object is quadruple( ), but this creates a new Immutable1 object and

leaves the original one untouched.

The method f( ) takes an Immutable1 object and performs various

operations on it, and the output of main( ) demonstrates that there is no

change to x. Thus, x's object could be aliased many times without harm

because the Immutable1 class is designed to guarantee that objects

cannot be changed.

The drawback to immutability

Creating an immutable class seems at first to provide an elegant solution.

However, whenever you do need a modified object of that new type you

must suffer the overhead of a new object creation, as well as potentially

causing more frequent garbage collections. For some classes this is not a

problem, but for others (such as the String class) it is prohibitively

expensive.

The solution is to create a companion class that can be modified. Then,

when you're doing a lot of modifications, you can switch to using the

modifiable companion class and switch back to the immutable class when

you're done.

The example above can be modified to show this:

//: appendixa:Immutable2.java

// A companion class for making

// changes to immutable objects.

class Mutable {

private int data;

public Mutable(int initVal) {

data = initVal;

}

public Mutable add(int x) {

data += x;

return this;

}

public Mutable multiply(int x) {

data *= x;

return this;

1050

Thinking in Java

}

public Immutable2 makeImmutable2() {

return new Immutable2(data);

}

public class Immutable2 {

private int data;

public Immutable2(int initVal) {

data = initVal;

}

public int read() { return data; }

public boolean nonzero() { return data != 0; }

public Immutable2 add(int x) {

return new Immutable2(data + x);

}

public Immutable2 multiply(int x) {

return new Immutable2(data * x);

}

public Mutable makeMutable() {

return new Mutable(data);

}

public static Immutable2 modify1(Immutable2 y){

Immutable2 val = y.add(12);

val = val.multiply(3);

val = val.add(11);

val = val.multiply(2);

return val;

}

// This produces the same result:

public static Immutable2 modify2(Immutable2 y){

Mutable m = y.makeMutable();

m.add(12).multiply(3).add(11).multiply(2);

return m.makeImmutable2();

}

public static void main(String[] args) {

Immutable2 i2 = new Immutable2(47);

Immutable2 r1 = modify1(i2);

Immutable2 r2 = modify2(i2);

System.out.println("i2 = " + i2.read());

System.out.println("r1 = " + r1.read());

Appendix A: Passing & Returning Objects

1051

System.out.println("r2 = " + r2.read());

}

} ///:~

Immutable2 contains methods that, as before, preserve the

immutability of the objects by producing new objects whenever a

modification is desired. These are the add( ) and multiply( ) methods.

The companion class is called Mutable, and it also has add( ) and

multiply( ) methods, but these modify the Mutable object rather than

making a new one. In addition, Mutable has a method to use its data to

produce an Immutable2 object and vice versa.

The two static methods modify1( ) and modify2( ) show two different

approaches to producing the same result. In modify1( ), everything is

done within the Immutable2 class and you can see that four new

Immutable2 objects are created in the process. (And each time val is

reassigned, the previous object becomes garbage.)

In the method modify2( ), you can see that the first action is to take the

Immutable2 y and produce a Mutable from it. (This is just like calling

clone( ) as you saw earlier, but this time a different type of object is

created.) Then the Mutable object is used to perform a lot of change

operations without requiring the creation of many new objects. Finally,

it's turned back into an Immutable2. Here, two new objects are created

(the Mutable and the result Immutable2) instead of four.

This approach makes sense, then, when:

You need immutable objects and

You often need to make a lot of modifications or

It's expensive to create new immutable objects.

Immutable Strings

Consider the following code:

//: appendixa:Stringer.java

public class Stringer {

static String upcase(String s) {

1052

Thinking in Java

return s.toUpperCase();

}

public static void main(String[] args) {

String q = new String("howdy");

System.out.println(q); // howdy

String qq = upcase(q);

System.out.println(qq); // HOWDY

System.out.println(q); // howdy

}

} ///:~

When q is passed in to upcase( ) it's actually a copy of the reference to q.

The object this reference is connected to stays put in a single physical

location. The references are copied as they are passed around.

Looking at the definition for upcase( ), you can see that the reference

that's passed in has the name s, and it exists for only as long as the body

of upcase( ) is being executed. When upcase( ) completes, the local

reference s vanishes. upcase( ) returns the result, which is the original

string with all the characters set to uppercase. Of course, it actually

returns a reference to the result. But it turns out that the reference that it

returns is for a new object, and the original q is left alone. How does this

happen?

Implicit constants

If you say:

String s = "asdf";

String x = Stringer.upcase(s);

do you really want the upcase( ) method to change the argument? In

general, you don't, because an argument usually looks to the reader of the

code as a piece of information provided to the method, not something to

be modified. This is an important guarantee, since it makes code easier to

write and understand.

In C++, the availability of this guarantee was important enough to put in a

special keyword, const, to allow the programmer to ensure that a

reference (pointer or reference in C++) could not be used to modify the

original object. But then the C++ programmer was required to be diligent

Appendix A: Passing & Returning Objects

1053

and remember to use const everywhere. It can be confusing and easy to

forget.

Overloading `+' and the StringBuffer

Objects of the String class are designed to be immutable, using the

technique shown previously. If you examine the online documentation for

the String class (which is summarized a little later in this appendix),

you'll see that every method in the class that appears to modify a String

really creates and returns a brand new String object containing the

modification. The original String is left untouched. Thus, there's no

feature in Java like C++'s const to make the compiler support the

immutability of your objects. If you want it, you have to wire it in yourself,

like String does.

Since String objects are immutable, you can alias to a particular String

as many times as you want. Because it's read-only there's no possibility

that one reference will change something that will affect the other

references. So a read-only object solves the aliasing problem nicely.

It also seems possible to handle all the cases in which you need a modified

object by creating a brand new version of the object with the

modifications, as String does. However, for some operations this isn't

efficient. A case in point is the operator `+' that has been overloaded for

String objects. Overloading means that it has been given an extra

meaning when used with a particular class. (The `+' and `+=' for String

are the only operators that are overloaded in Java, and Java does not

allow the programmer to overload any others)5.

When used with String objects, the `+' allows you to concatenate Strings

together:

String s = "abc" + foo + "def" + Integer.toString(47);

5 C++ allows the programmer to overload operators at will. Because this can often be a

complicated process (see Chapter 10 of Thinking in C++, 2nd edition, Prentice-Hall, 2000),

the Java designers deemed it a "bad" feature that shouldn't be included in Java. It wasn't

so bad that they didn't end up doing it themselves, and ironically enough, operator

overloading would be much easier to use in Java than in C++. This can be seen in Python

(see www.Python.org) which has garbage collection and straightforward operator

overloading.

1054

Thinking in Java

You could imagine how this might work: the String "abc" could have a

method append( ) that creates a new String object containing "abc"

concatenated with the contents of foo. The new String object would then

create another new String that added "def," and so on.

This would certainly work, but it requires the creation of a lot of String

objects just to put together this new String, and then you have a bunch of

the intermediate String objects that need to be garbage-collected. I

suspect that the Java designers tried this approach first (which is a lesson

in software design--you don't really know anything about a system until

you try it out in code and get something working). I also suspect they

discovered that it delivered unacceptable performance.

The solution is a mutable companion class similar to the one shown

previously. For String, this companion class is called StringBuffer, and

the compiler automatically creates a StringBuffer to evaluate certain

expressions, in particular when the overloaded operators + and += are

used with String objects. This example shows what happens:

//: appendixa:ImmutableStrings.java

// Demonstrating StringBuffer.

public class ImmutableStrings {

public static void main(String[] args) {

String foo = "foo";

String s = "abc" + foo +

"def" + Integer.toString(47);

System.out.println(s);

// The "equivalent" using StringBuffer:

StringBuffer sb =

new StringBuffer("abc"); // Creates String!

sb.append(foo);

sb.append("def"); // Creates String!

sb.append(Integer.toString(47));

System.out.println(sb);

}

} ///:~

In the creation of String s, the compiler is doing the rough equivalent of

the subsequent code that uses sb: a StringBuffer is created and

append( ) is used to add new characters directly into the StringBuffer

Appendix A: Passing & Returning Objects

1055

object (rather than making new copies each time). While this is more

efficient, it's worth noting that each time you create a quoted character

string such as "abc" and "def", the compiler turns those into String

objects. So there can be more objects created than you expect, despite the

efficiency afforded through StringBuffer.

The String and

StringBuffer classes

Here is an overview of the methods available for both String and

StringBuffer so you can get a feel for the way they interact. These tables

don't contain every single method, but rather the ones that are important

to this discussion. Methods that are overloaded are summarized in a

single row.

First, the String class:

Method

Arguments,

Use

Overloading

Creating String

Constructor

Overloaded: Default,

objects.

String,

StringBuffer, char

arrays, byte arrays.

length( )

Number of characters

in the String.

charAt()

int Index

The char at a location in

the String.

getChars( ),

The beginning and

Copy chars or bytes

getBytes( )

into an external array.

end from which to

copy, the array to copy

into, an index into the

destination array.

toCharArray( )

Produces a char[]

containing the

characters in the

String.

equals( ), equals-

A String to compare

An equality check on

IgnoreCase( )

with.

the contents of the two

1056

Thinking in Java

Method

Arguments,

Use

Overloading

Strings.

compareTo( )

A String to compare

Result is negative, zero,

with.

or positive depending

on the lexicographical

ordering of the String

and the argument.

Uppercase and

lowercase are not equal!

boolean result

regionMatches( )

Offset into this

indicates whether the

String, the other

region matches.

String and its offset

and length to

compare. Overload

adds "ignore case."

startsWith( )

String that it might

boolean result

start with. Overload

indicates whether the

adds offset into

String starts with the

argument.

endsWith( )

String that might be

boolean result

a suffix of this String.

indicates whether the

argument is a suffix.

indexOf( ),

Overloaded: char,

Returns -1 if the

lastIndexOf( )

char and starting

argument is not found

index, String,

within this String,

String, and starting

otherwise returns the

index.

index where the

argument starts.

lastIndexOf( )

searches backward from

end.

substring( )

Overloaded: Starting

Returns a new String

index, starting index,

object containing the

and ending index.

specified character set.

concat( )

The String to

Returns a new String

concatenate

object containing the

original String's

characters followed by

Appendix A: Passing & Returning Objects

1057

Method

Arguments,

Use

Overloading

the characters in the

argument.

replace( )

The old character to

Returns a new String

search for, the new

object with the

character to replace it

replacements made.

with.

Uses the old String if

no match is found.

toLowerCase( )

Returns a new String

toUpperCase( )

object with the case of

all letters changed. Uses

the old String if no

changes need to be

made.

trim( )

Returns a new String

object with the white

space removed from

each end. Uses the old

String if no changes

need to be made.

valueOf( )

Overloaded: Object,

Returns a String

char[], char[] and

containing a character

offset and count,

representation of the

argument.

boolean, char, int,

long, float, double.

intern( )

Produces one and only

one String ref per

unique character

sequence.

You can see that every String method carefully returns a new String

object when it's necessary to change the contents. Also notice that if the

contents don't need changing the method will just return a reference to

the original String. This saves storage and overhead.

Here's the StringBuffer class:

Method

Arguments, overloading

Use

1058

Thinking in Java

Method

Arguments, overloading

Use

Constructor

Overloaded: default, length

Create a new

StringBuffer object.

of buffer to create, String

to create from.

toString( )

Creates a String from

this StringBuffer.

length( )

Number of characters

in the StringBuffer.

capacity( )

Returns current

number of spaces

allocated.

ensure-

Integer indicating desired

Makes the

Capacity( )

capacity.

StringBuffer hold at

least the desired

number of spaces.

setLength( )

Integer indicating new

Truncates or expands

length of character string in

the previous character

buffer.

string. If expanding,

pads with nulls.

charAt( )

Integer indicating the

Returns the char at

location of the desired

that location in the

element.

buffer.

setCharAt( )

Integer indicating the

Modifies the value at

that location.

location of the desired

element and the new char

value for the element.

Copy chars into an

getChars( )

The beginning and end

external array. There

from which to copy, the

is no getBytes( ) as

array to copy into, an index

in String.

into the destination array.

append( )

Overloaded: Object,

The argument is

String, char[], char[]

converted to a string

with offset and length,

and appended to the

boolean, char, int, long,

end of the current

float, double.

buffer, increasing the

buffer if necessary.

insert( )

Overloaded, each with a

The second argument

first argument of the offset

is converted to a

Appendix A: Passing & Returning Objects

1059

Method

Arguments, overloading

Use

at which to start inserting:

string and inserted

Object, String, char[],

into the current buffer

boolean, char, int, long,

beginning at the

float, double.

offset. The buffer is

increased if necessary.

reverse( )

The order of the

characters in the

buffer is reversed.

The most commonly used method is append( ), which is used by the

compiler when evaluating String expressions that contain the `+' and

`+=' operators. The insert( ) method has a similar form, and both

methods perform significant manipulations to the buffer instead of

creating new objects.

Strings are special

By now you've seen that the String class is not just another class in Java.

There are a lot of special cases in String, not the least of which is that it's

a built-in class and fundamental to Java. Then there's the fact that a

quoted character string is converted to a String by the compiler and the

special overloaded operators + and +=. In this appendix you've seen the

remaining special case: the carefully built immutability using the

companion StringBuffer and some extra magic in the compiler.

Summary

Because everything is a reference in Java, and because every object is

created on the heap and garbage-collected only when it is no longer used,

the flavor of object manipulation changes, especially when passing and

returning objects. For example, in C or C++, if you wanted to initialize

some piece of storage in a method, you'd probably request that the user

pass the address of that piece of storage into the method. Otherwise you'd

have to worry about who was responsible for destroying that storage.

Thus, the interface and understanding of such methods is more

complicated. But in Java, you never have to worry about responsibility or

whether an object will still exist when it is needed, since that is always

1060

Thinking in Java

taken care of for you. Your can create an object at the point that it is

needed, and no sooner, and never worry about the mechanics of passing

around responsibility for that object: you simply pass the reference.

Sometimes the simplification that this provides is unnoticed, other times

it is staggering.

The downside to all this underlying magic is twofold:

You always take the efficiency hit for the extra memory

management (although this can be quite small), and there's always

a slight amount of uncertainty about the time something can take

to run (since the garbage collector can be forced into action

whenever you get low on memory). For most applications, the

benefits outweigh the drawbacks, and particularly time-critical

sections can be written using native methods (see Appendix B).

Aliasing: sometimes you can accidentally end up with two

references to the same object, which is a problem only if both

references are assumed to point to a distinct object. This is where

you need to pay a little closer attention and, when necessary,

clone( ) an object to prevent the other reference from being

surprised by an unexpected change. Alternatively, you can support

aliasing for efficiency by creating immutable objects whose

operations can return a new object of the same type or some

different type, but never change the original object so that anyone

aliased to that object sees no change.

Some people say that cloning in Java is a botched design, and to heck with

it, so they implement their own version of cloning6 and never call the

Object.clone( ) method, thus eliminating the need to implement

Cloneable and catch the CloneNotSupportedException. This is

certainly a reasonable approach and since clone( ) is supported so rarely

within the standard Java library, it is apparently a safe one as well. But as

long as you don't call Object.clone( ) you don't need to implement

Cloneable or catch the exception, so that would seem acceptable as well.

6 Doug Lea, who was helpful in resolving this issue, suggested this to me, saying that he

simply creates a function called duplicate( ) for each class.

Appendix A: Passing & Returning Objects

1061

Exercises

Solutions to selected exercises can be found in the electronic document The Thinking in Java

Annotated Solution Guide, available for a small fee from .

Demonstrate a second level of aliasing. Create a method that takes

a reference to an object but doesn't modify that reference's object.

However, the method calls a second method, passing it the

reference, and this second method does modify the object.

Create a class myString containing a String object that you

initialize in the constructor using the constructor's argument. Add

a toString( ) method and a method concatenate( ) that

appends a String object to your internal string. Implement

clone( ) in myString. Create two static methods that each take

a myString x reference as an argument and call

x.concatenate("test"), but in the second method call clone( )

first. Test the two methods and show the different effects.

Create a class called Battery containing an int that is a battery

number (as a unique identifier). Make it cloneable and give it a

toString( ) method. Now create a class called Toy that contains

an array of Battery and a toString( ) that prints out all the

batteries. Write a clone( ) for Toy that automatically clones all of

its Battery objects. Test this by cloning Toy and printing the

result.

Change CheckCloneable.java so that all of the clone( )

methods catch the CloneNotSupportedException rather than

passing it to the caller.

Using the mutable-companion-class technique, make an

immutable class containing an int, a double and an array of

char.

Modify Compete.java to add more member objects to classes

Thing2 and Thing4 and see if you can determine how the

timings vary with complexity--whether it's a simple linear

relationship or if it seems more complicated.

1062

Thinking in Java

Starting with Snake.java, create a deep-copy version of the

snake.

Inherit an ArrayList and make its clone( ) perform a deep copy.

Appendix A: Passing & Returning Objects

1063

Table of Contents:
