CS201 Introduction to Programming

Lecture Handout

Introduction to Programming

Lecture No. 10

Reading Material

Deitel & Deitel C++ How to Program

Chapter 3

3.7, 3.11, 3.12, 3.14, 3.17

Contents

Header Files

Scope of Identifiers

Functions

- Call by Value

- Call by Reference

Header Files

You have already been using a header file from day-zero. You know that we used to

write at the top before the start of the main() function <iostream.h>, with `.h' as an

extension, you might have got the idea that it is a header file.

Now we will see why a Header file is used.

In the previous lecture, we discussed a little bit about Function Prototypes. One thing is

Declaration and other is Definition. Declaration can also be called as 'Prototype'.

Normally, if we have lot of functions and want to use them in some other function or

program, then we are left with only one way i.e. to list the prototypes of all of them

before the body of the function or program and then use them inside the function or

program. But for frequent functions inside a program, this technique increases the

complexity (of a program). This problem can be overcome by putting all these function

prototypes in one file and writing a simple line of code for including the file in the

program. This code line will indicate that this is the file, suppose 'area.h' containing all

the prototypes of the used functions and see the prototypes from that file. This is the basic

Page 91

CS201 Introduction to Programming

concept of a header file.

So what we can do is:

- Make our own header file which is usually a simple text file with '.h' extension ('.h'

extension is not mandatory but it is a rule of good programming practice).

- Write function prototypes inside that file. (Recall that prototype is just a simple line

of code containing return value, function name and an argument list of data types

with semi-colon at the end.)

- That file can be included in your own program by using the `#include' directive and

that would be similar to explicitly writing that list of function prototypes.

Function prototypes are not the only thing that can be put into a header file. If you

remember that we wrote a program for calculating Area of a Circle in our previous

lectures. We used the value of 'pi' inside that and we have written the value of 'pi' as

3.1415926. This kind of facts are considered as Universal Constants or Constants within

our domain of operations . It would be nice, if we can assign meaningful names to them.

There are two benefits of doing this. See, We could have declared a variable of type

double inside the program and given a name like 'pi':

double pi = 3.1415926;

Then everywhere in the subsequent calculations we can use 'pi'.

But it is better to pre-define the value of the constant in a header file ( one set for all) and

simply including that header file, the constant `pi', is defined. Now, this meaningful

name `pi' can be used in all calculations instead of writing the horrendous number

3.1415926 again and again.

There are some preprocessor directives which we are going to cover later. At the

moment, we will discuss about `#define' only. We define the constants using this

preprocessor directive as:

#define pi 3.1415926

The above line does a funny thing as it is not creating a variable. Rather it associates a

name with a value which can be used inside the program exactly like a variable. (Why it

is not a variable?, because you can't use it on the left hand side of any assignment.).

Basically, it is a short hand, what actually happens. You defined the value of the `pi' with

`#define' directive and then started using `pi' symbol in your program. Now we will see

what a compiler does when it is handed over the program after the writing process.

Wherever it finds the symbol `pi', replaces the symbol with the value 3.1415926 and

finally compiles the program.

Thus, in compilation process the symbols or constants are replaced with actual values of

them. But for us as human beings, it is quite readable to see the symbol `pi'. Additionally,

if we use meaningful names for variables and see a line `2 * pi * radius', it becomes

obvious that circumference of a circle is being calculated. Note that in the above

statement, `2 * pi * radius'; 2 is used as a number as we did not define any constant for it.

We have defined `pi' and `radius' but defining 2 would be over killing.

Page 92

CS201 Introduction to Programming

Scope of Identifiers

An 'Identifier' means any name that the user creates in his/her program. These names can

be of variables, functions and labels. Here the scope of an identifier means its visibility.

We will focus Scope of Variables in our discussion.

Suppose we write the function:

void func1()

{

int i;

...

//Some other lines of code

int j = i+2;

//Perfectly alright

...

}

Now this variable `i' can be used in any statement inside the function func1(). But

consider this variable being used in a different function like:

void func2()

{

int k = i + 4;

//Compilation error

...

}

The variable `i' belongs to func1() and is not visible outside that. In other words, `i' is

local to func1().

To understand the concept of scope further, we have to see what are Code Blocks? A

code block begins with `{` and ends with `}'.Therefore, the body of a function is

essentially a code block. Nonetheless, inside a function there can be another block of

code like 'for loop' and 'while loop' can have their own blocks of code respectively.

Therefore, there can be a hierarchy of code blocks.

A variable declared inside a code block becomes the local variable for that for that block.

It is not visible outside that block. See the code below:

void func()

{

int outer;

//Function level scope

...

Page 93

CS201 Introduction to Programming

{

int inner;

//Code block level scope

inner = outer;

//No problem

...

}

inner ++;

//Compilation error

}

Please note that variable `outer' is declared at function level scope and variable `inner' is

declared at block level scope.

The `inner' variable declared inside the inner code block is not visible outside it . In other

words, it is at inner code block scope level. If we want to access that variable outside its

code block, a compilation error may occur.

What will happen if we use the same names of variables at both function level scope and

inner block level scope? Consider the following code:

Line

void increment()

{

int num;

//Function level scope

...

{

int num;

//Bad practice, not recommended

...

num ++;

//inner num is incremented

...

10.

}

11.

}

Note that there is no compilation error if the variable of the same name `num' is declared

at line 6 inside the inner code block (at block level scope). Although , there is no error in

naming the variables this way, yet this is not recommended as this can create confusion

and decrease readability. It is better to use different names for these variables.

Which variable is being used at line 8? The answer is the `num' variable declared for

inner code block (at block level scope). Why is so? It is just due to the fact that the outer

variable `num' (at function level scope) is hidden in the inner code block as there is a

local variable of the same name. So the local variable `num' inside the inner code block

over-rides the variable `num' in the outer code block.

Remember, the re-use of a variable is perfectly alright as we saw in the code snippet

Page 94

CS201 Introduction to Programming

above while using `outer' variable inside the inner code block. But re-declaring a variable

of the same name like we did for variable `num' in the inner code block, is a bad practice.

Now, is there a way that we declare a variable only once and then use it inside all

functions. We have already done a similar task when we wrote a function prototype

outside the body of all the functions. The same thing applies to declaration of variables.

You declare variables outside of a function body (so that variable declarations are not

part of any function) and they become visible and accessible inside all functions of that

file. Notice that we have just used a new word `file'.

A file or a source code file with extension `.c' or `.cpp' can have many functions inside.

A file will contain one main() function maximum and rest of the functions as many as

required. If you want a variable to be accessible from within all functions, you declare the

variable outside the body of any function like the following code snippet has declared

such a variable `size' below.

#include <iostream.h>

...

// Declare your global variables here

int size;

...

int main( ... )

{

...

}

Now, this `size' is visible in all functions including main(). We call this as 'file scope

variable' or a 'global variable'. There are certain benefits of using global variables. For

example, you want to access the variable `size' from anywhere in your program but it

does have some pitfalls. You may inadvertently change the value of the variable `size'

considering it a local variable of the function and cause your program to behave

differently or affect your program logic.

Hence, you should try to minimize the use of global variables and try to use the local

variables as far as possible. This philosophy leads us to the concept of Encapsulation and

Data Hiding that encourages the declaration and use of data locally.

In essence, we should take care of three levels of scopes associated with identifiers:

global scope, function level scope and block level scope.

Let's take a look of very simple example of global scope:

#include <iostream.h>

//Declare your global variables here

int i;

Page 95

CS201 Introduction to Programming

void main()

{

i = 10;

cout << "\n" << "In main(), the value of i is: " << i;

f();

cout << "\n" << "Back in main(), the value of i is: " << i;

}

void f()

{

cout << "\n" << "In f(), the value of i is: " << i;

i = 20;

}

Note the keyword `void' here, which is used to indicate that this function does not return

anything.

The output of the program is:

In main(), the value of i is: 10

In f(), the value of i is: 10

Back in main(), the value of i is: 20

Being a global variable, `i' is accessible to all functions. Function f() has changed its

value by assigning a new value i.e. 20.

If the programmer of function f() has changed the value of `i' accidentally taking it a

local variable, your program's logic will be affected.

Function Calling

We have already discussed that the default function calling mechanism of C is a 'Call by

Value'. What does that mean? It means that when we call a function and pass some

arguments (variables) to it, we are passing a copy of the arguments (variables) instead of

original variables. The copy reaches to the function that uses it in whatever way it wants

and returns it back to the calling function. The passed copy of the variable is used and

original variable is not touched. This can be understood by the following example.

Suppose you have a letter that has some mistakes in it. For rectification, you depute

somebody to make a copy of that letter, leave the original with you and make corrections

in that copy. You will get the corrected copy of the letter and have the unchanged original

one too. You have given the copy of the original letter i.e. the call by value part.

But if you give the original letter to that person to make corrections in it, then that person

will come back to you with the changes in the original letter itself instead of its copy.

This is call by reference.

Page 96

CS201 Introduction to Programming

The default of C is 'Call by Value'. It is better to use it as it saves us from unwanted side

effects. Relatively, 'Call by Reference' is a bit complex but it may be required sometimes

when we want the actual variable to be changed by the function being called.

Let's consider another example to comprehend 'Call by Value' and how it works. Suppose

we write a main() function and another small function f(int) to call it from main(). This

function f( ) accepts an integer, doubles it and returns it back to the main() function. Our

program would look like this:

#include <iostream.h>

void f(int);

//Prototype of the function

void main()

{

int i;

i = 10;

cout << "\n" << " In main(), the value of i is: " << i;

f(i);

cout << "\n" << " Back in main(), the value of i is: " << i;

}

void f (int i)

{

i *= 2;

cout << "\n" << " In f(), the value of i is: " << i;

}

The output of this program is as under:

In main(), the value of i is: 10

In f(), the value of i is: 20

Back in main(), the value of i is: 10

As the output shows the value of the variable `i' inside function main() did not change, it

proves the point that the call was made by value.

If there are some values we want to pass on to the function for further processing, it will

be better to make a copy of those values , put it somewhere else and ask the function to

take that copy to use for its processing. The original one with us will be secure.

Let's take another example of call by value, which is bit more relevant. Suppose we want

to write a function that does the square of a number. In this case, the number can be a

double precision number as seen below:

Page 97

CS201 Introduction to Programming

#include <iostream.h>

double square (double);

void main()

{

double num;

num = 123.456;

cout << "\n" << " The square of " << num << " is " << square(num);

cout << "\n" << " The current value of num is " << num;

}

double square (double x)

{

return x*x;

}

'C' does not have built-in mathematical operators to perform square, square root, log and

trigonometric functions. The C language compiler comes along a complete library for

that. All the prototypes of those functions are inside `<math.h>'. In order to use any of

the functions declared inside `<math.h>', the following line will be added.

#include <math.h>

Remember, these functions are not built-in ones but library is supplied with the C-

compiler. It may be of interest to you that all the functions inside `<math.h>' are called

by value. Whatever variable you will pass in as an argument to these functions, nothing

will happen to the original value of the variable. Rather a copy is passed to the function

and a result is returned back, based on the calculation on that copy.

Now, we will see why Call by Reference is used.

We would like to use 'call by reference' while using a function to change the value of the

original variable. Let's consider the square(double) function again, this time we want the

original variable `x' to be squared. For this purpose, we passed a variable to the square()

function and as a result, on the contrary to the `Call by Value', it affected the calling

functions original variable. So these kinds of functions are `Call by Reference' functions.

Let us see, what actually happens inside Call by Reference?

As apparent from the name `By Reference', we are not passing the value itself but some

Page 98

CS201 Introduction to Programming

form of reference or address. To understand this, you can think in terms of variables

which are names of memory locations. We always access a variable by its name (which

in fact is accessing a memory location), a variable name acts as an address of the memory

location of the variable.

If we want the called function to change the value of a variable of the calling function, we

must pass the address of that variable to the called function. Thus, by passing the address

of the variable to the called function, we convey to the function that the number you

should change is lying inside this passed memory location, square it and put the result

again inside that memory location. When the calling function gets the control back after

calling the called function, it gets the changed value back in the same memory location.

In summary, while using the call by reference method, we can't pass the value. We have

to pass the memory address of the value. This introduces a new mechanism which is

achieved by using `&' (ampersand) operator in C language. This `&' operator is used to

get the address of a variable. Let's look at a function, which actually is a modification of

our previous square() function.

#include <iostream.h>

void square(double);

void main()

{

double x;

x = 123.456;

cout << "\n" << " In main(), before calling square(), x = " << x;

square(&x);

//Passing address of the variable x

cout << "\n" << " In main(), after calling square(), x = " << x;

}

void square(double* x)

//read as: x is a pointer of type double

{

*x = *x * *x;

//Notice that there is no space in *x

}

Here *x means whatever the x points to and &x means address of the variable x. We will

discuss Pointers in detail later.

We are calling function square(double*) with the statement square(&x) that is actually

passing the address of the variable x , not its value. In other words, we have told a box

number to the function square(double*) and asked it to take the value inside that box,

multiply it with itself and put the result back in the same box. This is the mechanism of

`Call by Reference'.

Page 99

CS201 Introduction to Programming

Notice that there is no return statement of square(double*) as we are putting the changed

value (that could be returned) inside the same memory location that was passed by the

calling function.

The output of the program will be as under:

In main(), before calling square(), x = 123.456

In main(), after calling square(), x = 15241.4

By and large, we try to avoid a call by reference. Why? Mainly due to the side-effects, its

use may cause. As mentioned above, it will be risky to tell the address of some variables

to the called function. Also, see the code above for some special arrangements for call by

reference in C language. Only when extremely needed, like the size of the data to be

passed as value is huge or original variable is required to be changed, you should go for

call by reference, otherwise stick to the call by value convention.

Now in terms of call by reference, we see that there are some places in `C' where the call

by reference function happens automatically. We will discuss this later in detail. For the

moment, as a hint, consider array passing in `C'.

Recursive Function

This is the special type of function which can call itself. What kind of function it would

be? There are many problems and specific areas where you can see the repetitive

behavior (pattern) or you can find a thing, which can be modeled in such a way that it

repeats itself.

Let us take simple example of x10, how will we calculate it? There are many ways of

doing it. But from a simple perspective, we can say that by definition x10 = x * x9. So

what is x9? It is x9 = x * x8 and so on.

We can see the pattern in it:

xn = x * xn-1

To compute it, we can always write a program to take the power of some number. How to

do it? The power function itself is making recursive call to itself. As a recursive function

writer, you should know where to stop the recursive call (base case). Like in this case,

you can stop when the power of x i.e. n is 1 or 0.

Similarly, you can see lot of similar problems like Factorials. A factorial of a positive

integer `n' is defined as:

n! = (n) * (n-1) * (n-2) * ..... * 2 * 1

Note that

Page 100

CS201 Introduction to Programming

n! = (n) * (n-1)!

and

(n-1)! = (n-1) * (n-2)!

This is a clearly a recursive behavior. While writing a factorial function, we can stop

recursive calling when n is 2 or 1.

long fact(long n)

{

if (n <= 1)

return 1;

else

return n * fact(n-1);

}

Note that there are two parts (branches) of the function: one is the base case ( which

indicates when the function will terminate) and other is recursively calling part.

All the problems can be solved using the iterative functions and constructs we have

studied until now. So the question is: do we need to use recursive functions? Yes, it adds

little elegance to the code of the function but there is a huge price to pay for this. Its use

may lead to the problems of having memory overhead. There may also be stacking

overhead as lots of function calls are made. A lot of functions can be written without

recursion (iteratively) and more efficiently.

So as a programmer, you have an option to go for elegant code or efficient code,

sometimes there is a trade-off. As a general rule, when you have to make a choice out of

elegance and efficiency, where the price or resources is not an issue, go for elegance but

if the price is high enough then go for efficiency.

`C' language facilitates us for recursive functions like lot of other languages but not all

computer languages support recursive functions. Also, all the problems can not be solved

by recursion but only those, which can be separated out for base case, not iterative ones.

Tips

Header file is a nice mechanism to put function prototypes and define constants

(global constants) in a single file. That file can be included simply with a single line

of code.

- There are three levels of scopes to be taken care of, associated with identifiers: global

scope, function level scope and block level scope.

- For Function calling mechanism, go for `Call by Value' unless there is a need of `Call

by Reference'.

Page 101

CS201 Introduction to Programming

Apply the recursive function where there is a repetitive pattern, elegance is required

and there is no resource problem.

Page 102

Table of Contents:
