Introduction to Computing CS101

LESSON 23

FLOW CONTROL & LOOPS

(Web Development Lesson 8)

During the last Lesson we had a discussion on Data Types, Variables & Operators

We found out about JavaScript data types

About variables and literals

We also discussed several operators supported by JavaScript

JavaScript Data Types

JavaScript recognizes & distinguishes among the following types of values:

Numbers

Booleans

Strings

Undefined

Variables

Variables give us the ability to manipulate data through reference instead of actual valueVariables are

containers that hold values

Declaring Variables

Although JavaScript allows variable declaration, it does not require it - except in the case when we want

to declare a variable being local (more on local variables later in the course!)

JavaScript Variables are Dynamically Typed

Any variable in JavaScript can hold any type of value, and the that type can change midway through the

program

FLOW CONTROL

Select between alternate courses of action depending upon

the evaluation of a condition

condition

True

False

statement

statement

block 1

block 2

JavaScript Flow Control Structures

if ... else

switch

147

Introduction to Computing CS101

if: Example 1

if ( day == "Sunday" )

bhola = "Cool" ;

semicolon

The condition

Set the value of the variable `bhola to `Cool'

enclosed in

if the `day' is equal to `Sunday'

This was the case if we want to execute a single statement

given that the condition is true

What if we want to execute multiple statements in case the

if: Example 2

if ( day == "Sunday" )

{

bhola = "Cool" ;

mood = "Great" ;

clothing = "Casual" ;

}

if: Example 2

Set the value of the variable

These curly braces group the

multiple statements into a single

`bhola to `Cool', `mood' to `Great',

compound statement

and `clothing' to `casual' if the

if ( day == "Sunday" ) {

bhola = "Cool" ;

mood = "Great" ;

Note: No

clothing = "Casual" ; semicolon after

the closing curly

}

brace

Set the value of the variable `status' to `Cool',

`mood' to `Great', and `clothing' to `casual' if the

`day' is equal to `Sunday'

Compound Statements

At times, we need to put multiple statements at

places where JavaScript expects only oneFor

those situations, JavaScript provides a way of

grouping a number of statements into a

This is done simply by enclosing any number

of statements within curly braces, {

}NOTE: Although the statements

within the block end in semicolons,

the block itself doesn't

if: Example 3

if ( (day == "Sunday") || (day == "Saturday") ) {

bhola = "Cool" ;

mood = "Great" ;

clothing = "Casual" ;

}

148

Introduction to Computing CS101

if: Example 4

weekend = ( day == "Sunday" ) || ( day ==

"Saturday" ) ;

if ( weekend ) {

bhola = "Cool" ;

mood = "Great" ;

What is the data

clothing = "Casual" ;

type of the variable

}

"weekend"?

We now know how to execute a statement or a block of statements given

that the condition is true

What if we want to include an alternate action as well, i.e. a statement or

a block of statements to be executed in case the condition in not true

if ... else: Example 1

if ( GPA >= 1.0 )

bhola = "Pass" ;

else

bhola = "Fail" ;

if ... else: Example 2

if ( GPA >= 1.0 ) {

bhola = "Pass" ;

}

Else

bhola = "Fail" ;

if ... else: Example 3

if ( GPA >= 1.0 ) {

bhola = "Pass" ;

mood = "Great"

;

} else

if ... else: Example 4

if ( GPA >= 1.0 ) {

bhola = "Pass" ;

mood = "Great" ;

} else {

bhola = "Fail" ;

mood = "Terrible" ; }

if ... else: Example 5

This piece of

code is correct,

but not very

if ( grade == "A" )

efficient!

points = 4.0 ;

if ( grade == "B" )

points = 3.0 ;

What can we do

if ( grade == "C" )

to improve it?

points = 2.0 ;

if ( grade == "D" )

points = 1.0 ;

if ( grade == "F" )

points = 0 0 ;

149

Introduction to Computing CS101

if ... else: Example 5

if ( grade == "A" )

This piece of

code is correct,

points =

but not very

4.0 ;

efficient!

if ( grade == "B" )

points =

3.0 ;

What can we do to

if ( grade == "C" )

improve it?

points =

2.0 ;

if ( grade == "D" )

points =

if ... else:

10;

Example 6

if ( grade == "A" )

points = 4.0 ;

else {

if ( grade == "B" )

points = 3.0 ;

else {

if ( grade == "C" )

points = 2.0 ;

else {

if ( grade == "D" )

points = 1.0 ;

else

points = 0.0 ;

}

switch ( grade ) {

case "A" :

switch:

points = 4.0 ;

A colon

Example 1

break ;

following the

case "B" :

case label is

points = 3.0 ;

required

break ;

case "C" :

points = 2.0 ;

break ;

case "D" :

points = 1.0 ;

break ;

default :

points = 0.0 ;

}

The expression

enclosed in

parentheses is

evaluated and matched

with case labels

This is a case

label

This `break' statement

is the exit point

The `default' statement acts like the

`else' clause in the `if...else'

structure

150

Introduction to Computing CS101

Switch Example 2

switch: Example 2

switch ( inquiry ) {

case "apple" :

document.write( "Apples are Rs 50/kg" ) ;

break ;

case "mangos" :

document.write( "Mangos are Rs 90/kg" ) ;

break ;

case "grapes" :

document.write( "Grapes are Rs 60/kg" ) ;

break ;

default :

document.write( inquiry + "? Please retry!" ) ;

}

if...else --?-- switch

If the action to be taken of the value of a single variable (or a

single expression), use `switch'

When the action depends on the values of multiple variables

(or expressions), use the `if...else' structure

if ... else: Example 7

if ( ( GPA >= 1.0 ) && ( attendance >= 40 ) )

bhola = "Pass" ;

else {

if ( ( GPA >= 2.0 ) && ( attendance >= 36 ) )

bhola

= "Probation" ;

else

bhola = "Fail" ;

LOOPS

}

Loop through a set of statements as long as a condition

is true

True

statement

condition

block

False

JavaScript's Looping Structures

while

for

Virt... l University of Pakistan

151

Introduction to Computing CS101

Decimal to Binary Conversion in JavaScript

x = 75 ;

// x is the decimal number

y = "" ;// y is the binary equivalent

while ( x > 0 ) {

The condition

remainder = x % 2 ;

enclosed in

quotient = Math.floor( x / 2 ) ;

parentheses

y = remainder + y ;

x = quotient ;

}

document.write( "y = " + y ) ;

while: Example 2

while ( tankIsFull == false ) {

tank = tank + bucket ;

}

document.write ( "Tank is full now" ) ;

while: Example 3

x=1;

while ( x < 6000 ) {

document.write ( x ) ;

x=x+1;

}

for: Example 1

Operation

Initial count

Condition

for ( x = 1 ; x < 6000 ; x = x + 1 ) {

document.write ( x ) ;

}

for: Description (1)

The `for' loop starts by initializing the counter variable (which in this case is

The initial value in this case is `1', but can be any other positive or negative

number as well

Next the `for' loop checks the condition. If the condition evaluates to a `true'

value, the `for' loop goes through the loop once

152

Introduction to Computing CS101

for: Description (2)

After reaching the end of that iteration, the `for' loop goes to the top once

again, performs the operation, checks the condition

If the condition evaluates to a `false' value, the `for' loop finishes looping

Otherwise, the `for' loop goes through the loop once again

Repeat from step 4

for: Example 2

for ( x = 99 ; x < 6000 ; x = x + 1 ) {

document.write ( x ) ;

}

for: Example 3

for ( x = 6000 ; x > 0 ; x = x - 1 ) {

How many iterations would

document.write ( x ) ;

this `for' loop run for?

}

6000?

for: Example 3

How many iterations

for ( x = 6000 ; x > 0 ; x = x - 1 ) {

would this `for' loop run

document.write ( x ) ;

for?

}

6000?

for: Example 4

for ( x = 6000 ; x < 0 ; x = x - 1 ) {

How many iterations

document.write ( x ) ;

would this `for' loop run

}

for?

for --?-- while

None?

When the exact number of iterations is known, use the

`for' loop

`for' loops become especially useful when used in conjunction with

arrays

We'll find out about arrays next time, and we'll probe their

usefulness as part of `for' loop structures

153

Introduction to Computing CS101

During Today's Lesson ...

We discussed the concept of flow control using the "if" and "switch" structures

And also the concept behind the "while" and "for" looping structures

We also solved simple problems using flow control and loop structures

Next (the 9th) Web Dev Lecture:

Arrays

We will find out why we need arrays

We will become able to use arrays for solving simple problems

154
