CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 34

Reading Material

Deitel & Deitel - C++ How to Program

Chapter 8

Summary

Arrays of Objects

Dynamic Arrays of Objects

Overloading new and delete Operators

Example of Overloading new and delete as Non-members

Example of Overloading new and delete as Members

Overloading [] Operator to Create Arrays

Arrays of Objects

A class is a user-defined data type. Objects are instances of classes the way int variables

are instances of ints. Previously, we have worked with arrays of ints. Now, we are going

to work with arrays of objects.

The declaration of arrays of user-defined data types is identical to the array of primitive

data types.

Following is a snapshot of our veteran Date class:

/* Snapshot of Date class discussed in previous lectures */

class Date

{

private:

int day, month, year;

public:

/* Parameterless constructor, it is created by the compiler automatically when we

don't write it for any of our class. */

Page 432

CS201 Introduction to Programming

Date( )

{

cout << "\n Parameterless constructor called ...";

month = day = year = 0;

}

/* Parameterized constructor; has three ints as parameters. */

Date(int month, int day, int year)

{

cout << "\n Constructor with three int parameters called ...";

this->month = month;

this->day = day;

this->year = year;

}

~Date ( )

{

cout << "\n Destructor called ...";

}

...

};

Consider the example of declaring an array of 10 date objects of Date class. In this case,

the declaration of arrays will be as under:

Following is the declaration:

Date myDates [10] ;

With this line (when this line is executed), we are creating 10 new objects of Date class.

We know that a constructor is called whenever an object is created. For every object like

myDate[0], myDate[1],.... myDate[9], the constructor of the Date class is called.

Theimportant thing to know here is that which constructor of Date class is being called to

construct objects of the array myDates. As we are not doing any initialization of the array

objects explicitly, the default constructor (parameterless constructor) of the Date class is

called. Remember, the default constructor is defined by the C++ compiler automatically

for every class that has no parameterless constructor defined already. In our case of Date

class, we have defined a parameterless constructor, therefore, the compiler will not

generate default constructor automatically.

We can also initialize the array elements at the declaration time. This initialization is

similar to that done for native data types. For int array, we used to do initialization in the

following manner:

int array [10] = { 0, 1, 2, 3, 4, 5, 6, 7, 8, 9 } ;

Similarly, we initialize Date array while declaring it:

Page 433

CS201 Introduction to Programming

Date yourDate [3] = { Date(10, 24, 1980), Date(06, 14, 1985), Date(07, 09,1986) };

The above statement will call the parameterized constructor Date (int month, int day, int

year) of Date class to create three objects of myDate array. This parameterized

constructor carries out initialization of the objects data member (month, day, year) with

the values supplied as arguments to it.

It will be interesting to know, how the following statement works:

Date myDate [10] = { Date(09, 03, 1970), Date(08, 23, 1974) } ;

We are trying to declare an array of 10 Date objects while supplying only initialization

values for the first two elements. At first, we might be doubtful if the statement is

compiled successfully. Not only it compiles successfully but also does the initialization

of the first two objects ( myDate[0], myDate[1] ). What will happen to the remaining

objects in the array? Actually, all the 10 objects are created successfully by the above

statement. The parameterized constructor is called for the first two objects ( myDate[0],

myDate[1] ) and parameterless constructor is called for the remaining objects

(myDate[2], myDate[3], ..., myDate[9]).

You might have noticed that at the array initialization stage, we have explicitly called

parameterized constructor of Date for every object. We may specify only the argument

when a constructor with only one parameter is called.

/* A snapshot of String class discussed in previous lectures */

class String

{

private :

char *buf ;

public:

// Constructors

String ();

String( const char *s )

{

buf = new char [ 30 ];

strcpy (buf,s);

}

...

};

Page 434

CS201 Introduction to Programming

For example, in the above-mentioned case of String class, we have a constructor that is

accepting one argument of type char *. While writing our code, we can declare and

initialize an array of Strings as follows:

String message [10] = {

"First line of message\n",

"Second line of message\n",

String( "Third line of message\n"),

String( )

};

See the initializing arguments for first two objects i.e, (message[0], message[1]) in the

array. Here only one string is being passed. Therefore, for the first two objects,

constructor with one parameter of type char * of String class is called automatically. That

constructor is String ( char *

str ). For the third object (message[2]), the same

constructor with one char * as parameter is being called explicitly. For fourth object

(message[3]), parameterless constructor i.e., String ( ) is being called explicitly, though,

this was optional as parameterless constructor is called up automatically when no

initialization is made. As there is no explicit initialization for the remaining six objects,

the parameterless constructor is called up automatically.

Can we create arrays of objects dynamically? As usual, the answer is yes. Let's discuss it

in detail.

Dynamic Arrays of Objects

Consider the following statement:

String *text ;

text = new String [5] ;

In line 1, we have declared a pointer text of String type.

In line 2, we are creating an array of 5 objects of String type. This statement allocates

space for each object of the array, calls the parameterless constructor for each object and

starting address of the first object is assigned to the pointer text.

The important point to be noted here is that in line 2, we can't initialize objects because

there is no way to provide initializers for the elements of an array allocated with new.

The default constructor (parameterless constructor) is called for each element in the array

allocated with new. Remember, the default constructor for a class is generated by C++

compiler automatically if it is not defined already in the class definition.

To deallocate these arrays of objects, the delete operator is used in the same way as it is

used for the native data types.

There are few cautions that should be taken care of while performing these operations of

allocation and deallocation with arrays of objects.

Firstly, while deallocating an array allocated with new operator, it is important to tell the

compiler that an array of objects is being deleted. The brackets ( [] ) are written in our

delete statement after the delete keyword to inform the delete operator that it is going to

Page 435

CS201 Introduction to Programming

delete an array. The consequences of using the wrong syntax are serious. For example, if

we want to delete previously created array of five String objects using the following

statement:

delete text; // Incorrect syntax of deleting an array

The delete operator in this case will not be aware of deleting (deallocating) an array of

objects. This statement will call the destructor only for the object pointed by the text

pointer i.e. String[0] and deallocate the space allocated to this object. The requirement is

to call the destructor for all the objects inside the array and deallocate the space allocated

to all of these objects. But on account of the wrong syntax, only the first object is deleted

and the remaining four objects ( String[1], String[2], String[3], String[4] pointed by

text[1], text[2], text[3], text[4] respectively ) remain in the memory intact. The memory

space occupied by these four objects results in memory leak as the same program or any

other program on the same computer cannot use it unless it is deallocated.

Calling the destructor while destroying an object becomes essential when we have

allocated some memory in free store from inside the object (usually from within the

constructor).

To destroy an array of objects allocated on free store using the new operator, an array

equivalent of delete operator is used. The array equivalent of delete operator is to write

empty square brackets after the delete keyword (delete [] ). So the correct statement is:

delete [] text ;

This statement destroys the whole array properly. It calls destructor for each object inside

the array and deallocates the space allotted to each object. Actually, by looking at the

brackets ( [] ) after delete, the compiler generates code to determine the size of the array

at runtime and deallocate the whole array properly. Here, it will generate code to

deallocate an array of 5 objects of String type.

If we create an array of Date objects and want to delete them without specifying array

operator: It will look as under:

// Bad Technique: deleting an array of objects without []

// for a class that is not doing dynamic memory allocation internally

Date * ppointments;

appointments = new Date[10];

...

delete appointments; // Same as delete [] appointments;

Although, this is good to deallocate an array of objects without specifying array operator

([]) as there is no dynamic memory allocation occurring from inside the Date class. But

this is a bad practice. In future, the implementation of this class may change. It may

contain some dynamic memory allocation code. So it is always safer to use array operator

( [] ) to delete arrays.

Can we overload new and delete operators? Yes, it is possible to overload new and delete

operators to customize memory management. These operators can be overloaded in

global (non-member) scope and in class scope as member operators.

Page 436

CS201 Introduction to Programming

Overloading of new and delete Operators

Firstly, we should know what happens when we use new operator to create objects. The

memory space is allocated for the object and then its constructor is called. Similarly,

when we use delete operator with our objects, the destructor is called for the object before

deallocating the storage to the object.

When we overload new or delete operators, it can only lead to a change in the allocation

and deallocation part. The call to the constructor after allocating memory while using new

operator and call to the destructor before deallocating memory while using delete

operator will be there. These calls to constructors and destructors are controlled by the

language itself and these cannot be altered by the programmer.

One of the reasons of overloading new and delete operators can be their limited current

functionality. For example, we allocate space on free store using the new operator for

1000 ints. It will fail and return 0 if there is no contiguous space for 1000 ints in free

store. Rather the free store has become fragmented. The total available memory is much

more than 1000 ints , but in fragments. There is no contiguous segment of at least 1000

ints. The built-in new operator will fail to get the required space but we can overload our

own new operator to de-fragment the memory to get at least 1000 ints space. Similarly,

we can overload delete operator to deallocate memory.

In the embedded and real-time systems, a program may have to run for a very long time

with restricted resources. Such a system may also require that memory allocation always

takes the same amount of time. There is no allowance for heap exhaustion or

fragmentation. A custom memory allocator is the solution. Otherwise, programmers will

avoid using new and delete altogether in such cases and miss out on a valuable C++ asset.

There are also downsides of this overloading. If we overload new or delete operator at

global level, the corresponding built-in new or delete operator will not be visible to whole

of the program. Instead our globally written overloaded operator takes over its place all

over. Every call to new operator will use our provided new operator's implementation.

Even in the implementation of new operator, we cannot use the built-in new operator.

Nonetheless,when we overload new operator at a class level then this implementation of

new operator will be visible to only objects of this class. For all other types (excluding

this class) will still use the built-in new operator. For example, if we overload new

operator for our class Date then whenever we use new with Date, our overloaded

implementation is called.

Date* datePtr = new Date;

This statement will cause to call our overloaded new operator. However, when we use

new with any other type anywhere in our program as under:

int* intPtr = new int [10];

The built-in new operator is called. Therefore, it is safer to overload new and delete

operators for specific types instead of overloading it globally.

Page 437

CS201 Introduction to Programming

An important point to consider while overloading new operator is the return value when

the new operator fails to fulfill the request. Whether the operator function will return 0 or

throw an exception.

Following are the prototypes of the new and delete operators:

void * operator new ( size_t size ) ;

void operator delete ( void * ptr) ;

The new operator returns a void * besides accepting a parameter of whole numbers size_t.

This prototype will remain as it is while overloading new operator. In the implementation

of overloaded new operator, we may use calloc( ) or malloc( ) for memory allocation and

write some memory block's initialization code.

The delete operator returns nothing (void) and accepts a pointer of void * to the memory

block. So the same pointer that is returned by the new operator, is passed as an argument

to the delete operator. Remember, these rules apply to both if operators (new and delete)

are overloaded as member or non-member operators (as global operators). Importantly,

whenever we use these operators with classes, we must know their sequence of events

that is always there with these operators. For new operator, memory block is allocated

first before calling the constructor. For delete operator, destructor for the object is called

first and then the memory block is deallocated. Importantly, our overloaded operators of

new and delete only takes the part of allocation and deallocation respectively and calls to

constructors and destructors remain intact in the same sequence.

Because of this sequence of events, the behavior of these new and delete operators is

different from the built-in operators of new and delete. The overloaded new operator

returns void * when it is overloaded as non-member (global). However, it returns an

object pointer like the built-in new operator, when overloaded as a member function.

It is important to understand that these operator functions behave like static functions

when overloaded as member functions despite not being declared with static keyword.

static functions can access only the static data members that are available to the class

even before an object is created. As we already know that new operator is called to

construct objects, it has to be available before the object is constructed. Similarly, the

delete operator is called when the object has already been destructed by calling destructor

of the object.

Example of Overloading new and delete as Non-members

Suppose we want new to initialize the contents of a memory block to zero before

returning it. We can achieve this by writing the operator functions as follows:

/* The following program explains the customized new and delete operators */

#include <iostream.h>

#include <stdlib.h>

#include <stddef.h>

Page 438

CS201 Introduction to Programming

// ------------- Overloaded new operator

void * operator new ( size_t size )

{

void * rtn = calloc( 1, size ); // Calling calloc() to allocate and initialize memory

return rtn;

}

// ----------- Overloaded delete operator

void operator delete ( void * ptr )

{

free( ptr ); // Calling free() to deallocate memory

}

void main()

{

// Allocate a zero-filled array

int *ip = new int[10];

// Display the array

for ( int i = 0; i < 10; i ++ )

cout << " " << ip[i];

// Release the memory

delete [] ip;

}

The output of the program is as follows.

0000000000

Note that the new operator takes a parameter of type size_t. This parameter holds the size

of the object being allocated, and the compiler automatically sets its value whenever we

use new. Also note that the new operator returns a void pointer. Any new operator we

write must have this parameter and return type.

In this particular example, new calls the standard C function calloc to allocate memory

and initialize it to zero.

The delete operator takes a void pointer as a parameter. This parameter points to the

block to be deallocated. Also note that the delete operator has a void return type. Any

delete operator we write, must have this parameter and return type.

In this example, delete simply calls the standard C function free to deallocate the

memory.

Example of Overloading new and delete as Members

// Class-specific new and delete operators

Page 439

CS201 Introduction to Programming

#include <iostream.h>

#include <string.h>

#include <stddef.h>

const int MAXNAMES = 100;

class Name

{

public:

Name( const char *s ) { strncpy( name, s, 25 ); }

void display() const { cout << '\n' << name; }

void * operator new ( size_t size );

void operator delete( void * ptr );

~Name() {}; // do-nothing destructor

private:

char name[25];

};

// -------- Simple memory pool to handle fixed number of Names

char pool[MAXNAMES] [sizeof( Name )];

int inuse[MAXNAMES];

// -------- Overloaded new operator for the Name class

void * Name :: operator new( size_t size )

{

for( int p = 0; p < MAXNAMES; p++ )

if( !inuse[p] )

{

inuse[p] = 1;

return pool + p;

}

return 0;

}

// --------- Overloaded delete operator for the Names class

void Name :: operator delete( void *ptr )

{

inuse[((char *)ptr - pool[0]) / sizeof( Name )] = 0;

}

void main()

{

Name * directory[MAXNAMES];

char name[25];

for( int i = 0; i < MAXNAMES; i++ )

{

Page 440

CS201 Introduction to Programming

cout << "Enter name # " << i+1 << ": ";

cin >> name;

directory[i] = new Name( name );

}

for( i = 0; i < MAXNAMES; i++ )

{

directory[i]->display();

delete directory[i];

}

The output of the above program is given below.

Enter name # 1: ahmed

Enter name # 2: ali

Enter name # 3: jamil

Enter name # 4: huzaifa

Enter name # 5: arshad

Enter name # 6: umar

Enter name # 7: saleem

Enter name # 8: kamran

Enter name # 9: babar

Enter name # 10: wasim

ahmed

ali

jamil

huzaifa

arshad

umar

saleem

kamran

babar

wasim

This program declares a global array called pool that can store all the Name objects

expected. There is also an associated integer array called inuse, which contains true/false

flags that indicate whether the corresponding entry in the pool is in use.

When the statement directory[i] = new Name( name ) is executed, the compiler calls

the class's new operator. The new operator finds an unused entry in pool, marks it as used,

and returns its address. Then the compiler calls Name's constructor, which uses that

memory and initializes it with a character string. Finally, a pointer to the resulting object

is assigned to an entry in directory.

When the statement delete directory[i] is executed, the compiler calls Name 's destructor.

In this example, the destructor does nothing; it is defined only as a placeholder. Then the

Page 441

CS201 Introduction to Programming

compiler calls the class's delete operator. The delete operator finds the specified object's

location in the array and marks it as unused, so the space is available for subsequent

allocations.

Note that new is called before the constructor, and that delete is called after the

destructor.

Overloading [ ] Operator to Create Arrays

We know that if we overload operators new and delete for a class, those overloaded

operators are called whenever we create an object of that class. However, when we create

an array of those class objects, the global operator new( ) is called to allocate enough

storage for the array all at once, and the global operator delete( ) is called to release that

storage.

We can control the allocation of arrays of objects by overloading the special array

versions of operator new[ ] and operator delete[ ] for the class.

Previously, while employing global new operator to create an array of objects, we used to

tell the delete operator by using the array operator( [] ) to deallocate memory for an

array. But it is our responsibility to provide or to overload different type of new and

different type of delete.

There is a common problem when working with arrays. While traversing elements from

the array, we might run off the end of the array. This problem might not be caught by the

compiler. However, some latest compilers might be able to detect this.

int iarray [10] ;

for ( int i = 0; i < 100; i++ )

{

// Some code to manipulate array elements

}

If a variable is used in the condition of the loop instead of the constant value, the

probability of that error increases. Variable might have an entirely different value than

that anticipated by the programmer.

We can overcome this problem of array bound by overloading array operator `[]'. As

usual before overloading, we should be clear about the functionality or semantics of the

array operator. We use array operator to access an element of array. For example, when

we write iarray[5], we are accessing the 6th element inside array iarray. As we want to

check for validity of index every time, an array element is accessed. We can do this by

declaring the size of the array using #define and checking the index against the size every

time the array is accessed.

#define MAXNUM 1000

int iarray [MAXNUM];

Page 442

CS201 Introduction to Programming

Below is the syntax of declaration line of overloaded array operator:

int& operator [] ( int index ) ;

In the body of this operator, we can check whether the index is greater or equal to the

MAXNUM constant. If this is the case, the function may throw an exception. At the

moment, the function only displays an error message. If index is less than MAXNUM and

greater than or equal to zero, a reference to the value at the index location is returned.

Let's write a class IntArray and see the array manipulation.

The following example defines the IntArray class, where each object contains

an array of integers. This class overloads the [] operator to perform

range checking.

#include <iostream.h>

#include <string.h>

class IntArray

{

public:

IntArray( int len );

int getLength( ) const;

int & operator[] ( int index );

~IntArray( );

private:

int length;

int *aray;

};

// ------------ Constructor

IntArray :: IntArray( int len )

{

if( len > 0 )

{

length = len;

aray = new int[len];

// initialize contents of array to zero

memset( aray, 0, sizeof( int ) * len );

}

else

{

length = 0;

aray = 0;

}

Page 443

CS201 Introduction to Programming

}

// ------------ Function to return length

inline int IntArray :: getLength() const

{

return length;

}

// ------------ Overloaded subscript operator

// Returns a reference

int & IntArray :: operator []( int index )

{

static int dummy = 0;

if( (index = 0) &&

(index < length) )

return aray[index];

else

{

cout << "Error: index out of range.\n";

return dummy;

}

// ------------ Destructor

IntArray :: ~IntArray()

{

delete aray;

}

void main()

{

IntArray numbers( 10 );

int i;

for( i = 0; i < 10; i ++ )

numbers[i] = i;

// Use numbers[i] as lvalue

for( i = 0; i < 10; i++ )

cout << numbers[i] << '\n';

}

This program first declares numbers of type IntArray object that can hold ten integers.

Later, it assigns a value to each element in the array. Note that the array expression

appears on the left side of the assignment. This is legal as the operator[] function returns

a reference to an integer. This means the expression numbers[i] acts as an alias for an

element in the private array and it can be the recipient of an assignment statement. In this

situation, returning a reference is not simply more efficient but also necessary.

Page 444

CS201 Introduction to Programming

The operator[] function checks whether the specified index value is within range or not.

If it is within the range, the function returns a reference to the corresponding element in

the private array. If it is not, the function prints out an error message and returns a

reference to a static integer. This prevents out-of-range array references from overwriting

other regions of memory while causing unexpected program behavior.

Tips

The default constructor is defined by the C++ compiler automatically for every

class that has no default constructor (parameterless constructor) defined already.

The default constructor (parameterless constructor) is called for each element in

the array allocated with new.

The new operator returns a void *, accepts a parameter of type size_t.

The delete operator returns nothing (void) and accepts a pointer of void * to the

memory block.

With new operator function, a block of memory is allocated first and then

constructor is called.

With delete operator, destructor of the object is called first and then memory

block is deallocated.

By overloading new and delete operators, only allocation and deallocation part

can be overridden.

The same pointer that is returned by the new operator, is passed as an argument to

the delete operator. These rules apply to both, if operators (new and delete) are

overloaded as member or non-member operators (as global operators).

By overloading the array operator ( [] ), one can implement mechanism to check

for array bound.

Page 445

Table of Contents:
