CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 44

Reading Material

Lecture 25 - Lecture 43

Summary

Matrix Class

Definition of Matrix Constructor

Destructor of Matrix Class

Utility Functions of Matrix

Input Function

Transpose Function

Code of the Program

Matrix Class

After talking at length about the concept of matrices in the previous lecture, we are going

to have a review of `code' today with special emphasis on concepts of constructors and

destructors. We may also briefly discuss where should a programmer return by value,

return by reference besides having a cursory look on the usage of the pointers.

The data structure of the Matrix class is very simple. We have defined an arbitrary

number of functions and operators. You may add and subtract more functions in it. In this

lecture, we have chosen just a few as it is not possible to discuss each and every one in a

brief discourse. As discussed earlier, the code is available to use that can be compiled and

run. This class is not complete and a lot of things can be added to it. You should try to

enhance it, try to improve and add to its functionality.

One of the things that a programmer will prefer to do with this class is its templatization.

We have implemented it for type double. It was done due to the fact that the elements of

the Matrix are of type double. You may like to improve and make it a templatized class

so that it can also handle integer elements. This class is written in a very straightforward

manner. The double is used only for elements to develop it into a Matrix class for

integers if you replace all the double word with the int. Be careful, you cannot revert it

Page 561

CS201 Introduction to Programming

back to double by just changing all the int to double as integers are used other than

element types.

Let's discuss the code beginning with the data structure of the class. In keeping the

concepts of data hiding and encapsulation, we have put the data in the private section of

the class. We have defined number of rows (i.e. numRows) and number of columns (i.e.

numCols) as integers. These will always be whole number. As we cannot have one and a

half row or column, so these are integers.

The private part of the Matrix class is:

int numRows, numCols;

double **elements;

These are fixed and defined. So whenever you have an object of this class, it will have a

certain number of rows and certain number of columns. These are stored in the variables-

numRows and numCols. Where will be the values of the elements of this matrix? The

next line is double **elements; i.e. elements is an array of pointers to double. First * is

for array and second * makes it a pointer. It means that `elements' is pointing to a two-

dimension array of double. When we say elements[i], it means that it is pointing to an

array of double. If we say elements[i][j], it means we are talking about a particular

element of type double. We have not taken the two-dimension array in the usual way but

going to dynamic memory allocation. We have developed a general Matrix class. The

objects created from it i.e. the instances of this class, could be small matrices as 2*2.

These may also be as big matrix as 20*20. In other words, the size of the matrix is

variable. In fact, there is no requirement that size should be square. It may not be 20*20.

It may be a matrix of 3*10 i.e. three rows and ten columns. So we have complete

flexibility. When we create an object, it will store the number of rows in numRows and

number of columns in numCols. The elements will be dynamically allocated memory in

which the double value is stored.

While using the dynamic memory, it is good to keep in mind that certain things are

necessary to be implemented in the class. 1) Its constructor should make memory

allocation. We will use the new operator, necessitating the need of defining its destructor

also. Otherwise, whenever we create an object, the memory will be allocated from the

free store and not de-allocated resulting in the wastage of the memory. Therefore a

destructor is necessary while de-allocating memory. 2) The other thing while dealing

with classes having dynamic memory allocation, we need to define an assignment

operator. If we do not define the assignment operator, the default will do the member

wise copy i.e. the shallow copy. The value of pointer will be copied to the pointer but the

complete data will not be copied. We will see in the code how can we overcome this

problem..

Let's discuss the code in the public interface of the class. The first portion of the public

interface is as:

Page 562

CS201 Introduction to Programming

Matrix(int=0, int=0);

// default constructor

Matrix(const Matrix & ); // copy constructor

~Matrix();

// Destructor

In the public interface, the first thing we have is the constructors. In the default

constructor, you see the number of columns and number of rows. The default values are

zero. If you just declare a matrix as Matrix m, it will be an object of class Matrix having

zero rows and zero columns i.e. memory is not allocated yet. Then we have also written a

copy constructor. Copy constructor becomes necessary while dealing with dynamic

memory allocation in the class. So we have to provide constructor, destructor, assignment

operator and the copy constructor. The declaration line of copy constructor is always the

same as the name of the class. In the argument list, we have a reference to an object of

the same class i.e. Matrix(const Matrix & ); The & represents the reference. This is the

prototype. After constructors, we have defined a destructor. Its prototype is also standard.

Here it is ~Matrix(); it takes no argument and returns nothing. Remember that

constructors and destructors return nothing.

After this, we have utility functions for the manipulation of the Matrix.

int getRows(void) const;

// Utility fn, returns no. of rows

int getCols(void) const;

// Utility fn, returns no. of columns

const Matrix & input(istream &is = cin); // Read from istream i.e. keyboard

const Matrix & input(ifstream &is);

// Read matrix from ifstream

void output(ofstream &os) const;

// Utility fn, prints matrix with graphics

void output(ostream &os = cout) const; // Utility fn, prints matrix with graphics

const Matrix& transpose(void);

// Transpose the matrix and return a ref

We have defined two small functions as getRows and getCols which will return the

number of rows and number of columns of the matrix respectively. Here, you are writing

the class and not the client which will use this class. During the usage of this class, there

may be need of some more functions. You may need to add some more functionality

depending on its usage. At this point, a function may be written which will return some

particular row as a vector or the nth column of a matrix. These things are left for you to

do.

We need some function to input values into the matrix. There are two input functions

both named as input. One is used to get the value from the keyboard while the other to

get the values from some file. There is a little bit difference between the declaration of

these two that will be discussed later. The input function which will get the input from

the keyboard, takes an argument of type istream. Remember that cin, that is associated

with the keyboard, is of type istream. These are member functions and called by some

object of Matrix. The Matrix object will be available to it through this pointer. The

Page 563

CS201 Introduction to Programming

istream is passed as argument and we have given a temporary name to the input argument

i.e. is and its default value is cin. It is a nice way of handling default values. If you write

in the main program as m.input() where m is an object of type Matrix, it will get the input

from the keyboard. This is due to the fact that it is getting cin by default. We have

defined another input function and that is an example of function overloading. This

function takes ifstream as input argument i.e. a file stream. If we want to read the matrix

data from some file, this input function may be employed. There is no default argument

in it.

Similarly we have two output functions. The names are chosen as arbitrary. You may

want to use print or display. One output function will display the matrix on the screen. Its

argument is ostream while the default value will be cout. The other output function will

be used when we want to write the matrix in some file. It takes ofstream as argument and

we have not provided any default argument to it. You will have to provide a file handle to

use this function.

Let's continue to talk about the arithmetic manipulations we want to do with the matrices.

Matrix operator+( Matrix &m) const; // Member op + for A+B; returns matrix

Matrix operator + (double d) const;

// Member op + for A+d; returns matrix

const Matrix & operator += (Matrix &m); // Member op += for A +=B

friend Matrix operator + (double d, Matrix &m); // friend operator for d+A

Matrix operator-( Matrix & m) const; // Member op - for A-B; returns matrix

Matrix operator - (double d) const;

// Member op - for A-d;

const Matrix & operator -= (Matrix &m); // Member op -= for A-=B;

friend Matrix operator - (double d, Matrix& m); // Friend op - for d-A;

Matrix operator*(const Matrix & m); // Member op * for A*B;

Matrix operator * (double d) const; // Member op * for A*d;

friend Matrix operator * (const double d, const Matrix& m);//friend op*, d*A

const Matrix& transpose(void); // Transpose the matrix and return a ref

const Matrix & operator = (const Matrix &m); // Assignment operator

We have defined different functions for plus. Some of these are member operators while

the others called as friend. The first plus operator is to add two matrices. It is a member

operator that takes a Matrix object as argument. The second one is to add some double

number to matrix. Remember that we are having a class of Matrix with double elements.

So we will add double number to it. It is also a member operator. When you write

something like m + d, where m is an object of type Matrix and d is a double variable, this

operator will be called. Here Matrix object is coming on the left-hand side and will be

available inside the operator definition by this pointer. On the other hand, the double

value d is presented as argument to the operator.

Page 564

CS201 Introduction to Programming

There is another variety of adding double to the matrix i.e. if we write as d + m. On the

left-hand side, we don't have Matrix. It cannot be a member function as the driving force

is not an object of our desired class. If not a member function, it will have two arguments.

First argument will be of type double while the second one is going to be of Matrix object

in which we will add the double number. As it is not a member function and we want to

manipulate the private data members of the class, it has to be a friend function. Function

will be defined outside, at file level scope. In other words, it will not be a member

function of class Matrix but declared here as a friend. It is defined as:

Friend Matrix operator + (double d, Matrix &m);

Its return type is Matrix. When we add a double number, it will remain as Matrix .We

will be able to return it. The final variant is included as an example of code reuse i.e. the

+= operator. We write in our program i += 3; and it means i = i + 3; It would be nice if

we can write A += B where A and B both are matrices.

After plus, we can do the same thing with the minus operator. Having two matrices-A and

B, we want to do A-B. On the left hand side, we have Matrix, so it will be a member

operator. The other matrix will be passed as argument. In A-B, A is calling this operator

while B being passed as argument. We can also do A-d where A is a Matrix and d is of

type double. For this, we will have to write a member operator. All these operators are

overloaded and capable of returning Matrix. In this overloaded operator, double will be

passed as argument. Then we might want to do it as d - A, where d is double variable and

A is of type Matrix. Since the left hand side of the minus (-) is double, we will need a

friend function, as it is not possible to employ a member function. Its prototype is as:

friend Matrix operator - (double d, Matrix& m);

Let's now talk about multiplication. We have discussed somewhat about it in the previous

lecture. For multiplication, the first thing one needs to do is the multiplication of two

matrices i.e. A*B where A and B both are matrices. As on the left hand side of the

operator * we have a Matrix so it will be a member function so A can be accessed through

this pointer. B will be passed as argument. A matrix should be returned. Thus, we have a

member operator that takes an argument of type Matrix and returns a Matrix. You may

like to do the same thing, which we did with the plus and minus. In other words, a

programmer will multiply a matrix with a double or multiply a double with a matrix. In

either case, we want that a matrix should be returned. So at first, A * d should be a

member function. Whereas d * A will be a friend function. Again the return type will be a

Matrix.

In case of division, we have only one case i.e. the division of the matrix with a double

number. This is A / d where A is a Matrix while d is a double variable. We will divide all

the elements of the matrix with this double number. This will return a matrix of the same

size as of original.

Page 565

CS201 Introduction to Programming

Taking benefit of the stream insertion and extraction operator, we can use double greater

than sign ( >>) and write as >> m where m is a Matrix. For this purpose, we have written

stream extraction operator. The insertion and extraction functions will be friend functions

as on the left-hand side, there will be either input stream or output stream.

We have also defined assignment function in it. As we are using dynamic memory

allocation in the class, assignment is an important operator. Another important function is

transpose, in which we will interchange the rows into columns and return a Matrix. This

is the interface of our Matrix class. You may want to add other functions and operators

like +=, -=, *=. But it is not possible to add /= due to its very limited scope.

We have used the keyword const in our class. You will find somewhere the return type as

Matrix and somewhere as Matrix &. We will discuss each of these while dealing with

the code in detail.

Definition of Matrix Constructor

Let's start with the default constructor. Its prototype is as under:

Matrix(int = 0, int = 0);

// default constructor

We are using the default argument values here. In the definition of this function, we will

not repeat the default values. Default values are given at one place. The definition code is

as:

Matrix::Matrix(int row, int col)

//default constructor

{

numRows = row;

numCols = col;

elements = new (double *) [numRows];

for (int i = 0; i < numRows; i++){

elements[i] = new double [ numCols];

for(int j = 0; j < numCols; j++)

elements[i][j] =0.0; // Initialize to zero

}

Two integers are passed to it. One represents the number of rows while the other is

related to the number of columns of the Matrix object that we want to create. At first,

we will assign these values to numRows and numCols that form a part of the data

structure of our class. Look at the next line. We have declared elements as **elements i.e.

the array of pointers to double. We can directly allocate it by getting the elements of

Page 566

CS201 Introduction to Programming

numRows times numCols of type double from free store. But we don't have the double

pointer. Therefore, first of all, we say that element is array of pointer to double and

allocate pointers as much as needed. So we use the new operator and use double* cast. It

means that whatever is returned is of type pointer to double. How many pointers we

need? This is equal to number of rows in the matrix. There is one pointer for each of the

rows i.e. now a row can be an array. This is a favorable condition, as we have to enter

data in the columns. Now elements is numRows number of pointers to double. After

having this allocation we will run a loop.

In C/C++ languages, every row starts from zero and ends with upper-limit 1. Now in

the loop, we have to allocate the space for every elements[i]; How much space is needed

here? This will be of type double and equal to number of columns. So when we say new

double[numCols], it means an array of double. As elements[i] represents a pointer and

now it is pointing to an array. Remember that pointers and arrays are synonymous. Now

a pointer is pointing to this array. We have the space now and want to initialize the

matrix. For this, we have written another loop. To assign the value, we will write as:

elements[i][j] = 0.0;

Let's review this again. First of all we have assigned the values to numRows and

numCols. Later, we allocated the pointers of double from the free store and assigned to

elements. Then we got the space for each of this pointer to store double. Finally, we

initialized this space with 0.0. Now we have a constructive matrix.

Is there any exceptional value? We can think of assigning negative values to number of

rows or number of columns. If you want to make sure that this does not happen, you can

put a test by saying that numRows and numCols must be greater than or equal to zero.

Passing zero is not a problem as we have zero space and nothing happens actually. Now

we get an empty matrix of dimension 0*0. But any positive number supplied will give us

a constructor and initialize zero matrix.

Let's discuss the other constructor. This is more important in the view of this class

especially at a time when we are going to do dynamic memory allocation. This is copy

constructor. It is used when we write in our program as Matrix A(B); where A and B both

are matrices. We are going to construct A while B already exists. Here we are saying that

give us a new object called A which should be identical to the already existing object B.

So it is a copy constructor. We are constructing an object as a copy of another one that

already exists. The other usage of this copy constructor is writing in the main function as

Matrix A = B; Remember that this is declaration and not assignment statement. Here

again copy constructor will be called. We are saying that give us a duplicate of B and its

name should be A. Here is the code of this function:

Matrix::Matrix(const Matrix &m)

{

numRows = m.numRows;

numCols = m.numCols;

Page 567

CS201 Introduction to Programming

elements = new (double *) [numRows];

for (int i = 0; i < numRows; i++){

elements[i] = new double [ numCols];

for(int j = 0; j < numCols; j++)

elements[i][j] = m.elements[i][j];

}

We are passing it a constant reference of Matrix object to ensure that the matrix to be

copied is not being changed. Therefore we make it const. We are going to create a brand

new object that presently does not exist. We need to repeat the code of regular

constructor except the initialization part. Its rows will be equal to the rows of the object

supplied i.e. numRows = m.numRows. Similarly the columns i.e. numCols= m.numCols.

Now we have to allocate space while using the same technique earlier employed in case

of the regular constructor. In the default constructor, we initialize the elements with zero.

Here we will not initialize it with zero and assign it the value of Matrix m as

elements[i][j] = m.elements[i][j]. Remember that we use the dot operator to access the

data members. We have not used the dot operator on the left hand side. This is due to the

fact that this object is being constructed and available in this function through this

pointer. Therefore the dot operator on the left hand side is not needed. We will use it on

the right hand side to access the data members of Matrix m. This is our copy constructor.

In this function, we have taken the number of rows and columns of the object whose copy

is being made. Then we allocate it the space and copy the values of elements one by one.

The other thing that you might want to know is the use of nested loop both in regular

constructor and the copy constructor.

Destructor of Matrix Class

`Destructor' is relatively simple. It becomes necessary after the use of new in the

constructor. While creating objects, a programmer gets memory from the free store. So in

the destructor, we have to return it. We will do it as:

delete [] elements;

Remember that `elements' is the variable where the memory has been allocated. The []

simply, indicates that it is an array. The compiler automatically takes care of the size of

the array and the memory allocated after being returned, goes back to the free store.

There is only one line in the destructor. It is very simple but necessary in this case.

Utility Functions of Matrix

The functions getRows() and getCols() are relatively simple. They do not change

anything in the object but only read from the object. Therefore we have made this

function constant by writing the const keyword in the end. It means that it does not

change anything. The code of the getRows() functions is as follows:

int Matrix :: getRows ( ) const

{

Page 568

CS201 Introduction to Programming

return numRows;

}

This function returns an int representing the number of rows. It will be used in the main

function as i = m.getRows(); where i is an int and m is a Matrix object. Same thing

applies to the getCols() function. It is of type const and returns an int representing the

number of columns.

Let's talk about little bit more complicated function. It is the output to the screen

functions. We want that our matrix should be displayed on the screen in a beautiful way.

You have seen that in the books that matrix is written in big square brackets. The code of

the function is as:

void Matrix::output(ostream &os) const

{

// Print first row with special characters

os.setf(ios::showpoint);

os.setf(ios::fixed,ios::floatfield);

os << (char) 218;

for(int j = 0; j < numCols; j++)

os << setw(10) << " ";

os << (char) 191 << "\n";

// Print remaining rows with vertical bars only

for (int i = 0; i < numRows; i++){

os << (char) 179;

for(int j = 0; j < numCols; j++)

os << setw(10)<< setprecision(2) << elements[i][j];

os << (char) 179 << "\n";

}

// Print last row with special characters

os << (char) 192;

for(int j = 0; j < numCols; j++)

os << setw(10) << " ";

os << (char) 217 << "\n";

}

We have used special characters that can be viewed in the command window. We have

given you an exercise of printing the ASCII characters on the screen. After ASCII code

128, we have special graphic symbols. We have used the values of those symbols here.

To print those in the symbol form, we have forced it to be printed as char. If we do not

use the char, it would have printed the number 218 i.e. it would have written an integer.

Page 569

CS201 Introduction to Programming

We have forced it to print the character whose ASCII value is 218. Now it prints the

graphic symbol for that character. We have referenced the ASCII table and seen which

symbol will fit in the left corner i.e. 218. So we have written it as:

os << (char) 218;

os is the output stream. char is forcing it to be print as character. The left corner will be

printed on the screen as . Now we need the space to print the columns of the matrix. In

the first line we will print the spaces using a loop as:

for(int j = 0; j < numCols; j++)

os << setw(10) << " ";

Here we have changed the width as 10. You can change it to whatever you like. Then we

print nothing in the space of ten characters and repeat that for the number of columns in

the matrix. After this, we printed the right corner. This is the first line of the display.

Other lines will also contain the values of the elements of the matrix. These lines will

start with a vertical line and then the element values of the row and in the end we have a

vertical line. For each row, we have a vertical bar and the number values which will be

equal to number of columns (elements in each row equals to the number of columns) and

then a vertical bar in the end. In the beginning of this code, we have used two other

utilities to improve the formatting. Here we have a matrix of type double so every

element

the

matrix

double.

For

double,

have

used

os.setf(ios::fixed,ios::floatfield); that means that it is a fixed display. Scientific notation

will not be used while decimal number is displayed with the decimal point. After this, we

have set the precision with two number of places. So we have a format and our decimal

numbers will always be printed with two decimal places. The numbers are being printed

with a width of ten characters so the last three places will be as .xx. Rest of the code is

simple enough. We have used the nested loops. Whenever you have to use rows and

columns, it will be good to use nested loops. When all the rows have been printed, we

will print the below corners. We referenced the ASCII table, got the graphic symbol,

printed it, left the enough space and then printed the other corner. The matrix is now

complete. When this is displayed on the screen, it seems nicely formatted matrix with

graphic symbols. That is our basic output function.

Let's look at the file output function. While doing the output on the screen, we made it

nicely formatted. Now you may like to store the matrix in a file. While storing the matrix

in the file, there is no need of these lines and graphic symbol. We only need its values to

read the matrix from the file. So there is a pair of functions i.e. output the matrix in the

file and input from the file. To write the output function, we actually have to think about

the input function.

Suppose, we have declared a 2*2 Matrix m in our program. Somewhere in the program,

we want to populate this matrix from the file. Do we know that we have a 2*2 matrix in

the file. How do we know that? It may 5*5 or 7*3 matrix. So what we need to do is

somehow save the number of rows and columns in the file as well. So the output function

Page 570

CS201 Introduction to Programming

that puts out on the file must put out the number of rows and number of columns and then

all of the elements of the matrix. Following is the code of this function:

void Matrix::output(ofstream &os) const

{

os.setf(ios::showpoint);

os.setf(ios::fixed,ios::floatfield);

os << numRows << " " << numCols << "\n";

for (int i = 0; i < numRows; i++){

for(int j = 0; j < numCols; j++)

os << setw(6) << setprecision(2) << elements[i][j];

os << "\n";

}

The code is shorter than the other output function due to non-use of the graphical

symbols. First of all, we output the number of rows and number of columns. Then for

these rows and columns, data elements are written. We have also carried out a little bit

formatting. While seeing this file in the notepad, you will notice that there is an extra line

on the top that depicts the number of rows and columns.

Input Functions

Input functions are also of two types like output functions. The first function takes input

from the keyboard while the other takes input from the file. The function that takes input

from the keyboard is written in a polite manner because humans are interacting with it.

We will display at the screen "Input Matrix size: 3 rows by 3 columns" and it will ask

"Please enter 3 values separated by spaces for row no. 1" for each row. Spaces are

delimiter in C++. So spaces will behave as pressing enter from the keyboard. If you have

to enter four numbers in a row, you will enter as number (space) number (space) number

(space) number before pressing the enter key. We have a loop inside which will process

input stream and storing these values into elements[i][j]; So the difference between this

function and the file input function is 1) It prompts to the user and is polite. 2) It will read

from the keyboard and consider spaces as delimiter.

The other input function reads from the file. We have also stored the number of rows and

number of columns in the file. The code of this function is:

const Matrix & Matrix::input(ifstream &is)

{

int Rows, Cols;

is >> Rows;

is >> Cols;

Page 571

CS201 Introduction to Programming

if(Rows > 0 && Cols > 0){

Matrix temp(Rows, Cols);

*this = temp;

for(int i = 0; i < numRows; i++){

for(int j = 0; j < numCols; j++){

is >> elements[i][j];

}

return *this;

}

First of all, we will read the number of rows and number of columns from the file. We

have put some intelligence in it. It is better to check whether numRows and numCols is

greater than zero. If it is so, then do something. Otherwise, there is nothing to do. If rows

and columns are greater than zero, then there will be a temporary matrix specifying its

rows and columns. These values are read from the file, showing that we have a matrix of

correct size. Now this matrix is already initialized to zero by our default constructor. We

can do two things. We can either read the matrix, return the value or we can first assign it

to the matrix that was calling this function. We have assigned it first as *this = temp; here

temp is a temporary matrix which is created in this function but *this is whatever this

points to. Remember that this is a member function so this pointer points to the matrix

that is calling this function. All we have to do is to assign the temp to the matrix, which is

calling this function. This equal to sign is our assignment operator, which we have

defined in our Matrix class. If the dimensions of the calling matrix are not equal to the

temp matrix, the assignment operator will correct the dimensions of the calling matrix. It

will assign the values, which in this case is zero so far. Now we will read the values from

the file using the nested loops. The other way is to read the values from the file and

populate the temp matrix before assigning it to the calling matrix in the end. That is the

end of the function. Remember that the temp matrix, which we have declared in this

function, will be destroyed after the exit from the function. This shows that the

assignment operator is important here. All the values will be copied and it will perform a

deep copy. Does this function return something? Its return type is reference to a const

Matrix. Its ending line is return *this that means return whatever this points to and it is

returned as reference. The rule of thumb is whenever we are returning the this pointer, it

will be returned as a reference because this is the same object which is calling it. When

you are returning a matrix that is not a reference, it is a returned by value. The complete

matrix will be copied on the stack and returned. This is slightly wasteful. Yet you cannot

return a reference to the temp object in this code. The reference of the temp will be

returned but destroyed when the function is finished. The reference will be pointing to

nothing. So you have to be careful while returning a reference to this.

Transpose Function

The transpose of a matrix will interchange rows into columns. There are two alternative

requirements. In the first case, we have a square matrix i.e. the number of rows is equal to

Page 572

CS201 Introduction to Programming

number of columns. In this situation, we don't need extra storage to do this. If the number

of rows is not equal to the number of columns, then we have to deal it in a different way.

We can use general case for both purposes but you will notice that it is slightly

insufficient. Here is the code of the function.

const Matrix & Matrix::transpose()

{

if(numRows == numCols){ // Square matrix

double temp;

for(int i = 0;i < numRows; i++){

for(int j = i+1; j < numCols; j++){

temp = elements[i][j];

elements[i][j] = elements[j][i];

elements[j][i] = temp;

}

else // not a square matrix

{

Matrix temp(numCols, numRows);

for(int i = 0; i < numRows; i++){

for(int j = 0; j < numCols; j++){

temp.elements[j][i] = elements[i][j];

}

*this = temp;

}

return *this;

}

In the beginning, we checked the case of square matrix i.e. if the number of rows is equal

to number of columns. Here we are dealing with the square matrix. We have to change

the rows into columns. For this purpose, we need a temporary variable. In this case, it is a

variable of type double because we are talking about a double matrix. Look at the loop

conditions carefully. The outer loop runs for i = 0 to i < numRows and the inner loop

runs from j = i+1 to j < numCols. Then we have standard swap functionality. We have

processed one triangle of the matrix. If you start the inner loop from zero, think logically

what will happen. You will interchange a number again and again, but nothing will

happen in the end, leaving no change in the matrix. This is the case of the square matrix.

But in case of non-square matrix i.e. the code in the else part, we have to define a new

matrix. Its rows will be equal to the columns of the calling matrix and its columns will be

equal to the number of rows. So we have defined a new Matrix temp with the number of

rows and columns interchanged as compared to the calling matrix. Its code is

straightforward. We are doing the element to element copy. The difference is, in the loop

we are placing the x row, y col element of the calling matrix to y row, x col of the temp

matrix. It is an interchange of the rows and columns according to the definition of the

Page 573

CS201 Introduction to Programming

transpose. When we have all the values copied in the temp. We do our little magic that is

*this = temp. Which means whatever this points to, now assigned the values of the matrix

temp. Now our horizontal matrix becomes vertical and vice versa. In the end, we return

this. This is the basic essence of transpose code.

We will continue the discussion on the code in the next lecture. We will look at the

assignment operator, stream operator and try to recap the complete course.

Code of the Program

The complete code of the matrix class is:

#include <iostream.h>

#include <iomanip.h>

#include <stdlib.h>

#include <stdio.h>

#include <fstream.h>

class Matrix

{

private:

int numRows, numCols;

double **elements;

public:

Matrix(int=0, int=0);

// default constructor

Matrix(const Matrix & );

// copy constructor

~Matrix();

// Destructor

int getRows(void) const;

// Utility fn, returns no. of rows

int getCols(void) const;

// Utility fn, returns no. of columns

const Matrix & input(istream &is = cin); // Read matrix from istream

const Matrix & input(ifstream &is);

// Read matrix from istream

void output(ofstream &os) const;

// Utility fn, prints matrix with graphics

void output(ostream &os = cout) const; // Utility fn, prints matrix with graphics

const Matrix& transpose(void);

// Transpose the matrix and return a ref

const Matrix & operator = (const Matrix &m);

// Assignment operator

Matrix operator+( Matrix &m) const;

// Member op + for A+B; returns matrix

Matrix operator + (double d) const;

const Matrix & operator += (Matrix &m);

friend Matrix operator + (double d, Matrix &m);

Matrix operator-( Matrix & m) const;

// Member op + for A+B; returns matrix

Matrix operator - (double d) const;

const Matrix & operator -= (Matrix &m);

Page 574

CS201 Introduction to Programming

friend Matrix operator - (double d, Matrix& m);

Matrix operator*(const Matrix & m);

Matrix operator * (double d) const;

friend Matrix operator * (const double d, const Matrix& m);

Matrix operator/(const double d);

friend ostream & operator << ( ostream & , Matrix & );

friend istream & operator >> ( istream & , Matrix & );

friend ofstream & operator << ( ofstream & , Matrix & );

friend ifstream & operator >> ( ifstream & , Matrix & );

};

Matrix::Matrix(int row, int col)

//default constructor

{

numRows = row;

numCols = col;

elements = new (double *) [numRows];

for (int i = 0; i < numRows; i++){

elements[i] = new double [ numCols];

for(int j = 0; j < numCols; j++)

elements[i][j] = 0; // Initialize to zero

}

Matrix::Matrix(const Matrix &m)

{

numRows = m.numRows;

numCols = m.numCols;

elements = new (double *) [numRows];

for (int i = 0; i < numRows; i++){

elements[i] = new double [ numCols];

for(int j = 0; j < numCols; j++)

elements[i][j] = m.elements[i][j];

}

Matrix::~Matrix(void)

{

delete [] elements;

}

int Matrix :: getRows ( ) const

{

return numRows;

Page 575

CS201 Introduction to Programming

}

int Matrix :: getCols ( ) const

{

return numCols;

}

void Matrix::output(ostream &os) const

{

// Print first row with special characters

os.setf(ios::showpoint);

os.setf(ios::fixed,ios::floatfield);

os << (char) 218;

for(int j=0; j<numCols; j++)

os << setw(10) << " ";

os << (char) 191 << "\n";

// Print remaining rows with vertical bars only

for (int i=0; i<numRows; i++){

os << (char) 179;

for(int j=0; j<numCols; j++)

os << setw(10)<< setprecision(2) << elements[i][j];

os << (char) 179 << "\n";

}

// Print last row with special characters

os << (char) 192;

for(int j=0; j<numCols; j++)

os << setw(10) << " ";

os << (char) 217 << "\n";

}

void Matrix::output(ofstream &os) const

{

os.setf(ios::showpoint);

os.setf(ios::fixed,ios::floatfield);

os << numRows << " " << numCols << "\n";

for (int i=0; i<numRows; i++){

for(int j=0; j<numCols; j++)

os << setw(6) << setprecision(2) << elements[i][j];

os << "\n";

}

const Matrix & Matrix::input(istream &is)

{

cout << "Input Matrix size: " << numRows << " rows by " << numCols << "

Page 576

CS201 Introduction to Programming

columns\n";

for(int i=0; i<numRows; i++){

cout << "Please enter " << numCols << " values separated by spaces for row

no." << i+1 << ": ";

for(int j=0; j<numCols; j++){

cin >> elements[i][j];

}

return *this;

}

const Matrix & Matrix::input(ifstream &is)

{

int Rows, Cols;

is >> Rows;

is >> Cols;

if(Rows>0 && Cols > 0){

Matrix temp(Rows, Cols);

*this = temp;

for(int i=0; i<numRows; i++){

for(int j=0; j<numCols; j++){

is >> elements[i][j];

}

return *this;

}

const Matrix & Matrix::transpose()

{

if(numRows == numCols){ // Square matrix

double temp;

for(int i=0; i<numRows; i++){

for(int j=i+1; j<numCols; j++){

temp = elements[i][j];

elements[i][j] = elements[j][i];

elements[j][i] = temp;

}

else

{

Matrix temp(numCols, numRows);

for(int i=0; i<numRows; i++){

for(int j=0; j<numCols; j++){

temp.elements[j][i] = elements[i][j];

Page 577

CS201 Introduction to Programming

}

*this = temp;

}

return *this;

}

const Matrix & Matrix :: operator = ( const Matrix & m )

{

if( &m != this){

if (numRows != m.numRows || numCols != m.numCols){

delete [] elements;

elements = new (double *) [m.numRows];

for (int i = 0; i < m.numRows; i++)

elements[i]=new double[m.numCols ];

}

numRows = m.numRows;

numCols = m.numCols;

for ( int i=0; i<numRows; i++){

for(int j=0; j<numCols; j++){

elements[i][j] = m.elements[i][j];

}

return *this;

}

Matrix Matrix::operator + ( Matrix &m ) const

{

// Check for conformability

if(numRows == m.numRows && numCols == m.numCols){

Matrix temp(m);

for (int i = 0; i < numRows; i++){

for (int j = 0; j < numCols; j++){

temp.elements[i][j] += elements[i][j];

}

return temp ;

}

Matrix Matrix::operator + ( double d ) const

{

Matrix temp(*this);

for (int i = 0; i < numRows; i++){

for (int j = 0; j < numCols; j++){

Page 578

CS201 Introduction to Programming

temp.elements[i][j] += d;

}

return temp ;

}

const Matrix & Matrix::operator += (Matrix &m)

{

*this = *this + m;

return *this;

}

Matrix Matrix::operator - ( Matrix &m ) const

{

// Check for conformability

if(numRows == m.numRows && numCols == m.numCols){

Matrix temp(*this);

for (int i = 0; i < numRows; i++){

for (int j = 0; j < numCols; j++){

temp.elements[i][j] -= m.elements[i][j];

}

return temp ;

}

Matrix Matrix::operator - ( double d ) const

{

Matrix temp(*this);

for (int i = 0; i < numRows; i++){

for (int j = 0; j < numCols; j++){

temp.elements[i][j] -= d;

}

return temp ;

}

const Matrix & Matrix::operator -= (Matrix &m)

{

*this = *this - m;

return *this;

}

Matrix Matrix::operator* ( const Matrix& m)

{

Matrix temp(numRows,m.numCols);

Page 579

CS201 Introduction to Programming

if(numCols == m.numRows){

for ( int i = 0; i < numRows; i++){

for ( int j = 0; j < m.numCols; j++){

temp.elements[i][j] = 0.0;

for( int k = 0; k < numCols; k++){

temp.elements[i][j] += elements[i][k] * m.elements[k][j];

}

return temp;

}

Matrix Matrix :: operator * ( double d) const

{

Matrix temp(*this);

for ( int i = 0; i < numRows; i++){

for (int j = 0; j < numCols; j++){

temp.elements[i][j] *= d;

}

return temp;

}

Matrix operator * (const double d, const Matrix& m)

{

Matrix temp(m);

temp = temp * d;

return temp;

}

Matrix Matrix::operator / (const double d)

{

Matrix temp(*this);

for(int i=0; i< numRows; i++){

for(int j=0; j<numCols; j++){

temp.elements[i][j] /= d;

}

return temp;

}

Matrix operator + (double d, Matrix &m)

{

Matrix temp(m);

for(int i=0; i< temp.numRows; i++){

Page 580

CS201 Introduction to Programming

for(int j=0; j<temp.numCols; j++){

temp.elements[i][j] *= d;

}

return temp;

}

Matrix operator - (double d, Matrix& m)

{

Matrix temp(m);

for(int i=0; i< temp.numRows; i++){

for(int j=0; j<temp.numCols; j++){

temp.elements[i][j] = d - temp.elements[i][j];

}

return temp;

}

ostream & operator << ( ostream & os, Matrix & m)

{

m.output();

return os;

}

istream & operator >> ( istream & is, Matrix & m)

{

m.input(is);

return is;

}

ofstream & operator << ( ofstream & os, Matrix & m)

{

m.output(os);

return os;

}

ifstream & operator >> ( ifstream & is, Matrix & m)

{

m.input(is);

return is;

}

int main()

{

// declaring two matrices

Matrix m(4,5), n(5,4);

Page 581

CS201 Introduction to Programming

// getting input from keyboard

cout << "Taking the input for m(4,5) and n(5,4) \n";

m.input();

n.input();

// displaying m and taking its transpose

cout << "Displaying the matrix m(4,5) and n(5,4)\n";

m.output();

n.output();

cout << "Taking the transpose of matrix m(4,5) \n";

m.transpose();

cout << "Displaying the matrix m(5,4) and n(5,4) \n";

m.output();

cout << "Adding matrices n into m \n";

m = m + n;

m.output();

cout << "Calling m + m + 4 \n";

m = m + m + 4;

m.output();

cout << "Calling m += n \n";

m += n;

m.output();

cout << "Calling m = m - n \n";

m = m - n;

m.output();

cout << "Calling m = m - 4 \n";

m = m - 4;

m.output();

cout << "Calling m -= n \n";

m -= n;

m.output();

m.transpose();

Matrix c;

cout << "Calling c = m * n \n";

Page 582

CS201 Introduction to Programming

c = m * n;

c.output();

cout << "Calling c = c * 4.0 \n";

c = c * 4.0;

c.output();

cout << "Calling c = 4.0 * c \n";

c = 4.0 * c ;

c.output();

cout << "Testing stream extraction \n";

// cin >> c;

cout << "Testing stream insertion \n";

// cout << c;

cout << "Writing into the file d:\\junk.txt \n" ;

ofstream fo("D:/junk.txt");

fo << c;

fo.close();

cout << "Reading from the file d:\\junk.txt \n";

ifstream fi("D:/junk.txt");

fi >> c;

fi.close();

cout << c;

system("PAUSE");

return 0;

}

The output of the program is:

Taking the input for m(4,5) and n(5,4)

Input Matrix size: 4 rows by 5 columns

Please enter 5 values separated by spaces for row no.1: 1.0 2.0 3.0 4.0 5.0

Please enter 5 values separated by spaces for row no.2: 7.0 5.5 2.3 2.0 1.0

Please enter 5 values separated by spaces for row no.3: 3.3 2.2 1.1 4.4 5.5

Please enter 5 values separated by spaces for row no.4: 9.9 5.7 4.3 2.3 1.5

Input Matrix size: 5 rows by 4 columns

Please enter 4 values separated by spaces for row no.1: 11.25 12.25 13.25 14.25

Please enter 4 values separated by spaces for row no.2: 25.25 50.50 75.75 25.50

Please enter 4 values separated by spaces for row no.3: 15.15 5.75 9.99 19.90

Page 583

CS201 Introduction to Programming

Please enter 4 values separated by spaces for row no.4: 25.50 75.75 10.25 23.40

Please enter 4 values separated by spaces for row no.5: 50.50 75.50 25.25 15.33

Displaying the matrix m(4,5) and n(5,4)

┌

┐

│

1.00

2.00 3.00

4.00 5.00│

│

7.00

5.50 2.30

2.00 1.00│

│

3.30

2.20 1.10

4.40 5.50│

│

9.90

5.70 4.30

2.30 1.50│

└

┘

┌

┐

│ 11.25 12.25 13.25 14.25│

│ 25.25 50.50 75.75 25.50│

│ 15.15

5.75 9.99 19.90 │

│ 25.50 75.75 10.25 23.40│

│ 50.50 75.50 25.25 15.33│

└

┘

Taking the transpose of matrix m(4,5)

Displaying the matrix m(5,4) and n(5,4)

┌

┐

│

1.00

7.00 3.30

9.90│

│

2.00

5.50 2.20

5.70│

│

3.00

2.30 1.10

4.30│

│

4.00

2.00 4.40

2.30│

│

5.00

1.00 5.50

1.50│

└

┘

Adding matrices n into m

┌

┐

│ 12.25 19.25 16.55 24.15│

│ 27.25 56.00 77.95 31.20│

│ 18.15

8.05 11.09 24.20 │

│ 29.50 77.75 14.65 25.70│

│ 55.50 76.50 30.75 16.83│

└

┘

Calling m + m + 4

┌

┐

│ 28.50 42.50 37.10 52.30 │

│ 58.50 116.00 159.90 66.40│

│ 40.30 20.10 26.18 52.40 │

│ 63.00 159.50 33.30 55.40 │

│ 115.00 157.00 65.50 37.66│

└

┘

Calling m += n

┌

┐

│ 39.75 54.75 50.35 66.55 │

│ 83.75 166.50 235.65 91.90│

│ 55.45 25.85 36.17 72.30 │

Page 584

CS201 Introduction to Programming

│ 88.50 235.25 43.55 78.80 │

│ 165.50 232.50 90.75 52.99│

└

┘

Calling m = m - n

┌

┐

│ 28.50 42.50 37.10 52.30 │

│ 58.50 116.00 159.90 66.40│

│ 40.30 20.10 26.18 52.40 │

│ 63.00 159.50 33.30 55.40 │

│ 115.00 157.00 65.50 37.66│

└

┘

Calling m = m - 4

┌

┐

│ 24.50 38.50 33.10 48.30 │

│ 54.50 112.00 155.90 62.40│

│ 36.30 16.10 22.18 48.40 │

│ 59.00 155.50 29.30 51.40 │

│ 111.00 153.00 61.50 33.66│

└

┘

Calling m -= n

┌

┐

│ 13.25 26.25 19.85 34.05 │

│ 29.25 61.50 80.15 36.90 │

│ 21.15 10.35 12.19 28.50 │

│ 33.50 79.75 19.05 28.00 │

│ 60.50 77.50 36.25 18.33 │

└

┘

Calling c = m * n

┌

┐

│ 5117.55 8866.42 4473.54 3066.94 │

│ 7952.36 15379.14 7884.15 5202.50 │

│ 4748.18 8540.74 7566.73 3570.75 │

│ 3386.23 5949.35 4280.89 2929.51 │

└

┘

Calling c = c * 4.0

┌

┐

│ 20470.19 35465.70 17894.15 12267.75 │

│ 31809.46 61516.55 31536.59 20810.01 │

│ 18992.71 34162.97 30266.91 14283.00 │

│ 13544.91 23797.41 17123.54 11718.05 │

└

┘

Calling c = 4.0 * c

┌

┐

│ 81880.76 141862.80 71576.62 49071.00

│

│ 127237.84 246066.20 126146.34 83240.04

│

│ 75970.86 136651.88 121067.65 57132.02

│

Page 585

CS201 Introduction to Programming

│ 54179.64 95189.64 68494.16 46872.18

│

└

┘

Testing stream extraction

Testing stream insertion

Writing into the file d:\junk.txt

Reading from the file d:\junk.txt

┌

┐

│ 81880.76

0.81 0.62

0.00

│

│ 127237.84

0.20 0.35

0.04

│

│ 75970.86

0.88 0.66

0.02

│

│ 54179.65

0.65 0.16

0.18

│

└

┘

Press any key to continue . . .

Page 586

Table of Contents:
