CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 25

Reading Material

Deitel & Deitel - C++ How to Program

Chapter 3

3.16, 3.18, 3.20

Summary

Lecture Overview

History of C/C++

Structured Programming

Limitations of Structured Programming

Default Function Arguments

Example of Default Function Arguments

Placement of Variable Declarations

Example of Placement of Variable Declarations

Inline Functions

Example of Inline Functions versus Macros

Function Overloading

Example of Function Overloading

Lecture Overview

From this lecture we are starting exciting topics, which we have been talking about many

times in previous lectures. Until now, we have been discussing about the traditional

programming following top down approach using C/C++. By and large we have been

using C language, although, we also used few C++ functions like C++ I/O using cin and

cout instead of standard functions of C i.e., printf() and scanf(). Today and in

subsequent lectures, we will talk about C++ and its features. Note that we are not

covering Object Oriented Programming here as it is a separate subject.

Page 308

CS201 Introduction to Programming

History of C/C++

C language was developed by scientists of Bell Labs in 1970s. It is very lean and mean

language, very concise but with lot of power. C conquered the programming world and

took it by storm. Major operating systems e.g., Unix was written in C language.

Going briefly into the history of languages, after the Machine Language (language of 0s

and 1s), the Assembly Language was developed. Using Assembly language,

programmers could use some symbolic codes, which were easier to understand by novice

people. After that high-level languages like COBOL, FORTRAN were developed. These

languages were more English like and as a result easier to understand for us as human

beings. This was the age of spaghetti code where programs were not properly structured

and their branches were growing in every direction. As a result, it is difficult o read,

understand and manage. These problems lead to the innovation of structured

programming where a problem was broken into smaller parts. But this approach also had

limits. In order to understand those limits, we will see what is structured programming

first before going into its limitations detail.

Structured Programming

We have learned so far, C is a language where programs are composed of functions.

Basically, a problem is broken into small pieces or modules and each small piece

corresponds to a function. This was the top-down structured programming approach.

We have already discussed few rules of structured programming, which are still valid and

will remain valid in the future. Let's reiterate those:

- Divide and Conquer; one should not write very long functions. If a function is

getting longer than two or three pages or screens then it is divided into smaller,

concise and well-defined tasks. Later each task becomes a function.

- Inside the functions, Single Entry Single Exit rule should be tried to obey as much

as possible. This rule is very important for readability and useful in managing

programs. Even if the developer itself tries to use the same function after sometime, it

would be easier for him to read his own code if he has followed the rules properly.

We try to reuse our code as much as possible. It is likely that we may reuse our code

or functions. That reuse might happen quite after sometime. Never think that your

written code will not change or will not be used again.

- You should comment your programs well. Your comments are only not used by

other people but by yourself also, therefore, you should write useful and lots of

comments. At least comment, what the function does, what are its parameters and

what does it return back. The comments should be meaningful and useful about the

processing of the function.

You should use the principles of structured programming as the basis of your programs.

Page 309

CS201 Introduction to Programming

Limitations of Structured Programming

When we design a functional program, the data it requires to process, is an entity that lies

outside of the program. We take care of the function rather than the data it is going to

process. When the problems became complex, we came to know that we can't leave the

data outside. Somehow the data processed by the program should be present inside it as a

part of it. As a result, a new thought process became prevalent that instead of the program

driven by functions, a program should be driven by data. As an example, while working

with our Word processors when we want a text to be bold, firstly that text is selected and

then we ask Word to make it bold. Notice in this example the data became first and then

the function to make it bold. This is programming driven by data. This approach

originated the Object Oriented Programming.

In the early 1980s a scientist in Bell Labs Bejarne Stroustrup started working in

enhancing C language to overcome the shortcomings of structured approach. This

evolution of C language firstly known to be C with Classes, eventually called C++. Then

the follow-up version of C++ is the Java language. Some people call Java as C plus plus

minus. This is not exactly true but the evolution has been the same way.

C++ does not contain the concept of Classes only but some other features were also

introduced. We will talk about those features before we talk about the classes.

Default Function Arguments

While writing and calling functions, you might have noticed that sometimes the

parameter values remain the same for most of the calls and others keep on changing. For

example, we have a function:

power( long x, int n )

Where x is the number to take power of and n is the power to which x is required to be

raised.

Suppose while using this function you came to know that 90% of the calls are for

squaring the number x in your problem domain. Then this is the case where default

function arguments can play their role. When we find that there are some parameters of a

function that by and large are passed the same value. Then we start using default function

arguments for those parameters.

The default value of a parameter is provided inside the function prototype or function

definition. For example, we could declare the default function arguments for a function

while declaring or defining it. Below is the definition of a very simple function f() that is

called most of the times with parameters values of i as 1 and x as 10.5 most of the times

then by we can give default values to the parameters as:

void f ( int i = 1, double x = 10.5 )

{

cout << "The value of i is: " << i;

cout << "The value of x is: " << x;

}

Page 310

CS201 Introduction to Programming

Now this function can be called 0, 1 or 2 arguments.

Suppose we call this function as:

f();

See we have called the function f() without any parameters, although, it has two

parameters. It is perfectly all right and this is the utility of default function arguments.

What do you think about the output. Think about it and then see the output below:

The value of i is: 1

The value of x is: 10.5

In the above call, no argument is passed, therefore, both the parameters will use their

default values.

Now if we call this function as:

f(2);

In this case, the first passed in argument is assigned to the first variable (left most

variable) i and the variable x takes its default value. In this case the output of the function

will be as under:

The value of i is: 2

The value of x is: 10.5

The important point here is that your passed in argument is passed to the first parameter

(the left most parameter). The first passed in value is assigned to the first parameter,

second passed in value is assigned to the second parameter and so on. The value 2 cannot

be assigned to the variable x unless a value is explicitly passed to the variable i. See the

call below:

f(1, 2);

The output of the function will be as under:

The value of i is: 1

The value of x is: 2

Note that even the passed in value to the variable i is the same as its default value, still to

pass some value to the variable x, variable i is explicitly assigned a value.

While calling function, the arguments are assigned to the parameters from left to right.

There is no luxury or feature to use the default value for the first parameter and passed in

value for the second parameter. Therefore, it is important to keep in mind that the

parameters with default values on left cannot be left out but it is possible for the

parameter with default values on right side.

Because of this rule of assignment of values to the parameters, while writing functions,

the default values are written from right to left. For example, in the above example of

function f(), if the default value is to be provided to the variable x only then it should be

on the left side as under:

void f( int i, double x = 10.5 )

{

Page 311

CS201 Introduction to Programming

// Display statements

}

If we switch the parameters that the variable x with default value becomes the first

parameter as under:

void f( double x = 10.5, int i )

{

// Display statements

}

Now we cannot use the default value of the variable x, instead we will have to supply

both of the arguments. Remember, whenever you want to use default values inside a

function, the parameters with default values should be on the extreme right of the

parameter list.

Example of Default Function Arguments

// A program with default arguments in a function prototype

#include <iostream.h>

void show( int = 1, float = 2.3, long = 4 );

void main()

{

show();

// All three arguments default

show( 5 );

// Provide 1st argument

show( 6, 7.8 );

// Provide 1st and 2nd

show( 9, 10.11, 12L ); // Provide all three argument

}

void show( int first, float second, long third )

{

cout << "\nfirst = " << first;

cout << ", second = " << second;

cout << ", third = " << third;

}

The output of the program is:

first = 1, second = 2.3, third = 4

first = 5, second = 2.3, third = 4

first = 6, second = 7.8, third = 4

first = 9, second = 10.11, third = 12

Page 312

CS201 Introduction to Programming

Placement of Variable Declarations

This has to do with the declaration of the variables inside the code. In C language, all the

variables are declared at the top of the function or code block and then we can use them

later on in the code. We have already relaxed this rule, now, we will discuss it explicitly.

One of the enhancements in C++ over C is that a variable can be declared anywhere in

the function. The philosophy of this enhancement is that a variables is declared just

before it is actually used in the code. That will increase readability of the code.

It is not hard and fast direction but it is a tip of good programming practice. One can still

declare variables at the start of the program, function or code block. It is a matter of style

and convenience. One should be consistent in his/her style.

We should be clear about implications of declaring variables at different locations. For

example, we declare a variable i as under:

{

// code block

int i;

...

}

The variable i is declared inside the code block in the beginning of it. i is visible inside

the code block but after the closing brace of this code block, i cannot be used. Be aware

of this, whenever you declare a variable inside a block, the variable i is alive inside that

code block. Outside of that code block, it is no more there and it can not referenced any

further. Compiler will report an error if it is tried to access outside that code block.

You must have seen in your books many times, a for loop is written in the following

manner:

for (int i = 0; condition; increment/decrement statements )

{

...

}

i = 500;

// Valid statement and there is no error

The variable i is declared with the for loop statement and it is used immediately. We

should be clear about two points here. Firstly, the variable i is declared outside of the for

loop opening brace, therefore, it is also visible after the closing brace of the for loop.

So the above declaration of i can also be made as under:

int i;

for ( i = 0; condition; increment/decrement statements)

{

...

}

Page 313

CS201 Introduction to Programming

This approach is bit more clear and readable as it clearly declares the variable i outside

the for statement. But again, it is a matter of style and personal preference, both

approaches are correct.

Example of Placement of Variables Declarations

// Variable declaration placement

#include <iostream.h>

void main()

{

// int lineno;

for( int lineno = 0; lineno < 3; lineno++ )

{

int temp = 22;

cout << "\nThis is line number " << lineno

<< " and temp is " << temp;

}

if( lineno == 4 ) // lineno still accessible

cout << "\nOops";

// Cannot access temp

}

The output of the program is:

This is line number 0 and temp is 22

This is line number 1 and temp is 22

This is line number 2 and temp is 22

Inline Functions

This is also one of the facilities provided by C++ over C. In our previous lectures, we

discussed and wrote macros few macros like max and circlearea.

While using macros, we use the name of the macro in our program. Before the

compilation process starts the macro names are replaced by the preprocessor with their

definitions (defined with #define).

Inline functions also work more or less in the same manner as macros. The functions are

declared inline by writing inline keyword before the name of the function. This is a

directive to the compiler and it causes the full definition of the function to be inserted in

each place the function is called. Inserting individual copies of functions eliminates the

overhead of calling a function (such as loading parameters onto the stack).

We see what are the advantages and disadvantages of it:

Page 314

CS201 Introduction to Programming

We'll discuss the disadvantages first. Let's suppose the inline function is called 100 times

inside your program and that function itself is of 10 lines in length. Then at 100 places

inside your program this 10 lines function definition is written, causes the program size to

increase by 1000 lines. Therefore, the size of the program increases significantly. The

increase in size of program may not be an issue if you have lots of resources of memory

and disk space available but preferably, we try not to increase the size of the program

without any benefit.

Also the inline directive is a request to the compiler to treat the function as inline. The

compiler is on its own to accept or reject the request of inlining. To get to know whether

the compiler has accepted the request to make it inline or not, is possible through the

program's debugging. But this is bit tedious at this level of our programming expertise.

Now we'll see what are the advantages of this feature of C++. While writing macros, we

knew that it is important to enclose the arguments of macros within parenthesis. For

example, we wrote square macro as:

#define square(x)

(x) * (x)

when this macro is called by the following statement in our code:

square( i + j );

then it is replaced with the definition of the square macro as:

( i + j ) * ( i + j );

Just consider, we have not used parenthesis and written our macro as under:

#define square(x)

x *x

then the substitution of the macro definition will be as:

i + j * i + j;

But the above definition has incorrect result. Because the precedence of the

multiplication operator (*) is higher than the addition operator (+), therefore, the above

statement is executed semantically as:

i + (j * i) + j;

Hence, the usage of brackets is necessary to make sure that the macros work as expected.

Secondly, because the macros are replaced with preprocessors and not by compiler,

therefore, they are not aware of the data types. They just replace the macro definition and

there is no type checking on the parameters of the macro. Same macro can be used for

multiple data types. For instance, the above square macro can be used for long, float,

double and char data types.

Page 315

CS201 Introduction to Programming

Inline functions behave as expected like a function and they don't have any side effects.

Secondly, the automatic type checking for parameters is also done for inline functions. If

there is a difference between data types provided and expected, the compiler will report

an error unlike a macro.

Now, we see a program code to differentiate between macros and inline functions:

Example of Inline Functions versus Macros

// A macro vs. an inline function

#include <iostream.h>

#define MAX( A, B ) ((A) > (B) ? (A) : (B))

inline int max( int a, int b )

{

if ( a > b )

return a;

return b;

}

void main()

{

int i, x, y;

x = 23; y = 45;

i = MAX( x++, y++ ); // Side-effect:

// larger value incremented twice

cout << "x = " << x << " y = " << y << '\n';

x = 23; y = 45;

i = max( x++, y++ ); // Works as expected

cout << "x = " << x << " y = " << y << '\n';

}

The output of this program is:

x = 24 y = 47

x = 24 y = 46

You can see that the output from the inline function is correct while the macro has

produced incorrect result by incrementing variable y two times. Why is this so?

The definition of the macro contains the parameters A and B two times in its body and

keeping in mind that macros just replace the argument values inside the definition, it

looks like the following after replacement.

( (x++) > (y++) ? (x++) : (y++) );

Clearly, the resultant variable either x or y, whichever is greater (y in this case) will be

incremented twice instead of once.

Page 316

CS201 Introduction to Programming

Now, the interesting point is why this problem is not there in inline functions. Inside the

code, the call to the inline function max is made by writing the following statement:

i = max( x++, y++ );

While calling the inline function, compiler does the type checking and passes the

parameters in the same way as in normal function calls. The arguments are incremented

once after their values are replaced inside the body of the function max and this is our

required behavior.

Hence, by and large it is better to use inline functions rather than macros. Still macros can

be utilized for small definitions.

The inline keyword is only a suggestion to the compiler. Functions larger than a few lines

are not expanded inline even if they are declared with the inline keyword.

If the inline function is called many times inside the program and from multiple source

files (until now, usually we have been using only one source file) then the inline function

is put in a header file. That header file can be used (by using #include) by multiple source

files later.

Also keep in mind that after multiple files include the header file that contains the inline

function, all of those files must be recompiled after the inline function in the header file is

changed.

Now, we are going to cover exciting part of this lecture i.e., Function Overloading.

Function Overloading

You have already seen overloading many times. For example, when we used cout to

print our string and then used it for int, long, double and float etc.

cout << "This is my string";

cout << myInt ;

This magic of cout that it can print variables of different data types is possible because of

overloading. The operator of cout (<<) that is stream insertion operator is overloaded for

many data types. Header file iostream.h contains prototypes for all those functions. So

what actually is overloading?

"Using the same name to perform multiple tasks or different tasks depending on the

situation."

Page 317

CS201 Introduction to Programming

cout is doing exactly same thing that depending on the variable type passed to it, it prints

an int or a double or a float or a string. That means the behavior is changing but the

function cout << looks identical.

As we all know that computers are dumb machines and they cannot decide anything on

their own. Therefore, if it is printing variables of different types, we have to tell it clearly

and separately for each type like int or double etc. In this separately telling process, the

operator used is the same <<. So in a way that operator of << is being overloaded. For

this lecture, we will not go into the detail of operator overloading but we will limit our

discussion to function overloading.

Function overloading has the same concept that the name of the function will remain

same but its behavior may change. For example, if we want to take square root of a

number. That number can be an integer, float or a double and depending on the type of

the argument, we may need to do different calculation. If we want to cater to the two data

types int and double, we will write separate functions for int and double.

double intsqrt ( int i );

double doublesqrt ( double d );

We can use the function intsqrt() where integer square root is required and doublesqrt()

where square root of double variable is required. But this is an overhead in the sense that

we have to remember multiple function names, even if the behavior of the functions is of

similar type as in this case of square root. We should also be careful about auto-widening

that if we pass an int to doublesqrt() function, compiler will automatically convert it to

double and then call the funtion doublesqrt(). That may not be what we wanted to

achieve and there is no way of checking that we have used the correct function. The

solution to this problem is function overloading.

While overloading functions, we will write separate functions for separate data types but

the function name will remain same. Return type can be different if we want to change,

for example in the above case we might want to return an int for square root function for

ints and double for a square root of a double typed variable. Now, we will declare them

as under:

int

sqrt ( int i );

double sqrt ( double d );

Now, we have two functions with the same name. How will they be differentiated inside

the program?

The differentiation comes from the parameters, which are passed to these functions. If

somewhere in your program you wrote: sqrt( 10.5 ), the compiler will automatically

determine that 10.5 is not an integer, it is either float or a double. The compiler will look

for the sqrt() with parameter of type float or a parameter with type as double. It will find

the function sqrt() with double parameter and call it. Suppose in the subsequent code,

there is a call to sqrt() function as under:

Page 318

CS201 Introduction to Programming

int i;

sqrt ( i );

Now, the compiler will automatically match the prototype and will call the sqrt() with int

as parameter type.

What is the advantage of this function overloading?

Our program is more readable after using function overloading. Instead of having lot of

functions doing the same kind of work but with different names. How does the compiler

differentiate, we have already discussed that compiler looks at the type and number of

arguments. Suppose there are two overloaded functions as given below:

int f( int x, int y );

int f( int x, int y, int z );

One function f() takes two int parameter and other one takes three int type parameters.

Now if there is call as the following:

int x = 10;

int y = 20;

f( x, y );

The function f() with two int parameters is called.

In case the function call is made in the following way:

int x = 10;

int y = 20;

int z = 30;

f( x, y, z );

The function f() with three int parameters is called.

We have not talked about the return type because it is not a distinguishing feature while

overloading functions. Be careful about it, you cannot write:

int

f ( int );

double f ( int );

The compiler will produce error of ambiguous declarations.

So the overloaded functions are differentiated using type and number of arguments

passed to the function and not by the return type. Let's take a loop of some useful

example. We want to write functions to print values of different data types and we will

use function overloading for that.

/* Overload functions to print variables of different types */

#include <iostream.h>

Page 319

CS201 Introduction to Programming

void print (int i)

{

cout << "\nThe value of the integer is: " << i;

}

void print (double d)

{

cout << "\nThe value of the double is: " << d;

}

void print (char* s)

{

cout << "\nThe value of the string is: " << s;

}

main (void)

{

int i = 100;

double d = 123.12;

char *s = "This is a test string";

print ( i );

print ( d );

print ( s );

}

The output of the program is:

The value of the integer is: 100

The value of the double is: 123.12

The value of the string is: This is a test string

You must have noticed that automtically the int version of print() function is called for i,

double version is called for d and string version is called for s.

Internally, the compiler uses the name mangling technique to generate a unique token

that is assigned to each function. It processes the function name and its parameters within

a logical machine to generate this unique number for each function.

Example of Function Overloading

/* The following example replaces strcpy and strncpy with the single function name

stringCopy. */

// An overloaded function

Page 320

CS201 Introduction to Programming

#include <iostream.h>

#include <string.h>

inline void stringCopy( char *dest, const char *src )

{

strcpy( dest, src );

// Calls the standard C library function

}

inline void stringCopy( char *dest, const char *src, int len )

{

strncpy( dest, src, len ); // // Calls another standard C library function

}

static char stringa[20], stringb[20]; // Declared two arrays of characters of size 20

void main()

{

stringCopy( stringa, "That" );

// Copy the string `That' into the array stringa

stringCopy( stringb, "This is a string", 4 ); // Copy first 4 characters to stringb array

cout << stringb << " and " << stringa; // Display the contents on the screen

}

Page 321

Table of Contents:
