CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 33

Reading Material

Deitel & Deitel - C++ How to Program

Chapter. 7, 8

7.5, 8.1, 8.2, 8.7, 8.9

Summary

22)

Operator Overloading

23)

Assignment Operator

24)

Example

25)

this Pointer

26)

Self Assignment

27)

Returning this Pointer from a Function

28)

Conversions

29)

Sample Program (conversion by constructor)

Operator Overloading

As earlier discussed, overloading of operators is carried out in classes on some occasions

to enable ourselves to write a code that looks simple and clean. Suppose, there is a class

and its two objects, say a and b, have been defined. Addition of these objects in the class

by writing a + b will mean that we are adding two different objects (objects are instance

of a class which is a user defined data type). We want our code to be simple and elegant.

In object base programming, more effort is made in class definitions, as classes are data

types that know how to manipulate themselves. These know how to add objects of their

own type together, how to display themselves and do many other manipulations. While

discussing date class in the previous lecture, we referred to many examples. In an

example, we tried to increment the `date'. The best way is to encapsulate it in the class

itself and not in the main program when we come around to use the date class.

Assignment Operator

At first, we ascertain whether there is need of an assignment operator or not? It is needed

when we are going to assign one object to the other, that means when we want to have

Page 417

CS201 Introduction to Programming

expression like a = b. C++ provides a default assignment operator. This operator does a

member-wise assignment. Let's say, we have in a structure of a class three integers and

two floats as data members. Now we take two objects of this class a and b and write a =

b. Here the first integer of a will have the value of first integer of b. The second will have

the value of second integer and so on. This means that it is a member-wise copy. The

default assignment operator does this. But what is to do if we want to do something more,

in some special cases?

Now let's define a String class. We will define it our self, without taking the built in

String class of C. We know that a string is nothing but an array of characters. So we

define our String class, with a data member buffer, it is a pointer to character and is

written as *buf i.e. a pointer to character (array). There are constructors and destructors of

the class. There is a member function length that returns the length of the string of the

calling object. Now we want an assignment operator for this class. Suppose we have a

constructor that allows placing a string into the buffer. It can be written in the main

program as under:

String s1 ( "This is a test" ) ;

Thus, an object of String has been created and initialized. The string "This is a test" has

been placed in its buffer. Obviously, the buffer will be large enough to hold this string as

defined in our constructor. We allocate the memory for the buffer by using new operator.

What happens if we have another String object, let's say s2, and want to write s2 = s1 ;

Here we know that the buffer is nothing but a pointer to a memory location. If it is an

array of characters, the name of the array is nothing but a pointer to the start of the

memory location. If default assignment operator is used here, the value of one pointer i.e.

buf of one object will be assigned to buf of the other object. It means there will be the

same address in the both objects. Suppose we delete the object s1, the destructor of this

object will free the allocated memory while giving it back to the free store. Now the buf

of s2 holds the address of memory, which actually has gone to free store, (by the

destructor of s1). It is no longer allocated, and thus creates a problem. Such problems are

faced often while using default assignment operator. To avoid such problems, we have to

write our own assignment operator.

Before going on into the string assignment operator, let's have a look on the addition

operator, which we have defined for strings. There is a point in it to discuss. When we

defined addition operator for strings, we talked about that what we have to do if we want

to add (concatenate) a string into the other string. There we had a simple structure i.e.

there is a string defined char buf with a space of 30 characters. If we have two string

objects and the strings are full in the both objects. Then how these will be added? Now

suppose for the moment that we are not doing memory allocation. We have a fixed string

buffer in the memory. It is important that the addition operator should perform an error

check. It should take length of first string , then the length of second string, before adding

them up, and check whether it is greater than the length defined in the String (i.e. 30 in

this case). If it is greater than that, we should provide it some logical behavior. If it is not

Page 418

CS201 Introduction to Programming

greater, then it should add the strings. Thus, it is important that we should do proper error

checking.

Now in the assignment operator, the problem here is that the buf, that we have defined,

should not point to the same memory location in two different objects of type String.

Each object should have its own space and value in the memory for its string. So when

we write a statement like s2 = s1, we want to make sure that at assignment time, the

addresses should not be assigned. But there should be proper space and the strings should

be copied there. Let's see how we can do this.

Now take a look on the code itself. It is quiet straight forward what we want to do is that

we are defining an assignment operator (i.e. =) for the String class. Remember that the

object on left side will call the = operator. If we write a statement like s2 = s1; s2 will be

the calling object and s1 will be passed to the = operator as an argument. So the data

structure of s2 i.e. buf is available without specifying any prefix. We have to access the

buf of s1 by writing s1.buf.

Suppose s2 has already a value. It means that if s2 has a value, its buffer has allocated

some space in the memory. Moreover, there is a character string in it. So to make an

assignment first empty that memory of s2 as we want to write something in that memory.

We do not know whether the value, we are going to write, is less or greater than the

already existing one. So the first statement is:

delete buf ;

Here we write buf without any prefix as it is buf of the calling object. Now this buffer is

free and needs new space. This space should be large enough so that it can hold the string

of s1. First we find the length of the string of s1 and then we use the new operator and

give it a value that is one more than the length of the buffer of s1. So we write it as:

buf = new char[length + 1] ;

where length is the length of s1. Here buf is without a prefix so it is the buf of object on

the left hand side i.e. s2. Now, when the buf of s2 has a valid memory address, we copy

the buf of s1 into the buf of s2 with the use of string copy function (strcpy). We write it

as:

strcpy ( buf, s1.buf ) ;.

Now the buf of string of s1 has been copied in the buf of s2 that are located at different

spaces in the memory. The advantage of it is that now if we delete one object s1 or s2, it

will not affect the other one. The complete code of this example is given below.

Example

/*This program defines the assignment operator. We copy the string of one object

Page 419

CS201 Introduction to Programming

into the string of other object using different spaces for both strings in the memory.

#include <iostream.h>

#include <string.h>

#include <stdlib.h>

// class definition

class String

{

private :

char *buf ;

public:

// constructors

String();

String( const char *s )

{

buf = new char [ 30 ];

strcpy (buf,s);

}

// display the string

void display ( )

{

cout << buf << endl ;

}

// getting the length of the string

int length ()const

{

return strlen(buf);

}

// overloading assignment operator

void operator = ( const String &other );

};

// ----------- Assignment operator

void String::operator = ( const String &other )

{

int length ;

length = other.length();

delete buf;

buf = new char [length + 1];

strcpy( buf, other.buf );

}

//the main program that uses the new String class with its assignment operator:

main()

{

Page 420

CS201 Introduction to Programming

String myString( "here's my string" );

cout << "My string is = " ;

myString.display();

cout << '\n';

String yourString( "here's your string" );

cout << "Your string is = " ;

yourString.display();

cout << '\n';

yourString = myString;

cout << "After assignment, your string is = " ;

yourString.display();

cout << '\n';

system ("pause");

}

Following is the output of the program.

My string is = here's my string

Your string is = here's your string

After assignment, your string is = here's my string

The above example is regarding the strings. Yet in general, this example pertains to all

classes in which we do memory manipulations. Whenever we use objects that allocate

memory, it is important that an assignment operator (=) should be defined for it.

Otherwise, the default operator will copy the values of addresses and pointers. The actual

values and memory allocation will not be done by it.

Let's go on and look what happens when we actually do this assignment? In the

assignment of integers, say we have three integers i, j and k with some values. It is quiet

legal to write as i = j ; By this ,we assign the value of j to i. After this we write k = i ; this

assigns the value of i to k. In C, we can write the above two assignment statements in one

line as follows

k=i=j;

This line means first the value of j is assigned to i and that value of i is assigned to k.

The mechanism that makes this work is that in C or C++ every expression itself has a

value. This value allows these chained assignment statements to work. For example,

when we write k = i = j ; then at first i = j is executed. The value at the left hand side of

this assignment statement is the value of the expression that is returned to the part `k ='

.This value is later assigned to k. Now take another example. Suppose we have the

following statement:

Page 421

CS201 Introduction to Programming

k = i = ++j ;

In this statement, we use the pre-increment operator, as the increment operator (++) is

written before j. This pre-increment operator will increment the value of j by 1 and this

new value will be assigned to i. It is pertinent to note that this way ++j returns a value

that is used in the statement. After this, the value of i is assigned to k. For integers, it is

ok. Now, how can we make this mechanism work with our String objects. We have three

String objects s1, s2 and s3. Let's say there is a value (a string ) in the buffer of s1. How

can we write s3 = s2 = s1;. We have written s2 = s1 in the previous example in

assignment operator. We notice that there is no return statement in the code of the

assignment operator. It means that operator actually returns nothing as it has a void return

type. If this function is not returning any thing then s3 = s2 = s1 ; cannot work. We make

this work with the help of this pointer.

this Pointer

Whenever an object calls a member function, the function implicitly gets a pointer from

the calling object. That pointer is known as this pointer. `this' is a key word. We cannot

use it as a variable name. `this' pointer is present in the function, referring to the calling

object. For example, if we have to refer a member, let's say buf, of our String class, we

can write it simply as:

buf ;

That means the buf of calling object is being considered. We can also write it as

this->buf ;

i.e. the data member of the object pointed by this pointer is being called. These ( buf and

this->buf ) are exactly the same. We can also write it in a third way as:

(*this).buf ;.

So these three statements are exactly equivalent. Normally we do not use the statements

written with this key word. We write simply buf to refer to the calling object.

In the statement (*this).buf ; The parentheses are necessary as we know that in object.buf

the binding of dot operator is stronger than the *. Without parentheses the object.buf is

resolved first and is dereferenced. So to dereference this pointer to get the object, we

enforced it by putting it in parentheses.

Self Assignment

Suppose, we have an integer `i. In the program, somewhere, we write i = i ; It's a do

nothing line which does nothing. It is not an error too. Now think about the String object,

we have a string s that has initialized to a string, say, `This is a test'. And then we write s

= s ; The behavior of equal operator that we have defined for the String object is that it, at

first deletes the buffer of the calling object. While writing s = s ; the assignment operator

Page 422

CS201 Introduction to Programming

frees the buffer of s. Later, it tries to take the buffer of the object on right hand side,

which already has been deleted and trying to allocate space and assign it to s. This is

known as self-assignment. Normally, self -assignment is not directly used in the

programs. But sometimes, it is needed. Suppose we have the address of an object in a

pointer. We write:

String s, *sptr ;

Now sptr is a pointer to a String while s is a String object. In the code of a program we

can write

sptr = &s ;

This statement assigns the address of s to the pointer sptr. Now some where in the

program we write s = *sptr ; that means we assign to s the object being pointed by sptr.

As sptr has the address of s , earlier assigned to it. This has the same effect as s = s ;. The

buffer of s will be deleted and the assignment will not be done. Thus, the program will

become unpredictable. So self-assignment is very dangerous especially at a time when we

have memory manipulation in a class. The String class is a classic example of it in which

we do memory allocation. To avoid this, in the equal operator (operator=), we should first

check whether the calling object (L.H.S.) and the object being gotten (R.H.S.) are the

same or not. So we can write the equal operator (operator=) as follows

void String::operator=( const String &other )

{

if( this == &other )

return;

delete buf;

length = other.length;

buf = new char[length + 1];

strcpy( buf, other.buf );

}

Here above, the statement if ( this == &other) checks that if the calling object (which is

referred by this) is the same as the object being called then do nothing and return as in

this case it is a self assignment. By doing this little change in our assignment operator, it

has become safe to use. So it is the first usage of this pointer that is a check against self

assignment.

Page 423

CS201 Introduction to Programming

Returning this Pointer From a Function

Now lets look at the second use of this pointer. We want to do the assignment as

s3 = s2 = s1 ;

In this statement the value of s2 = s1 is assigned to s3. So to do this it is necessary that

the assignment operator should return a value. Thus, our assignment operator will expand

so that it could return a value. The assignment operator, till by now copies the string on

right hand side to the left hand side. This means s2 = s1 ; can be done by this. Now we

want that this s2 should be assigned to s3, which can be done only if s2 = s1 returns s2

(an object). So we need to return a String object. Here becomes the use of this pointer, we

will write as

return *this ;

Here, in the assignment operator code this is referring to the calling object (i.e. s2 in this

case). So when we write return *this ; it means return the calling object ( object on

L.H.S.) as a value. Thus s3 gets the value of s2 by executing s3 = s2 where s2 is the

value returned by the assignment operator by s2 = s1; Thus the complete assignment

operator (i.e. operator= function) that returns a reference to an object will be written as

under

String &String::operator=( const String &other )

{

if( &other == this ) //if calling and passed objects are

return *this;

// same then do nothing and

return

delete buf;

Page 424

CS201 Introduction to Programming

length = other.length;

buf = new char[length + 1];

strcpy( buf, other.buf );

return *this;

}

Now, here the first line shows that this operator= function returns a reference to an

object of type String and this function takes a reference as an argument. The above

version of operator= function takes a reference as an argument. First of all it checks it

with the calling object to avoid self assignment. Then it deletes the buffer of calling

object and creates a new buffer large enough to hold the argument object. And then at the

last it returns the reference of the calling object by using this pointer.

With this version of the assignment operator ( operator= function) we can chain together

assignments of String objects like s3 = s2 = s1 ;

Actually, we have been using this pointer in chained statements of cout. For example, we

write

cout << a << b << c ;

Where a, b, and c are any data type. It works in the way that the stream of cout i.e. << is

left associative. It means first cout << a is executed and to further execute it, the second

<< should have cout on its left hand side. So here, in a way, in this operator overloading,

a reference to the calling object that is cout is being returned to the stream insertion <<.

Thus a reference of cout is returned, and (as a reference to cout is returned) the << sees a

cout on left hand side and thus the next << b is executed and it returns a reference to cout

and with this reference the next << c works. This all work is carried out by this pointer.

We have seen that value can be returned from a function with this pointer. We used it

with assignment operator. Lets consider our previous example of Date class. In that class

we defined increment operator, plus operator, plus equal operator, minus operator and

minus equal operator. Suppose we have Date objects d1, d2 and d3. When we write like

d2 = d1++ ; or d2 = d1 + 1 ; here we realize that the + operator and the ++ operator

should return a value. Similarly, other operators should also return a value. Now let's

consider the code of Date class. Now we have rewritten these operators. The difference in

code of these is not more than that now it returns a reference to an object of type Date.

There are two changes in the previous code. First is in the declaration line where we now

use & sign for the reference and we write it like

Date& Date::operator+=(int days)

We write this for the all operators (i.e. +, ++, - and -=). Then in the function definition we

return the reference of the left hand side Date object ( i.e. calling object) by writing

return *this ;

Now we can rewrite the operator+= of the Date class as follows.

The declaration line in the class definition will be as

Page 425

CS201 Introduction to Programming

Date& operator+=(int days);

And the function definition will be rewritten as the following.

Date& Date::operator+=(int days)

// return type reference to

object

{

for (int i=0; i < days; i++)

*this++;

return *this; // return reference to object

}

This concludes that whenever we are writing arithmetic operator and want that it can be

used in chained statements (compound statements) then we have to return a value. The

easiest and most convenient way of returning that value is by returning a reference to the

calling object. So, by now we can easily write the statements of date object, just like we

write for integers or floats. We can write

date2 = date1 + 1 ;

date2 = date1++ ;

and so on.

Conversions

Being in the C language, suppose we have an integer i and a float x. Now in the program

we write x = i ; As we know that the operations of int and float are different in the

memory. Therefore, we need to do some kind of conversion. The language automatically

converts i (int) to a float (or to whatever type is on the L.H.S.) and then does the

assignment.

Both C and C++ have a set of rules for converting one type to another. These rules are

used in the following situations

When assigning a value. For example, if you assign an integer to a variable of

type long, the compiler converts the integer to a long.

When performing an arithmetic operation. For example, if you add an integer and

floating-point value, the compiler converts the integer to a float before it performs

the

addition.

When passing an argument to a function; for example, if you pass an integer to a

function that expects a long.

When returning a value from a function; for example, if you return a float from a

function that has double as its return type.

In all of these situations, the compiler performs the conversion implicitly. We can make

the conversion explicit by using a cast expression.

Page 426

CS201 Introduction to Programming

Now the question arises that can we do conversion with objects of our own classes. The

answer is yes. If we go to the basic definition of a class it is nothing but a user defined

data type. As it is a user defined data type, we can also define conversion on it. When we

define a class in C++, we can specify the conversions that the compiler can apply when

we use instances of that class. We can define conversions between classes, or between a

class and a built-in type

There is an example of it. Suppose we have stored date in a serial number form. So now it

is not in the form of day, month and year but it is now a long integer. For example if we

start from January 1, 1900 then 111900 will be the day one, second January will be the

day 2, third January will be the day 3 and so on. Going on this way we reached in year

2000. There will be a serial number in year 2000. This will be a single long integer that

represents the number of days since a particular date. Now if we have a Date object

called d and an integer i. We can write d = i ; which means we want that i should go in

the serial part of d. This means convert the integer i into date object and then the value of

i should go into the serial number and then that object should be assigned to d. We can

make this conversion of Date object. We do this in the constructor of the class. We pass

the integer to the constructor, here convert it into a date, and the constructor then returns

a Date object. On the other hand, if there is no constructor then we can write conversion

function. We have used the conversion operator with cast. The way of casting is that we

write the name of the cast (type to which we want to convert) before the name of

variable. Thus if we have to write x = i ; where x is a float and i is an integer then we

write it with conversion function as x = (float) i ; The (float) will be the conversion

operator. Normally this conversion is done by default but sometimes we have to force it.

Now we want to write a conversion operator, which converts an integer to a Date object.

(here Date is not our old class, it's a new one). We can write a conversion function. This

function will be a member of the Date class. This function will return nothing, as it is a

conversion function. The syntax of this function will be Date () that means now this is a

conversion function.

In the body of this function we can write code of our own. Thus we can define the

operator, and it will work like that we write within the parentheses the name of the

conversion operator. The conversion functions are quiet interesting. They allow us to

manipulate objects of different classes. For example, we have two classes one is a truck

and other is a car. We want to convert the car to a truck. Here we can write a conversion

function, which says take a car convert it into a truck and then assign it to an object of

class truck.

Sample Program (conversion by constructor)

Lets take a look at an example in which the conversion functions are being used. There is

a class Fraction. Lets talk why we called it Fraction class. Suppose we have an

assignment

double x = 1/3 ;

Page 427

CS201 Introduction to Programming

When we store 1/3 in the computer memory, it will be stored as a double precision

number. There is a double precision division of 1 by 3 and the answer 0.33333... is

stored. Here the number of 3s depends upon the space in the memory for a double

precision number. That value is assigned to a double variable. What happens if we

multiply that double variable by 3, that means we write 3 * x; where x was equal to 1/3

(0.33333...). The answer will be 0.99999..., whatever the number of digits was. The

problem here is that the answer of 3 * 1 / 3 is 1 and not 0.99999. This problem occurs,

when we want to represent the numbers exactly. The fraction class is the class in which

we provide numerator and denominator to the object and it stores them separately. It will

always keep them as an integer numerator and an integer denominator and we can do all

kinds of arithmetic with it. Now if 1 and 3 are stored separately as numerator and

denominator, how we can add them to some other fraction. We have enough tools at our

disposal. One of which is that we can overload the addition operator. We can add 1/3 and

2/5, the result of which is another fraction i.e. numerator and denominator. In this way we

have no worries of round off errors, the truncation and conversions of int and floats.

Considering the Fraction class we can think of a constructor which takes an integer and

converts it into a fraction. We do not want that as a fraction there should be some value

divided by zero. So we define the default constructor that takes two integers, one for

numerator and one for denominator. We provide a default value for the denominator that

is 1. It means that now we can construct a fraction by passing it a single integer, in which

case it will be represented as a fraction with the passed integer as a numerator and the

default vale i.e. 1 as the denominator. If we have a fraction object f and we write f = 3;

Then automatically this constructor (i.e. we defined) will be called which takes a single

integer as an argument. An object of type fraction will be created and the assignment will

be carried out. In a way, this is nothing more than a conversion operation. That is a

conversion of an integer into a fraction. Thus a constructor that takes only one parameter

is considered a conversion function; it specifies a conversion from the type of the

parameter to the type of the class.

So we can write a conversion function or we can use a constructor of single argument for

conversion operation. We cannot use both, we have to write one or the other. Be careful

about this. We don't use conversion functions often but sometimes it is useful to write

them. The conversion operators are useful for defining an implicit conversion from the

class to a class whose source code we don't have access to. For example, if we want a

conversion from our class to a class that resides within a library, we cannot define a

single-argument constructor for that class. Instead, we must use a conversion operator.

It makes our code easier and cleaner to maintain. It is important that pay more attention

while defining a class. A well-defined class will make their use easy in the programming.

Following is the code of the example stated above.

/* This program defines a class Fraction which stores numerator and

denominator of a fractional number separately. It also overloads the

addition operator for adding the fractional numbers so that exact results

can be obtained.

Page 428

CS201 Introduction to Programming

#include <stdlib.h>

#include <math.h>

#include <iostream.h>

// class definition

class Fraction

{

public:

Fraction();

Fraction( long num, long den );

void display() const;

Fraction operator+( const Fraction &second ) const;

private:

static long gcf( long first, long second );

long numerator, denominator;

};

// ----------- Default constructor

Fraction::Fraction()

{

numerator = 0;

denominator = 1;

}

// ----------- Constructor

Fraction::Fraction( long num, long den )

{

int factor;

if( den == 0 )

den = 1;

numerator = num;

denominator = den;

if( den < 0 )

{

numerator = -numerator;

denominator = -denominator;

}

factor = gcf( num, den );

if( factor > 1 )

{

numerator /= factor;

denominator /= factor;

}

// ----------- Function to print a Fraction

Page 429

CS201 Introduction to Programming

void Fraction::display() const

{

cout << numerator << '/' << denominator;

}

// ----------- Overloaded + operator

Fraction Fraction::operator+( const Fraction &second ) const

{

long factor, mult1, mult2;

factor = gcf( denominator, second.denominator );

mult1 = denominator / factor;

mult2 = second.denominator / factor;

return Fraction( numerator * mult2 + second.numerator * mult1,

denominator * mult2 );

}

// ----------- Greatest common factor

// computed using iterative version of Euclid's algorithm

long Fraction::gcf( long first, long second )

{

int temp;

first = labs( first );

second = labs( second );

while( second > 0 )

{

temp = first % second;

first = second;

second = temp;

}

return first;

}

//main program

void main()

{

Fraction a, b( 23, 11 ), c( 2, 3 );

a = b + c;

a.display();

cout << '\n';

system("pause");

}

The output of the program is as follows

91/33

Page 430

CS201 Introduction to Programming

Here is an example from the real world. What happens if we are dealing with currency?

The banks deal with currency by using computer programs. These programs maintain the

accounts by keeping the track of transactions and manipulating deposits and with drawls

of money. Suppose the bank declares that this year the profit ratio is 3.76 %. Now if the

program calculates the profit as 3.67 % of the balance, will it be exactly in rupees and

paisas or in dollars and cents? Normally, all the currencies have two decimal digits after

decimal point. Whenever we apply some kind of rates in percentage the result may

become in three or four decimal places. The banks cannot afford that the result of 90

paisas added to 9 rupees and 10 paisas become 10 rupees and 1 paisa. They have to

accurate arithmetic. So they do not rely on programs that use something like double

precisions to represent currencies. They would have rather written in the program to treat

it as a string. Thus 9 is a string, 10 is a string and the program should define string

addition such that the result of addition of the strings .10 and .90 should be 1.00. Thus,

there are many things that happen in real world that force us as the programmer to

program the things differently. So we do not use native data types.

The COBOL, COmmon Business Oriented Language has a facility that we can represent

the decimal numbers exactly. Internally it (the language) keeps them as strings in the

memory. There is no artificial computer representation of numbers. Now a day, the

languages provide us the facility by which we can define a data type according to a

specific requirement, as we defined fraction to store numerator and denominator

separately. By using this fraction data type, we never loose precision in arithmetic. The

same thing applies to the object like currency, where we can store the whole number part

and the fractional part both as separate integers and never loose accuracy. But whenever

we get into these classes, it is our responsibility to start writing all of the operators that

are required to make a complete class.

Page 431

Table of Contents:
