B: The Java Native

Interface (JNI)

The material in this appendix was contributed by and used with the

permission of Andrea Provaglio (www.AndreaProvaglio.com).

The Java language and its standard API are rich enough

to write full-fledged applications. But in some cases you

must call non-Java code; for example, if you want to

access operating-system-specific features, interface with

special hardware devices, reuse a preexisting, non-Java

code base, or implement time-critical sections of code.

Interfacing with non-Java code requires dedicated support in the

compiler and in the Virtual Machine, and additional tools to map the Java

code to the non-Java code. The standard solution for calling non-Java

code that is provided by JavaSoft is called the Java Native Interface,

which will be introduced in this appendix. This is not an in-depth

treatment, and in some cases you're assumed to have partial knowledge of

the related concepts and techniques.

JNI is a fairly rich programming interface that allows you to call native

methods from a Java application. It was added in Java 1.1, maintaining a

certain degree of compatibility with its Java 1.0 equivalent: the native

method interface (NMI). NMI has design characteristics that make it

unsuitable for adoption across all virtual machines. For this reason, future

versions of the language might no longer support NMI, and it will not be

covered here.

Currently, JNI is designed to interface with native methods written only

in C or C++. Using JNI, your native methods can:

♦ Create, inspect, and update Java objects (including arrays and Strings)

♦ Call Java methods

1065

♦ Catch and throw exceptions

♦ Load classes and obtain class information

♦ Perform run-time type checking

Thus, virtually everything you can do with classes and objects in ordinary

Java you can also do in native methods.

Calling a native method

We'll start with a simple example: a Java program that calls a native

method, which in turn calls the standard C library function printf( ).

The first step is to write the Java code declaring a native method and its

arguments:

//: appendixb:ShowMessage.java

public class ShowMessage {

private native void ShowMessage(String msg);

static {

System.loadLibrary("MsgImpl");

// Linux hack, if you can't get your library

// path set in your environment:

// System.load(

// "/home/bruce/tij2/appendixb/MsgImpl.so");

}

public static void main(String[] args) {

ShowMessage app = new ShowMessage();

app.ShowMessage("Generated with JNI");

}

} ///:~

The native method declaration is followed by a static block that calls

System.loadLibrary( ) (which you could call at any time, but this style

is more appropriate). System.loadLibrary( ) loads a DLL in memory

and links to it. The DLL must be in your system library path. The file

name extension is automatically added by the JVM depending on the

platform.

1066

Thinking in Java

In the above code you can also see a call to the System.load( ) method,

which is commented out. The path specified here is an absolute path,

rather than relying on an environment variable. Using an environment

variable is naturally the better and more portable solution, but if you can't

figure that out you can comment out the loadLibrary( ) call and

uncomment this one, adjusting the path to your own directory.

The header file generator: javah

Now compile your Java source file and run javah on the resulting .class

file, specifying the --jni switch (this is done automatically for you by the

makefile in the source code distribution for this book):

javah --jni ShowMessage

javah reads the Java class file and for each native method declaration it

generates a function prototype in a C or C++ header file. Here's the

output: the ShowMessage.h source file (edited slightly to fit into this

book):

/* DO NOT EDIT THIS FILE

- it is machine generated */

#include <jni.h>

/* Header for class ShowMessage */

#ifndef _Included_ShowMessage

#define _Included_ShowMessage

#ifdef __cplusplus

extern "C" {

#endif

* Class:

ShowMessage

* Method:

ShowMessage

* Signature: (Ljava/lang/String;)V

JNIEXPORT void JNICALL

Java_ShowMessage_ShowMessage

(JNIEnv *, jobject, jstring);

#ifdef __cplusplus

}

Appendix B: The Java Native Interface (JNI)

1067

#endif

As you can see by the #ifdef __cplusplus preprocessor directive, this

file can be compiled either by a C or a C++ compiler. The first #include

directive includes jni.h, a header file that, among other things, defines

the types that you can see used in the rest of the file. JNIEXPORT and

JNICALL are macros that expand to match platform-specific directives.

JNIEnv, jobject and jstring are JNI data type definitions, which will be

explained shortly.

Name mangling and function

signatures

JNI imposes a naming convention (called name mangling) on native

methods. This is important, since it's part of the mechanism by which the

virtual machine links Java calls to native methods. Basically, all native

methods start with the word "Java," followed by the name of the class in

which the Java native declaration appears, followed by the name of the

Java method. The underscore character is used as a separator. If the Java

native method is overloaded, then the function signature is appended to

the name as well; you can see the native signature in the comments

preceding the prototype. For more information about name mangling and

native method signatures, please refer to the JNI documentation.

Implementing your DLL

At this point, all you have to do is write a C or C++ source code file that

includes the javah-generated header file and implements the native

method, then compile it and generate a dynamic link library. This part is

platform-dependent. The code below is compiled and linked into a file

called MsgImpl.dll for Windows or MsgImpl.so for Unix/Linux (the

makefile packaged with the code listings contains the commands to do

this--it is available on the CD ROM bound into this book, or as a free

download from ):

//: appendixb:MsgImpl.cpp

//# Tested with VC++ & BC++. Include path must

//# be adjusted to find the JNI headers. See

1068

Thinking in Java

//# the makefile for this chapter (in the

//# downloadable source code) for an example.

#include <jni.h>

#include <stdio.h>

#include "ShowMessage.h"

extern "C" JNIEXPORT void JNICALL

Java_ShowMessage_ShowMessage(JNIEnv* env,

jobject, jstring jMsg) {

const char* msg=env->GetStringUTFChars(jMsg,0);

printf("Thinking in Java, JNI: %s\n", msg);

env->ReleaseStringUTFChars(jMsg, msg);

} ///:~

The arguments that are passed into the native method are the gateway

back into Java. The first, of type JNIEnv, contains all the hooks that

allow you to call back into the JVM. (We'll look at this in the next section.)

The second argument has a different meaning depending on the type of

method. For non-static methods like the example above, the second

argument is the equivalent of the "this" pointer in C++ and similar to this

in Java: it's a reference to the object that called the native method. For

static methods, it's a reference to the Class object where the method is

implemented.

The remaining arguments represent the Java objects passed into the

native method call. Primitives are also passed in this way, but they come

in by value.

In the following sections we'll explain this code by looking at the ways that

you access and control the JVM from inside a native method.

Accessing JNI functions:

the JNIEnv argument

JNI functions are those that the programmer uses to interact with the

JVM from inside a native method. As you can see in the example above,

every JNI native method receives a special argument as its first

parameter: the JNIEnv argument, which is a pointer to a special JNI

Appendix B: The Java Native Interface (JNI)

1069

data structure of type JNIEnv_. One element of the JNI data structure is

a pointer to an array generated by the JVM. Each element of this array is a

pointer to a JNI function. The JNI functions can be called from the native

method by dereferencing these pointers (it's simpler than it sounds).

Every JVM provides its own implementation of the JNI functions, but

their addresses will always be at predefined offsets.

Through the JNIEnv argument, the programmer has access to a large set

of functions. These functions can be grouped into the following

categories:

♦ Obtaining version information

♦ Performing class and object operations

♦ Handling global and local references to Java objects

♦ Accessing instance fields and static fields

♦ Calling instance methods and static methods

♦ Performing string and array operations

♦ Generating and handling Java exceptions

The number of JNI functions is quite large and won't be covered here.

Instead, I'll show the rationale behind the use of these functions. For

more detailed information, consult your compiler's JNI documentation.

If you take a look at the jni.h header file, you'll see that inside the #ifdef

__cplusplus preprocessor conditional, the JNIEnv_ structure is

defined as a class when compiled by a C++ compiler. This class contains a

number of inline functions that let you access the JNI functions with an

easy and familiar syntax. For example, the line of C++ code in the

preceding example:

env->ReleaseStringUTFChars(jMsg, msg);

could also be called from C like this:

(*env)->ReleaseStringUTFChars(env, jMsg, msg);

1070

Thinking in Java

You'll notice that the C style is (naturally) more complicated--you need a

double dereferencing of the env pointer, and you must also pass the same

pointer as the first parameter to the JNI function call. The examples in

this appendix use the C++ style.

Accessing Java Strings

As an example of accessing a JNI function, consider the code in

MsgImpl.cpp. Here, the JNIEnv argument env is used to access a Java

String. Java Strings are in Unicode format, so if you receive one and

want to pass it to a non-Unicode function (printf( ), for example), you

must first convert it into ASCII characters with the JNI function

GetStringUTFChars( ). This function takes a Java String and converts

it to UTF-8 characters. (These are 8 bits wide to hold ASCII values or 16

bits wide to hold Unicode. If the content of the original string was

composed only of ASCII, the resulting string will be ASCII as well.)

GetStringUTFChars( ) is one of the member functions in JNIEnv. To

access the JNI function, we use the typical C++ syntax for calling a

member function though a pointer. You use the form above to access all of

the JNI functions.

Passing and using Java

objects

In the previous example we passed a String to the native method. You

can also pass Java objects of your own creation to a native method. Inside

your native method, you can access the fields and methods of the object

that was received.

To pass objects, use the ordinary Java syntax when declaring the native

method. In the example below, MyJavaClass has one public field and

one public method. The class UseObjects declares a native method that

takes an object of class MyJavaClass. To see if the native method

manipulates its argument, the public field of the argument is set, the

native method is called, and then the value of the public field is printed.

//: appendixb:UseObjects.java
