Advanced Computer
Architecture-CS501
________________________________________________________
Advanced
Computer Architecture
Lecture
No. 30
Reading
Material
Vincent
P. Heuring & Harry F. Jordan
Chapter
8
Computer
Systems Design and Architecture
8.3.3,
8.4
Summary
·
Nested
Interrupts
·
Interrupt
Mask
· DMA
Nested
Interrupts
(Read
from Book, Jordan Page
397)
Interrupt
Mask
(Read
from Book, Jordan Page
397)
Priority
Mask
(Read
from Book, Jordan Page
398)
Examples
Example
# 123
Assume
that three I/O devices are
connected to a 32-bit, 10 MIPS
CPU. The first
device
is a hard
drive with a maximum
transfer rate of 1MB/sec. It has a
32-bit bus. The
second
device is
a floppy drive with a
transfer rate of 25KB/sec over a
16-bit bus, and the
third
device is
a keyboard that must be
polled thirty times per second.
Assuming that the
polling
operation requires 20 instructions
for each I/O device,
determine the
percentage
of CPU
time required to poll each
device.
Solution:
The
hard drive can transfer
1MB/sec or 250 K 32-bit words
every second. Thus, this
hard
drive
should be polled using at least
this rate.
Using
1K=210, the number of
CPU instructions required
would be
250 x 210 x 20 = 5120000 instructions per
second.
23
Adopted
from [H&P org]
Page
309
Last
Modified: 01-Nov-06
Advanced Computer
Architecture-CS501
________________________________________________________
Percentage
of CPU time required for
polling is
(5.12 x
106)/ (10
x106) = 51.2%
The
floppy disk can transfer
25K/2= 12.5 x 210 half-words per second. It should
be
polled
with at least this rate. The
number of CPU instructions
required will be 12.5 x 210
x 20 = 256,000
instructions per second.
Therefore,
the percentage of CPU time
required for polling
is
(0.256 x
106)/ (10 x 106) = 2.56%.
For
the keyboard, the number of
instructions required for
polling is
30 x 20 = 600
instructions per second.
Therefore,
the percentage of CPU time
spent in polling is
600 / (10
x 106) = 0.006%
It is
clear from this example
that while it is acceptable to
use polling for a keyboard
or a
floppy
drive, it is very risky to
use polling for the
hard drive. In general, for
devices with
a high
data rate, the use of
polling is not
adequate.
Example
# 22
a. What
should be the polling
frequency for an I/O device if
the average delay
between
the time when the
device wants to make a request and the
time when it is
polled,
is to be at most 10 ms?
b. If it
takes 10,000 cycles to poll
the I/O device, and the
processor operates at
100MHz,
what % of the CPU time is
spent polling?
c. What
if th24e system wants to
provide an average delay of
1msec?
Solution:
a.
Assuming that the I/O
requests are distributed
evenly in time, the average
time
that a
device will have to wait for
the processor to poll is
half the time
between
polling
attempts. Therefore, to provide an
average delay of 10 ms, the
processor
will have
to poll every 20 ms, or 50
times per second.
b. If
each polling attempt takes
10,000 cycles, then the
processor will spend 500,000
cycles
polling each second. The % of
CPU time spent in polling is
then
(0.5x106)/(100x106)=0.5%
c. To
provide an average delay of
1ms, the polling frequency
must be increased. The
processor
will have to poll every 2ms,
or 500 times per second. This will
consume
5,000,000
cycles for polling. The % of
CPU time spent polling then
becomes
5/100=5%.
24
Adopted
from [Schaum]
Page
310
Last
Modified: 01-Nov-06
Advanced Computer
Architecture-CS501
________________________________________________________
Example
# 325
What
percentage of time will a 20MIPS
processor spend in the busy
wait loop of an 80-
character
line printer when it takes 1
msec to print a character and a
total of 565
instructions
need to be executed to print an 80
character line. Assume that
two
instructions
are executed in the polling
loop.
Solution:
Out of
the total 565 instructions
executed to print a line,
80x2=160 are required
for
polling.
For a 20MIPS processor, the
execution of the remaining 405
instructions takes
405/
(20x106) = 20.25µsec.
Since the printing of 80 characters takes
80ms, (80-0.02025)
=79.97msec is spent in
the polling loop before
the next 80 characters can be printed.
This
is
79.97/80=99.96% of the total
time.
Example
# 426
Consider
a 20 MIPS processor with
several input devices attached to it,
each running at
1000 characters per
second. Assume that it takes 17
instructions to handle an interrupt.
If
the
hardware interrupt response
takes 1µsec,
what is the maximum number
of devices
that can
be handled simultaneously?
Solution:
A service
for one character requires
17/ (20x106) +1µsec=1.85µsec.
Since each device
runs at
1000 characters per second, 1.85 ms of handling
time is required by each
device
every
second. Therefore the maximum
number of devices that can be handled is
1/
(1.85x10-3) = 540.
Example
# 527
Assume
that a floppy drive having a
transfer rate of 25KB per second is
attached to a 32
bit,
10MIPS CPU using an
interrupt driven interface.
The drive has a 16-bit
data bus.
Assume
that the interrupt overhead
is 20 instructions. Calculate the
fraction of CPU time
required
to service this drive when
it is active.
Solution:
Since the
floppy drive has a 16-bit
data bus, it can transfer
two bytes at one time. Thus
its
transfer
rate is 25/2 = 12.5K half-words
(16-bits each) per second. This corresponds to
an
overhead
of 20 instructions or 12.5K x 20 = 12.5 x
210 x 20 = 256000 instructions
per
second.
Example
# 628
A
processor with a 500 MHz clock
requires 1000 clock cycles to
perform a context
switch
and start an ISR. Assume
each interrupt takes 10,000
cycles to execute the
ISR
25
Adopted
from [H&J]
26
Adopted
from [H&J]
27
Adopted
from [H&P org]
28
Adopted
from [Schaum]
Page
311
Last
Modified: 01-Nov-06
Advanced Computer
Architecture-CS501
________________________________________________________
and the
device makes 200 interrupt
requests per second. Also, assume
that the processor
polls
every 0.5msec during the
time when there are no
interrupts. Further assume
that
polling
an I/O device requires 500 cycles.
Compute the
following:
a. How
many cycles per second does
the processor spend handling
I/O from the
device if
only interrupts are
used?
b. What
fraction of the CPU time is
used in interrupt handling
for part (a)?
c. How
many cycles per second are
spent on I/O if polling is also used
with
interrupts?
d. How
often should the processor
poll so that polling incurs
the same overhead as
interrupts?
Solution:
a. The
device makes 200 interrupt
requests per second, each of which
takes
10,000 +
2x1000 (context switching to
the ISR and back from
it)
= 12,000
cycles.
Thus, a
total of 200x12,000=2,400,000 cycles per
second are spent handling
I/O
using
interrupts.
b. The
percentage of the processor
time used in interrupt
handling is
2,400,000/(500x106)
or 0.48%.
c. There
are 200 interrupt requests per second, or
one interrupt request every 5
ms.
Every
interrupt consumes a total of 12,000
cycles, as calculated in part
(a). For a
500 MHz
CPU, this is
12000/(500
x 106 ) = 24
microseconds.
For 200
interrupts per second, this is 4.8
msec.
This
leaves 1000 - 4.8 = 995.2 msec
for polling.
Since the
processor polls once every
0.5 msec during the
time when there is no
interrupt,
this corresponds to
995/0.5 =
1990 times per second.
The
total number of cycles
required for polling
is
1990 x 500 = 995,000
cycles per second.
Thus,
the total time spent on I/O
when using polling
with
interrupts
is
Page
312
Last
Modified: 01-Nov-06
Advanced Computer
Architecture-CS501
________________________________________________________
2,400,000
+ 995,000 = 3,395,000 cycles per
second.
d. The
interrupt overhead is 1000 cycles per
second for a context switch
to the ISR
and 1000
cycles per second back from
it. This is a total of 2 x 1000
cycles per
second.
With 200 interrupts per second, this
is
200 x 2000 = 400,000
cycles per second.
The
polling overhead is 500 cycles per
second. Thus, for the same
overhead
as
interrupts,
the polling operation should
be performed
400,000 / 500 = 800
times per second,
or 1/800
= every 1.25 msec.
Direct
Memory Access
(DMA)
Direct
memory access is a technique,
where by the CPU passes
its control to the
memory
subsystem
or one of its peripherals, so that a
contiguous block of data
could be
transferred
from peripheral device to
memory subsystem or from
memory subsystem to
peripheral
device or from one peripheral
device to another peripheral
device.
Advantage
of DMA
The
transfer rate is pretty fast and
conceptually you could
imagine that through
disabling
the
tri-state buffers, the
system bus is isolated and a direct
connection is established
between
the I/O subsystem and the
memory subsystem and then
the CPU is free. It is
idle
at that
time or it could do some
other activity. Therefore,
the DMA would be quite
useful,
if a
large amount of data needs
to be transferred, for example
from a hard disk to a
printer
or we
could fill up the buffer of a
printer in a pretty short
time.
As compared to
interrupt driven I/O or the
programmed I/O, DMA would be
much faster.
What is
the consequence? The consequence is
that we need to have another
chip, which is
a DMA controller.
"A DMA
controller could be a CPU in
itself and it could control
the
total
activity and synchronize the
transfer of data". DMA could be
considered as a
technique
of transferring data from I/O to
memory and from memory to I/O
without the
intervention
of the CPU. The CPU
just sets up an I/O module or a
memory
subsystem,
so that it passes control and
the data could be passed on
from I/O to memory
or from
memory to I/O or within the
memory from one subsystem to
another subsystem
without
interaction of the CPU.
After this data transfer is
complete, the control is
passed
from I/O
back to the CPU.
Now we
can illustrate further the advantage of
DMA using following
example.
Example
of DMA
If we
write instruction load as
follows:
load
[2], [9]
This
instruction is illegal and not
available in the SRC processor. The
symbols [2] and [9]
represent
memory locations. If we want to
have this transfer to be done
then two steps
would be
required. The instruction
would be:
load
r1, [9]
store r1,
[2]
Page
313
Last
Modified: 01-Nov-06
Advanced Computer
Architecture-CS501
________________________________________________________
Thus it
is not possible to transfer from one
memory location to another
without involving
the
CPU. The same applies to
transfer between memory and
peripherals connected to I/O
ports.
For example we cannot
have:
out
[6], datap
It has to
be done again in two steps:
load
r1, [6]
out
r1, datap
Similar
comments apply to the "in"
instruction. Thus the real
cause of the limited
transfer
rate is
the CPU itself. It acts as
an unnecessary middle man. The
example illustrates
that
in
general, every data word
travels over the system bus
twice and this is not
necessary,
and
therefore, the DMA in such
cases is pretty
useful.
DMA
Approach
The DMA
approach is to turn off i.e.
through tri-state buffers and
therefore, electrically
disconnect
from the system bus,
the CPU and let a peripheral
device or a memory
subsystem
or any other module or
another block of the same
module communicate
directly
with the memory or with
another peripheral device.
This would have
the
advantage of
having higher transfer rates
which could approach that of
limited by the
memory
itself.
Disadvantage of
DMA
The
disadvantage however, would be that an
additional DMA controller would
be
required,
that could make the system a
bit more complex and
expensive. Generally,
the
DMA
requests have priority over
all other bus activities
including interrupts. No
interrupts
may be recognized during a DMA
cycle.
Page
314
Last
Modified: 01-Nov-06
Table of Contents:
- Computer Architecture, Organization and Design
- Foundations of Computer Architecture, RISC and CISC
- Measures of Performance SRC Features and Instruction Formats
- ISA, Instruction Formats, Coding and Hand Assembly
- Reverse Assembly, SRC in the form of RTL
- RTL to Describe the SRC, Register Transfer using Digital Logic Circuits
- Thinking Process for ISA Design
- Introduction to the ISA of the FALCON-A and Examples
- Behavioral Register Transfer Language for FALCON-A, The EAGLE
- The FALCON-E, Instruction Set Architecture Comparison
- CISC microprocessor:The Motorola MC68000, RISC Architecture:The SPARC
- Design Process, Uni-Bus implementation for the SRC, Structural RTL for the SRC instructions
- Structural RTL Description of the SRC and FALCON-A
- External FALCON-A CPU Interface
- Logic Design for the Uni-bus SRC, Control Signals Generation in SRC
- Control Unit, 2-Bus Implementation of the SRC Data Path
- 3-bus implementation for the SRC, Machine Exceptions, Reset
- SRC Exception Processing Mechanism, Pipelining, Pipeline Design
- Adapting SRC instructions for Pipelined, Control Signals
- SRC, RTL, Data Dependence Distance, Forwarding, Compiler Solution to Hazards
- Data Forwarding Hardware, Superscalar, VLIW Architecture
- Microprogramming, General Microcoded Controller, Horizontal and Vertical Schemes
- I/O Subsystems, Components, Memory Mapped vs Isolated, Serial and Parallel Transfers
- Designing Parallel Input Output Ports, SAD, NUXI, Address Decoder , Delay Interval
- Designing a Parallel Input Port, Memory Mapped Input Output Ports, wrap around, Data Bus Multiplexing
- Programmed Input Output for FALCON-A and SRC
- Programmed Input Output Driver for SRC, Input Output
- Comparison of Interrupt driven Input Output and Polling
- Preparing source files for FALSIM, FALCON-A assembly language techniques
- Nested Interrupts, Interrupt Mask, DMA
- Direct Memory Access - DMA
- Semiconductor Memory vs Hard Disk, Mechanical Delays and Flash Memory
- Hard Drive Technologies
- Arithmetic Logic Shift Unit - ALSU, Radix Conversion, Fixed Point Numbers
- Overflow, Implementations of the adder, Unsigned and Signed Multiplication
- NxN Crossbar Design for Barrel Rotator, IEEE Floating-Point, Addition, Subtraction, Multiplication, Division
- CPU to Memory Interface, Static RAM, One two Dimensional Memory Cells, Matrix and Tree Decoders
- Memory Modules, Read Only Memory, ROM, Cache
- Cache Organization and Functions, Cache Controller Logic, Cache Strategies
- Virtual Memory Organization
- DRAM, Pipelining, Pre-charging and Parallelism, Hit Rate and Miss Rate, Access Time, Cache
- Performance of I/O Subsystems, Server Utilization, Asynchronous I/O and operating system
- Difference between distributed computing and computer networks
- Physical Media, Shared Medium, Switched Medium, Network Topologies, Seven-layer OSI Model
