CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 30

Reading Material

Deitel & Deitel - C++ How to Program

Chapter. 3

3.17

Summary

13)

Reference data type

14)

Example 1

15)

Difference Between References and Pointers

16)

Dangling References

17)

Example 2

Reference data type

Out today's topic is about references. This is a very important topic from the C++

prospective. Today we will see what is a reference, how can we use them. C++ defines a

thing by which we can create an alias or synonym of any data type. That synonym is

called reference. How do we declare a reference? We declare it by using & operator.

Now it is little bit confusing. We have used & as address-of operator and here we are

using it for referencing. We will write as

int &i;

It means that i is a reference to an integer. Keep that statement very clear in your mind. It

is easier to read from right to left. A reference is a synonym. If we want to give two

names to same thing then we use reference. Reference has to be initialized when it is

declared. Suppose if we have an integer as i and we want to give it second name. We will

reference it with j as:

int &j = i;

We declared an integer reference and initialized it. Now j is another name for i. Does it

mean that it creates a new variable? No, its not creating a new variable. Its just a new

Page 378

CS201 Introduction to Programming

name for the variable which already exists. So if we try to manipulate i and j individually,

we will came to know that we have been manipulating the same number.

Lets take a look at a very simple example. In the main function we take an int variable i

and then we write int &j = i; Now we assign some value (say 123) to i. Now display the

value of i using cout. It will show its value as 123. Display the value of j using cout. We

will not use & operator to display the value of j. We will only use it at the time of

declaration and later we don't need it. The & is not reference operator rather it acts as

reference declarator. The value of j will be same as of i i.e. 123.

int i;

int &j = i;

i = 123;

cout << "\n The value of i = " << i;

cout << "\n The value of j = " << j;

Now what will happen if we increment i as i++; and print the values of i and j. You will

note that the value of i and j both have been incremented. We have only incremented i but

j is automatically incremented. The reason is that both are referring to the same location

in the memory. j is just another name for i.

What is the benefit of reference and where can we use it? References are synonyms and

they are not restricted to int's, we can have reference of any data type. We can also take

reference of a class. We wrote a function to show the use of pointers. That function is

used to interchange two numbers. If we have two integers x and y. We want that x should

contain the value of y and y should get the value of x. One way of doing this is in the

main program i.e.

int x = 10;

int y = 20;

int tmp;

tmp = y;

y = x;

x = tmp;

The values of both x and y have been interchanged. We can also swap two numbers using

a function. Suppose we have a swap function as swap(int x, int y) and we write the above

code in it, what will happen? Nothing will be changed in the calling program. The reason

is call by value. So when the main function calls the function swap(x, y). The values of x

and y will be passed to the swap function. The swap function will get the copies of these

variables. The changes made by the swap function have no effect on the original

variables. Swap function does interchange the values but that change was local to the

swap function. It did not effect anything in the main program. The values of x and y in the

main program remains same.

Page 379

CS201 Introduction to Programming

We said that to execute actual swap function we have to call the function by reference.

How we did that. We did not send x and y rather we sent the addresses of x and y. We

used address operator to get the addresses. In the main function we call swap function as

swap(&x, &y); In this case we passed the addresses of two integers. The prototype of the

swap function is swap(int*, int*) which means that swap function is expecting pointers of

two integers. Then we swap the values of i and j using the * notations. It works and in the

main program, the values are interchanged. This was a clumsy way. We can use reference

in this case with lot of ease. Let us see how we can do that. Lets rewrite the swap

function using references. The prototype will be as:

swap (int &i, int &j);

Swap is a function that is expecting i as a reference to an integer and the second argument

is j which is also a reference to an integer. The calling function has to pass references.

What will we write in the body of the function? Here comes the elegance of the

references. In the body we will treat i and j as they are ordinary integers. We will take a

temporary integer and interchange the values of i and j.

swap (int &i, int &j)

{

int temp;

temp = x;

x = y;

y = temp;

}

In the main program, you will see that the values of two integers have been interchange.

What is the way to call this function? In the main program, we will call this function as

swap(x, y). Its an ordinary call but the function is expecting addresses which is

automatically done. The memory locations of the integers are passed and the function is

interchanging the original numbers. This is one beautiful example in which we avoided

all the cumbersome of pointer notation. What is the downfall of this? As nothing comes

for free. In this case when you are reading the main function you will see swap (x, y)

which seems a call by value. This is a rule of C/C++ that when we pass two variables to

some function they are passed by values. You will have to look for the definition of swap

function to realize that it is not call by value but is call by reference. Second thing is if we

have another swap function, which is receiving two integers. Can we define two

functions as swap(int x, int y) and swap(int &x, int &y)? One function is receiving two

integers and other is receiving two references of integers. Can we do that? Types are

different so we can overload. Unfortunately not, in the main function the way to call both

functions is same i.e. swap(x, y). How does the compiler know that which functions is

being called? There is no way for the compiler to find out. Therefore there is an

ambiguity and that is not allowed. The only thing to realize is the side effect. Side effects

are critical to take care of whenever you are doing call by reference. Here in this example

we do want that two numbers should be interchanged. There may be some situation

where we want to send the references and don't want that original data should be

Page 380

CS201 Introduction to Programming

affected. These situations arise when we want to pass a large data structure to a function.

To understand this we have to understand how the function call executes. We have

discussed it before, now lets recap it. In real world, suppose I am reading a book. While

reading I notice a word which I think I have to look up. I stop reading, markup the page

and then look that word in dictionary or encyclopedia. While reading the definition of

that word I look another special word which I need to lookup. I put a marker here and go

for looking the definition of that new word. Eventually I understand all the words I need

to look up. Now I want to go to the point at which I left the study. I close the dictionary

or encyclopedia and goes back to the original book which I was studying. Now I

understand all the words in my study and continue the study from the point where I left.

If we think about it, it was a function call. We were doing some work, suddenly we call a

function and stop that work and execution went to the function. When the execution of

the function came to end, we came back to our calling function and continued with it.

Computers do the same work with stack. So when the program comes back from the

function it should know the point at which it lefts. We supposed here a word to look up,

now consider that it was a paragraph or essay I am going to look up. Now to lookup that

essay in other books I have to take the entire paragraph or essay with me to that book.

Think about the stack. On the stack, the original condition of the program (state) has

saved. Now we put our essay or paragraph on it and then opened the other book and

searched the book for this essay. In this way, we want to explain that the thing we passed

to the function from the main was itself a huge/large thing (as we resemble it with

paragraph or essay). So there was a big overhead in writing that thing out into a

temporary space in memory and then picking it up and looking it up.

We can make this process more efficient. The issue is that in this example we do not want

to change the paragraph or essay which we are going to look up. We only want to look it

up. We want only to use it but don't want to change its words. Unfortunately the baggage

that comes with doing this is that first make a copy of this (essay) then go with this copy

and when the work with it ends, leave (through away) the copy and start the original

work. This is inefficient.

But if we took the reference of that essay and passed the address of it and went to the

function to look it up. There is a danger that comes with the address, that is while looking

up that essay I underlined different words and when I came back to original book I saw

that these line marks were also there. Thus we passed something by value rather we

passed something by reference. By passing the reference, we actually pass the original.

Think about it in another way. We go to a library and said the librarian to issue us a book,

which we want to take home for study. Suppose, that book is the only one copy available

in the library (or in the world). The librarian will not issue the book. Because it is the

only copy available in the world. He does not want to issue this original book to someone

as someone can marks different lines with a pen and thus can damage the original book.

The librarian will do that he will take a photocopy of that book and issue it. Making a

photocopy of the book and then take the book is a bothersome work.

Here we don't want to damage the book. We just want to read it. But can I somehow take

the original book? Put it in a special polythene bag and give it to you in such a way that

Page 381

CS201 Introduction to Programming

you can read it without damaging it. By doing this we get efficiency but danger is still

there. This is actually a call by reference. We have the reference (the original book). If

we do something to the original book, the library book will be damaged. Can we

somehow prevent this from happening? And also have the efficiency of not having to

make a copy.

Now come back to the computer world. Suppose we have a data structure. There is a

string of 1000 characters in it. We want to pass that data structure to a function. If we

pass it by value which is sake, the original structure will not be affected. We first will

copy that string of 1000 characters at some place, which is normally made on the stack.

Then the function will be called. The function will take the copy of these 1000 characters

and will manipulate it. Then it will give the control back to the caller program and will

destroy that copy of string. For efficiency, we want that instead of making a copy of this

string, its reference should be written. We have been doing this with pointers and

addresses. So we write there the address and pass it to the function. How we can prevent

the side effects? There may be these side effects with references. So be very careful while

using references with function calls.

Can we do something to prevent any changes? The way we do it is by using the const key

word. When we write the const key word with the reference, it means that it is a reference

to some thing but we cannot change it. Now we have an elegant mechanism. We can get

the efficiency of call by reference instead of placing a string of 1000 characters on the

stack, we just put the address of the string i.e. reference on the stack. In the prototype of

the function, it is mentioned that it takes a const. This is a reference that may be to a char,

int, double or whatever but it is a const. The function cannot change it. The function gets

the address, does its work with it but cannot change the original value. Thus, we can have

an efficiency of a call by reference and a safety of a call by value. To implement all this

we could have used the key word const with an address operator or a pointer but we can

use a reference that is an elegant way. There is no need in the function to dereference a

reference by using * etc, they are used as ordinary variable names.

Example 1

Now let us have an example. Here we defined a structure bigone that has a string of 1000

characters. Now we want to call a function by three different ways to manipulate this

string. The first way is the call by value, which is a default mechanism, second is the call

by reference using pointers and the third way is call by reference using reference

variables. We declared the prototypes of these functions. Here we declared three

functions. The first function is valfunc which uses a call by value. We simply wrote the

value of the structure. The function prototype is as under.

void valfunc( bigone v1 );

The second function is ptrfunc in which we used call by reference using pointers. We

passed a pointer to the structure to this function. The prototype of it is as follows.

void ptrfunc( const bigone *p1 );

The third function is reffunc which uses the way of calling by reference using references.

We wrote its prototype as

Page 382

CS201 Introduction to Programming

void reffunc( const bigone &r1 );

Note that we wrote & sign with the name of the variable in the prototype of the function,

we will not write it in the call of the function.

In the main program, we called these function. The call to the valfunc is a simple one we

just passed the name of the object of the structure i.e. v1. As the function is called by

using the call by value the manipulation in the function will not affect the original value.

We wrote it as:

valfunc ( bo );

In this call a copy of bo is placed on the stack and the function uses that copy.

Next we called the function ptrfunc. We passed the address of the structure to ptrfunc by

using the & operator. Here we are talking about the function call (not function prototype)

and in function call we write ptrfunc ( &bo ) ; which means we passed the address of bo

(the object of structure) to the function. The efficiency here is that it writes only the

address of the object to the stack instead of writing the whole object.

The call to the third function reffunc is simple and looks like the call by value. There is

no operator used in this call it is simply written as:

reffunc ( bo ) ;

Here we cannot overload the valfunc and reffunc, their names must be different.

Otherwise the calls look same and become ambiguous.

The pointer call and reference call are sending the references to the original structures so

these are dangerous. If we want to prevent the function from changing that then we

should define the function by const keyword with its argument pointer or reference. Then

the function can not modify the original value, it can only read it. So by this we get the

efficiency of the call by reference and the safety of the call by value.

The complete code of the example is given here.

// Reference parameters for reducing overhead

// and eliminating pointer notation

#include <iostream.h>

// A big structure

struct bigone

{

int serno;

char text[1000]; // A lot of chars

} bo = {123, "This is a BIG structure"};

// Three functions that have the structure as a parameter

void valfunc( bigone v1 );

// Call by value

void ptrfunc( const bigone *p1 );

// Call by pointer

void reffunc( const bigone &r1 );

// Call by reference

Page 383

CS201 Introduction to Programming

// main program

void main()

{

valfunc( bo );

// Passing the variable itself

ptrfunc( &bo );

// Passing the address of the variable

reffunc( bo );

// Passing a reference to the variable

}

//Function definitions

// Pass by value

void valfunc( bigone v1 )

{

cout << '\n' << v1.serno;

cout << '\n' << v1.text;

}

// Pass by pointer

void ptrfunc( const bigone *p1 )

{

cout << '\n' << p1->serno; // Pointer notation

cout << '\n' << p1->text;

}

// Pass by reference

void reffunc( const bigone &r1 )

{

cout << '\n' << r1.serno;

// Reference notation

cout << '\n' << r1.text;

}

Following is the output of the above program.

123

This is a BIG structure

123

This is a BIG structure

123

This is a BIG structure

Difference Between References and Pointers

The reference in a way keeps the address of the data entity. But it is not really an address

it is a synonym, it is a different name for the entity. We have to initialize the reference

when we declare it. It has to point to some existing data type or data value. In other

words, a reference cannot be NULL. So immediately, when we define a reference, we

have to declare it. This rule does not apply to functions. When we are writing the

argument list of a function and say that it will get a reference argument, here it is not

Page 384

CS201 Introduction to Programming

needed to initialize the reference. This reference will be passed by the calling function.

But in the main program if we declare a reference then we have to initialize it. When a

reference is initialized, we cannot reassign any other value to it. For example, we have ref

that is a reference to an integer. In the program we write the line int &ref = j ;

Here j is an integer which has already been declared. So we have declared a reference and

initialized it immediately. Suppose we have an other integer k. We cannot write in the

program ahead as ref = k; Once a reference has defined, it always will refer to the same

integer location as j. So it will always be pointing to the same memory location. We can

prove this by printing out the address of the integer variable and the address of the

reference that points to it.

In programming, normally we do not have a need to create a reference variable to point to

another data member or data variable that exists, because creating synonym that means

two names for the same thing, in a way is confusing. We don't want that somewhere in

the program we are using i (actual name of variable) and somewhere ref (reference

variable) for manipulating the same data variable. The main usage of it is to implement

the call by reference through an elegant and clean interface. So reference variables are

mostly used in function calls.

The difference between pointers and references is that we can do arithmetic with pointers.

We can increment, decrement and reassign a pointer. This cannot be done with

references. We cannot increment, decrement or reassign references.

References as Return Values

A function itself can return a reference. The syntax of declaration of such a function will

be as under.

datatype& function_name (parameter list)

Suppose we have a function myfunc that returns the reference to an integer. The

declaration of it will be as:

int & myfunc() ;

Dangling Reference

The functions that return reference have danger with it. The danger is that when we return

a value from such a function, that value will be reference to some memory location.

Suppose that memory location was a local variable in the function which means we

declare a variable like int x; in the function and then returns its reference. Now when the

function returns, x dies (i.e. goes out of scope). It does not exist outside the function. But

we have sent the reference of that dead variable to the calling function. In other words,

the calling program now has a reference variable that points to nowhere, as the thing

(data variable) to which it points does not exist. This is called a dangling reference. So be

careful while using a function that returns a reference. To prevent dangling reference the

functions returning reference should be used with global variables. The function will

return a reference to the global variable that exists throughout the program and thus there

will be no danger of dangling reference. It can be used with static variables too. Once the

Page 385

CS201 Introduction to Programming

static variables are created, they exist for the life of the program. They do not die. So

returning their reference is all right.

So, never return a reference to a local variable otherwise, there will be a dangling

reference. Some compilers will catch it but the most will not. The reason is that the

function that is returning a reference has defined separately. It does not know whether the

reference is to a global or local variable, because we can do many manipulations in it and

then return it. But normally compilers will catch this type of error.

Example 2

Let us look at an example of functions returning references. First, we declare a global

variable that is an integer called myNum and say it is zero. Then we declare a function

num that returns a reference to an integer. This function returns myNum, the global

variable, in the form of reference. So now when there will be a function call, the return of

the function will be a reference to the global variable called myNum. Now we can write

the main function. Here we write myNum = 100 ; This assigns a value 100 to the global

variable. Next we write

int i ;

i = num () ;

Now a reference to myNum is returned. We would want to assign a reference to a

reference but we can use it as an ordinary variable. Thus that value is assigned to i.

Now look at the next line which says num () = 200 ; We know that the left hand side of

the assignment operator can only be a simple variable name, what we called l-value (left

hand side value). It cannot be an expression, or a function call. But here in our program

the function call is on left hand side of the assignment. Is it valid? In this case it is valid,

because this function called num is returning a reference to a global variable. If it returns

a reference, it means it is a synonym. It is like writing myNum = 200 ; The example

shows that it can be done but it is confusing and is a bad idea. We can put a reference

returning function on the left hand side of an assignment statement but it is confusing and

bad idea.

Following is the code of the example.

/*Besides passing parameters to a function, references can also be used to return values

from a function */

#include <iostream.h>

int myNum = 0;

// Global variable

int& num()

{

return myNum;

}

void main()

Page 386

CS201 Introduction to Programming

{

int i;

i = num();

cout << " The value of i = " << i << endl;

cout << " The value of myNum = " << myNum << endl;

num() = 200; // mynum set to 200

cout << " After assignment the value of myNum = " << myNum << endl;

}

Following is the output of the program.

The value of myNum = 0

After assignment the value of myNum = 200

The references are useful in implementing a call by reference in an efficient fashion and

writing the function very elegantly without using dereference operators.

We use & sign for declaring a reference. In the program code, how do we find out that it

is a reference or an address is being taken? The simple rule is that if in the declaration

line there is reference symbol (& sign) with the variable name then that is a reference

declaration. These will be like int &i, float &f and char &c etc. In the code whenever we

have simply &i, it means we are taking address. So it's a simple rule that when, in the

code, we see a data type followed by & sign, it's a reference. And when the & sign is

being used in the code with a variable name then it is the address of the variable.

In C and C++ every statement itself returns a value. It means a statement itself is a value.

Normally the value is the value of left hand side. So when we write a = b; the value of b

is assigned to a and the value of a becomes the value of the entire statement. Therefore

when we write a = b = c ; first b = c executes and the value of c is assigned to b. Since b

= c is a statement and this statement has the value of b. Now a takes the value of this

statement (which happened to be b). So a = b also works. Similarly a + b + c also works

in the same way that the value of c is added to b and then this result is added to a.

What happens when we write cout << "The value of integer is " << i << endl ;

Here first extreme right part will be executed and then the next one and so on or the other

way. On the screen the "The value of integer is" displayed first and then the value of the i

and in the end new line. So it is moving from left to right. When cout gets the first part

i.e. "The value of integer is", this is a C statement. When this will be executed, the

sentence "The value of integer is" is displayed on the screen. But what will be its value?

That has to do something with the next << part and is needed with this << sign. We know

that we need cout on the left side of << sign. So actually what happened is when the first

part of the statement is executed. When the statement cout << " The value of integer is"

executed cout is returned. The next part is << i and it becomes cout << i; the value of i is

printed and as a result of the statement cout is returned again which encounters with <<

endl; and a new line is inserted on the screen and cout is returned as a result of the

statement execution. The return of the complete statement remains cout. The cout is

stream, it does not have value per se. The reference to the stream is returned. The same

Page 387

CS201 Introduction to Programming

reference which we have discussed today. The same thing applies to operators like +, -, *,

/. This will also apply to = (assignment operator) and so on. We will be using lot of

reference variables there.

Summary

We have learned a new data type i.e. reference data type. We said that reference is

synonym or alias for another type of data. Take int's synonym or double's synonym. In

other words, it's the second name of a variable. Then we talk about some do's and dont's.

Normally we do not use two names for the same variable. It's a bad idea and leads to

confusing the programmer. Then we found the most useful part of using a reference. If

we have to implement call by reference with function then using the prototype of the

function which is expecting references and it leads to clean programming. You use the

names of the arguments without using any dereferencing operator like *. The most useful

part is implementing the call by reference. Then we looked at the difference of pointers

and references. We cannot increment the reference variable. Arithmetic is not allowed

with references but most importantly, reference variables must be initialized when they

are declared. This is import. We can declare pointers and later can assign it some value.

The use of reference with classes will be covered later. We have also seen a preview of

the usage of references. In that preview we have learned new things that every statement

itself has some value and that value is returned. Use it or not it's a different issue. We call

a function on a single line like f(x); may be f(x) returns some value and we did not use it.

Not a problem. Similarly if we say a = b; this statement itself have some value whether

we use it or not. Then we see how the cout statement is executed. Every part of the

statement returns some value which is the reference to cout itself. It becomes the

reference to the stream.

How these references will be declared and used? We will cover this with operator

overloading. Try to write some programs using references and implement call by

reference using references instead of pointers.

Tips

The use of reference data type is the implementation of call by reference in an

elegant way.

We cannot do arithmetic with references like pointers.

Reference variables must be initialized immediately when they are declared.

To avoid dangling reference, don't return the reference of a local variable from a

function.

In functions that return reference, use global or static variables.

The reference data types are used as ordinary variables without any dereference

operator.

Page 388

Table of Contents:
