Introduction to Computing CS101

LESSON 36

DATA MANAGEMENT

During the last Lesson ...

(Intelligent Systems)

We looked at the distinguishing features of intelligent systems w.r.t. other software systems

We looked at the role of intelligent systems in scientific, business, consumer and other applications

We discussed several techniques for designing intelligent systems

(Artificial) Intelligent Systems:

SW programs or SW/HW systems designed to perform complex tasks employing strategies that mimic

some aspect of human thought

Not a Suitable Hammer for All Nails!

if the nature of computations required in a task is not well understood

or there are too many exceptions to the

rules

or known algorithms are too complex or inefficient

then AI has the potential of offering an acceptable solution

Selected Applications:

Games: Chess, SimCity

Image recognition

Medical diagnosis

Robots

Business intelligence

Neural Networks:

Original inspiration was the human brain; emphasis now on usefulness as a computational tool.

Genetic Algorithms (1):

Based on Darwin's evolutionary principle of `survival of the fittest'

GAs require the ability to recognize a good solution, but not how to get to that solution

Rulebased Systems (1):

Based on the principles of the logical reasoning ability of humans.

Fuzzy Logic (1):

Based on the principles of the approximate reasoning faculty that humans use when faced with linguistic

ambiguity

The Right Technique:

Selection of the right AI technique requires intimate knowledge about the problem as well as the

techniques under consideration

Real problems may require a combination of techniques (AI and/or nonAI) for an optimal solution

241

Introduction to Computing CS101

Three exciting areas of AI applications Robotics:

Automatic machines that perform various tasks that were previously done by humans

Autonomous Web Agents (1):

Computer program that performs various actions continuously, autonomously on behalf of their

principal!

Decision Support Systems:

Interactive software designed to improve the decision-making capability of their users

The do not make decisions - just assist in the process

Today's Goals:(Data Management)

First of a two-Lesson sequence

Today we will become familiar with the issues and problems related to data-intensive computing

We will find out about flat-files, the simpleast databases

Next time, in our 4th Lesson on productivity software, we will discuss relational databases and

implement a simple relational database

Keeping track of a few dozen data items is straight forward

However, dealing with situations that involve significant number of data items, requires more attention

to the data handling process

Dealing with millions - even billions - of inter-related data items requires even more careful thought

36.1 BholiBooks.com :

Consider the situation of a large, online bookstore

They have an inventory of millions of books, with new titles constantly arriving, and old ones being

phased out on a regular basis

The price for a book is not a static feature; it varies every once in a while

Thousands of books are shipped each day, changing the inventory constantly

Some are returned, again changing the inventory situation constantly

The cost of each shipped order depends on:

Prices of individual books

Size of the order

Location of the customer

Mode of shipment

For each order, the customer's particulars _ name, address, phone number, credit card number are

required

Generally, that data is not deleted after the completion of the transaction; instead, it is kept for future

reference

All the transaction activity and the inventory changes result in:

Thousands of data items changing every day

Thousands of additional data items being added everyday

Keeping track & taking care (i.e. management) of all that constantly changing and expanding data is not

a trivial task and requires disciplined attention and actions for ensuring the smooth & profitable

operation of the bookstore

36.2 Issues in Data Management:

Data entry

Data updates

Data integrity

242

Introduction to Computing CS101

Data security

Data accessibility

Data Entry:

New titles are added every day

New customers are being added every day

Some of the above may require manual entry of new data into the computer systems

That new data needs to be added accurately

That can be achieved, for one, by user-interfaces that prevent the input of invalid data

Data Updates :

Old titles are deleted on a regular basis

Inventory changes every instant

Book prices change

Shipping costs change

Customers' personal data change

Various discount schemes are always commencing and concluding

All those actions require updates to existing data

Those changes need to be entered accurately

That can also be achieved by user-interfaces that prevent the input of invalid data

Data Security :

All the data that BholiBooks has in its computer systems is quite critical to its operation

The security of the customers' personal data is of utmost importance. Hackers are always looking for

that type of data, especially for credit card numbers

Enough leaks of that type, and customers will stop doing business with BholiBooks

This problem can be managed by using appropriate security mechanisms that provide access to

authorized persons/computers only

Security can also be improved through:

Encryption

Private or virtual-private networks

Firewalls

Intrusion detectors

Virus detectors

Data Integrity:

Integrity refers to maintaining the correctness and consistency of the data

Correctness: Free from errors

Consistency: No conflict among related data items

Integrity can be compromised in many ways:

Typing errors

Transmission errors

Hardware malfunctions

Program bugs

Viruses

Fire, flood, etc.

Ensuring Data Integrity:

Type Integrity is implemented by specifying the type of a data item:

243

Introduction to Computing CS101

Example: A credit card number consists of 12 digits. An update attempting to assign a value with more

or fewer digits or one including a non-numeral should be rejected

Limit Integrity is enforced by limiting the values of data items to specified ranges to prevent illegal

values

Example: Age of person should not be negative

Referential Integrity requires that an item referenced by the data for some other item must itself exist in

the database

Example: If an airline reservation is requested for a particular flight, then the corresponding flight

number must actually exist

Physical Integrity is ensured through hardware redundancy, backups, etc

Data Accessibility:

If the transaction and inventory data is placed in a disorganized fashion on a hard disk, it becomes very

difficult to later search for a stored data item

What is required is that:

Data be stored in an organized manner

Additional info about the data be storedso that the data access times are minimized

What if two customers check on the aavailability of a certain title simultaneously?

On seeing its availability, they both order the title for which, unfortunately, only a single copy is

available

Same is the case when two airline customers try booking the only available seat

A solution to this concurrency control problem: Lock access to data while someone is using it

We can write our own SW that can take care of all the issues that we just discussed

We can save ourselves lots of time, cost, and effort by buying ourselves a Database Management

System (DBMS) that takes care of most, if not all, of the issues

36.3 DBMS :

DBMSes are popularly, but incorrectly, also known as `Databases'

A DBMS is the SW system that operates a database, and is not the database itself

Some people even consider the database to be a component of the DBMS, and not an entity outside the

DBMS

DBMS

Database

User/

Progra

A DBMS takes care of the storage, retrieval, and management of large data sets on a database

It provides SW tools needed to organize & manipulate that data in a flexible manner

It includes facilities for:

244

Introduction to Computing CS101

Adding, deleting, and modifying data

Making queries about the stored data

Producing reports summarizing the required contents

Database:

A collection of data organized in such a fashion that the computer can quickly search for a desired data

item

All data items in it are generally related to each other and share a single domain

They allow for easy manipulation of the data

They are designed for easy modification & reorganization of the information they contain

They generally consist of a collection of interrelated computer files

Example: VU Student Database:

Student's name

Student's photograph

Father's name

Phone number

Street address

eMail address

Courses being taken

Courses already taken & grades

Pre-VU educational record

Example: BholiBooks' Customer DB:

Name, address, phone & fax, eMail

Credit card type, number, expiration date

Shipping preference

Books on order

All books that were ever shipped to the customer

Book preference

Example: BholiBooks' Inventory DB:

Book title, author, publisher, binding, date of publication, price

Book summary, table of contents

Customers', editors', newspaper reviews

Number in stock

Number on order

Special offer details

36.4 OS Independence:

DBMS stores data in a database, which is a collection of interrelated files

Storage of files on the computer is managed by the computer OS's file system

Intimate knowledge of the OS & its file system is required to provide rapid access to the data

The DBMS takes care of those details

It hides the actual storage details of data files from the user

It provides an OS-independent view of the data to the user, making data manipulation and management

much more convenient

What can be stored in a database?

In the old days, databases were limited to numbers, Booleans, and text

245

Introduction to Computing CS101

These days, anything goes

As long as it is digital data, it can be stored:

Numbers, Booleans, text

Sounds

Images

Video

In the very, very old days ...:

Even large amounts of data was stored in text files, known as flat-file databases

All related info was stored in a single long, tab- or comma-delimited text file

Each group of info called a record - in that file was separated by a special character; vertical bar `|'

was a popular option

Each record consisted of a group of fields, each field containing some distinct data item

246

Introduction to Computing CS101

Flat-File

Database

Record

Field

Record

Delimiter

247

Introduction to Computing CS101

Title, Author, Publisher,

Price, InStock|Good Bye Mr.

Bhola, Altaf Khan,

BholiBooks, 1000, Y|The

Terrible Twins, Bhola

Champion, BholiBooks, 199,

Y|Calculus & Analytical

Geometry, Smith Sahib, Good

Publishers, 325, N|Accounting

Secrets, Zamin Geoffry,

Sangg-e-Kilometer Publishers,

29, Y|

36.5 The Trouble with Flat-File Databases:

The text file format makes it hard to search for specific information or to create reports that include only

certain fields from each record

Reason: One has to search sequentially through the entire file to gather desired info, such as `all books

by a certain author'

However, for small sets of data say, consisting of several tens of kB they can provide reasonable

performance

Consider this tabular approach ...

(same records, same fields, but in a different format)

Title

Author

Publisher

Price

InStock

Good Bye Mr.

Altaf Khan

BholiBooks

1000

Bhola

The Terrible

Bhola

BholiBooks

199

Twins

Champion

Calculus &

Good

Smith Sahib

325

Analytical

Publishers

Geometry

Sung-e-

Accounting

Zamin

Kilometer

Secrets

Geoffry

Publishers

Tabular Storage: Features & Possibilities:
