CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 29

Reading Material

Deitel & Deitel - C++ How to Program

Chapter. 7

7.4

Summary

Friend functions

Declaration of Friend Functions

Sample Program 1

Sample Program 2

10)

Sample Program 3

11)

Friend Classes

12)

Summary

Friend functions

Today, we are going to discuss a very interesting subject i.e. Friend Functions. We will

see what is the relationship of friendship with our object-based programming. Before

going into details of the subject, it is better to have a fresh look on the definition of

`class'. `Class is a user defined data type'. The `class' provides encapsulation facility to

the programmer. We can gather data at some place and some function that manipulates

that data. In the previous lecture, two keywords, `private' and `public' were introduced.

We define data members as `private' that are visible only from inside the class and

hidden from the outside. However, `public data member functions' is the interface of the

class available for outside world. Objects are accessed by these functions that can

manipulate the private data of the class. We cannot access the private data of the class

directly. This concept of data encapsulation and data hiding is very important concept in

software engineering. It allows us to separate the interface from the implementation of

the class i.e. we can hide how we have done the task and make visible what to do. It is

critically important for large and complex systems. Sometimes, a need may arise to

access the private data of the class from outside.

Let's talk about the concept of friendship. What you see on the screen during the lecture

is the picture of the instructor. This is the public interface. That is all you know. What is

Page 363

CS201 Introduction to Programming

inside his mind you never know. It is all `private'. The instructor has access to his own

mind and feelings. But you do not have access to that. Do you know any human being

who has access to your mind and feelings? What we call that human being. He is known

as friend. Normally other people don't know about our thoughts. Only friends know

about it. Friends have access to the inner thoughts and have inner knowledge of a friend.

Can we apply this definition to objects?

The friend functions of a class have access to the private data members of class. Despite

being a good thing, there is possibility of vulnerability. We are opening our thoughts,

inside view for somebody else. Without having 100% trust, it will be risky to make our

thoughts and feelings public. We want that our private data is accessible to someone

outside, not public for everybody. Otherwise, the data encapsulation and data-hiding

concept will be violated. We keep the data members private and declare some specific

functions that are not member of the class but friend of the class. As friends, they have

access to the inside data structure of the class despite not being members.

Declaration of Friend functions

To declare a friend function, we can put it anywhere in the class. According to the

definition of the friend functions, they have access to the private data members of the

class. These can also access the private utility functions of the class. The question arises

where we should put the friend function whether in the private or public part of the class.

Be sure that friend is a very strong statement. It is too strong to be affected by public or

private. We can put it anywhere in the class. But remember that friend functions are not

member of the class. So their definition will be always outside the class. However, the

prototype of the function will be written in the class. We use the keyword `friend' before

the prototype of the function.

friend

return_type

friend_function_name(int, char);

If we have a class, suppose `Date' and want to declare a friend function of this class. In

the definition of the class, we will write the friend function's prototype with the keyword

`friend'. To access the private data, friend function will need the object. Therefore,

usually in the parameter list of friend function, we provide the object of that class.

Normally, the programmers work this way. As the friend function is not affected by the

private or public keyword, so we can declare it anywhere inside the class definition.

Programmers generally declare the friend functions at the top of the class definition. So,

the friend functions are declared at the start of the class definition, followed by the

private data and public data. This is a guideline. You can develop your own style. We

normally make a header file of the class definition and implementation in the other file.

The member functions are defined in the implementation file and compiled to get an

object file. We declare the friend function in the class definition that is in the header file.

Let's go back to the definition of the friendship. I can declare you my friend and tell you

about my inner thoughts and feelings. But it does not work both ways. In other words,

friendship is granted, never taken. So, a class can declare a friend function and someone

from outside the class cannot declare itself friend of a class. This is also an important

Page 364

CS201 Introduction to Programming

concept. If someone from outside the class can declare itself friend of the class, then by

definition that external function would have access to the private data member of the

class. But this will negate the concept of the encapsulation and data hiding. It does not

work this way. A function cannot declare itself friend of a class. Rather, a class has to

declare itself that a function is friend of the class or not. So the class declares a friend

function. These functions can not declare themselves friend of a class from outside. Once,

the friend functions are declared and the class is compiled, no one from outside cannot

make his function friend of your class. Outside functions can only view the interface of

the class.

Let's summaries this concept. Friend functions are not member functions of the class.

The class itself declares the friend functions. The prototype of friend functions is written

in the definition of the class with the keyword `friend'. These functions have access to the

private data member of the class, which means they have access to everything in the

class. Normally we pass an object of the class to these functions in the argument list so

that it can manipulate the data of the object. Style is up to you but normally we write

friend functions at the top of the class definition.

Sample Program 1

We have a class with a single private data member of type int. We have declared a friend

function that accepts an object of that class as argument. We call that friend function

increment. This friend function will increment the private integer data member of the

class. We will give another integer argument to that function that will be added to the

data member. The name of the private data member is, for example, topSecret. Let's call

the class as myClass. In the interface, we write display() function that will print the value

of the topSecret. The constructor of the class will initialize the topSecret with 100. The

definition of the friend function will be outside the class. We do not write the keyword

`friend' with the function definition. It will be a void function, having two arguments as:

void increment(myClass *a, int i)

{

a->topSecret += i;

}

Now the increment function has added the value of i to the private data member i.e.

topSecret of the passed object. In the main function, we declare an object of type myClass

as myClass x; On the execution of this statement, an object will be created in the

memory. A copy of its data members and functions will also be created besides calling a

constructor. The place for topSecret will be reserved in the memory while the constructor

will assign the value 100 to the variable topSecret. Now if we say x.display(); it will

display the value of the topSecret i.e.100. After this, we call the increment friend function

and pass it &x and 10 as arguments. Again we call the display function of myClass as

x.display(); Now the value of the topSecret will be 110. That means the `topSecret' which

was the private data member of the class has been changed by the increment friend

function. Be sure that the increment function is not the member function of the class. It is

an ordinary function sitting outside the class but class itself has declared it as friend. So

Page 365

CS201 Introduction to Programming

now the friend function has access to the private data member and has the ability to

change it. Try to write an ordinary function (not friend function) `increment2' which tries

to manipulate the topSecret. See what will happen? The compiler will give an error that a

non- member function can not access the private data of the class.

Here is the complete code of the program.

A sample program showing the use of friend function,

which access the private data member of the class.

#include <iostream.h>

class myClass

{

friend void increment(myClass *, int);

private:

int topSecret;

public:

void display() { cout << "\n The value of the topSecret is " <<

topSecret; }

myClass();

};

// constructor of the class

myClass::myClass()

{

topSecret = 100;

}

// Friend function definition

void increment(myClass *a, int i)

{

a->topSecret += i; // Modify private data

}

// showing the use of the friend function

void main()

{

myClass x;

x.display();

increment(&x, 10);

x.display();

}

Page 366

CS201 Introduction to Programming

The output of the program is:

The value of the topSecret is 100

The value of the topSecret is 110

Sample Program 2

Let's consider some complex example. We have two classes-myClass1 and myClass2.

Both classes have one private data member of type int i.e. int topSecret; Now we want to

add the values of private data members of both the classes and display it on the screen.

topSecret is a private data member of both the classes. One class can not see inside the

other class. myClass1 and myClass2 are both separate classes. We need a function sitting

outside the classes but can access the private data members of both the classes. Let's call

the function as addBoth. This function will add the value of topSecret of myClass1 to

topSecret of myClass2 and display the result on the screen. We need a function that can

look inside both classes i.e. friend of both classes. We know that classes have to declare a

function as friend.

The arguments of addBoth function will contain myClass1 and myClass2. In the

definition of the myClass1, we will write the prototype of addBoth function as:

friend void addBoth(myClass1, myClass2);

Can we write this line in the definition of the myClass1? We know that if we refer some

function as f(x) and the function f() is not defined or declared before this, the compiler

will give an error that function f() is not defined. So we at least declare the function

before main() so that compiler successfully compile the program. So there was

declaration of the function before its being called. Now same problem is in our friend

function prototype. We are referring both classes in it and our program does not know

anything about myClass2. We can tackle this problem by writing a line before the

definition of the class myClass1 as:

class myClass2;

It will declare that myClass2 is a class having its definition somewhere else. It is the same

as we declare functions before main. After writing that statement, we can refer myClass2

in our code. The definition of the class myClass1 will be as:

class myClass1

{

private:

int topSecret;

public:

void display() { cout << "\nThe value of the topSecret is " <<

topSecret; }

myClass1();

Page 367

CS201 Introduction to Programming

friend void addBoth(myClass1, myClass2);

};

myClass1::myClass1()

{

topSecret = 100;

}

The definition of myClass2 is also similar to myClass1.

class myClass2

{

private:

int topSecret;

public:

void display() { cout << "\nThe value of the topSecret is " <<

topSecret; }

myClass2();

friend void addBoth(myClass1, myClass2);

};

myClass2::myClass2()

{

topSecret = 200;

}

You must have noted that we have used the topSecret data member in both the classes. Is

it legal? Yes it is. There is no problem as one topSecret is part of myClass1 and other is

part of myClass2. Will there be same problem while declaring the friend function in

myClass2, i.e. myClass1 is not known? No. We have already defined the myClass1. We

have to declare a class only at a time when we are referring to it and it is not defined yet.

In the main program, we will take the object of myClass1 i.e. myClass1 a; The object will

be created in the memory and constructor is called to initialize the data members. The

value of topSecret will be 100. In the next line, we will take the object of myClass2 as

myClass2 b; Now b is an object of class myClass2. The memory will be reserved for it. It

has its own data members and the value of topSecret will be 200, initialized by the

constructor. Now we will display the values of both data members, using display()

function.

Now we will call the addBoth(a, b); As this function is friend of both classes, so it has

access to both the classes and their private data members. The definition of addBoth

function will be as under:

Page 368

CS201 Introduction to Programming

void addBoth(myClass1 a, myClass2 b)

{

cout << "\nThe value of topSecret in the myClass1 object is " <<

a.topSecret;

cout << "\nThe value of topSecret in the myClass2 object is " <<

b.topSecret;

cout << "\nThe sum of values of topSecret in myClass1 and

myClass2 is " <<

a.topSecret + b.topSecret;

}

This is an interesting function. Despite not being the member of any class, it can access

the data of both the classes. This function is friend of both the classes.

Here is the complete code of the program.

A sample program showing the use of friend function,

which access the private data members of two classes.

#include <iostream.h>

class myClass2; // declaring the class for the friend function in myClass1

// definition of the myClass1

class myClass1

{

// private data members. Hidden

private:

int topSecret;

// interface of the class

public:

void display() { cout << "\nThe value of the topSecret is " << topSecret; }

myClass1();

// friend function

friend void addBoth(myClass1, myClass2);

};

// definition of the constructor.

myClass1::myClass1()

{

topSecret = 100;

}

// Definition of the myClass2

Page 369

CS201 Introduction to Programming

class myClass2

{

// private data members. Hidden

private:

int topSecret;

// interface of the class

public:

void display() { cout << "\nThe value of the topSecret is " << topSecret; }

myClass2();

// friend function

friend void addBoth(myClass1, myClass2);

};

// definition of the constructor.

myClass2::myClass2()

{

topSecret = 200;

}

// The definition of the friend function which is adding the topSecret data member of both

the classes.

void addBoth(myClass1 a, myClass2 b)

{

cout << "\nThe value of topSecret in the myClass1 object is " <<

a.topSecret;

cout << "\nThe value of topSecret in the myClass2 object is " <<

b.topSecret;

cout << "\nThe sum of values of topSecret in myClass1 and

myClass2 is " << a.topSecret + b.topSecret;

}

// main program

void main()

{

// declaring the objects and displaying the values

myClass1 a;

myClass2 b;

a.display();

b.display();

// calling friend function and passing the objects of both the classes

addBoth(a, b);

}

Page 370

CS201 Introduction to Programming

The output of the program is;

The value of the topSecret is 100

The value of the topSecret is 200

The value of topSecret in the myClass1 object is 100

The value of topSecret in the myClass2 object is 200

The sum of values of topSecret in myClass1 and myClass2 is 300

The classes have defined and declared this function addBoth to be a friend. In each class,

we have declared it as a friend function. This function cannot declare itself a friend

function for these classes from outside. So be careful about this as a class declares its

friend functions. A function out side the class cannot declare itself a friend of the class.

The friend functions are not used very often.

Sample Program 3

Now we can expand our previous example. We can define functions subBoth, mulBoth

and divBoth as friend functions of the class, in addition of addBoth function. These friend

functions can manipulate the data members of the class.

Following is the code of the example that shows the usage of friend functions.

/* The following program demonstrate the declaration and uses of friend functions of a

class

We set values in the constructors of the classes. The program prompts the user to enter a

choice of addition, subtraction, multiplication or division. And then performs the

appropriate

operation by using the friend functions.

#include <iostream.h>

#include <stdlib.h>

class myClass2;

// declaration of the myClass2 for the friend functions

class myClass1

{

private:

float value ;

public:

myClass1 ( )

{

value = 200 ;

}

// friend functions

friend float addBoth ( myClass1, myClass2 ) ;

Page 371

CS201 Introduction to Programming

friend float subBoth ( myClass1, myClass2 ) ;

friend float mulBoth ( myClass1, myClass2 ) ;

friend float divBoth ( myClass1, myClass2 ) ;

};

class myClass2

{

private:

float value ;

public:

myClass2 ( )

{

value = 100 ;

}

// friend functions

friend float addBoth ( myClass1 , myClass2 ) ;

friend float subBoth ( myClass1 , myClass2 ) ;

friend float mulBoth ( myClass1 , myClass2 ) ;

friend float divBoth ( myClass1 , myClass2 ) ;

};

void main ( )

{

myClass1 myClass1Obj ;

//create an object of class myClass1

myClass2 myClass2Obj ;

//create an object of class myClass2

char choice;

cout << "Please enter one of the operator +, -, /, * " << "followed by Enter " <<

endl;

cin >> choice;

if ( choice == '+' )

{

cout << "The sum is : " << addBoth(myClass1Obj , myClass2Obj) << endl;

}

else if ( choice == '-' )

{

cout << "The difference is : " << subBoth(myClass1Obj , myClass2Obj) << endl;

}

else if ( choice == '*' )

{

cout << "The multiplication is : " << mulBoth(myClass1Obj , myClass2Obj) <<

endl;

}

else if ( choice == '/' )

Page 372

CS201 Introduction to Programming

{

cout << "The division is : " << divBoth(myClass1Obj , myClass2Obj) << endl;

}

else

{

cout << "Enter a valid choice next time. The program is terminating" << endl;

}

system ( "PAUSE" ) ;

}

float addBoth ( myClass1 object1 , myClass2 object2 )

{

return ( object1.value + object2.value ) ;

}

float subBoth ( myClass1 object1 , myClass2 object2 )

{

return ( object1.value - object2.value ) ;

}

float mulBoth ( myClass1 object1 , myClass2 object2 )

{

return ( object1.value * object2.value ) ;

}

float divBoth ( myClass1 object1 , myClass2 object2 )

{

return ( object1.value / object2.value ) ;

}

Following is the output of the program.

Please enter one of the operator +, -, /, * followed by Enter

The multiplication is : 20000

Friend Classes

We have seen that a class can define friend functions for itself. Similarly a class can be

declared as a friend class of the other class. In that case, the function of a class gets

complete access to the data members and functions of the other class. So it is an

interesting expansion of the definition that not only the functions but also a class can be a

friend of the other class. The syntax of declaring a friend class is that within the class

definition, we write the keyword friend with the name of the class. It is going to be a

friend class. i.e. friend class-name;

We can also write the word class after the keyword friend and before the class name as

friend class class-name ;

Page 373

CS201 Introduction to Programming

Now let's take another example of a class. Suppose, we have classes ClassOne and

OtherClass. We want to make OtherClass a friend class of the ClassOne. So we declare

OtherClass a friend class in the definition of the ClassOne as following.

class ClassOne

{

friend OtherClass ;

private:

//here we write the data members of ClassOne

};

The line

friend OtherClass ;

can also be written as

friend class OtherClass ;

The line friend OtherCalss; explains that OtherClass is a friend of ClassOne. If

OtherClass is the friend of ClassOne, all the functions of OtherClass will have access to

all the inside part of ClassOne.

The following code segment shows the declaration of friend class. It shows that

OtherClass is a friend of ClassOne so it has access to the private data of ClassOne.

class ClassOne

{

friend class OtherClass;

private:

int topSecret;

};

class OtherClass

{

public:

void change( ClassOne co )

};

void OtherClass::change( ClassOne co )

{

co.topSecret++; // Can access private data of class one

}

The friend keyword provides access in one direction only. This means that while

OtherClass is a friend of ClassOne, the reverse is not true. Here ClassOne declares that

OtherClass is my friend. But it does not work the other way. It does not mean that

ClassOne has access to the inside data members and methods of OtherClass. Thus, it is a

one way relationship i.e. the OtherClass can look into ClassOne, but ClassOne cannot

Page 374

CS201 Introduction to Programming

look inside OtherClass. If we want a two-way relationship, OtherClass will have to

declare ClassOne as a friend class, resulting in a complete two-way relationship.

Like functions, a class cannot declare itself a friend of some other class. A class can

declare its friend classes in its declaration and cannot be a friend of other classes by

declaring itself their friend. In the above example, ClassOne declares that OtherClass is

my friend class. So otherClass can access all the data members and methods (private,

public or utility functions) of ClassOne. It does not (and cannot) declare that I

(ClassOne) am a friend class of OtherClass. So ClassOne has no access to private data

members and methods of OtherClass. It can access these only if OtherClass declares

ClassOne as its friend. This means that by using the keyword friend, a class gives rights

of accessing its data members and methods to other classes and does not get the rights to

access other classes.

By declaring friend functions and classes, we negate the concept of data hiding and data

encapsulation and show the internal structure of the class to the friends. But the good

thing in it is that a class declares its friends while the other functions or classes cannot

look inside the class. The disadvantage of friend classes is that if we declare such a

relationship of friendship for two classes, this will become a pair of classes. To explain it

we go back to the concept of separating the interface and implementation. In case of

change in the implementation of ClassOne, the private data structure will also change.

For example, at first we have an integer variable int i; and later, we need two more

variables and we write it as int j, k, l; As the implementation of ClassOne has now

changed, the functions of OtherClass that wanted to manipulate the members of

ClassOne will not work now. It is critically important that friend classes should be

declared very carefully. When is it necessary? This can be understood by an example

from mathematics. We have straight line in math. The equation of straight line is: y = mx

+ c. Here m is the slope of line i.e. the angle which the line makes with x-axis. And c is

the intercept at y-axis. So if we have to define a straight line, there is need of two

numbers i.e. m and c. Now if we have to define a class StraightLine, the private data of it

will be double m, c; or let's use the names which are self explanatory like double slope,

intercept; And then in the class, there will be the methods of the class. We can write it as

calss StraightLine

{

//some methods

private:

double slope, intercept ;

};

Now we can also have another class quadratic that also belongs to mathematics. Suppose,

we have a parabola, the equation of which is y= ax2 + bx + c. Where a, b and c, for the

time being, are real constants. To define this quadratic equation as class, we have to

define the three coefficients a, b and c. The statement will be as under:

class Quadratic

{

//some methods

Page 375

CS201 Introduction to Programming

private:

double a, b, c ;

};

Now we have two classes i.e. StraightLine and Quadratic. In a mathematical problem,

when we have given a parabola (a quadratic equation) and a straight line (straight line

equation) and are asked to find the point at which the straight line intersects the parabola.

To solve it, we setup equations and solve them simultaneously and find out the result,

which may be in three forms. Firstly, there is the line that does not intersect the parabola.

The second is that it intersects the parabola at one point (i.e. it is a tangential line) and

third may be that the line intersects the parabola at two points.

When we setup these equations, we come to know that here the constants m, c(of straight

line), a, b and c of quadratic equation are being used. So from a programming perspective

if we had an object l1 of type StraighLine and an object q1 of type quadratic. And wanted

to find the intersection of l1 with q1. Now here is a situation where we need either a

friend function of both classes, so that it can manipulate the data of both classes, or need

to declare both classes as friend classes of each other and then write their methods to find

the intersection. Similarly we can have many other examples in which a class may need

to look into the other class. But it is not some thing to be done all the time. It should be

done only when necessary. Use of friend functions is normally a better idea. Using friend

classes means that both the classes are linked with each other. If the code in any one of

the class is modified i.e. its implementation is changed, we have to recompile both the

classes. Due to change in one class, the other class also needs to be changed,

necessitating the compilation of both the classes.

So we have lost the principle of separating the interface from the implementation. Now

let's talk about the limitations of this friendship business. Firstly, there is no transitive

dependency in friend declarations. Suppose I say student A is my friend and being a

friend he knows my thoughts and ideas. Now the student A says "student B is my friend"

i.e. student B knows thoughts and ideas of student A. Does it mean that student B is also

my friend? Does student B knows my thoughts and ideas? The answer is no. As I have

not declared student B a friend of mine, so he (student B) does not know about my

thoughts and ideas. The same applies to the friend definition for classes. The friendship is

not transitive. It is not like `A is a friend of B and B is a friend of C, therefore A is a

friend of C`. It does not work. A has to specifically declare `B is my friend and C is my

friend' to make B and C friends of him. There is no transitive dependency in friend

declarations.

Secondly, I can declare you to be my friend. This means I have unveiled my thoughts and

ideas to you. But I cannot get your thoughts and ideas unless you declare me a friend of

yours. So there is no association, which means A saying B is my friend does not imply in

any way that A is a friend of B. Here B is a friend of A. But B has to declare `A' its

friend. Thus the friend keyword produces one-way relationship.

Page 376

CS201 Introduction to Programming

Summary

The concept of classes allows us to separate implementation from interface.

A class is a user defined data type. In a class, we declare private data members and utility

functions so that they cannot be access from outside. Similarly, we declare some parts of

the class public that become the interface for the class and can be accessed from the

outside. These interface methods or public methods can manipulate the data of the class.

This is the encapsulation and data hiding.

We have the concept of friend functions. By declaring an external function as a friend

function, that function gets the complete access to the inner structure of the class

including all private data. When classes need to be interactive, these must be declared

friends of each other. Thus we have the concept of friend classes. The use of friend

function and class is a useful feature that sometimes we need to use. But we should use it

very sparingly and carefully as it basically negates the concepts of encapsulation and data

hiding.

The principles of friendship of functions and classes are that the friendship is granted, not

taken. So a class declares its friend functions and friend classes. If a class declares

another class as a friend, it is not always reciprocal. So declaration and granting of a right

is one way. The owner of the right grants it. So the class itself grants the privilege of

access to outsider functions or to other classes. It is not transitive. It does not go `A is a

friend of B and B is a friend of C therefore A is a friend of C'. It does not work that way.

It is restricted to a one-step relationship. If A is a friend of B, and B is a friend of C. If A

wants C to be a friend, it has to declare, "C is my friend".

Page 377

Table of Contents:
