:

//! A.DImp2 di2 = a.getD();

// Cannot access a member of the interface:

//! a.getD().f();

// Only another A can do anything with getD():

A a2 = new A();

a2.receiveD(a.getD());

}

} ///:~

The syntax for nesting an interface within a class is reasonably obvious,

and just like non-nested interfaces these can have public or "friendly"

visibility. You can also see that both public and "friendly" nested

interfaces can be implemented as a public, "friendly," and private

nested classes.

As a new twist, interfaces can also be private as seen in A.D (the same

qualification syntax is used for nested interfaces as for nested classes).

364

Thinking in Java

What good is a private nested interface? You might guess that it can only

be implemented as a private nested class as in DImp, but A.DImp2

shows that it can also be implemented as a public class. However,

A.DImp2 can only be used as itself. You are not allowed to mention the

fact that it implements the private interface, so implementing a private

interface is a way to force the definition of the methods in that interface

without adding any type information (that is, without allowing any

upcasting).

The method getD( ) produces a further quandary concerning the private

interface: it's a public method that returns a reference to a private

interface. What can you do with the return value of this method? In

main( ), you can see several attempts to use the return value, all of which

fail. The only thing that works is if the return value is handed to an object

that has permission to use it--in this case, another A, via the received( )

method.

Interface E shows that interfaces can be nested within each other.

However, the rules about interfaces--in particular, that all interface

elements must be public--are strictly enforced here, so an interface

nested within another interface is automatically public and cannot be

made private.

NestingInterfaces shows the various ways that nested interfaces can be

implemented. In particular, notice that when you implement an interface,

you are not required to implement any interfaces nested within. Also,

private interfaces cannot be implemented outside of their defining

classes.

Initially, these features may seem like they are added strictly for syntactic

consistency, but I generally find that once you know about a feature, you

often discover places where it is useful.

Inner classes

It's possible to place a class definition within another class definition. This

is called an inner class. The inner class is a valuable feature because it

allows you to group classes that logically belong together and to control

Chapter 8: Interfaces & Inner Classes

365

the visibility of one within the other. However, it's important to

understand that inner classes are distinctly different from composition.

Often, while you're learning about them, the need for inner classes isn't

immediately obvious. At the end of this section, after all of the syntax and

semantics of inner classes have been described, you'll find examples that

should make clear the benefits of inner classes.

You create an inner class just as you'd expect--by placing the class

definition inside a surrounding class:

//: c08:Parcel1.java

// Creating inner classes.

public class Parcel1 {

class Contents {

private int i = 11;

public int value() { return i; }

}

class Destination {

private String label;

Destination(String whereTo) {

label = whereTo;

}

String readLabel() { return label; }

}

// Using inner classes looks just like

// using any other class, within Parcel1:

public void ship(String dest) {

Contents c = new Contents();

Destination d = new Destination(dest);

System.out.println(d.readLabel());

}

public static void main(String[] args) {

Parcel1 p = new Parcel1();

p.ship("Tanzania");

}

} ///:~

The inner classes, when used inside ship( ), look just like the use of any

other classes. Here, the only practical difference is that the names are

366

Thinking in Java

nested within Parcel1. You'll see in a while that this isn't the only

difference.

More typically, an outer class will have a method that returns a reference

to an inner class, like this:

//: c08:Parcel2.java

// Returning a reference to an inner class.

public class Parcel2 {

class Contents {

private int i = 11;

public int value() { return i; }

}

class Destination {

private String label;

Destination(String whereTo) {

label = whereTo;

}

String readLabel() { return label; }

}

public Destination to(String s) {

return new Destination(s);

}

public Contents cont() {

return new Contents();

}

public void ship(String dest) {

Contents c = cont();

Destination d = to(dest);

System.out.println(d.readLabel());

}

public static void main(String[] args) {

Parcel2 p = new Parcel2();

p.ship("Tanzania");

Parcel2 q = new Parcel2();

// Defining references to inner classes:

Parcel2.Contents c = q.cont();

Parcel2.Destination d = q.to("Borneo");

}

} ///:~

Chapter 8: Interfaces & Inner Classes

367

If you want to make an object of the inner class anywhere except from

within a non-static method of the outer class, you must specify the type

of that object as OuterClassName.InnerClassName, as seen in main( ).

Inner classes and upcasting

So far, inner classes don't seem that dramatic. After all, if it's hiding

you're after, Java already has a perfectly good hiding mechanism--just

allow the class to be "friendly" (visible only within a package) rather than

creating it as an inner class.

However, inner classes really come into their own when you start

upcasting to a base class, and in particular to an interface. (The effect of

producing an interface reference from an object that implements it is

essentially the same as upcasting to a base class.) That's because the inner

class--the implementation of the interface--can then be completely

unseen and unavailable to anyone, which is convenient for hiding the

implementation. All you get back is a reference to the base class or the

interface.

First, the common interfaces will be defined in their own files so they can

be used in all the examples:

//: c08:Destination.java

public interface Destination {

String readLabel();

} ///:~

//: c08:Contents.java

public interface Contents {

int value();

} ///:~

Now Contents and Destination represent interfaces available to the

client programmer. (The interface, remember, automatically makes all

of its members public.)

When you get back a reference to the base class or the interface, it's

possible that you can't even find out the exact type, as shown here:

//: c08:Parcel3.java

// Returning a reference to an inner class.

368

Thinking in Java

public class Parcel3 {

private class PContents implements Contents {

private int i = 11;

public int value() { return i; }

}

protected class PDestination

implements Destination {

private String label;

private PDestination(String whereTo) {

label = whereTo;

}

public String readLabel() { return label; }

}

public Destination dest(String s) {

return new PDestination(s);

}

public Contents cont() {

return new PContents();

}

class Test {

public static void main(String[] args) {

Parcel3 p = new Parcel3();

Contents c = p.cont();

Destination d = p.dest("Tanzania");

// Illegal -- can't access private class:

//! Parcel3.PContents pc = p.new PContents();

}

} ///:~

Note that since main( ) is in Test, when you want to run this program

you don't execute Parcel3, but instead:

java Test

In the example, main( ) must be in a separate class in order to

demonstrate the privateness of the inner class PContents.

In Parcel3, something new has been added: the inner class PContents

is private so no one but Parcel3 can access it. PDestination is

Chapter 8: Interfaces & Inner Classes

369

protected, so no one but Parcel3, classes in the Parcel3 package (since

protected also gives package access--that is, protected is also

"friendly"), and the inheritors of Parcel3 can access PDestination. This

means that the client programmer has restricted knowledge and access to

these members. In fact, you can't even downcast to a private inner class

(or a protected inner class unless you're an inheritor), because you can't

access the name, as you can see in class Test. Thus, the private inner

class provides a way for the class designer to completely prevent any type-

coding dependencies and to completely hide details about

implementation. In addition, extension of an interface is useless from

the client programmer's perspective since the client programmer cannot

access any additional methods that aren't part of the public interface

class. This also provides an opportunity for the Java compiler to generate

more efficient code.

Normal (non-inner) classes cannot be made private or protected--only

public or "friendly."

Inner classes

in methods and scopes

What you've seen so far encompasses the typical use for inner classes. In

general, the code that you'll write and read involving inner classes will be

"plain" inner classes that are simple and easy to understand. However, the

design for inner classes is quite complete and there are a number of other,

more obscure, ways that you can use them if you choose: inner classes can

be created within a method or even an arbitrary scope. There are two

reasons for doing this:

As shown previously, you're implementing an interface of some

kind so that you can create and return a reference.

You're solving a complicated problem and you want to create a

class to aid in your solution, but you don't want it publicly

available.

In the following examples, the previous code will be modified to use:

A class defined within a method

370

Thinking in Java

A class defined within a scope inside a method

An anonymous class implementing an interface

An anonymous class extending a class that has a nondefault

constructor

An anonymous class that performs field initialization

An anonymous class that performs construction using instance

initialization (anonymous inner classes cannot have constructors)

Although it's an ordinary class with an implementation, Wrapping is

also being used as a common "interface" to its derived classes:

//: c08:Wrapping.java

public class Wrapping {

private int i;

public Wrapping(int x) { i = x; }

public int value() { return i; }

} ///:~

You'll notice above that Wrapping has a constructor that requires an

argument, to make things a bit more interesting.

The first example shows the creation of an entire class within the scope of

a method (instead of the scope of another class):

//: c08:Parcel4.java

// Nesting a class within a method.

public class Parcel4 {

public Destination dest(String s) {

class PDestination

implements Destination {

private String label;

private PDestination(String whereTo) {

label = whereTo;

}

public String readLabel() { return label; }

}

return new PDestination(s);

}

Chapter 8: Interfaces & Inner Classes

371

public static void main(String[] args) {

Parcel4 p = new Parcel4();

Destination d = p.dest("Tanzania");

}

} ///:~

The class PDestination is part of dest( ) rather than being part of

Parcel4. (Also notice that you could use the class identifier

PDestination for an inner class inside each class in the same

subdirectory without a name clash.) Therefore, PDestination cannot be

accessed outside of dest( ). Notice the upcasting that occurs in the return

statement--nothing comes out of dest( ) except a reference to

Destination, the base class. Of course, the fact that the name of the class

PDestination is placed inside dest( ) doesn't mean that PDestination

is not a valid object once dest( ) returns.

The next example shows how you can nest an inner class within any

arbitrary scope:

//: c08:Parcel5.java

// Nesting a class within a scope.

public class Parcel5 {

private void internalTracking(boolean b) {

if(b) {

class TrackingSlip {

private String id;

TrackingSlip(String s) {

id = s;

}

String getSlip() { return id; }

}

TrackingSlip ts = new TrackingSlip("slip");

String s = ts.getSlip();

}

// Can't use it here! Out of scope:

//! TrackingSlip ts = new TrackingSlip("x");

}

public void track() { internalTracking(true); }

public static void main(String[] args) {

Parcel5 p = new Parcel5();

372

Thinking in Java

p.track();

}

} ///:~

The class TrackingSlip is nested inside the scope of an if statement.

This does not mean that the class is conditionally created--it gets

compiled along with everything else. However, it's not available outside

the scope in which it is defined. Other than that, it looks just like an

ordinary class.

Anonymous inner classes

The next example looks a little strange:

//: c08:Parcel6.java

// A method that returns an anonymous inner class.

public class Parcel6 {

public Contents cont() {

return new Contents() {

private int i = 11;

public int value() { return i; }

}; // Semicolon required in this case

}

public static void main(String[] args) {

Parcel6 p = new Parcel6();

Contents c = p.cont();

}

} ///:~

The cont( ) method combines the creation of the return value with the

definition of the class that represents that return value! In addition, the

class is anonymous--it has no name. To make matters a bit worse, it looks

like you're starting out to create a Contents object:

return new Contents()

But then, before you get to the semicolon, you say, "But wait, I think I'll

slip in a class definition":

return new Contents() {

private int i = 11;

public int value() { return i; }

Chapter 8: Interfaces & Inner Classes

373

};

What this strange syntax means is: "Create an object of an anonymous

class that's inherited from Contents." The reference returned by the new

expression is automatically upcast to a Contents reference. The

anonymous inner-class syntax is a shorthand for:

class MyContents implements Contents {

private int i = 11;

public int value() { return i; }

}

return new MyContents();

In the anonymous inner class, Contents is created using a default

constructor. The following code shows what to do if your base class needs

a constructor with an argument:

//: c08:Parcel7.java

// An anonymous inner class that calls

// the base-class constructor.

public class Parcel7 {

public Wrapping wrap(int x) {

// Base constructor call:

return new Wrapping(x) {

public int value() {

return super.value() * 47;

}

}; // Semicolon required

}

public static void main(String[] args) {

Parcel7 p = new Parcel7();

Wrapping w = p.wrap(10);

}

} ///:~

That is, you simply pass the appropriate argument to the base-class

constructor, seen here as the x passed in new Wrapping(x). An

anonymous class cannot have a constructor where you would normally

call super( ).

374

Thinking in Java

In both of the previous examples, the semicolon doesn't mark the end of

the class body (as it does in C++). Instead, it marks the end of the

expression that happens to contain the anonymous class. Thus, it's

identical to the use of the semicolon everywhere else.

What happens if you need to perform some kind of initialization for an

object of an anonymous inner class? Since it's anonymous, there's no

name to give the constructor--so you can't have a constructor. You can,

however, perform initialization at the point of definition of your fields:

//: c08:Parcel8.java

// An anonymous inner class that performs

// initialization. A briefer version

// of Parcel5.java.

public class Parcel8 {

// Argument must be final to use inside

// anonymous inner class:

public Destination dest(final String dest) {

return new Destination() {

private String label = dest;

public String readLabel() { return label; }

};

}

public static void main(String[] args) {

Parcel8 p = new Parcel8();

Destination d = p.dest("Tanzania");

}

} ///:~

If you're defining an anonymous inner class and want to use an object

that's defined outside the anonymous inner class, the compiler requires

that the outside object be final. This is why the argument to dest( ) is

final. If you forget, you'll get a compile-time error message.

As long as you're simply assigning a field, the above approach is fine. But

what if you need to perform some constructor-like activity? With instance

initialization, you can, in effect, create a constructor for an anonymous

inner class:

//: c08:Parcel9.java

Chapter 8: Interfaces & Inner Classes

375

// Using "instance initialization" to perform

// construction on an anonymous inner class.

public class Parcel9 {

public Destination

dest(final String dest, final float price) {

return new Destination() {

private int cost;

// Instance initialization for each object:

{

cost = Math.round(price);

if(cost > 100)

System.out.println("Over budget!");

}

private String label = dest;

public String readLabel() { return label; }

};

}

public static void main(String[] args) {

Parcel9 p = new Parcel9();

Destination d = p.dest("Tanzania", 101.395F);

}

} ///:~

Inside the instance initializer you can see code that couldn't be executed

as part of a field initializer (that is, the if statement). So in effect, an

instance initializer is the constructor for an anonymous inner class. Of

course, it's limited; you can't overload instance initializers so you can have

only one of these constructors.

The link to the outer class

So far, it appears that inner classes are just a name-hiding and code-

organization scheme, which is helpful but not totally compelling.

However, there's another twist. When you create an inner class, an object

of that inner class has a link to the enclosing object that made it, and so it

can access the members of that enclosing object--without any special

qualifications. In addition, inner classes have access rights to all the

376

Thinking in Java

elements in the enclosing class3. The following example demonstrates

this:

//: c08:Sequence.java

// Holds a sequence of Objects.

interface Selector {

boolean end();

Object current();

void next();

}

public class Sequence {

private Object[] obs;

private int next = 0;

public Sequence(int size) {

obs = new Object[size];

}

public void add(Object x) {

if(next < obs.length) {

obs[next] = x;

next++;

}

private class SSelector implements Selector {

int i = 0;

public boolean end() {

return i == obs.length;

}

public Object current() {

return obs[i];

}

public void next() {

if(i < obs.length) i++;

}

3 This is very different from the design of nested classes in C++, which is simply a name-

hiding mechanism. There is no link to an enclosing object and no implied permissions in

C++.

Chapter 8: Interfaces & Inner Classes

377

public Selector getSelector() {

return new SSelector();

}

public static void main(String[] args) {

Sequence s = new Sequence(10);

for(int i = 0; i < 10; i++)

s.add(Integer.toString(i));

Selector sl = s.getSelector();

while(!sl.end()) {

System.out.println(sl.current());

sl.next();

}

} ///:~

The Sequence is simply a fixed-sized array of Object with a class

wrapped around it. You call add( ) to add a new Object to the end of the

sequence (if there's room left). To fetch each of the objects in a

Sequence, there's an interface called Selector, which allows you to see

if you're at the end( ), to look at the current( ) Object, and to move to

the next( ) Object in the Sequence. Because Selector is an interface,

many other classes can implement the interface in their own ways, and

many methods can take the interface as an argument, in order to create

generic code.

Here, the SSelector is a private class that provides Selector

functionality. In main( ), you can see the creation of a Sequence,

followed by the addition of a number of String objects. Then, a Selector

is produced with a call to getSelector( ) and this is used to move

through the Sequence and select each item.

At first, the creation of SSelector looks like just another inner class. But

examine it closely. Note that each of the methods end( ), current( ), and

next( ) refer to obs, which is a reference that isn't part of SSelector, but

is instead a private field in the enclosing class. However, the inner class

can access methods and fields from the enclosing class as if they owned

them. This turns out to be very convenient, as you can see in the above

example.

So an inner class has automatic access to the members of the enclosing

class. How can this happen? The inner class must keep a reference to the

378

Thinking in Java

particular object of the enclosing class that was responsible for creating it.

Then when you refer to a member of the enclosing class, that (hidden)

reference is used to select that member. Fortunately, the compiler takes

care of all these details for you, but you can also understand now that an

object of an inner class can be created only in association with an object of

the enclosing class. Construction of the inner class object requires the

reference to the object of the enclosing class, and the compiler will

complain if it cannot access that reference. Most of the time this occurs

without any intervention on the part of the programmer.

static inner classes

If you don't need a connection between the inner class object and the

outer class object, then you can make the inner class static. To

understand the meaning of static when applied to inner classes, you must

remember that the object of an ordinary inner class implicitly keeps a

reference to the object of the enclosing class that created it. This is not

true, however, when you say an inner class is static. A static inner class

means:

You don't need an outer-class object in order to create an object of

a static inner class.

You can't access an outer-class object from an object of a static

inner class.

static inner classes are different than non-static inner classes in another

way, as well. Fields and methods in non-static inner classes can only be

at the outer level of a class, so non-static inner classes cannot have static

data, static fields, or static inner classes. However, static inner classes

can have all of these:

//: c08:Parcel10.java

// Static inner classes.

public class Parcel10 {

private static class PContents

implements Contents {

private int i = 11;

public int value() { return i; }

}

Chapter 8: Interfaces & Inner Classes

379

Table of Contents:
