Information System (CS507)

Audit trails and logs

An audit trail is a logical record of computer activities/usage/processing pertaining to an operating

or application system or user activities. An information system may have several audit trails, each

devoted to a particular type of activity. All these audit trails are primarily extracted from the audit

log recorded on chronological basis. The audit log is maintained only for the list of activities

specified for which the log is to be maintained. The information can be recorded varies including

but not limited to

1. Time stamp for the log in/out time

2. Terminal in use

3. Files accessed

4. Transactions performed

5. Amendments made

Audit trails can provide a means to help accomplish several security-related objectives, including

individual accountability, reconstruction of events (actions that happen on a computer system),

intrusion detection, and problem analysis, as well as evidence of the correct processing regimes

within a system

There are typically two kinds of audit records:

(1) An event-oriented log ---- this usually contain records describing system events, application

events, or user events. An audit trail should include sufficient information to establish what events

occurred and who (or what) caused them.

(2) A record of every keystroke---- often called keystroke monitoring. Keystroke monitoring is

the process used to view or record both the keystrokes entered by a computer user and the

computer's response during an interactive session. Keystroke monitoring is usually considered a

special case of audit trails.

35.1 Documentation

Audit trails and logs are a form of documentation which helps in reviewing various activities

undertaken by various users. Any alterations and modifications made in the documentation should

be logged as well for monitoring the integrity. Documentation may include program code of

application softwares, technical manuals, user manuals and any other system-related

documentation. This would help to see that data is not modified on the instructions of the users.

Log of all amendments should be supported by proper authorization by responsible officers.

Accountability through audit trails

Audit trails are technical mechanism that helps managers maintains individual accountability.

Users can be identified by the log being maintained. Users are informed of what the password

allows them to do and why it should be kept secure and confidential. Audit trails help to provide

variants from normal behavior which may lead to unauthorized usage of resources. For example

· Audit trails can be used together with access controls to identify and provide

information about users suspected of improper modification of data (e.g., introducing

errors into a database).

· An audit trail may record "before" and "after" images, also called snapshots of records.

149

Information System (CS507)

This helps in audit evaluation work.

35.2 Audit trails and types of errors

Audit trail analysis can often distinguish between operator-induced errors (during which the system

may have performed exactly as instructed) or system-created errors (e.g., arising from a poorly

tested piece of replacement code). For Example a system fails or the integrity of a file (either

program or data) is questioned, an analysis of the audit trail can reconstruct the series of steps

taken by the system, the users, and the application. Knowledge of the conditions that existed at the

time of, for example, a system crash, can be useful in avoiding future mishaps.

Intrusion detection

Intrusion detection refers to the process of identifying attempts to penetrate a system and gain

unauthorized access. If audit trails have been designed and implemented to record appropriate

information, they can assist in intrusion detection. Intrusion detection system can be made part of

the regular security system to effectively detect intrusion. Real time intrusion detection is technical

and complex to achieve but reasonable extent can be attained. Real-time intrusion detection is

primarily aimed at outsiders attempting to gain unauthorized access to the system.

Variance detection and audit trails

Trends/variance-detection tools look for anomalies in user or system behavior. It is possible to

monitor usage trends and detect major variations. The log can be detected and analyzed to detect

the irregularity. For example, if a user typically logs in at 9 a.m., but appears at 4:30 a.m. one

morning, this may indicate either a security problem or a malfunctioning of the system clock, that

may need to be investigated. The log can be sorted/filtered for all log ins befor 9 a.m. from that

particular terminal.

Audit trails and logs have significant importance in conducting audit of information system in a

computerized environment. Where computer equipment becomes a major component of

information management, auditing through the computer gets more delicate and sensitive. Audit

trail and logs help in auditing through the computer as against auditing around the computer.

35.3 Definition of Audit

In accounting and finance terms, audit is a process which includes an examination of records or

financial accounts to check their accuracy, an adjustment or correction of accounts an examined

and verified account. However the concept is a bit different in case of information systems. An

examination of systems, programming and datacenter procedures in order to determine the

efficiency of computer operations.

35.4 IS audit

Information systems include accounting and finance function as a critical part of the entire system.

Hence, these days audit of information systems as whole incisively focuses on finance and

accounting aspect as well. For example, all banks and financial institutions have soft wares

supporting interest computations. During the audit of IS, the integrity of the source code/program

instructions have to be checked and assurance obtained that these have not been tampered with or

altered in any manner.

An information technology (IT) audit or information systems (IS) audit is an examination of the

controls within an entity's Information technology infrastructure. When transactions are

150

Information System (CS507)

executed and recorded through computers, the lack of physical audit trail requires

implementation of controls with the Information systems so as to give the same result as

controls are implemented in a manual information system IS audit focuses more on examining

the integrity of controls and ensuring whether they are properly working. Obtained evidence

evaluation can ensure whether the organization's information systems safeguard assets,

maintains data integrity, and is operating effectively and efficiently to achieve the organization's

goals or objectives.

35.5 Parameters of IS audit

Regarding Protection-of-Information-Assets, one purpose of an IT audit is to review and evaluate

an organization's information system's availability, confidentiality, and integrity by answering

questions such as:

1. Will the organization's computer systems be available for the business at all times when

required? (Availability)

2. Will the information in the systems be disclosed only to authorize users? (Confidentiality)

3. Will the information provided by the system always be accurate, reliable, and timely?

(Integrity)

4. Besides, the availability, confidentiality and integrity of information systems receiving IT

auditor consideration; it has been suggested by other authors that information system

utility, possession and authenticity also be considered by answering questions such as:

5. Will the organization's computer system provide useful information when required?

(Utility)

6. Will the physical aspects of the organization's computer systems be protected from the

threat of theft? (Possession)

7. Will the information provided by the system always be genuine, original without

unauthorized change? (Authenticity)

35.6 Risk Based Audit Approach

This approach to audit proceeds with following steps

1. Understanding the business process

2. Understanding the control structure built in the system

3. Understanding of inherent risks (risks which are covered through instituting) controls,

which can occur in the absence of controls e.g.

· Political legal factors affecting the business,

· Nature of industry the organization exists

4. Risk assessment

5. Categorization of risks identified

As in the case of other audits, an IS audit can also be streamlined based on this approach. The

purpose of ensuring a high level of IS security and conducting effective IS audit, presupposes

risk assessment which helps in implementation of security policy. Risk management is the core

line of this entire IT/IS audit. It is a very important concept, now we would discuss this

concept in detail.

151
